snow chains RAM CHASSIS CAB 2019 Owners Manual

SAFETY 181
NOTE:
When filling warm tires, the tire pressure may need to be
increased up to an additional 4 psi (28 kPa) above the recom -
mended cold placard pressure in order to turn the Tire Pres -
sure Monitoring Telltale Light off.
Service TPMS Warning
If a system fault is detected, the “Tire Pressure Monitoring
Telltale Light” will flash on and off for 75 seconds and then
remain on solid. The system fault will also sound a chime. In
addition, the instrument cluster will display a "SERVICE
TPM SYSTEM" message for a minimum of five seconds and
then display dashes (- -) in place of the pressure value to indi -
cate which sensor is not being received.
If the ignition switch is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault no
longer exists, the “Tire Pressure Monitoring Telltale Light”
will no longer flash, and the "SERVICE TPM SYSTEM"
message will no longer display, and a pressure value will
display in place of the dashes. A system fault can occur due
to any of the following:
• Signal interference due to electronic devices or driving
next to facilities emitting the same radio frequencies as the
TPM sensors. • Installing aftermarket window tinting that contains mate -
rials that may block radio wave signals.
• Accumulation of snow or ice around the wheels or wheel
housings.
• Using tire chains on the vehicle.
• Using wheels/tires not equipped with TPM sensors.
A system fault may occur due to an incorrect TPM sensor
location condition. When a system fault occurs due to an
incorrect TPM sensor location, the “Tire Pressure Monitoring
Telltale Light” will flash on and off for 75 seconds and then
remain on solid. The system fault will also sound a chime. In
addition, the instrument cluster will display a “Tire Pressure
Temporarily Unavailable” message in place of the tire pres -
sure display screen. If the ignition switch is cycled, this
sequence will repeat, providing the system fault still exists. If
the system fault no longer exists, the “Tire Pressure Moni -
toring Telltale Light” will no longer flash and the tire pres -
sure display screen will be displayed showing the tire
pressure values the correct locations. 4

SAFETY 187
• Installing aftermarket window tinting that contains mate -
rials that may block radio wave signals.
• Accumulation of snow or ice around the wheels or wheel
housings.
• Using tire chains on the vehicle.
• Using wheels/tires not equipped with TPM sensors.
General Information
This device complies with Part 15 of the FCC rules and RSS
210 of Industry Canada. Operation is subject to the following
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
NOTE:
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment. OCCUPANT RESTRAINT SYSTEMS
Some of the most important safety features in your vehicle
are the restraint systems:
Occupant Restraint Systems Features
• Seat Belt Systems
• Supplemental Restraint Systems (SRS) Air Bags
• Child Restraints
Some of the safety features described in this section may be
standard equipment on some models, or may be optional
equipment on others. If you are not sure, ask an authorized
dealer. 4

600
Seat Belts .......................................................................... 189, 241
Adjustable Shoulder Belt ................................................... 195
Adjustable Upper Shoulder Anchorage .......................... 195
Adjustable Upper Shoulder Belt Anchorage................... 195
Child Restraints ................................................................... 214
Extender................................................................................ 198
Front Seat...................................................................... 189, 193
Inspection ............................................................................. 241
Lap/Shoulder Belt Operation ........................................... 193
Lap/Shoulder Belt Untwisting ......................................... 194
Operating Instructions ....................................................... 193
Pregnant Women................................................................. 199
Reminder .............................................................................. 189
Seat Belt Extender ............................................................... 198
Seat Belt Reminder .............................................................. 189
Untwisting Procedure ........................................................ 194
Seat Belts Maintenance........................................................... 473
Seats ................................................................................ 39, 41, 42
Adjustment....................................................................... 39, 42
Easy Entry .............................................................................. 46
Folding Floor ....................................................................... 112
Head Restraints ..................................................................... 50
Memory .................................................................................. 44
Power ...................................................................................... 42
Rear Folding........................................................................... 39
Reclining Rear........................................................................ 41 Tilting ......................................................................................39
Security Alarm ...................................................................30, 148
Selection Of Coolant (Antifreeze) .........................................484
Sentry Key
Key Programming .................................................................29
Sentry Key (Immobilizer).........................................................28
Sentry Key Replacement ..........................................................29
Service Assistance ...................................................................585
Service Contract.......................................................................587
Service Manuals ......................................................................589
Shift Lever Override ...............................................................402
Shifting...................................................................................... 254
Automatic Transmission ............................................256, 265
Transfer Case .......................................................................280
Transfer Case, Shifting Into Transfer Case Neutral (N) ........... 360
Transfer Case, Shifting Out Of Transfer Case
Neutral (N) ...........................................................................362
Signals, Turn ..............................................................70, 157, 243
Siri..............................................................................................577
Sliding Rear Window, Power ..................................................94
Snow Chains (Tire Chains) ....................................................465
Snow Plow ...............................................................................355
Snow Tires ................................................................................461
Spare Tire Changing ...............................................................396
Spare Tire Stowage .................................................................396
Spare Tires ................................................................461, 462, 463
