Ram ProMaster 2019 User Guide

REAR VIEW
Rear View
1 — Rear Lights
2 — Cargo Door Outer Handle
2
GRAPHICAL TABLE OF CONTENTS 9

INSTRUMENT PANEL
Instrument Panel
1 — Multifunction Lever4 — Climate Controls
2 — Instrument Cluster 5 — Uconnect System
3 — Windshield Wiper Lever 6 — Switch Panel
10 GRAPHICAL TABLE OF CONTENTS

INTERIOR
Interior
1 — Window Switches4 — Gear Selector
2 — Door Handles 5 — Glove Compartment
3 — Seats 6 — Passenger Airbag
2
GRAPHICAL TABLE OF CONTENTS 11

GETTING TO KNOW YOUR VEHICLE
CONTENTS
KEYS .................................16
▫ KeyFob..............................16
 IGNITION SWITCH .......................18
▫ Mechanical Ignition Switch ................18
▫ Key-In-Ignition Reminder .................20
 SENTRY KEY ...........................20
▫ Replacement Keys .......................20
▫ General Information .....................21
 VEHICLE SECURITY ALARM — IF EQUIPPED . . .21
▫ To Arm The System ......................21
▫ To Disarm The System ....................21
▫ Rearming Of The System ..................21
▫ Security System Manual Override ............22
 DOORS ...............................22 ▫
Power Door Locks ......................22
▫ Auto Unlock Doors ......................23
▫ Automatic Door Locks ...................23
 SEATS ................................23
▫ Manual Adjustments .....................24
▫ Heated Seats — If Equipped ...............29
▫ Fold Down Tray — If Equipped .............30
▫ Adjustable Armrests — If Equipped ..........31
 HEAD RESTRAINTS ......................32
▫ Front Head Restraint Adjustment ............32
▫ Front Head Restraint Removal ..............33
 STEERING WHEEL .......................34
▫ Telescoping Steering Column ...............34
 MIRRORS ..............................343

▫Inside Day/Night Mirror — If Equipped ......34
▫ Outside Mirrors ........................35
▫ Power Mirrors — If Equipped ..............36
▫ Power Folding Mirrors — If Equipped .........36
▫ Heated Mirrors — If Equipped .............38
 EXTERIOR LIGHTS .......................38
▫ Multifunction Lever .....................38
▫ Headlights ............................39
▫ Daytime Running Lights — If Equipped .......39
▫ High Beam/Low Beam Select Switch .........39
▫ Flash-To-Pass ..........................40
▫ Parking Lights .........................40
▫ Follow Me Home/Headlight Delay ..........40
▫ Fog Lights — If Equipped .................40
▫ Turn Signals ...........................41
▫ Lane Change Assist ......................41
▫ Battery Saver ...........................41
INTERIOR LIGHTS .......................41
▫ Courtesy Lights .........................41
▫ Illuminated Entry .......................44
 WIPERS AND WASHERS ...................44
▫ Front Wiper Operation ...................44
 CLIMATE CONTROLS .....................45
▫ Manual Climate Control Overview ...........46
▫ Climate Control Functions .................50
▫ Operating Tips .........................51
 WINDOWS .............................53
▫ Power Windows ........................53
▫ Window Bar Grates — If Equipped ...........54
▫ Wind Buffeting .........................55
 HOOD ................................55
▫ Opening ..............................55
▫ Closing ...............................56
 CARGO AREA FEATURES ..................57
14 GETTING TO KNOW YOUR VEHICLE

INTERNAL EQUIPMENT ...................57
▫ Storage ..............................57
▫ Cupholders ...........................60 ▫
Power Outlets .........................60
▫ Auxiliary Switches — If Equipped ............63
3
GETTING TO KNOW YOUR VEHICLE 15

KEYS
Key Fob
Your vehicle uses a key start ignition system. The ignition
system consists of a key fob with a Remote Keyless Entry
(RKE) and an ignition switch.
The key fob contains an integrated mechanical key. To use
the mechanical key, simply push the mechanical key re-
lease button.
The vehicle is supplied with a code card containing key
code numbers to order duplicate keys, and the authorized
dealer that sold you your new vehicle has the key code
numbers for your vehicle locks. These numbers can be
used to order duplicate keys.Remote Keyless Entry (RKE)
This system allows you to lock or unlock the doors from
distances up to approximately 66 ft (20 m) using a hand-
held key fob. The key fob does not need to be pointed at the
vehicle to activate the system.
Key Fob With Integrated Mechanical Key
1 — Key Blade Release Button
2 — Driver/Passenger Unlock Button
3 — Lock Button
4 — Cargo Lock/Unlock Button
16 GETTING TO KNOW YOUR VEHICLE

NOTE:The key fob may not be able to be detected by the
vehicle if it is located next to a mobile phone, laptop or
other electronic device; these devices may block the key
fob’s wireless signal.
To Unlock The Doors
Push and release the unlock button on key fob once to
unlock only the front doors. Push and release the cargo
unlock button on key fob once to unlock the cargo area
(rear lateral sliding doors and rear door). The turn signal
lights will flash twice to acknowledge the unlock signal.
To Lock The Doors
Push and release the lock button on the key fob to lock all
doors. The turn signal lights will flash once to acknowl-
edge the signal. If a door is open, the turn signal lights will
flash at an increased rate.
Locking Doors With A Key
1. Insert the key with either side up.
2. Turn the key to the right to lock the door.
3. Turn the key to the left to unlock the door.
Refer to “Dealer Service” in “Servicing And Maintenance”
for maintenance procedures.
Sound Horn With Lock
This feature will cause the horn to chirp when the doors are
locked with the key fob. This feature can be turned on or
turned off. To change the current setting, refer to
“Uconnect Settings” in “Multimedia” for further informa-
tion.
Key Fob Battery Replacement
NOTE: Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Key Fob
3
GETTING TO KNOW YOUR VEHICLE 17

The recommended replacement battery is CR2032.
1. Push the mechanical key release button and release themechanical key to access the battery case screw located
on the side of the key fob.
2. Rotate the screw located on the side of the key fob using a small screwdriver.
3. Take out the battery case. Remove and replace the battery observing its polarity.
4. Refit the battery case inside the key fob and turn the screw to lock it into place.Programming Additional Key Fobs
Programming the key fob may be performed by an autho-
rized dealer.
General Information
The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-cluding interference that may cause undesired opera-
tion.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
IGNITION SWITCH
Mechanical Ignition Switch
1. Place the gear selector in PARK (if equipped with an automatic transmission).
Key Fob Screw Location
18 GETTING TO KNOW YOUR VEHICLE
