 LIGHTS ............................. .124
▫ Headlights .......................... .125
▫ Automatic Headlights — If Equipped ....... .125
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) .............. .125
▫ Daytime Running Lights (DRL) —
If Equipped ......................... .126
▫ Headlight Delay ....................... .126
▫ Automatic High Beam Headlamp Control —
If Equipped ......................... .126
▫ Parking Lights And Panel Lights ........... .128
▫ Fog Lights — If Equipped ............... .128
▫ Lights-On Reminder .................... .128
▫ Battery Saver ......................... .128
▫ Interior Lights ........................ .129
▫ Cargo Light ......................... .131
▫ Multifunction Lever ................... .132
▫ Turn Signals ......................... .132 ▫ Lane Change Assist .................... .132
▫ Flash-To-Pass ........................ .132
▫ High/Low Beam Switch ................ .133
 WINDSHIELD WIPERS AND WASHERS ...... .133
▫ Windshield Wipers .................... .133
▫ Windshield Wiper Operation .............. .133
▫ Intermittent Wiper System ............... .134
▫ Windshield Washers ................... .134
▫ Mist Feature ......................... .134
▫ Rain Sensing Wipers — If Equipped ........ .135
 TIL T STEERING COLUMN ................ .136
 DRIVER ADJUSTABLE PEDALS —
IF EQUIPPED ......................... .137
 HEATED STEERING WHEEL — IF EQUIPPED . .138
 SPEED CONTROL ...................... .139
▫ To Activate .......................... .140
▫ To Set A Desired Speed .................. .14096 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!To prevent possible damage, do not slam the hood to
close it. Use a firm downward push at the front center
of the hood to ensure that both latches engage.
LIGHTS
The headlight switch is located on the left side of the
instrument panel, next to the steering wheel. The headlight
switch controls the operation of the headlights, parking
lights, instrument panel lights, cargo lights and fog lights
(if equipped). Your vehicle is equipped with plastic headlight and fog
light (if equipped) lenses that are lighter and less suscep-
tible to stone breakage than glass lights. Plastic is not as
scratch resistant as glass and therefore different lens clean-
ing procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution followed
by rinsing.
NOTE: If your vehicle is equipped with illuminated ap-
proach lights under the outside mirrors they can be turned
off through the instrument cluster display or the Uconnect
radio. For further information refer to “Instrument Cluster
Display” and “Uconnect Settings” in “Understanding Your
Instrument Panel”.
CAUTION!Do not use abrasive cleaning components, solvents,
steel wool or other abrasive materials to clean the
lenses. (Continued)
Headlight Switch Location124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Parking Lights And Panel Lights
To turn on the parking lights and instrument panel
lights, rotate the headlight switch clockwise. To turn
off the parking lights, rotate the headlight switch back to
the O (off) position.
Fog Lights — If Equipped
The fog lights are turned on by rotating the headlight
switch to the parking light or headlight position and
pushing in the headlight rotary control.
The fog lights will operate only when the parking lights are
on or when the vehicle headlights are on low beam. An indicator light located in the instrument cluster display
will illuminate when the fog lights are on. The fog lights
will turn off when the switch is pushed a second time,
when the headlight switch is rotated to the off position, or
the high beam is selected.
Lights-On Reminder
If the headlights, parking lights, or cargo lights are left on
after the ignition is turned off, a chime will sound when the
driver ’s door is opened.
Battery Saver
To protect the life of your vehicle’s battery, load shedding
is provided for both the interior and exterior lights.
If the ignition is off and any door is left ajar for 10 minutes
or the dimmer control is rotated all the way up to the dome
on position for 10 minutes, the interior lights will automati-
cally turn off.
NOTE: Battery saver mode is cancelled if the ignition is on.
If the headlights remain on while the ignition is cycled off,
the exterior lights will automatically turn off after eight
minutes. If the headlights are turned on and left on for
eight minutes while the ignition is off, the exterior lights
will automatically turn off.Fog Light Switch128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Fog Light Indicator — If Equipped
Yellow Telltale
Light What It Means
Rear Fog Light Indicator
This indicator will illuminate when the rear fog lights are on.
Low Coolant Level Indicator Light
Yellow Telltale
Light What It Means
Low Coolant Level Indicator Light
This telltale will turn on to indicate the vehicle coolant level is low.
TOW/HAUL Indicator Light
Yellow Telltale
Light What It Means
TOW/HAUL Indicator Light
This light will illuminate when TOW HAUL mode is selected.212 UNDERSTANDING YOUR INSTRUMENT PANEL

2WD Indicator Light — If Equipped
Yellow Telltale
Light What It Means
2WD Indicator Light
This light alerts the driver that the vehicle is in the two-wheel drive mode.
Green Telltale Indicator Lights
Park/Headlight On Indicator Light
Green Telltale
Light What It Means
Park/Headlight On Indicator Light
This indicator will illuminate when the park lights or headlights are turned on.
Front Fog Indicator Light — If Equipped
Green Telltale
Light What It Means
Front Fog Indicator Light — If Equipped
This indicator will illuminate when the front fog lights are on. 4UNDERSTANDING YOUR INSTRUMENT PANEL 215

• For grease stains, apply MOPAR Multi-Purpose Cleaner
to a clean, damp cloth and remove stain. Use a fresh,
damp towel to remove soap residue.
• Do not use any harsh solvents or any other form of
protectants on Stain Repel products.
Interior Care
Use MOPAR Total Clean to clean fabric upholstery and
carpeting.
Use MOPAR Total Clean to clean vinyl upholstery.
MOPAR Total Clean is specifically recommended for
leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt can
act as an abrasive and damage the leather upholstery and
should be removed promptly with a damp cloth. Stubborn
soils can be removed easily with a soft cloth and MOPAR
Total Clean. Care should be taken to avoid soaking your
leather upholstery with any liquid. Please do not use
polishes, oils, cleaning fluids, solvents, detergents, or
ammonia-based cleaners to clean your leather upholstery.
Application of a leather conditioner is not required to
maintain the original condition. WARNING!Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in closed
areas they may cause respiratory harm.
CAUTION!• Direct contact of air fresheners, insect repellents,
suntan lotions, or hand sanitizers to the plastic,
painted, or decorated surfaces of the interior may
cause permanent damage. Wipe away immediately.
• Damage caused by these type of products may not be
covered by your New Vehicle Limited Warranty.
• Do not use Alcohol and Alcohol-based and/or Keton
based cleaning products to clean leather seats, as
damage to the seat may result.
Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone breakage
than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.484 MAINTAINING YOUR VEHICLE

REPLACEMENT BULBS
LIGHT BULBS — Interior
Bulb Number
Overhead Console Lamps TS 212-2
Dome Lamp 7679
For lighted switches, see your authorized dealer for
replacement instructions.
LIGHT BULBS — Exterior
Bulb Number
Quad Headlamp –
Low Beam H11
Quad Headlamp –
High Beam 9005
Quad Headlamp – Front
Turn Signal Lamp 3157NA
Premium Headlamp –
Low Beam HIR2
Premium Headlamp –
High Beam 9005 Bulb Number
Premium Headlamp –
Front Turn Signal Lamp LED (See authorized
dealer for service)
Horizontal Fog Lamp 9145
Vertical Fog Lamp 9006
Cab Roof Marker Lamps 194NA
Center High Mounted
Stop Lamp 921
Rear Cargo Lamp 921
Box Off Tail Lamps –
Stop/Turn/Tail/License
Plate 1157
Box Off Tail Lamps –
Back Up 1156494 MAINTAINING YOUR VEHICLE

Exhaust Gas Caution .................... .91, 400
Exhaust System ........................ .91, 470
Exterior Lighting .......................... .125
Exterior Lights .............................94
Filters
Air Cleaner ............................ .454
Air Conditioning .................... .291, 460
Engine Fuel ........................... .501
Engine Oil ......................... .453, 501
Engine Oil Disposal ...................... .453
Flashers
Turn Signal ...................... .94, 132, 216
Flat Tire Stowage .......................... .435
Flooded Engine Starting ..................... .323
Fluid, Brake ............................. .503
Fluid Capacities ........................... .500
Fluid Leaks ...............................94
Fluid Level Checks
Automatic Transmission ................... .479
Brake ................................ .475
Power Steering ......................... .350
Fluids, Lubricants And Genuine Parts ........... .501
Fog Lights ........................ .128, 212, 496
Fold Flat Load Floor ....................... .183 Four-Way Hazard Flasher .................... .426
Four Wheel Drive ......................... .338
Freeing A Stuck Vehicle ..................... .439
Front Axle (Differential) ..................... .476
Fuel ................................... .397
Adding .............................. .400
Additives ............................. .399
Clean Air ............................. .397
Ethanol .............................. .397
Filler Cap (Gas Cap) ..................... .401
Filter ................................ .501
Gasoline .............................. .397
Light ................................ .210
Materials Added ........................ .399
Methanol ............................. .397
Octane Rating .......................... .397
Requirements .......................... .397
Tank Capacity .......................... .500
Fuses .................................. .486
Garage Door Opener (HomeLink) ........... .161, 166
Gas Cap (Fuel Filler Cap) ................ .401, 449
Gasoline, Clean Air ........................ .397
Gasoline (Fuel) ........................... .397
Gasoline, Reformulated ..................... .397522 INDEX

Inverter Outlet (115V) ...................... .173
Jack Location ............................ .429
Jump Starting ............................ .436
Key Fob
Programming Additional Key Fobs .............19
Key Fob Battery Service (Remote Keyless Entry) .....26
Key Fob Programming (Remote Keyless Entry) ......22
Key Fob, Remote Keyless Entry .................22
Key-In Reminder ............................17
Keyless Enter-N-Go ..................... .35, 322
Lock The Vehicle’s Doors ............... .244, 263
Passive Entry ............................35
Passive Entry Programming .......... .35, 244, 263
Keyless Entry System ........................22
Key, Replacement ...........................19
Keys ....................................11
Key, Sentry (Immobilizer) ......................18
Lane Change And Turn Signals ................ .132
Lane Change Assist ........................ .132
Latches ..................................94
Lead Free Gasoline ........................ .397
Leaks, Fluid ...............................94 Life Of Tires ............................. .383
Light Bulbs ................................94
Lights ............................... .94, 124
AirBag ......................... .55, 92, 197
Automatic Headlights .................... .125
Brake Assist Warning ..................... .361
Brake Warning ......................... .198
Bulb Replacement .................... .494, 495
Cap Top Clearance ...................... .498
Cargo................................ .131
Center Mounted Stop ..................... .497
Courtesy/Reading ................ .130, 131, 160
Cruise ......................... .216, 217, 218
Daytime Running ....................... .126
Engine Temperature Warning ............... .200
Exterior ................................94
Fog........................... .128, 212, 496
Four-Wheel Drive Indicator ................ .341
Hazard Warning Flasher .................. .426
Headlights ............................ .125
High Beam ............................ .133
High Beam/Low Beam Select ............... .133
Hill Descent Control Indicator .............. .363
Illuminated Entry .........................22
Interior ..................... .129, 130, 131, 160524 INDEX
