222 Car careFuses
The fuses are housed in three fuse panels:
one behind a hatch on the left-hand end of
the dash, one in the engine bay (additional
small unit in front of battery) and one on the
left-hand side of the trunk. There is space
for spare fuses in the hatch on the left-hand
end of the dash.
To check if a fuse has blown, first remove it
from the panel. If the filament is broken, the
fuse has blown.
WARNING
To avoid the risk of short-circuiting and/or
fire breaking out in the electrical system,
the following should be heeded:
 Always consult an Saab dealer before
modifying or adding any electrical
equipment. Failure to do so can result
in the electrical system being
damaged.
 Never replace a fuse with one having
a higher rating than specified (see
page 224). The color of the fuse indi-
cates its amperage.
 If the same fuse blows repeatedly,
have the electrical system checked by
an Saab dealer.
 If a MAXI fuse blows, it means that
there is a major fault in the electrical
system. Have the car checked without
delay by an Saab dealer.
Sound fuse / Blown fuse
ProCarManuals.com

256 Car careInadequate coolinga Check that the controls for temperature
and air distribution are correctly set; see
“Manual climate-control system” on
page 98.
b Check that the condenser (in front of the
radiator) has not become clogged with
dirt and insects.
c Make sure that the compressor drive
belt does not slip (see page 205).
d Check the fuses for the ventilation fans
and compressor (see page 224).
Maintenance The compressor drive belt should be
inspected under the regular service
program.
 Clean away dirt and insects from the
condenser and radiator to prevent clog-
ging. When washing the car, use the hose
to spray the radiator and condenser
(located in front of the radiator) from both
sides (both from the front of the car and
from inside the engine bay). Do not use a
pressure washer.
Caution: Do not hose down the radia-
tor and condenser while the engine is
hot.Other than in extremely cold weather, do not
screen the radiator, e.g. with netting, as this
will greatly diminish its cooling capacity.
 Applicable to the manual climate control
system - During cold months the air condi-
tioning should be switched on once or
twice a month and run for 5–10 minutes
during highway driving once the engine is
warm.
This action saves the gaskets in the
compressor from being spoiled. The
compressor uses a lubricant that circu-
lates with the coolant.
Note:
The A/C system cannot be switched on
when the outside temperature is below 32°F
(0°C). Turn on the A/C system when the car
is standing in a warm place. Simplest is to
always have the A/C button pressed in. The
A/C system will then cut in automatically
when the outside temperature is high
enough.NOTICEDo not use a pressure washer when
cleaning the condenser or radiator due to
the risk of damage.
ProCarManuals.com

257 Car care
Headlight aimingThe vehicle has a visual optical headlight
aiming system equipped with vertical
aiming device. The aim has been preset at
the factory and should normally not need
further adjustments.
If your headlights are damaged in a crash,
the headlight aim may be affected. If you
believe your headlights need to be re-
aimed, we recommend that you take it to
your Saab dealer for service. However, it is
possible for you to re-aim your headlights as
described in the following procedure.To check the aim, the vehicle should be
properly prepared as follows:
 The vehicle shall be placed so that the
headlights are 25 ft (7.6 m) from a light
colored wall or other flat surface. The
aiming area should be darkened, this will
improve your ability to see the beam of the
low beam headlight being aimed.
An optical headlamp aimer can also be
used and will than replace the wall.
 The vehicle must have all four wheels on
a perfectly level surface which is level all
the way to the wall or other flat surface.
 The vehicle should be placed so it is per-
pendicular to the wall or other flat surface.
 The vehicle should be unloaded and fuel
tank full, and one person or 160 lbs.
(75 kg) on the drivers seat.  The vehicle should be fully assembled
and all other work stopped while headlight
aiming is being done.
 The vehicle should not have any snow, ice
or mud attached to it.
 Tires should be inflated to the prescribed
pressure.
 Close all doors.
 Rock the vehicle to stabilize the suspen-
sion.
Headlight aiming is done with the vehicle
low beam lamps. The high beam lamps will
be correctly aimed if the low beam lamps
are aimed properly.
WARNING
Before checking/adjusting the headlight
aiming, switch off the engine to avoid
danger of fingers and hands being injured
by moving parts.
The radiator fan can start up even when
the engine is switched off.NOTICETo make sure that your headlights are
aimed properly read all instructions
before beginning. Failure to follow these
instructions could cause damage to
headlight parts or a not correctly aimed
headlight.
ProCarManuals.com

262 Customer Assistance and InformationMaintenance scheduleThe Maintenance Schedule prescribes a
service program to the purchaser/operator
of a Saab that is reasonable and necessary
to ensure the proper emission control sys-
tems function, safety and reliability of the
Saab automobile in normal use. Additional
maintenance is recommended for specific
components when the car is operated under
certain severe conditions. Proper mainte-
nance is always a good practice!
Authorized Saab dealers are equipped and
trained to meet your Saab’s service needs.
They regularly receive up-to-date Saab ser-
vice manuals and parts and technical ser-
vice bulletins from Saab and are able,
through their franchise agreement, to attend
Saab service schools, obtain Saab special
tools and technical assistance and pur-
chase original equipment service and
replacement parts.
Today’s complex automobiles should only
be entrusted to the most knowledgeable
service professionals. A Saab dealer is your
best choice.
SERVICE INTERVALSThe maintenance schedule begins with an
Inspection Service at 30 days. A time for
service message will illuminate on the Saab
Instrument Display (SID) when the car is
due for regular maintenance. There are
three different messages that will appear:
TIME FOR INTERMEDIATE SERVICE
indicates that an oil/filter change is required
along with several inspections. This mes-
sage is set by the engine management
system which calculates service intervals
based on several factors including driving
habits, ambient temperature, number of
cold starts, mileage driven and elapsed time
since the last service. If mileage accumula-
tion does not occur, the message will be set,
and maintenance required at a maximum of
2 years.
TIME FOR MAIN AND INTERMEDIATE
SERVICE
indicates that an oil/filter change is required
along with several inspections and addi-
tional maintenance such as air filter or spark
plug replacement.TIME FOR MAIN SERVICE will be set when
additional maintenance is necessary, such
as air filter or spark plug replacement. When
the message Time for service. is displayed,
contact your Saab Dealer for a service
appointment.
Failure to perform scheduled maintenance
in a timely manner may result in serious
damage to key components or systems.
NOTICEThe Check-up will be done by your Saab
dealer at no charge and should be done
as close as possible to the scheduled 30
days.
ProCarManuals.com

266 Customer Assistance and InformationVehicle Data Collection and Event
Data RecorderYour vehicle, like other modern motor vehi-
cles, has a number of sophisticated com-
puter systems that monitor and control sev-
eral aspects of the vehicle’s performance.
Your vehicle uses on-board vehicle comput-
ers to monitor emission control components
to optimize fuel economy, to monitor condi-
tions for airbag deployment, to provide anti-
lock braking and to help the driver control
the vehicle in difficult driving situations.
Some information may be stored during reg-
ular operations to facilitate repair of
detected malfunctions; other information is
stored only in a crash or near crash event by
computer systems commonly called event
data recorder (EDR).
In a crash or near crash event, computer
systems, such as the Airbag Sensing and
Diagnostic Module (SDM) in your vehicle
may record information about the condition
of the vehicle and how it was operated, such
as engine speed, throttle position, vehicle
speed, seat belt usage, airbag readiness,
airbag performance data, and the severity
of a collision. These data have been used to
improve vehicle crash performance and
may be used to improve crash performance
of future vehicles and driving safety. These
on-board systems are somewhat like the
data recorders on many airplanes, but they
do not record sounds, such as conversation
of vehicle occupants.To read this information, special equipment
is needed and access to the vehicle or the
SDM is required. Saab will not access infor-
mation about a crash event or share it with
others other than
(a) with the consent of the vehicle owner or,
if the vehicle is leased, with the consent of
the lessee,
(b) in response to an official request of
police or similar government office,
(c) as part of Saab’s defense of litigation
through the discovery process, or
(d) as required by law.
In addition, once Saab collects or receives
data, Saab may
(a) use the data for research needs,
(b) make it available for research where
appropriate confidentiality is to be main-
tained and need is shown, or
(c) share summary data which is not tied to
a specific vehicle with non-Saab organiza-
tions for research purposes.
Others, such as law enforcement, may have
access to the special equipment that can
read the information if they have access to
the vehicle or SDM.
Please check the OnStar subscription ser-
vice agreement or manual for information
on its operations and data collection.
ProCarManuals.com

279 Technical data1 Region ________Y = Nor thern Europe
2 Country _______S = Sweden
3 Manufacturer ___3 = Saab Automobile AB
4 Product line ____F = 9-3
5 Model series ___B = 9-3 Linear
D = 9-3 Arc
F = 9-3 Vector6 Body version ___4 = 4-door
2 = Convertible
7 Gearbox _______5 = 5-speed manual
6 = 6-speed manual
9 = 5-speed automatic
8 Engine variant __S = 2.0t
Y = 2.0 Turbo
9 Check digit_____0-9 or X
10 Model year ____4 = 2004
11 Factory _______1 = Trollhättan
6 = Graz
12 Serial number __000001-999999 Position: 1234567891011 12
||||||||| | | |
Vehicle identifi-
cation number:Y S 3 F D 4 9 Y X 4 1 016584
||||||
1 2 3 4 5 6 = identification codes for certain chassis components
ProCarManuals.com

283 Index
Index
AA/C
__________________________ 101
ABS brakes
____________________ 161
ACC
_________________________ 103
Adjustment, steering wheel
________ 116
Air conditioning
_________________ 101
Air filter
_______________________ 198
Airbag
_________________________ 28
Anchorage eyes
________________ 137
Anti-corrosion treatment
__________ 253
Antilock braking system __________ 161
Anti-spin
______________________ 163
Ashtrays ______________________ 126
Autochecking of lights, warning and
indicator lights
__________________ 78
Autodimming
_______________ 129
, 130
Automatic climate control (ACC)
____ 103
Automatic tire pressure monitoring __ 229
Automatic transmission
___________ 153
BBattery
_______________________ 202
Bedding-in of new brake pads
_____ 151
Before towing a trailer
____________ 181
Bi-xenon headlights
_____________ 209Bi-xenon headlights, head light
levelling
_______________________ 91
Brake fluid, grade
_______________ 274
Brakes
________________________ 160
Braking _______________________ 160
Bulb changing
__________________ 208
Bulb table
_____________________ 221
Buying new tires
________________ 233
CCabin lighting
__________________ 123
Cabin lighting, Convertible
_________ 70
Car alarm
______________________ 48
Car transport ___________________ 186
Care of air conditioning
___________ 256
Change of address notification
_____ 264
Changing a tire
_________________ 245
Changing bulbs _________________ 208
Changing engine oil
_____________ 197
Changing the battery, remote control
_46
Changing wiper blades
___________ 206
Checking the number of remote
controls
_______________________ 45
Checks before towing a trailer
_____ 181
Child safety
_____________________ 21
Child safety locks, rear doors
_______ 44
Child seats
_____________________ 21
Cigarette lighter
_________________ 126
Cleaning the engine bay
__________ 249
Cleaning upholstery
_____________ 249Climate control system, manual
_____ 98
Closing the soft top manually,
Convertible
____________________ 60
Closing the soft top, Convertible
_____ 56
Clutch interlock
_________________ 152
Compact spare _________________ 243
Compass
______________________ 133
Condensation water, A/C
_________ 101
Convertible
_____________________ 53
Convertible, washing
_____________ 251
Coolant
_______________________ 199
Cruise control
__________________ 159
Cup holder
_____________________ 124
DDate codes, tires
________________ 243
Deep water, driving through
_______ 183
Definitions and terminology, tire ____ 240
Determining correct load, tires
_____ 242
Direction indicator stalk switch ______ 93
Direction indicators
_______________ 93
Dome light, Convertible
___________ 218
Dome light, Sport Sedan __________ 217
Donor battery, boost starting
_______ 187
Door handles
____________________ 40
Door mirrors ___________________ 128
Drive belt
______________________ 205
Drive belt, length
________________ 272
Driver’s seat with memory
__________ 19
Driving at night
_________________ 184
ProCarManuals.com

284 IndexDriving in cold climates
___________ 175
Driving in deep water
____________ 183
Driving in hot climates ____________ 177
Driving techniques
______________ 173
Driving with a heavy load on hilly
roads
________________________ 155
Driving with a load
______________ 183
Driving with a roof load ___________ 182
Driving with the compact spare wheel
187
Driving with the trunk lid open
______ 183
EEDR
_________________________ 266
ESP, anti-skid system
____________ 165
Easy entry, Convertible ____________ 65
Economical motoring
____________ 173
Electric engine heater ____________ 174
Electric heating, front seats
___ 102
, 111
Electric windows
________________ 117
Electric windows, Convertible
_______ 69
Electrical system, technical data ____ 272
Electrically adjustable seats
________ 18
Electronic Stability Program (ESP)
__ 165
Electronic steering wheel lock
_____ 142
Emergency opening of the narrow
backrest
_____________________ 138
Emergency operation of the sunroof
_ 122
Engine bay, cleaning
____________ 249
Engine heater
__________________ 174
Engine immobilizer
_______________ 47Engine number
_________________ 278
Engine oil, checking
_____________ 196
Engine oil, grade
________________ 270
Engine oil, volume _______________ 271
Engine temperature gauge
_________ 80
Engine, description
______________ 193
Engine, technical data ____________ 270
Engines
_______________________ 271
Event Data Recorder
____________ 266
Extra electrical socket ____________ 126
FFacilitating entry to rear seat,
Convertible
____________________ 65
Factors affecting fuel consumption
__ 173
Filler cap
______________________ 148
Filling up ______________________ 147
Flat spots, tires
_________________ 232
Floor jack
_____________________ 246
Folding down the rear seat
________ 134
Front fog lights
__________________ 93
Front towing eye ________________ 184
Fuel gauge
_____________________ 81
Fuel grade _____________________ 271
Functions, car alarm
______________ 51
Fuse panel in luggage compartment
_225
Fuse table
_____________________ 224
Fuses
________________________ 222
GGDO, garage door opener
_________ 130
Gear selector indicator, automatic
transmission
___________________ 82
Gearbox number ________________ 278
General safety instructions,
Convertible
____________________ 54
Glove compartment
______________ 126
Glove compartment lighting
________ 219
HHandbrake
_____________________ 167
Hazard warning lights
_____________ 94
Head restraint, Convertible
_________ 66
Head restraints
__________________ 20
Headlight flasher _________________ 92
Headlight levelling ________________ 91
Headlights
______________________ 91
Heated door mirrors
_____________ 102
Hood
_________________________ 192
Horn __________________________ 116
Horn button
____________________ 116
IIf a tire goes flat
_________________ 237
Ignition switch
__________________ 140
Immobilizer
_____________________ 47
ProCarManuals.com

286 IndexPinch protection, sunroof
_________ 122
Plates and labels, location ________ 278
Polishing and waxing
____________ 251
Poly-V-belt
____________________ 205
Position lights ___________________ 91
Power steering fluid, checking
_____ 201
Power steering fluid, grade
________ 273
Pressure gauge
_________________ 80
Pressure, tires
__________________ 231
Profiles, customized settings
_______ 83
QQuality grading, tires
_____________ 235
Quick guide, remote control
________ 41
RRain sensor
_____________________ 96
Raising the soft top manually,
Convertible ____________________ 60
Reading lights, Convertible
_________ 70
Rear fog light
___________________ 93
Rear seats, folding down
_________ 134
Rear towing eye
________________ 185
Rear window heating
____________ 102
Rearview mirrors
________________ 128
Recirculation
___________________ 101
Recommendations for automatic
transmission, towing a trailer
_____ 179Recommendations for manual
gearbox, towing a trailer
_________ 180
Recommended fuel grades ________ 147
Recommended snow chains _______ 275
Refueling
______________________ 147
Remote control
__________________ 40
Remote locking malfunction
________ 42
Replacement, wheel
_____________ 236
Reporting safety defects __________ 265
Rev counter
_____________________ 78
Reversing lights
_________________ 94
Roll bars, Convertible
_____________ 68
Roll-over protection, Convertible
_____ 68
Roof lighting
___________________ 123
Roof lighting, changing
___________ 217
Running-in
_____________________ 151
SSAHR, head restraint
_____________ 20
SDM
_________________________ 266
SID
___________________________ 83
SPA __________________________ 170
Saab Information Display
__________ 83
Saab Parking Assistance _________ 170
Saab Trionic engine management
system
______________________ 194
Safety belts _____________________ 11
Seatbelts
_______________________ 11
Seatbelts in rear seat, Convertible
___ 67
Seatbelts, care
_________________ 248Seatbelts, checking
______________ 248
Seats
__________________________ 16
Securing a load
_________________ 137
Sentronic, manual gear selection
___ 158
Service costs
___________________ 263
Service information
______________ 264
Service intervals
________________ 262
Service record retention
__________ 263
Signalling, horn
_________________ 116
Ski hatch
______________________ 136
Spare wheel ___________________ 243
Speed ratings, tires
______________ 239
Speedometer
____________________ 79
Starting the engine
______________ 142
Steering wheel adjustment
________ 116
Steering wheel lock
______________ 142
Steps for determining correct load
limit
_________________________ 242
Storage compartments
___________ 126
Sun visor
______________________ 124
Sunroof
_______________________ 120
Switches _______________________ 91
TTCS
__________________________ 163
Technical data
__________________ 268
Textile carpeting, cleaning
_________ 249
Tie down eyes
__________________ 137
Tightening torque, wheels
_________ 247
Tire chains
_____________________ 237
ProCarManuals.com
