3. Place a child restraint on the center rear seat. Route the
tether strap following the directions for the center
seating position, above.
4. Attach the hook to the outboard tether strap loop.
5. Tighten the tether straps according to the child seat
manufacturer ’s instructions, tightening the right and
left tether straps before the center tether strap. WARNING!• An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchorage position directly be-
hind the child seat to secure a child restraint top
tether strap.
• If your vehicle is equipped with a split rear seat,
make sure the tether strap does not slip into the
opening between the seatbacks as you remove slack
in the strap.
Transporting Pets
Air Bags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in a
collision.
Pets should be restrained in the rear seat in pet harnesses or
pet carriers that are secured by seat belts.Left Outboard And Center Seating Position Shown 2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89

ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the engine and
drivetrain (transmission and axle) in your vehicle.
Drive moderately during the first 300 miles (500 km). After
the initial 60 miles (100 km), speeds up to 50 or 55 mph (80
or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration within the
limits of local traffic laws contributes to a good break-in.
Wide-open throttle acceleration in low gear can be detri-
mental and should be avoided.
The engine oil installed in the engine at the factory is a
high-quality energy conserving type lubricant. Oil changes
should be consistent with anticipated climate conditions
under which vehicle operations will occur. For the recom-
mended viscosity and quality grades, refer to “Mainte-
nance Procedures” in “Maintaining Your Vehicle.”
CAUTION!Never use Non-Detergent Oil or Straight Mineral Oil
in the engine or damage may result. NOTE: A new engine may consume some oil during its
first few thousand miles (kilometers) of operation. This
should be considered a normal part of the break-in and not
interpreted as a problem. Please check your oil level with
the engine oil indicator often during the break in period.
Add oil as required.
Diesel Engine
The Cummins turbocharged diesel engine does not require
a break-in period due to its construction. Normal operation
is allowed, providing the following recommendations are
followed:
• Warm up the engine before placing it under load.
• Do not operate the engine at idle for prolonged periods.
• Use the appropriate transmission gear to prevent engine
lugging.
• Observe vehicle oil pressure and temperature indicators.
• Check the coolant and oil levels frequently.
• Vary throttle position at highway speeds when carrying
or towing significant weight.90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE: Light duty operation such as light trailer towing or
no load operation will extend the time before the engine is
at full efficiency. Reduced fuel economy and power may be
seen at this time.
For additional vehicle break-in requirements, refer to
“Trailer Towing” in “Starting and Operating” of the Own-
er ’s Manual.
Because of the construction of the Cummins turbocharged
diesel engine, engine run-in is enhanced by loaded oper-
ating conditions which allow the engine parts to achieve
final finish and fit during the first 6,000 miles (10 000 km).
SAFETY TIPS
Transporting Passengers
NOTE: Never transport passengers in the cargo area.
WARNING!• Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.
• It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people (Continued) WARNING! (Continued)riding in these areas are more likely to be seriously
injured or killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Exhaust Gas
WARNING!Exhaust gases can injure or kill. They contain carbon
monoxide (CO), which is colorless and odorless.
Breathing it can make you unconscious and can even-
tually poison you. To avoid breathing (CO), follow
these safety tips:
• Do not run the engine in a closed garage or in
confined areas any longer than needed to move your
vehicle in or out of the area.
• If you are required to drive with the trunk/liftgate/
rear doors open, make sure that all windows are
closed and the climate control BLOWER switch is set
at high speed. DO NOT use the recirculation mode. (Continued) 2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91

WARNING! (Continued)• If it is necessary to sit in a parked vehicle with the
engine running, adjust your heating or cooling con-
trols to force outside air into the vehicle. Set the
blower at high speed.
The best protection against carbon monoxide entry into the
vehicle body is a properly maintained engine exhaust
system.
Whenever a change is noticed in the sound of the exhaust
system, when exhaust fumes can be detected inside the
vehicle, or when the underside or rear of the vehicle is
damaged, have a competent mechanic inspect the complete
exhaust system and adjacent body areas for broken, dam-
aged, deteriorated, or mispositioned parts. Open seams or
loose connections could permit exhaust fumes to seep into
the passenger compartment. In addition, inspect the ex-
haust system each time the vehicle is raised for lubrication
or oil change. Replace as required. Safety Checks You Should Make Inside The Vehicle
Seat Belts
Inspect the seat belt system periodically, checking for cuts,
frays, and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Front seat belt assemblies must be replaced after a collision.
Rear seat belt assemblies must be replaced after a collision
if they have been damaged (i.e., bent retractor, torn web-
bing, etc.). If there is any question regarding seat belt or
retractor condition, replace the seat belt.
Air Bag Warning Light
The Air Bag Warning Light
will turn on for four to
eight seconds as a bulb check when the ignition is first
placed in the ON/RUN position. If the light is either not
on during starting, stays on, or turns on while driving,
have the system inspected at an authorized dealer as
soon as possible. This light will illuminate with a single
chime when a fault with the Air Bag Warning Light has
been detected, it will stay on until the fault is cleared. If
the light comes on intermittently or remains on while
driving, have an authorized dealer service the vehicle
immediately. Refer to “Occupant Restraints” for further
information.92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield. See your
authorized dealer for service if your defroster is inoper-
able.
Floor Mat Safety Information
Always use floor mats designed to fit the footwell of your
vehicle. Use only floor mats that leave the pedal area
unobstructed and that are firmly secured so that they
cannot slip out of position and interfere with the pedals or
impair safe operation of your vehicle in other ways.
WARNING!An improperly attached, damaged, folded, or stacked
floor mat, or damaged floor mat fasteners may cause
your floor mat to interfere with the accelerator, brake,
or clutch pedals and cause a loss of vehicle control. To
prevent SERIOUS INJURY or DEATH:
• ALWAYS securely attach your floor mat using
the floor mat fasteners. DO NOT install your floor
mat upside down or turn your floor mat over. (Continued) WARNING! (Continued)Lightly pull to confirm mat is secured using the
floor mat fasteners on a regular basis.
• ALWAYS REMOVE THE EXISTING FLOOR MAT
FROM THE VEHICLE before installing any
other floor mat. NEVER install or stack an addi-
tional floor mat on top of an existing floor mat.
• ONLY install floor mats designed to fit your vehicle.
NEVER install a floor mat that cannot be properly
attached and secured to your vehicle. If a floor mat
needs to be replaced, only use a FCA approved floor
mat for the specific make, model, and year of your
vehicle.
• ONLY use the driver ’s side floor mat on the driver ’s
side floor area. To check for interference, with the
vehicle properly parked with the engine off, fully
depress the accelerator, the brake, and the clutch
pedal (if present) to check for interference. If your
floor mat interferes with the operation of any pedal,
or is not secure to the floor, remove the floor mat
from the vehicle and place the floor mat in your
trunk. (Continued) 2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93

WARNING! (Continued)• ONLY use the passenger ’s side floor mat on the
passenger ’s side floor area.
• ALWAYS make sure objects cannot fall or slide into
the driver ’s side floor area when the vehicle is
moving. Objects can become trapped under accelera-
tor, brake, or clutch pedals and could cause a loss of
vehicle control.
• NEVER place any objects under the floor mat (e.g.,
towels, keys, etc.). These objects could change the
position of the floor mat and may cause interference
with the accelerator, brake, or clutch pedals.
• If the vehicle carpet has been removed and re-
installed, always properly attach carpet to the floor
and check the floor mat fasteners are secure to the
vehicle carpet. Fully depress each pedal to check for
interference with the accelerator, brake, or clutch
pedals then re-install the floor mats.
• It is recommended to only use mild soap and water
to clean your floor mats. After cleaning, always check
your floor mat has been properly installed and is
secured to your vehicle using the floor mat fasteners
by lightly pulling mat. Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread or sidewall. Inspect the tread for cuts
and cracks. Inspect sidewalls for cuts, cracks, and bulges.
Check the wheel bolts for tightness. Check the tires (includ-
ing spare) for proper cold inflation pressure.
Lights
Have someone observe the operation of brake lights and
exterior lights while you work the controls. Check turn
signal and high beam indicator lights on the instrument
panel.
Door Latches
Check for proper closing, latching, and locking.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel, power steering fluid (if
equipped), or brake fluid leaks are suspected. The cause
should be located and corrected immediately.94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS  MIRRORS ..............................99
▫ Inside Day/Night Mirror — If Equipped ......99
▫ Automatic Dimming Mirror — If Equipped .....99
▫ Automatic Dimming Mirror With Rear View
Camera Display — If Equipped ........... .104
▫ Outside Mirrors ...................... .105
▫ Outside Mirrors Folding Feature ........... .106
▫ Power Mirrors — If Equipped ............ .106
▫ Heated Mirrors — If Equipped ............ .107
▫ Illuminated Vanity Mirror — If Equipped ..... .108
▫ “Slide-On-Rod” Features Of Sun Visor —
If Equipped .......................... .108
▫ Trailer Towing Mirrors — If Equipped ...... .109
 SEATS................................110
▫ Driver’s Power Seat — If Equipped ..........110 ▫ Passenger ’s Power Seat — If Equipped .......111
▫ Power Lumbar — If Equipped .............112
▫ Heated Seats — If Equipped ...............113
▫ Ventilated Seats — If Equipped .............114
▫ Manual Seat Adjuster — If Equipped ........115
▫ 40-20-40 Front Bench Seat — If Equipped .....116
▫ Head Restraints ........................116
 DRIVER MEMORY SEAT — IF EQUIPPED ......119
▫ Programming The Memory Feature ......... .120
▫ Linking And Unlinking The Remote Keyless
Entry Key Fob To Memory ............... .120
▫ Memory Position Recall ................. .121
▫ Easy Entry/Exit Seat ................... .122
 TO OPEN AND CLOSE THE HOOD ......... .1233

 LIGHTS ............................. .124
▫ Headlights .......................... .125
▫ Automatic Headlights — If Equipped ....... .125
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) .............. .125
▫ Daytime Running Lights (DRL) —
If Equipped ......................... .126
▫ Headlight Delay ....................... .126
▫ Automatic High Beam Headlamp Control —
If Equipped ......................... .126
▫ Parking Lights And Panel Lights ........... .128
▫ Fog Lights — If Equipped ............... .128
▫ Lights-On Reminder .................... .128
▫ Battery Saver ......................... .128
▫ Interior Lights ........................ .129
▫ Cargo Light ......................... .131
▫ Multifunction Lever ................... .132
▫ Turn Signals ......................... .132 ▫ Lane Change Assist .................... .132
▫ Flash-To-Pass ........................ .132
▫ High/Low Beam Switch ................ .133
 WINDSHIELD WIPERS AND WASHERS ...... .133
▫ Windshield Wipers .................... .133
▫ Windshield Wiper Operation .............. .133
▫ Intermittent Wiper System ............... .134
▫ Windshield Washers ................... .134
▫ Mist Feature ......................... .134
▫ Rain Sensing Wipers — If Equipped ........ .135
 TIL T STEERING COLUMN ................ .136
 DRIVER ADJUSTABLE PEDALS —
IF EQUIPPED ......................... .137
 HEATED STEERING WHEEL — IF EQUIPPED . .138
 SPEED CONTROL ...................... .139
▫ To Activate .......................... .140
▫ To Set A Desired Speed .................. .14096 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫ To Deactivate ........................ .140
▫ To Resume Speed ..................... .140
▫ To Vary The Speed Setting ............... .141
▫ To Accelerate For Passing ................ .142
 PARKSENSE REAR PARK ASSIST —
IF EQUIPPED ......................... .142
▫ ParkSense Sensors ..................... .143
▫ ParkSense Warning Display ............... .143
▫ ParkSense Display ..................... .143
▫ Enabling And Disabling ParkSense ......... .147
▫ Service The ParkSense Rear Park Assist System. .147
▫ Cleaning The ParkSense System ............ .148
▫ ParkSense System Usage Precautions ........ .148
 PARKSENSE FRONT AND REAR PARK ASSIST —
IF EQUIPPED ......................... .150
▫ ParkSense Sensors ..................... .150
▫ ParkSense Warning Display ............... .151
▫ ParkSense Display ..................... .151 ▫ Enabling And Disabling Front And/Or Rear
ParkSense ........................... .153
▫ Service The ParkSense Park Assist System .... .154
▫ Cleaning The ParkSense System ............ .155
▫ ParkSense System Usage Precautions ........ .155
 PARKVIEW REAR BACK UP CAMERA —
IF EQUIPPED ......................... .156
 OVERHEAD CONSOLE — IF EQUIPPED ..... .159
▫ Courtesy/Reading Lights ................ .160
 GARAGE DOOR OPENER — IF EQUIPPED . . . .161
▫ Before You Begin Programming HomeLink . . . .162
▫ Programming A Rolling Code ............. .162
▫ Pr ogramming A Non-Rolling Code ......... .164
▫ Canadian/Gate Operator Programming ...... .165
▫ Using HomeLink ...................... .166
▫ Security ............................. .166
▫ Troubleshooting Tips ................... .166
▫ General Information .................... .1673UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97

 ELECTRICAL POWER OUTLETS ........... .168
 AUXILIARY SWITCHES — IF EQUIPPED ..... .172
 CIGAR LIGHTER AND ASH RECEIVER —
IF EQUIPPED ......................... .173
 POWER INVERTER — IF EQUIPPED ........ .173
 CUPHOLDERS ........................ .174
▫ Front Seat Cupholders (40–20–40 Seats) ...... .174
▫ Front Instrument Panel Cupholders —
Floor Storage Bin ...................... .174
▫ Rear Cupholders — If Equipped ........... .175
 STORAGE ............................ .176
▫ Glove Compartment .................... .176
▫ Door Storage ......................... .177 ▫ Center Storage Compartment — If Equipped . . .178
▫ Seatback Storage ...................... .180
▫ Storage (Regular Cab) ................... .181
▫ Storage and Seats (Crew Cab/Quad Cab) ..... .181
▫ Plastic Grocery Bag Retainers
(Regular Cab Models) .................. .182
 REAR WINDOW FEATURES .............. .182
▫ Rear Window Defroster ................. .182
▫ Power Sliding Rear Window — If Equipped . . .183
▫ Manual Sliding Rear Window — If Equipped . .183
 FOLD FLAT LOAD FLOOR — IF EQUIPPED . . . .18398 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
