remote control Ram ProMaster City 2016 Owner's Manual

Opening And Closing From The Inside
Opening:
Pull the interior door handle switch to unlock the door,
then pull the handle and slide the door towards the rear
of the vehicle until it can go no further.
Closing:
Pull the interior door handle switch to release the door
and then push it towards the front of the vehicle.
Child Lock System
This system prevents the sliding side doors being opened
from the inside.
It can be engaged only with the sliding side door open:
•Position 1 – engaged (door locked)
• Position 2 – disengaged (door can be opened from
inside) The device remains engaged even if the doors are un-
locked remotely.
Key Emergency Lock (KEL) Device
The sliding side doors are provided with a device for
locking all the doors using the lock in case of a power
fault.
The device can be engaged with the sliding side doors
open as follows:
•
Position 1– device not engaged (doors released)
• Position 2 – device engaged (fit the metal insert of the
ignition key in its seat and rotate clockwise), door
locked
The device is released and thus the doors can be opened
as follows:
If the power is restored:
• By remote control.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

iPod control supports Mini, 4G, Photo, Nano, 5G iPod
and iPhone devices. Some iPod software versions may
not fully support the iPod control features. Please visit
Apple’s website for software updates.For further information, refer to the Uconnect Supple-
ment Manual.
STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED
The remote sound system controls are located on the back
surface of the steering wheel. Reach behind the wheel to
access the switches.
USB Input And AUX Jack
1 — USB Input
2 — AUX Audio Jack
202 UNDERSTANDING YOUR INSTRUMENT PANEL

The right hand control is a rocker type switch with a
push-button in the center. Pushing the top of the switch
will increase the volume, and pushing the bottom of the
switch will decrease the volume.The button located in the center of the right hand control
will switch modes to Radio, AUX or other valid audio
sources.
The left hand control is a rocker type switch with a
push-button in the center. The function of the left hand
control is different depending on which mode you are in.
The following describes the left hand control operation in
each mode.
Radio Operation
Pushing the top of the switch will SEEK up for the next
listenable station and pushing the bottom of the switch
will SEEK down for the next listenable station.
The button located in the center of the left hand control
will tune to the next pre-set station that you have
programmed in the radio pre-set buttons.
Remote Sound System Controls (Back View Of Steering
Wheel)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 203

Customer Assistance...................... .409
Customer Programmable Features .............191
Data Recorder, Event .......................60
Daytime Running Lights ....................111
Dealer Service ........................... .353
Defroster, Rear Window .....................140
Defroster, Windshield ....................88, 207
Diagnostic System, Onboard .................350
Dipsticks Oil (Engine) .......................... .355
Power Steering ........................ .240
Disabled Vehicle Towing ....................341
Disposal Antifreeze (Engine Coolant) ................370
Door Ajar .............................. .157
Door Ajar Light ......................... .157
Door Locks ..............................21
Doors ..................................21 Driving
Through Flowing, Rising, Or Shallow Standing
Water ............................... .238
Electrical Outlet, Auxiliary (Power Outlet) ........130
Electric Rear Window Defrost .................140
Electric Remote Mirrors ......................96
Electronic Brake Control System ...............244
Brake Assist System .....................246
Electronic Range Select (ERS) .................236
Electronic Roll Mitigation (ERM) ..............252
Electronic Speed Control (Cruise Control) ........119
Electronic Stability Control (ESC) ..............248
Electronic Throttle Control Warning Light ........152
Electronic Vehicle Information Center (EVIC) Exit Trip ............................. .187
NewTrip ............................ .187
Start Of Trip Procedure ...................187
Trip Computer ........................ .187
10
INDEX 423

Door.................................21
Lubrication, Body ........................ .361
Lug Nuts .............................. .312
Maintenance Free Battery ....................359
Maintenance Procedures ....................354
Maintenance Schedule ..................... .402
Malfunction Indicator Light (Check Engine) . . .168, 352
Manual, Service ......................... .414
Master Cylinder (Brakes) ....................373
Methanol .............................. .285
Mirrors .................................94
Electric Powered .........................96
Electric Remote .........................96
Exterior Folding .........................95
Outside ...............................94
Rearview ..............................94
Modifications/Alterations, Vehicle ...............7
Monitor, Tire Pressure System ................279MOPAR Parts
........................ .353, 413
MTBE/ETBE ........................... .285
Multi-Function Control Lever .................111
New Vehicle Break-In Period ..................85
Occupant Restraints ........................32
Octane Rating, Gasoline (Fuel) .............284, 397
Oil Change Indicator ...................... .186
Oil Change Indicator, Reset ..................186
Oil, Engine ......................... .355, 397
Capacity ............................ .396
Change Interval ....................... .356
Checking ............................ .355
Dipstick ............................. .355
Disposal ............................. .358
Filter ............................ .358, 397
Filter Disposal ........................ .358
Identification Logo ..................... .356
428 INDEX

Recorder, Event Data.......................60
Recreational Towing ...................... .307
Reformulated Gasoline .....................285
Refrigerant ............................. .361
Reminder, Seat Belt .........................34
Remote Sound System (Radio) Controls .........202
Replacement Bulbs ....................... .392
Replacement Keys .........................15
Replacement Parts ........................ .353
Replacement Tires ........................ .276
Reporting Safety Defects ....................413
Restraint, Head .......................... .103
Restraints, Child ...........................61
Restraints, Occupant ........................32
Rotation, Tires .......................... .278
Safety Checks Inside Vehicle ..................88
Safety Checks Outside Vehicle .................90
Safety Defects, Reporting ....................413 Safety, Exhaust Gas
.........................87
Safety Information, Tire .....................253
Safety Tips ...............................86
Schedule, Maintenance .....................402
Seat Belt Adjustable Upper Shoulder Belt Anchorage ......41
Automatic Locking Retractor (ALR) ...........44
Energy Management Feature ................44
Lap/Shoulder Belt Operation ................38
Lap/Shoulder Belts .......................36
Lap/Shoulder Belt Untwisting ...............40
Pregnant Women ........................43
Seat Belt Pretensioner .....................43
Seat Belt Reminder .......................34
Seat Belt System .........................32
Seat Belt Maintenance ..................... .382
Seat Belt Reminder .........................34
Seat Belts ............................ .34, 88
Adjustable Shoulder Belt ...................41
430 INDEX

Trailer Towing........................ .301
Tread Wear Indicators ....................274
Tire Safety Information .....................253
Tire Service Kit .......................... .314
Tongue Weight/Trailer Weight ................298
Towing ............................... .293
Disabled Vehicle ....................... .341
Guide .............................. .298
Recreational .......................... .307
Weight .............................. .298
Towing Vehicle Behind A Motorhome ...........307
Traction ............................... .237
Traction Control ......................... .246
Trailer Towing .......................... .293
Cooling System Tips .....................306
Hitches ............................. .297
Minimum Requirements ..................299
Tips................................ .305
Trailer And Tongue Weight ................298 Wiring
.............................. .302
Trailer Towing Guide ...................... .298
Trailer Weight ........................... .298
Transaxle Automatic ......................... .12, 223
Transmission ........................... .228
Automatic ..................... .226, 228, 375
Maintenance .......................... .375
Transmitter Battery Service (Remote Keyless Entry) . .19
Transporting Pets ..........................85
Tread Wear Indicators ..................... .274
Turn Signals ............................ .173
Uconnect Voice Command ...................210
Uniform Tire Quality Grades .................415
Unleaded Gasoline ....................... .284
Untwisting Procedure, Seat Belt ................40
Vehicle Certification Label ...................291
10
INDEX 433
