relay SAAB 9-3 2005 Owners Manual

6Engine bayColor code______________ 278
Engine number __________ 278
Gearbox number _________ 278
Warning labels __________ 7
Vehicle identification number 278Alternator ______________ 210
Drive belt _______________ 210
Exhaust emission control __ 151
Ignition system __________ 272
Simple troubleshooting
(A/C, ACC) _____________ 257
Spark plugs _____________ 272
Turbo gauge ____________ 84Engine oil: checking level __ 202Automatic transmission _________ 159
Transmission: technical data _____ 272
Manual transmission ___________ 158
Battery ______________________ 208
Battery charge ________________ 208
Jump starting _________________ 193
Changing engine oil ____________ 203
Engine: description ____________ 199
Engine: technical data __________ 270
Important considerations for driving 150
Oil grade and viscosity__________ 270
Topping-up fluid _________ 211
Wash/wipe stalk switch____ 100
Washer fluid ____________ 211
Washer jets ____________ 212
Power steering ________________ 207
Fluid: checking/topping up _______ 207
Coolant: checking/topping-up ____ 205
Driving in hot climates __________ 183
Radiator _____________________ 270
Temperature gauge ____________ 84
Changing a fuse _________ 227
Fuse table _____________ 232
Fuses _________________ 227
Relays ________________ 232ABS brakes_____________ 166
Brake pads _____________ 206
Brake system ___________ 274
Brake fluid______________ 206
ProCarManuals.com

228 Car careA special tool for removing fuses is provided
on the hatch on the left-hand end of the
dash. Simply push the tool onto the fuse,
squeeze and remove the fuse.Some fuses and relays may be fitted but not
connected to the car’s electrical system.
MAXI fusesThe car also has a number of large fuses
known as MAXI fuses. These are designed
to protect the car’s electrical system from
being damaged. Each MAXI fuse protects a
number of electrical circuits and functions
and therefore has a higher rating (amper-
age) than the standard fuses. No spare
MAXI fuses are supplied with the car.NOTICEIf a MAXI fuse blows, there is a major fault
in the electrical system. Have the car
checked at a Saab dealer.
Fuse panel in end of dash
ProCarManuals.com

233 Car care
Fuse panel in front of battery
Relays
R 1 Washer fluid pump, windshield
R2 -
R3 -
R4 -
R 5 Flash-to-pass
R6 Horn
R7 -
R8 Starter motor
R 9 Windshield wipers ON/OFF
R10 -
R11 Ignition +15
R12 Windshield wipers, high/low speed
R13 -
R14 Washer fluid pump, headlights
R15 -
R16 -
No. Amp. Function
1--
2 20 Fuel pump; preheated oxygen sensors (lambda
probe)
310A/C compressor
430Main relay
Relays
1-
2 A/C-compressor
3 Preheated oxygen sensors (lambda probe)
4 Main relay, engine (ECM/EVAP/injectors)
