washer fluid SAAB 9-3 2004 Owners Manual

3
Instrument panelChanging bulbs __________ 208
Front fog lights___________ 93
Headlight levelling ________ 91
High/low beam __________ 92
Parking lights____________ 91
Rear fog light ____________ 93Cruise Control ___________ 159
Direction indicators _______ 93
High/low beam control stalk 92
Fuel gauge __________________ 81
Odometer and trip meter ________ 79
Speedometer ________________ 79
Tachometer __________________ 78
Temperature gauge ____________ 80
Turbo gauge _________________ 80
Warning and indicator lights _____ 74Ashtray _____________________ 126
Cigarette lighter _______________ 126
Clock _______________________ 88
Profiler ______________________ 83
Saab Information Display (SID) ___ 83
Replacing wiper blades ___ 206
Washers and wipers ______ 95
Washer fluid ____________ 206Automatic climate control __ 103
Car care and maintenance _ 255
Hazard warning lights_____ 94
Manual climate control ____ 98
Seat heating ____________ 102
Seat heating, ACC _______ 111
ProCarManuals.com

6Engine bayColor code______________ 278
Engine number __________ 278
Gearbox number _________ 278
Warning labels __________ 7
Vehicle identification number 278Alternator ______________ 205
Drive belt _______________ 205
Exhaust emission control __ 145
Ignition system __________ 272
Simple troubleshooting
(A/C, ACC) _____________ 255
Spark plugs _____________ 272
Turbo gauge ____________ 80Engine oil: checking level __ 196Automatic transmission _________ 153
Transmission: technical data _____ 272
Manual transmission ___________ 152
Battery ______________________ 202
Battery charge ________________ 202
Jump starting _________________ 187
Changing engine oil ____________ 197
Engine: description ____________ 193
Engine: technical data __________ 270
Important considerations for driving 144
Oil grade and viscosity__________ 270
Topping-up fluid _________ 206
Wash/wipe stalk switch____ 95
Washer fluid ____________ 206
Washer jets ____________ 207
Power steering ________________ 201
Fluid: checking/topping up _______ 201
Coolant: checking/topping-up ____ 199
Driving in hot climates __________ 177
Radiator _____________________ 270
Temperature gauge ____________ 80
Changing a fuse _________ 222
Fuse table _____________ 227
Fuses _________________ 222
Relays ________________ 227ABS brakes_____________ 160
Brake pads _____________ 200
Brake system ___________ 274
Brake fluid______________ 200
ProCarManuals.com

95 Instruments and controls
Wipers and washersWindshield wipersPosition 1 is a spring-loaded position that
will produce a single sweep of the wipers.
In position 2 you can set the delay period for
intermittent wiping using the thumbwheel on
the stalk switch. There are 5 delay periods
from which to choose, ranging from 2 to
15 seconds.
The wipers always return to their home posi-
tion when the ignition is turned off.
To leave the wipers positioned vertically on
the windshield, proceed as follows:
1 Switch off the engine and remove the
remote control.
2 Activate the wipers within the next
16 seconds by pressing the stalk switch
down.
When the ignition is next switched on the
wipers will return to their home position.
WashersActivate the washers by pulling the stalk
switch towards the steering wheel.
When the washers are operated, the wipers
will make 3, 4 or 5 sweeps, depending on
how long the washers were kept on. If
the speed of the car is less than 12 mph
(20 km/h), the wipers will make an addi-
tional sweep after roughly 8 seconds.
When the washer fluid level drops below
1 quart (1 litre), the headlight washers are
deactivated. This is in order to prioritize the
windshield. The following message is dis-
played on the SID:
To prevent the smell of washer fluid from
entering the car, recirculation can be acti-
vated automatically while the windshield is
washed. The recirculation symbol will how-
ever not light up. This function is optional;
contact a Saab dealer. This automatic recir-
culation is the factory default setting as long
as the system is working in full "AUTO"
mode with no customized settings.
Headlight washers (certain variants
only)The headlights are washed at the same time
as the windshield if the headlights are on.
The headlights are washed every fifth time
the windshield washers are used or if two
(2) minutes have elapsed since the wind-
shield was last washed.
The headlight washers are not activated at
speeds in excess of 125 mph (200 km/h). Washer fluid level low.
Refill.Windshield wipers0OFF
1 Single sweep
2 Intermittent wiping
3 Low speed
4 High speed
5 Windshield and headlight washing (certain
variants only)
ProCarManuals.com

111 Instruments and controls
The seat cushions and backrests of the front
seats are heated.
Heating is thermostatically controlled.
Heating is controlled manually but can also
be automatic. Refer to Profiler on page 112.
Three heating levels are available. Pressing
the button once will turn the heating on at full
power. Pressing the button a total of 4 times
will turn the heating off.
 = full.
 = medium.
 = low.
CalibrationCalibration is performed automatically
every fifth time the car is started after having
been switched off for more than 2 hours or
if the battery has been disconnected.ProgrammingA number of functions can be customized
under Profiler (see page 112). Further cus-
tomizations can be made at a Saab dealer.Tips(before contacting a Saab workshop)
 If you feel that the ACC system is not func-
tioning satisfactorily, select "Default
Settings" under Profiler (see page 112.
 To prevent the smell of washer fluid from
entering the car, recirculation can be acti-
vated automatically while the windshield
is washed. The recirculation symbol will
however not light up. This function is
optional; contact a Saab dealer. This
automatic recirculation is the factory
default setting as long as the system is
working in full "AUTO" model with no
customized settings.
Electric heating, front
seats (option)
ProCarManuals.com

169 Starting and driving
Long-term parkingIf the car is not going to be used for some
time, e.g. three to four months, the following
steps are recommended:
 Drain the washer fluid reservoir and
hoses.
 Wash and wax the car. Clean the rubber
seals on the hood, trunk lid and doors,
and lubricate them with glycerol
(glycerine).
 After washing the car, dry the brake discs
to avoid corrosion by taking the car out on
the road and applying the brakes a few
times.
 Fill the fuel tank to prevent condensation
forming in it.
 Top up the coolant and check the anti-
freeze before the onset of winter. Park the car in a dry, covered and well-
ventilated building. Leave the parking
brake OFF!
Convertible: If the car is stored, the soft
top should be closed.
 If necessary, use wheel chocks and leave
the parking brake off.
 Disconnect the negative (–) battery lead.
If frost is likely to occur during the storage
period, remove the battery and store it in
a frost-free place.
 If it is not possible to stand the car on axle
stands, increase the tire pressure to
43 psi (3 bar).
Leave all the door windows open a crack
and cover the car with a non-plastic
tarpaulin – not one made of plastic which will
not breath.
ProCarManuals.com

191 Car care
Hood ________________ 192
Engine ______________ 193
Engine bay ___________ 195
Engine oil ____________ 196
Air filter______________ 198
Transmission fluid ____ 198
Coolant ______________ 199
Brake/clutch fluid and
brake pads__________ 200
Power steering________ 201
Battery ______________ 202
Drive belt ____________ 205
Wipers and washers ___ 206
Wiper blades _________ 206
Changing bulbs _______ 208 Fuses ________________ 222
Automatic tire pressure
monitoring __________ 229
Tires _________________ 231
Compact spare tire _____ 243
Changing a tire ________ 245
Safety belts ___________ 248
Upholstery and trim ____ 249
Textile carpeting _______ 249
Engine bay ____________ 249
Washing ______________ 250
Waxing and polishing ___ 251
Touching up the paint___ 251
Anti-corrosion treatment 253
Recovery and/or
recycling of automotive
materials ____________ 255
Air conditioning (A/C) ___ 255
Car care
ProCarManuals.com

195 Car care
1 Oil filler cap
2 Coolant reservoir
3 Brake and clutch fluid reservoir
4Battery
5 Fuse box
6 Washer-fluid reservoir
7 Power-steering fluid reservoir
8 Engine-oil dipstick
Engine bay
ProCarManuals.com

206 Car careWipers and washersWiper bladesCheck and clean all wiper blades regularly.
If poor wiper performance is experienced,
clean the windshield with washer fluid. This
is particularly important if the car has been
through an automatic car wash, as these
sometimes leave a wax coating on the wind-
shield.
If wiper performance is still unsatisfactory,
fit new blades.
To fit new blades:
1 Press in the catch (1).
2 Pull the complete wiper blade down-
wards so that it comes away from the
wiper arm. Slide the entire blade out
from the arm.
WashersThe reservoir capacity is 6.5 qts. (6.2 litres).
WARNING
Take care not to spill washer fluid concen-
trate onto hot surfaces. Washer fluid
concentrate can contain flammable ingre-
dients such as alcohol.Washer fluid reservoir Change of wiper blades
ProCarManuals.com

207 Car care
When the washer fluid level drops below
1 quart (1 litre), the headlight washers are
deactivated. This is in order to prioritize the
windshield. The following message is
displayed on the SID:
Headlight washers are only available on
certain markets.
Fill with a mixture of washer fluid and water
as recommended by the table on
the packaging to reduce the risk of freezing
and to ensure effective cleaning (see also
page 95).
To prevent the smell of washer fluid from
entering the car, recirculation can be acti-
vated automatically while the windshield is
washed. The recirculation symbol will how-
ever not light up. This function is optional;
contact a Saab dealer.
Washer jetsThe washer jets, which are adjustable, can
be cleaned with a pin if necessary. Washer fluid level low.
Refill.
ProCarManuals.com

210 Car careLow beam, halogenLeft-hand side
1 Lift aside the hose running along the side of the battery cover.
2 Release the two retainers (a quarter of a turn counterclockwise)
in the leading edge of the cover and remove the cover.
3 Pull up the washer fluid filler pipe.
4 Remove the air pipe from the front edge of the battery box.
5 Pull up the fuse panel in front of the battery (certain variants),
see page 228.
Both sides
1 Remove the cover from the rear of the headlight.
2 Twist the bulb holder counterclockwise and withdraw the holder
from the reflector.
3 Change the bulb without touching the glass with your fingers.
Insert the bulb holder into the reflector and twist it clockwise until
it locks.4 Refit the cover over the rear of the headlight.
Left-hand side
5 Refit the air pipe to the front of the battery box.
6 Refit the washer fluid filler pipe.
7 Refit the battery cover.
NOTICEDo not fit bulbs with a higher rating than 55 W as this could
damage the headlight reflector. Furthermore, the car’s wiring is
not designed to cope with higher wattages.
Retainers on the battery cover Changing the low beam bulb
ProCarManuals.com
