display RENAULT TWINGO RS 2009 2.G Electrical Equipment - Multimedia Connection Workshop Manual

86C -3V1 MR-413-X44-86C000$010.mif
MULTIMEDIA CONNECTION
Fault finding – Introduction86C
CBOX
Vdiag No.: 04
To cut off the + after ignition feed, proceed as follows:
Faults
Faults are declared either present or stored (depending on whether they appeared in a certain context and have
disappeared since, or whether they remain present but have not been diagnosed within the current context).
The present or stored status of faults should be taken into consideration when the diagnostic tool is used after the
+ after ignition feed has been activated (without any of the system components being activated).
For a present fault, apply the procedure described in the Interpretation of faults section.
For a stored fault, note the faults displayed and apply the Notes section.
If the fault is confirmed when the instructions are applied, the fault is present. Deal with the fault.
If the fault is not confirmed, check:
–the electrical lines which correspond to the fault,
–the connectors on these lines (corrosion, bent pins, etc.),
–the resistance of the component detected as faulty,
–the condition of the wires (melted or split insulation, wear).
Conformity check
The aim of the conformity check is to check the data that does not display a fault on the diagnostic tool when the
data is inconsistent. Therefore, this stage is used to:
–carry out fault finding on faults that do not have a fault display, and which may correspond to a customer complaint.
–check that the system is operating correctly and that there is no risk of a fault recurring after repair.
This section gives the fault finding procedures for statuses and parameters and the conditions for checking them.
If a status is not behaving normally or a parameter is outside the permitted tolerance values, consult the
corresponding fault finding page.
Customer complaints - Fault finding chart
If the test with the diagnostic tool is OK but the customer complaint is still present, the fault should be processed by
customer complaints. For vehicles with radio frequency remote control/key, use the key to switch off the ignition.
For vehicles with Renault cards,
Press the Start button twice briefly (less than 3 seconds),
Ensure that the forced + after ignition feed has been cut off by checking that the computer warning lights on the
instrument panel have gone out.
A synopsis of the general procedure to follow is provided on the following page in the form of a flow chart.

86C-14V1 MR-413-X44-86C000$030.mif
86C
CBOX
Vdiag No.: 04
The mobile connectivity computer provides the link between the radio and the mobile peripherals connected to the
mobile connectivity terminal.
It transmits:
–Audio signals to the speakers via the radio.
–Display information (song title, list, etc.) to the display via the radio.
The mobile connectivity terminal enables different types of mobile medium to be connected using the USB port and
the Jack socket.
The multimedia connection unit (Display or Multimedia connection unit) receives various signals from the vehicle
CAN (speed, status of exterior lights) and retransmits them to the radio via the Multimedia CAN.
The multimedia connection unit (Display or Multimedia connection unit) transmits the activation signal to the radio
and to the other computers participating in the multimedia function when the user switches on the radio.
The display shows different multimedia information such as radio information, the time and the temperature.
The radio control satellite on the steering wheel enables the different radio functions to be accessed.
MULTIMEDIA CONNECTION
Fault finding – Role of components

86C-15V1 MR-413-X44-86C000$040.mif
86C
CBOX
Vdiag No.: 04
I. LIST OF COMPONENTS
Number Description Number Description
1Radio 9Mobile connectivity terminal (digital /
analogue)
2Diagnostic socket 10 Rear right-hand speaker
3Display 11 Rear left-hand speaker
4Supply 12 Front right-hand speaker
5Radio control satellite 13Front right-hand tweeter (depending on
equipment).
6Earth 14 Front left-hand speaker
7 Mobile connectivity terminal (RCA type) 15Front left-hand tweeter (depending on
equipment).
8Mobile connectivity computer 16 Aerial
MULTIMEDIA CONNECTION
Fault finding – Operating diagram

86C-18V1 MR-413-X44-86C000$050.mif
86C
CBOX
Vdiag No.: 04
The mobile connectivity computer enables music files to be played (MP3, WMA, etc.) on:
•USB mobile peripherals (USB key, MP3 player, etc.) (Except hard disk with own power supply),
•audio peripherals via the jack socket.
The multimedia system offers the following possibilities:
•Choose FM radio stations using the presets, the list or manual selection.
•Have access to an automatically updated FM radio list.
•Listen to CDs and MP3s.
•Control the radio using the radio control satellite.
•Have access to optimised audio and acoustic telephone configurations for each vehicle according to the vehicle
type.
•Modify various acoustic parameters (base, treble, front/rear balance, etc.).
•Use the hands-free telephone function (sound relayed towards the radio speakers) with a Bluetooth telephone.
•Use voice recognition for the telephone functions (button on the radio control satellite). The voice identifier can be
recorded.
•Benefit from a connection for a CD changer.
•Possibility of connecting a peripheral with a USB port, Jack socket, etc.
•Has anti-theft protection
Computer activation system
The mobile connectivity computer has an activation system.
The mobile connectivity computer is activated under the following conditions:
•by pressing the radio ON/OFF button,
•by starting the engine.
The mobile connectivity computer is switched off under the following conditions:
•The ignition is switched off.
•Door opened (Clio III)
•Door opened for 1 minute (New Twingo)
•By pressing the radio ON/OFF button (Clio III and New Twingo).
The multimedia connection unit (Display or Multimedia connection unit ) is activated by the UCH (central door
unlocking); this then activates the multimedia computers (Navigation, Radio, mobile connectivity computer, etc.) via
the "Activation signal" connections.
MULTIMEDIA CONNECTION
Fault finding – Function

86C-32V1 MR-413-X44-86C000$100.mif
86C
CBOX
Vdiag No.: 04
MAIN SCREEN
NOTESOnly carry out a conformity check after a complete check with the diagnostic tool. The
values shown in this conformity check are given as a guide.
Application conditions: Engine stopped, ignition on.
FunctionParameter or Status
Check or ActionDisplay and
NotesFault finding
PeripheralET002:USB peripheralABSENT / PRESENT
Connect a peripheral to the USB
portIn the event of an
inconsistency, consult
the interpretation of
ALP2 My USB
peripheral cannot be
read.
ET003:JACK peripheralABSENT / PRESENT
Connect a musical peripheral to
the jack socket.In the event of an
inconsistency, consult
the interpretation of
ALP3 Auxiliary input
does not work.
Analogue
signal levelPR001:Analogue signal level,
right-hand track0 V < X < 4 VIn the event of an
inconsistency, consult
the interpretation of
ALP3 Auxiliary input
does not work.
PR002 Analogue signal level,
left-hand track0 V < X < 4 VIn the event of an
inconsistency, consult
the interpretation of
ALP3 Auxiliary input
does not work.
CBOX_V04_CCONF
MULTIMEDIA CONNECTION
Fault finding – Conformity check

86C-37
AFTER REPAIRWhen communication is established, deal with any faults indicated.
V1 MR-413-X44-86C000$150.mif
86C
CBOX
Vdiag No.: 04
ALP 1 No dialogue with the computer
NOTESTry to establish dialogue with a computer on another vehicle to check that the
diagnostic tool is not faulty. If the diagnostic tool is not causing the fault and dialogue
cannot be established with any other computer on the same vehicle, it may be that a
faulty computer is disrupting the fault finding line.
Use a process of successive disconnections to locate this computer.
Check the battery voltage, component code 107, and perform the necessary operations
to obtain the correct voltage (12 V < X < 15 V).
Ensure that the communication conditions are present: + After ignition feed and radio
on/off button pressed.
Use the Wiring Diagrams Technical Note for Clio III or New Twingo.
For a vehicle equipped with a Navigation computer, use component 1714, Multimedia
connection unit, for fault finding on the Multimedia interface unit.
Otherwise use component 653, display computer.
If the vehicle is equipped with a navigation computer, the mobile connectivity computer
is connected to the navigation computer, component code 662, otherwise it is
connected to the radio, component code 261.
CBOX_V04_ALP1
MULTIMEDIA CONNECTION
Fault finding – Fault Finding Chart
