SAAB 9-5 2004 Owners Manual

281 Specifications
1 Region ___________Y = Northern Europe
2 Country __________S = Sweden
3 Manufacturer _____3 = Saab Automobile AB
4 Product line ______E = 9-5
5 Model series ______B = 9-5 Linear with driver’s and
passenger-side airbags
D = 9-5 Arc with driver’s and
passenger-side airbags
H = 9-5 Aero with driver’s and
passenger-side airbags
6 Body version _____4 =
5 =4-door
5-door
7 Gearbox __________5 = Manual 5-speed
9 = Automatic 5-speed8 Engine variant _____A =
E =
G =2.3T
2.3t
2.3 Turbo
9 Check digit ________0–9/X
10 Model year ________4 = 2004
11 Factory ___________3 = Trollhättan
12 Serial number ______000001–999999 position:1234567891011 12
||||||||||| |
V.I.N.:YS3EF4 9E64 3045842
| | ||||
1 2 3456= identification codes for certain chassis details
IB1917
ProCarManuals.com

282 SpecificationsSeveral of the systems in your Saab
car can be adjusted to better fit your
individual needsSome functions are governed by legal
requirements and cannot therefore be
reprogrammed.
Consult an authorized Saab dealer for fur-
ther information.
Car alarm/central locking system:
 The sound level of the siren when locking/
unlocking, HIGH or LOW.
 The number of blinks when locking/
unlocking, 1 to 7.
 Automatic locking of the trunk when the
car is driven, 1 to 8 mph (2–14 km/h), YES
or NO.
 Preclude the unlocking of the trunk while
the car is driven, YES or NO.
 Automatic locking of the trunk after
1 second–4 minutes if it has not been
opened, YES or NO.
 Automatic locking of the trunk when it is
closed, YES or NO.
 Automatic locking of all doors when the
car is driven above 7.5 mph (12 km/h),
YES or NO.Saab Information Display:
 Outdoor temperature display can be
adjusted.
Miscellaneous:
 Select the on-time for heated rear seat.
 Coolant temperature gauge adjustment
can be increased/decreased.
 Fuel level gauge adjustment can be
increased/decreased.
 Additional sweep of the wipers after wind-
shield washer function (ON or OFF).
 Follow me home on-time can vary from 20
to 50 seconds.
 Night panel illumination deactivation
speed for the speedometer can be
adjusted.
Following adjustments can be done
by the driver:Automatic Climate Control (ACC):
To alter the preprogrammed ”AUTO” start
up mode with your own preferences you can
manually select the desired settings for:
 Temperature.
 Fan speed.
Air distribution.
See ”Programming I” on page 81 and ”Pro-
gramming II” on page 82.
Saab 9-5 Audio System (see page 101):
 Maximum starting volume (when the
radio is switched on).
 Telephone volume (if the car is equipped
with a phone connected to the audio sys-
tem).
 Speed dependent volume (volume
increases or decreases with vehicle
speed).
 Loudness.
Daytime Running Lights:
To disable, turn off the ignition and pull out
fuse 35, see page 229.
ProCarManuals.com

283 Index
Index
AA/C system, fault diagnosis
_______ 252
A/C system, maintenance
_________ 252
ABS brakes
____________________ 168
ACC
__________________________ 75
ACC functions
___________________ 78
ACC, automatic climate control
_____ 75
ACC, calibration
_________________ 83
ACC, condensation _______________ 84
ACC, programming _______________ 81
ACC, useful tips
_________________ 83
Adjusting the steering wheel
_______ 120
Adjustment, seats
________________ 12
Air conditioning (A/C), fault diagnosis
and maintenance ______________ 252
Air distribution, ACC ______________ 80
Airbag
_________________________ 31
Alarm _________________________ 46
Alarm functions
__________________ 49
Alarm signals
________________ 46
, 49
Alternator
_____________________ 212
Alternator drive belt
__________ 212
, 275
Alternator rating
________________ 275
Anticorrosion treatment
___________ 256
Antidazzle rear-view mirror
________ 125
Ashtrays
______________________ 131
Audio System
___________________ 85
Audio System, quick guide
_________ 87
Autochecking of lights on starting
____ 60Automatic climate control (ACC)
_____ 75
Automatic transmission, technical
data
_________________________ 276
Aviod theft, tip
__________________ 197
BBattery
________________________ 210
Battery charging/replacing
________ 211
Battery, boost starting
____________ 191
Before a long journey ____________ 258
Before towing a camper or trailer
___ 181
Belt guide
______________________ 17
Boost starting using jump leads
____ 191
Brake and clutch fluid
____________ 208
Brake-fluid reservoir
_____________ 208
Brakes, technical data ____________ 277
Bulbs, changing
________________ 215
Bulbs, table of
__________________ 226
Buying new tires ________________ 235
CCD changer
_____________________ 97
CD player
______________________ 95
CHECK messages
_______________ 67
CHECKING
_____________________ 67
Calibration, ACC
_________________ 83
Cancelling the programmed settings
_81
Car alarm
______________________ 46
Car care
______________________ 199
Cargo net, 9-5 Wagon
____________ 142Carpeting, care of
_______________ 253
Cassette player
__________________ 92
Catalytic converter, important
considerations _________________ 152
Central locking ___________________ 40
Change language in SID
___________ 68
Change of address notification
_____ 266
Changing a wheel
_______________ 247
Changing bulbs
_________________ 215
Changing wiper blades
___________ 213
Charger/Jump starting ____________ 193
Charging the battery/Jump starting
__ 193
Chassis number
________________ 280
Chassis number, key to
___________ 281
Checks before towing a camper or
trailer
________________________ 181
Child safety
_____________________ 23
Child safety locks, rear doors
_______ 43
Cleaning, engine bay
_____________ 255
Clock
_______________________ 67
, 68
Color code, body
________________ 280
Color code, trim _________________ 280
Compact spare wheel
____________ 246
Compass
______________________ 126
Condensation, ACC
_______________ 84
Coolant
_______________________ 207
Courtesy Headlight Feature
________ 70
Cruise control
__________________ 167
Cup holder
_____________________ 134
ProCarManuals.com

284 IndexDDICE/TWICE
___________________ 228
Dampers
______________________ 277
Date code, tires
_________________ 245
Definitions and terminology, tire
____ 242
Determining correct load, tires
_____ 244
Dim-dipped beam
________________ 69
Direction indicators _______________ 71
Door handles
___________________ 40
Door mirrors
___________________ 121
Doors, locks & luggage compartment
_39
Drive belt
______________________ 275
Drive belt, alternator
_____________ 212
Drive belts, length
_______________ 275
Driver’s seat, programmable
________ 14
Driving at night
_________________ 185
Driving in hot weather
____________ 177
Driving with a load
______________ 185
EEDR
_________________________ 267
ESP __________________________ 172
Electric heating seat
______________ 15
Electric heating, front seats
________ 15
Electric windows
________________ 127
Electrical system, technical data
____ 275
Electronic Stability Program, ESP __ 172
Electronic starting interlock
_________ 41
Emergency operation of sunroof
____ 129
Emission control systems
_________ 202Engine bay
____________________ 201
Engine bay, cleaning
_____________ 255
Engine number
_________________ 280
Engine oil, grade ________________ 273
Engine, description ______________ 203
Engine, technical data ____________ 272
Engine, temperature gauge
________ 61
Engine-oil level, checking
_________ 204
Event Data Recorder
____________ 267
Expansion tank, coolant __________ 207
FFault codes, Audio System
________ 106
Flat spots, tires
_________________ 234
Fluid level, automatic transmission
__ 206
Folding the rear seat, 9-5 Sedan
___ 135
Folding the rear seat, 9-5 Wagon ___ 138
Frequently asked questions on airbag

37
Front fog lights
__________________ 72
Frost warning
___________________ 64
Fuel
__________________________ 154
Fuel consumption
________________ 63
Fuel filler door
__________________ 146
Fuel gauge
_____________________ 61
Fuel grade _____________________ 272
Fuse box under hood
____________ 231
Fuse panel
____________________ 227
Fuses
________________________ 227
GGarage door opener
_____________ 122
Gearbox number
________________ 280
Gearbox oil, checking
____________ 206
Gearbox, technical data, __________ 276
Glove compartment
______________ 132
HHandbrake
_____________________ 196
Hazard warning lights
_____________ 72
Head restraint
___________________ 16
Headlight flasher _________________ 69
Headlights
______________________ 69
Hood
_________________________ 200
Horn __________________________ 120
IIf a tire goes flat
_________________ 239
Ignition switch
__________________ 148
Immobilizer
_____________________ 41
Indicator and warning lights
_________ 54
Indicator lights
___________________ 54
Instrument illumination
____________ 71
Instruments and controls ___________ 53
Interior equipment
_______________ 119
Interior lighting
__________________ 130
Interior rearview mirror
___________ 121
ProCarManuals.com

285 Index
JJack
_________________________ 249
KKey
___________________________ 40
Key to chassis number
___________ 281
Key, remove
___________________ 148
LLATCH (child safety)
______________ 24
Labeling, tire sidewall ____________ 240
Labels
__________________________ 7
Leather upholstery, care of
________ 253
Light horn
______________________ 69
Light switches ___________________ 69
Loading your vehicle
_____________ 242
Luggage-compartment lighting
_____ 130
MMain instrument panel
____________ 54
Main/dipped beam
_______________ 69
Maintenance schedule ___________ 264
Maintenance, A/C-system _________ 252
Manual gearbox, technical data
____ 276
Maxi fuses
_____________________ 228
Milometer ______________________ 60
Motoring abroad
________________ 258
NNew tires, buying
_______________ 235
Night Panel
_____________________ 67
OOil capacity, engine
______________ 272
Oil change, engine ______________ 204
Oil specification
_________________ 272
OnStar
________________________ 107
Outdoor temperature
______________ 63
Owner assistance
_______________ 265
PPaintwork, touching-in
____________ 255
Parking Assistance
______________ 194
Parking lights
___________________ 69
Plates and labels ________________ 280
Poly-V-belt
____________________ 212
Power steering _________________ 209
Power-steering fluid
_____________ 209
Pressure gauge
__________________ 62
Programming I, ACC
______________ 81
Programming II, ACC _____________ 82
Programming the ACC ____________ 81
QQuality grading, tires
_____________ 237
Questions on function of airbag
______ 37
Quick guide, Audio System
_________ 87
RRadiator fan
____________________ 212
Radio
__________________________ 90
Rain sensor
_____________________ 73
Rear fog light ____________________ 70
Rear seat, 9-5 Sedan, folding
______ 135
Rear seat, 9-5 Wagon, folding ______ 138
Rear-seat head restraints
__________ 16
Rear-view mirror, antidazzle _______ 125
Rearview mirrors
________________ 121
Reclamation
___________________ 258
Recommendations for cars with
automatic transmission, towing a
camper or trailer
_______________ 179
Refuelling
_____________________ 154
Relay panel ____________________ 230
Remote control __________________ 40
Remote-control battery, changing
____ 43
Remove the key
________________ 148
Replacement, wheel _____________ 238
Reporting safety defects __________ 266
Reprogramming of systems _______ 282
Reservoir, power-steering fluid _____ 209
Rev counter
_____________________ 60
Reversing lights
__________________ 72
ProCarManuals.com

286 IndexRoof load
_____________________ 183
Running-in ____________________ 174
SSDM
_________________________ 267
SID
___________________________ 63
Saab 9-5 Audio System
___________ 85
Saab Information Display (SID)
_____ 63
Saab Parking Assistance
_________ 194
Safety belts
_____________________ 17
Safety belts, care of
_____________ 253
Safety-belt pretensioners
__________ 18
Safety-belt reminder
______________ 17
Seats
__________________________ 12
Securing a load
__________________ 44
Selector lever indication, automatic
transmission
___________________ 63
Sentronic, manual mode
__________ 163
Service costs
__________________ 265
Service information
______________ 266
Service intervals
________________ 264
Service record retention
__________ 265
Settings, seats
__________________ 12
Side airbags
____________________ 35
Signalling, horn _________________ 120
Sliding floor, 9-5 Wagon
__________ 143
Snow chains
___________________ 176
Spare wheel ___________________ 246
Spare wheel and tools
___________ 145
Spark plugs
____________________ 275
Speedometer ________________ 60
, 61Starting in cold weather, ACC
_______ 81
Starting in hot weather, ACC _______ 81
Steering wheel adjustment
________ 120
Steering, technical data
__________ 277
Steps for determining correct load
limit
_________________________ 244
Stone-chip damage, repairing
______ 255
Storage compartments
___________ 132
Sun visors
_____________________ 131
Sunroof
_______________________ 128
Suspension ____________________ 277
Suspension, technical data
________ 277
Switches
_______________________ 69
Symboler ________________________ 9
Systems, adjustment
_____________ 282
TTCS OFF
_______________________ 59
Table of fuses
__________________ 229
Tachometer
_____________________ 60
Tailgate, opening
________________ 44
Tank gauge
_____________________ 61
Technical data __________________ 269
Telematics
_____________________ 107
Temperature control, ACC
_________ 77
Temperature gauge, engine ________ 61
Temperature zones, ACC
__________ 77
Textile carpeting
________________ 253
Through-load hatch ______________ 137
Tie Downs
_____________________ 137
Tightening torque, wheel studs
_____ 247Tip, driving at night
______________ 185
Tip, to avoid theft
________________ 197
Tire chains
_____________________ 239
Tire date code __________________ 245
Tire inspection and rotation
________ 234
Tire markings
___________________ 241
Tire pressure ___________________ 186
Tire sidewall labeling
_____________ 240
Tire terminology and definitions
____ 242
Tire, compact spare
______________ 246
Tires
_____________________ 233
, 278
Tires, winter
____________________ 278
Tools
_________________________ 145
Touching-in the paintwork
_________ 255
Towbar attachment
______________ 178
Towbar load
____________________ 182
Towing the car __________________ 188
Towing, automatics
______________ 188
Traction
_______________________ 171
Trailer weights
__________________ 271
Treadwear indicators
_____________ 235
Trionic
________________________ 202
Trip computer
___________________ 63
Trip meter
______________________ 60
Trunk
_________________________ 135
Trunk lid, opening
________________ 44
Turbo gauge
____________________ 62
Turbo, points to note
_____________ 151
ProCarManuals.com

287 Index
UUnder the hood
_________________ 201
Uniform tire quality grading
________ 237
Upholstery and trim
______________ 253
Upholstery and trim, care of
_______ 253
Useful tips, ACC
_________________ 83
VVanity mirrors
__________________ 131
Vehicle Data Collection
___________ 267
Ventilated front seats
_____________ 15
Viscosity, engine oil
_____________ 272
WWarning labels
___________________ 7
Warning light, AIR BAG
___________ 36
Warning lights
___________________ 54
Washers
______________________ 213
Washers, windshield
_____________ 214
Washing the car
________________ 254
Waxing and polishing
____________ 255
Wear indicators, tires ____________ 235
Wheel replacement
______________ 238
Wheel, change
_________________ 247
Wheels and tires ________________ 278
Wheels and tires, sizes
___________ 278
When it is time for new tires
_______ 235
Windshield washers
______________ 73
Windshield wipers
________________ 73
Winter tires
________________ 244
, 278
Wiper blades, replacing
__________ 213
Wipers and washers
__________ 73
, 213
ProCarManuals.com

288 IndexNotes
ProCarManuals.com
