fuse box SAAB 9-3 2004 Owners Manual

6Engine bayColor code______________ 278
Engine number __________ 278
Gearbox number _________ 278
Warning labels __________ 7
Vehicle identification number 278Alternator ______________ 205
Drive belt _______________ 205
Exhaust emission control __ 145
Ignition system __________ 272
Simple troubleshooting
(A/C, ACC) _____________ 255
Spark plugs _____________ 272
Turbo gauge ____________ 80Engine oil: checking level __ 196Automatic transmission _________ 153
Transmission: technical data _____ 272
Manual transmission ___________ 152
Battery ______________________ 202
Battery charge ________________ 202
Jump starting _________________ 187
Changing engine oil ____________ 197
Engine: description ____________ 193
Engine: technical data __________ 270
Important considerations for driving 144
Oil grade and viscosity__________ 270
Topping-up fluid _________ 206
Wash/wipe stalk switch____ 95
Washer fluid ____________ 206
Washer jets ____________ 207
Power steering ________________ 201
Fluid: checking/topping up _______ 201
Coolant: checking/topping-up ____ 199
Driving in hot climates __________ 177
Radiator _____________________ 270
Temperature gauge ____________ 80
Changing a fuse _________ 222
Fuse table _____________ 227
Fuses _________________ 222
Relays ________________ 227ABS brakes_____________ 160
Brake pads _____________ 200
Brake system ___________ 274
Brake fluid______________ 200
ProCarManuals.com

91 Instruments and controls
SwitchesThe parking lights and daytime running
lights come on automatically when the igni-
tion switch is in the ON position.
High beam can not be activated in this posi-
tion but headlight flasher can.
The parking lights can be turned on irre-
spective of the position of the ignition
switch. If the parking lights are on and the
driver’s door is opened, a reminder to turn
them off will sound.
Do not use the parking lights alone while
driving.
The parking lights may be used in combina-
tion with the front fog lights (see page 93).
Low beam headlights are turned on when
the ignition switch is turned to ON and
turned off when the switch is turned back to
LOCK.
Headlight levelling(cars with Bi-Xenon headlights)
Cars with Bi-Xenon headlights are
equipped with an automatic headlight level-
ling system, with self-calibrates each time
the vehicle is started.
If a fault arises in the automatic headlight
levelling system, the headlights will be
angled down to avoid dazzling drivers in
oncoming traffic. Adjust your speed accord-
ingly as the range of the headlights will be
reduced. Check fuse 20 in the engine bay
fuse box (see page 227).
A fault in the system will produce the follow-
ing message on the Saab Information Dis-
play (SID):
Special equipment is required for adjusting
the basic headlight alignment.
Daytime Running Lights
Parking lights
Headlights
Headlight levelling
malfunction.
Contact Saab dealer.
Light switches
ProCarManuals.com

156 Starting and drivingLimp-homeIf the transmission malfunctions, the control
module will activate limp-home mode. In
this mode, only 2nd and 5th gears are avail-
able. Select 2nd gear when driving at low
speeds and 5th gear at higher speeds. 2nd
gear must be selected manually. Select 5th
gear manually or move the selector lever
to D (see page 158).
The following message is shown on the SID:Temporary override of Park Brake Shift
Lock
1 Apply the parking brake.
2 Lift up the rubber mat in the storage
compartment ahead of the selector
lever.
3 Under the floor of the storage compart-
ment is a yellow plastic lever. Use a thin
tool, such as a screwdriver, to press and
hold the plastic lever while moving the
selector lever from P to N.
4 Remove the tool.
5 Release the parking brake if the car is to
be moved immediately, otherwise it
should remain on.
Check fuse 6 in the engine bay fuse box.
If the fuse is OK the battery may be dead.
Contact a Saab dealer to have the problem
checked and rectified. Gearbox malfunction.
Limited performance.
Contact Saab dealer.
NOTICEDue to electrical problems it may not be
possible to move the selector lever out of
the park position, even if the ignition is
ON. If for some reason the selector lever
has to be moved out of the park position
(i.e. to tow the car a short distance) do as
described below.
Temporary override of Park Brake Shift
Lock
ProCarManuals.com

190 Starting and drivingFor long tripsBefore starting off on a long journey, it is
advisable to have your car inspected by
your Saab dealer.
Obtain a few important items to take along
on your journey, such as spare bulbs, wiper
blades, fuses, a drive belt (poly-V-belt) and
the like.
You can check some points yourself before-
hand:
 Check that no oil or fuel leaks out of the
engine or gearbox/transmission.
 Check the coolant and power steering
fluid levels. Check also for leaks.
 Inspect the drive belt (poly-V-belt) and
replace if it shows any signs of wear.
 Check the battery charge.
 Check the tires for tread pattern and air
pressure, including the compact spare
tire.
 Take an extra remote control and keep it
separate.
 Check the brakes.
 Check all bulbs.
 Check for the presence of the tool kit and
jack in the car.
ProCarManuals.com

195 Car care
1 Oil filler cap
2 Coolant reservoir
3 Brake and clutch fluid reservoir
4Battery
5 Fuse box
6 Washer-fluid reservoir
7 Power-steering fluid reservoir
8 Engine-oil dipstick
Engine bay
ProCarManuals.com

209 Car care
Bi-Xenon headlight, main and dipped beam (certain
variants only)Bi-xenon headlights produce roughly two times as much light as
halogen bulbs and have a significantly longer service life.
The lamp units consist of a gas discharge lamp containing xenon.
When the lights are switched on a very high voltage activates the
xenon gas. The lamps soon reach full intensity.
Cars with Bi-Xenon headlights have automatic levelling. The level-
ling system is comprised of two sensors, one on the front suspen-
sion and one on the rear suspension, and a control unit by the engine
bay fuse box. Headlight alignment is adjusted automatically to the
car’s load to prevent dazzling drivers in oncoming traffic.
If a fault is detected in the system, the following message will be dis-
played on the SID:
WARNING
Bi-Xenon headlights are high tension. All work on Bi-Xenon head-
lights, including changing bulbs, must be carried out by dealer
personnel.
Headlight levelling
malfunction.
Contact Saab dealer.
Contact a Saab dealer to have a Bi-Xenon
headlight changed
ProCarManuals.com

210 Car careLow beam, halogenLeft-hand side
1 Lift aside the hose running along the side of the battery cover.
2 Release the two retainers (a quarter of a turn counterclockwise)
in the leading edge of the cover and remove the cover.
3 Pull up the washer fluid filler pipe.
4 Remove the air pipe from the front edge of the battery box.
5 Pull up the fuse panel in front of the battery (certain variants),
see page 228.
Both sides
1 Remove the cover from the rear of the headlight.
2 Twist the bulb holder counterclockwise and withdraw the holder
from the reflector.
3 Change the bulb without touching the glass with your fingers.
Insert the bulb holder into the reflector and twist it clockwise until
it locks.4 Refit the cover over the rear of the headlight.
Left-hand side
5 Refit the air pipe to the front of the battery box.
6 Refit the washer fluid filler pipe.
7 Refit the battery cover.
NOTICEDo not fit bulbs with a higher rating than 55 W as this could
damage the headlight reflector. Furthermore, the car’s wiring is
not designed to cope with higher wattages.
Retainers on the battery cover Changing the low beam bulb
ProCarManuals.com

211 Car care
High beam, halogenLeft-hand side
1 Lift aside the hose running along the side of the battery cover.
2 Release the two retainers (a quarter of a turn counterclockwise)
in the leading edge of the cover and remove the cover.
3 Pull up the washer fluid filler pipe.
4 Remove the air pipe from the front edge of the battery box.
5 Pull up the fuse panel in front of the battery (certain variants),
see page 228.
Both sides
1 Remove the cover from the rear of the headlight.
2 Twist the bulb holder counterclockwise and withdraw the holder
from the reflector.
3 Change the bulb without touching the glass with your fingers.
Insert the bulb holder into the reflector and twist it clockwise until
it locks.4 Refit the cover over the rear of the headlight.
Left-hand side
5 Refit the air pipe to the front of the battery box.
6 Refit the washer fluid filler pipe.
7 Refit the battery cover.
NOTICEDo not fit bulbs with a higher rating than 55 W as this could
damage the headlight reflector. Furthermore, the car’s wiring is
not designed to cope with higher wattages.
Retainers on the battery cover Changing the high beam bulb
ProCarManuals.com

284 IndexDriving in cold climates
___________ 175
Driving in deep water
____________ 183
Driving in hot climates ____________ 177
Driving techniques
______________ 173
Driving with a heavy load on hilly
roads
________________________ 155
Driving with a load
______________ 183
Driving with a roof load ___________ 182
Driving with the compact spare wheel
187
Driving with the trunk lid open
______ 183
EEDR
_________________________ 266
ESP, anti-skid system
____________ 165
Easy entry, Convertible ____________ 65
Economical motoring
____________ 173
Electric engine heater ____________ 174
Electric heating, front seats
___ 102
, 111
Electric windows
________________ 117
Electric windows, Convertible
_______ 69
Electrical system, technical data ____ 272
Electrically adjustable seats
________ 18
Electronic Stability Program (ESP)
__ 165
Electronic steering wheel lock
_____ 142
Emergency opening of the narrow
backrest
_____________________ 138
Emergency operation of the sunroof
_ 122
Engine bay, cleaning
____________ 249
Engine heater
__________________ 174
Engine immobilizer
_______________ 47Engine number
_________________ 278
Engine oil, checking
_____________ 196
Engine oil, grade
________________ 270
Engine oil, volume _______________ 271
Engine temperature gauge
_________ 80
Engine, description
______________ 193
Engine, technical data ____________ 270
Engines
_______________________ 271
Event Data Recorder
____________ 266
Extra electrical socket ____________ 126
FFacilitating entry to rear seat,
Convertible
____________________ 65
Factors affecting fuel consumption
__ 173
Filler cap
______________________ 148
Filling up ______________________ 147
Flat spots, tires
_________________ 232
Floor jack
_____________________ 246
Folding down the rear seat
________ 134
Front fog lights
__________________ 93
Front towing eye ________________ 184
Fuel gauge
_____________________ 81
Fuel grade _____________________ 271
Functions, car alarm
______________ 51
Fuse panel in luggage compartment
_225
Fuse table
_____________________ 224
Fuses
________________________ 222
GGDO, garage door opener
_________ 130
Gear selector indicator, automatic
transmission
___________________ 82
Gearbox number ________________ 278
General safety instructions,
Convertible
____________________ 54
Glove compartment
______________ 126
Glove compartment lighting
________ 219
HHandbrake
_____________________ 167
Hazard warning lights
_____________ 94
Head restraint, Convertible
_________ 66
Head restraints
__________________ 20
Headlight flasher _________________ 92
Headlight levelling ________________ 91
Headlights
______________________ 91
Heated door mirrors
_____________ 102
Hood
_________________________ 192
Horn __________________________ 116
Horn button
____________________ 116
IIf a tire goes flat
_________________ 237
Ignition switch
__________________ 140
Immobilizer
_____________________ 47
ProCarManuals.com

285 Index
Important considerations for driving
_ 144
Important information, petrol-engined
cars with catalytic converters
_____ 145
Indicator lights
___________________ 74
Inflation, tires __________________ 231
Instrument illumination, adjusting
____ 92
Interior lighting
_________________ 123
Interior lighting, Convertible
________ 70
Interior rearview mirror
___________ 129
Intermittent malfunctioning, central
locking
_______________________ 42
JJump starting
__________________ 187
KKey
___________________________ 40
Kick-down
_____________________ 155
LLATCH (child safety)
______________ 22
Labeling, tire sidewall ____________ 238
Labels and plates, location
________ 278
Lashing eyes
___________________ 137
Laying the car up
_______________ 169
Leather upholstery, cleaning
_______ 249Lighting in luggage compartment,
Convertible
____________________ 70
Limp-home
____________________ 144
Limp-home, automatic transmission
_156
Load carriers, roof
_______________ 182
Load indices, tires _______________ 239
Loading your vehicle _____________ 240
Load-through hatch ______________ 136
Locking a car with flat battery
_______ 43
Locks
__________________________ 40
Long-term parking
_______________ 169
Luggage compartment
___________ 134
Luggage compartment lighting
_ 124
, 138
Luggage compartment lighting,
Convertible
____________________ 70
Luggage compartment lighting,
changing
_____________________ 219
MMAXI fuses
____________________ 223
Main instrument panel
_____________ 74
Main/dipped beam
_______________ 92
Maintenance schedule ___________ 262
Manual climate control ____________ 98
Manual gear selection ____________ 158
Manual gearbox
________________ 152
Manual tripping of car alarm
________ 50
Materials used in the car, reclamation
255
Memory, driver’s seat
_____________ 19
Messages on SID, Convertible
______ 63Milometer
_______________________ 79
Mug holder ____________________ 124
NNew tires, buying
________________ 233
Night driving
___________________ 184
Number plate lighting, changing
____ 219
OORVR
________________________ 194
Oil capacity, engine
______________ 271
Opening handles
_________________ 40
Opening the soft top, Convertible
____ 56
Outside mirrors
_________________ 128
Owner assistance _______________ 264
PPanic function, car alarm
___________ 50
Park Brake Shift Lock
____________ 154
Park Brake Shift Lock, temporary
override
______________________ 156
Parking
_______________________ 167
Parking aid ____________________ 170
Parking brake __________________ 167
Parking on a hill _________________ 168
Pinch protection, electric windows
__ 118
ProCarManuals.com
