stop start RENAULT DUSTER 2015 Owner's Guide

JauneNoir Noir texte
5.8
ENG_UD38373_2
Kit de gonflage des pneumatiques (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
TYRE INFLATION KIT (4/4)
Once the tyre is correctly inflated,
remove the kit: slowly unscrew the in-
flation adapter 1 to prevent any repair
product from escaping and store the
container in plastic packaging to pre-
vent the product from escaping.
– Affix the driving recommendation
label to the dashboard where it can
easily be seen by the driver;
– Put the kit away.
– At the end of this initial inflation op-
eration, air will still escape from the
tyre. You must drive a short distance
in order to seal the hole.
– Start immediately and drive at be-
tween 12 and 40 mph (20 and
60 km/h) in order to distribute the
product evenly in the tyre and, after
driving for 2 miles (3 km), stop and
check the pressure.
– If the pressure is greater than 1.3 bar
but less than the recommended
pressure (refer to the label affixed to
the edge of the driver’s door), read-
just it. Otherwise, please contact an
authorised dealer: the tyre cannot be
repaired.
Precautions when using the
kit
The kit should not be operated for more
than 15 consecutive minutes.
1
Following repair with the kit,
do not travel further than
120 miles (200 km). In addi-
tion, reduce your speed and
under no circumstances exceed
48 mph (80 km/h). The sticker,
which you must affix in a prominent
position on the dashboard, reminds
you of this.
Depending on the country or local
legislation, a tyre repaired with the
inflation kit may need to be replaced.

JauneNoir Noir texte
5.29
ENG_UD39267_6
Fusibles (H79 - H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
FUSES (2/8)
Fuses in engine compartment B
Some functions are protected by fuses
located in the engine compartment
(unit B).
However, because of their reduced
accessibility, we advise you to have
your fuses replaced by an approved
dealer.
B
Special features of LPG versions
The specific LPG circuit shut-off fuse 3
is located in the box B.
3
When working in the engine
compartment, ensure that
the windscreen wiper stalk
is in the park position.
Risk of injury.
Deactivate the Stop and
Start function for any opera-
tion performed in the engine
compartment.

JauneNoir Noir texte
5.36
ENG_UD32190_1
Batterie : dépannage (H79 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
BATTERY: troubleshooting (1/2)
To avoid all risk of sparks:
– Ensure that any consumers (cour-
tesy lights, etc.) are switched off
before disconnecting or reconnect-
ing the battery;
– when charging, stop the charger
before connecting or disconnecting
the battery;
– to avoid creating a short circuit be-
tween the terminals, do not place
metal objects on the battery;
– always wait at least one minute after
the engine has been switched off
before disconnecting a battery;
– make sure that you reconnect the
battery terminals after refitting.
Handle the battery with care
as it contains sulphuric acid,
which must not come into
contact with eyes or skin. If
it does, wash the affected area with
plenty of cold water and consult a
doctor, if necessary.
Ensure that naked flames, red hot
objects and sparks do not come into
contact with the battery as there is a
risk of explosion.
The engine may be hot during oper-
ations in close proximity. In addition,
the engine cooling fan may start to
operate at any moment. Risk of se-
rious injury.
Certain batteries may have
specific recharging require-
ments; consult your au-
thorised dealer. Avoid any
risk of sparks, as this could cause
a sudden explosion, and always
charge the battery in a well-venti-
lated area. Risk of serious injury.
Connecting a battery charger
The battery charger must be com-
patible with a battery with nominal
voltage of 12 volts.
Do not disconnect the battery when the
engine is running. Follow the instruc-
tions given by the manufacturer of
the battery charger you are using.
When many accessories are fitted to
the vehicle, have them connected to
the + after ignition feed.

JauneNoir Noir texte
5.45
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (1/5)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
The starter is activated POSSIBLE CAUSES WHAT TO DO
Warning lights dim or fail to come on;
the starter does not run.Battery terminals disconnected,
oxidised or incorrectly secured.Retighten them, reconnect them or clean
them if they are oxidised.
Battery discharged or worn.Connect another battery to the faulty bat-
tery. Refer to the information on “Battery:
troubleshooting” in Section 5 or replace the
battery if necessary.
Do not push the vehicle if the steering
column is locked.
The engine will not start. Starting conditions are not fulfilled.Refer to the information on “Starting/stop-
ping the engine in Section 2.
The steering column remains locked. Steering wheel locked. To unlock, gently move the key and the
steering wheel (refer to the information on
the “Ignition switch” in Section 2).

JauneNoir Noir texte
7.4
FRA_UD39333_8
Index (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_7
ALPHABETICAL INDEX (4/5)
remote control door locking
batteries ....................................................................... 5.38
remote control door locking unit ................................1.2 → 1.4
RENAULT ANTI-INTRUDER DEVICE (RAID) ..................... 1.8
replacement parts ................................................................ 6.8
reverse gear
selecting ....................................................................... 2.29
reversing sensor ..................................................... 2.49 – 2.50
roof bars ............................................................................ 3.28
roof rack
roof bars ....................................................................... 3.28
running in ............................................................................. 2.2
S
seat belts ...............................................................1.14 → 1.22
service sheets..........................................................6.9 → 6.14
signals and lights .................................................... 1.61 – 1.62
speakers
location ........................................................................ 5.43
special features of diesel versions..................................... 2.11
special features of LPG versions ..... 2.12 → 2.14, 5.28 → 5.35
special features of petrol vehicles ..................................... 2.10
speed limiter ..........................................................2.38 → 2.40
starting .......................................................................2.3 → 2.6
starting the engine .....................................................2.2 → 2.9
steering wheel
adjustment ................................................................... 1.57
Stop & Start ...............................................................2.7 → 2.9
Stop & Start function..................................................2.7 → 2.9
storage compartment.............................................3.16 → 3.19
storage compartments ...........................................3.16 → 3.19
sun visor ............................................................................ 3.13
T
tailgate ...................................................................3.23 → 3.25tanks and reservoirs
brake fluid ...................................................................... 4.8
coolant ........................................................................... 4.9
tanks and reservoirs:
windscreen washer ...................................................... 4.10
technical specifications .......................................6.2, 6.6 → 6.8
telephone ........................................................................... 3.29
towing .................................................................................. 6.7
breakdown .......................................................5.40 → 5.42
towing equipment ......................................................... 3.26
towing a caravan ................................................................. 6.7
towing hitch............................................................5.40 → 5.42
towing rings ............................................................ 3.24 – 3.25
towing weights ..................................................................... 6.7
traction control .......................................................2.34 → 2.37
transporting children ..............................................1.23 → 1.33
transporting objects
in the luggage compartment ............................. 3.24 – 3.25
trims ..................................................................................... 5.9
trip computer and warning system.........................1.51 → 1.56
tyre inflation kit...........................................................5.5 → 5.8
tyre pressure.............................2.22 → 2.28, 4.12 – 4.13, 5.13
tyre pressure loss warning.....................................2.22 → 2.28
tyre pressures ......................................................... 4.12 – 4.13
tyres ............................. 2.22 → 2.28, 4.12 – 4.13, 5.12 → 5.15
V
variable power-assisted steering ....................................... 1.57
vehicle identification ............................................................ 6.2
vehicle identification plates ........................................6.2 → 6.4
ventilation
air conditioning ...................................................... 3.2 – 3.3
heating and air conditioning system ....................3.4 → 3.7
W
warning buzzer .................................................................. 1.62
