SAAB 9-5 2006 Owners Manual

261 Specifications
Trailer:
Luggage compartment
Volume (SAE):
9-5 Sedan _______________________ 15.9 cu.ft.
(450 litres)
9-5 SportCombi, rear seat upright ____ 31.4 cu. ft.
(890 litres)
9-5 SportCombi, rear seat folded _____ 73.0 cu. ft.
(2067 litres)
Luggage compartment, length, 9-5 Sedan:
Rear seat upright _________________ 43.0 in (1092 mm)
Rear seat folded down _____________ 67.5 in (1714 mm)
Luggage compartment, length,
9-5 SportCombi:
Rear seat upright _________________ 42.8 in (1087 mm)
Rear seat folded __________________ 68.2 in (1732 mm)
WARNING
 The GVW and maximum axle loads must not be exceeded.
Note that if some accessories (e.g. towbar, CD changer) are
fitted, the available load capacity is reduced by the weight of
these.
 When carrying a load in the luggage compartment, make sure
that it is tied down securely, particularly when part or all of the
rear seat is folded down.
Maximum towing speed, trailer with brakes 60 mph (100 km/h)
Trailer with brakes _________________ Maximum weight:
3500 lbs (1588 kg)
Trailer without brakes ______________ Maximum weight:
1000 lbs (450 kg)
Maximum load on ball hitch __________ 110–165 lbs
(50–75 kg)
The above speed and weight restrictions are those specified by
Saab Automobile AB.
Note that local restrictions may apply to trailer speeds and weights
(see page 176).
95usM06.book Page 261 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

262 SpecificationsEngine
Fuel
4-cylinder ________________________ Four cylinders, twin
overhead cam-
shafts, 16 valves
and two balancer
shafts.
Cylinder bores _____________________ 3.54 in (90 mm)
Stroke ___________________________ 3.54 in (90 mm)
Swept volume _____________________ 139.7 cu.in
(2.290 litres)
Idling speed _______________________ 825 rpm (man.)
860 rpm (aut.)
Antifreeze_________________________ Saab-approved
antifreeze
Coolant capacity ___________________ 7.8 qts (7.4 litres)Fuel-tank capacity ____________ 18.5 gal. (70 litres)
For optimum performance Saab
recommends:_________________
AON93*
* If AON 90 is used some decrease in engine power can occur.
Gasoline with a lower octane rating can be used, although not
lower than AON 87. However, engine performance will fall slightly
and heavy loading and laboring should be avoided. For optimum
performance, use the recommended grade of fuel.
For further information on fuel, see page 150.95usM06.book Page 262 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

263 Specifications
Engine oil To meet demands in Saab's extended service intervals all
engines are filled with specially designed synthetic factory fill
oils. Long service intervals, fuel economy and environmental
issues are the base for our choice of oil. By using oils approved
by Saab you minimise the tendencies for oil sludge build, by that
protecting the engine from harmful, wear increasing, deposits.
Approved engine oils:
All gasoline engines - Fully synthetic engine oil - approved
against the GM-LL-A025 specification - with viscosity
SAE 0W-30 or SAE 0W-40.
Oil used at, or in-between, service must be approved against the
engine´s specified classification to render possible the usage of
Saab Automobile AB specified service intervals.
For optimum performance Saab recommends the use of Saab
Long Life Turbo Oil 0W-30 or Mobil 1 0W-40 European Car for-
mula, but other oils approved against the above specification
and with proper SAE viscosity 0W-30 or 0W-40 may also be
used.
Servicing/Oil changes:
To be able to use recommended service intervals the need to
use only approved engine oils is vital. Use only engine oils
approved for your engine. Service should be done according
to the recommended service intervals to optimize your engine's
function through out its entire life. Saab Automobile AB will not
take responsibility for any damage that might occur due to
neglecting to meet above mentioned requirements.At your Saab dealers you can find Saab Genuine or Mobil
engine oils. Among those there are oils specially designed to
meet your engines specific needs. We recommend that you,
with the help of our skilled service personnel, choose your oil
from that assortment.
Other oil companies also offer engine oils approved against GM
specifications. Oils meeting these standards may be marketed
as synthetic. However, not all synthetic engine oils will meet your
engine´s specific requirements. Please ensure only to use oils
approved against your engine´s specific requirements, i.e.
GM-LL-A025 with viscosity SAE 0W-30 or 0W-40.
Recommended oil viscosity
Viscosity is a measurement of the oil´s thickness at various tem-
peratures, according to the SAE standard. This thickness influ-
ences e.g. fuel economy and cold starting properties. For
optimum performance Saab recommends:
For gasoline engines:
SAE 0W-30
or
SAE 0W-40 engine oil
Extra engine oil additives
Don't add anything to your oil. The recommended oils are all you
will need for good engine performance and protection.
95usM06.book Page 263 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

264 Specifications
Engine variants
When to change engine oil
Your vehicle will display when it is time for servicing on the SID,
based on the mileage and time since the last service.
For this service system to work it is of outmost importance that
the right engine oil is used.
When the message for service is displayed you need to have the
required service done as soon as possible.
After the service your service personnel will reset the service
indicator. It is important to reset the service indicator in order to
optimize the time to the next service.
Oil capacity incl. filter (on changing) ____ 4.1 qts (4.0 litres) 2.3 Turbo Ecopower
Rating, EEC at 5000 rpm ____________ 260 hp (191 kW)
Maximum torque, EEC at 1900 rpm ____ 258.0 ft.lb.
(350 Nm)
Compression ratio _________________ 9.3:195usM06.book Page 264 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

265 Specifications
Electrical system Drive belts Voltage __________________________ 12 V
Battery capacity ___________________ 70 Ah
Starter motor ______________________ 1.4 kW
Alternator rating ____________________ 140 A/14 V
Firing order _______________________ 1–3–4–2
Spark plugs:
2.3 Turbo _______________________ NGK
PFR 6H-10
Electrode gap ____________________ 0.0374 in (0.95 mm)Engine variants Outside length
Drive belt _________________________ 95.08 in
(2415 mm)
Drive belt
IB929
95usM06.book Page 265 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

266 SpecificationsManual gearbox Automatic transmission Type ____________________________ All-synchromesh
5-speed with final
drive and differen-
tial
Oil ______________________________ Saab MTF 0063
Oil capacity _______________________ 1.9 qts (1.8 litres)
Oil volume (on changing) ____________ 1.6 qts (1.5 litres)
Clutch type _______________________ Hydraulic, single
dry-plate clutch of
diaphragm-spring
type
Speed (mph / km/h) at 1000 rpm in 5th gear: 27–29 / 43–47Type _____________________________ Electronically con-
trolled 5-speed,
fully automatic with
hydraulic torque
converter, plane-
tary gear set and
integral final drive
Lock-up function in
selector positions 3,
4 and 5.
Selector-lever positions ______________ P R N D M L
Clutch type ________________________ Hydraulic plate
clutches, brake
bands and one-way
couplings
Speed (mph / km/h) at 1000 rpm in 5th gear: 29–30 / 46–4895usM06.book Page 266 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

267 Specifications
Suspension
Steering Brake system Spring type, front and rear ___________ Coil springs
Maximum deflection of springs:
Front __________________________ 7.09 in (180 mm)
Rear ___________________________ 7.87 in (200 mm)
Dampers, front and rear _____________ Gas-filled dampers
Steering _________________________ Power-assisted
steering of
rack-and-pinion
type; telescopic
steering-column
shaft with universal
joints
Number of turns, lock to lock __________ 2.9
Power-steering fluid ________________ Power-steering fluid
CHF 11S or
CHF 202Footbrake (ABS) ____________________ Hydraulic, dual-
circuit brake sys-
tem. Diagonally
split circuit with vac-
uum servo unit.
Disc brakes front
and rear. EBD, see
page 162.
Parkingbrake _______________________ Acts on rear wheels
Brake fluid _________________________ DOT 4
Brake-fluid capacity _________________ 0.951 qts (900 ml)
Disc diameter:
Front, ventilated ___________________ 12.05 in (308 mm)
Rear, solid _______________________ 11.26 in (286 mm)
Total friction area of brake pads:
Front ___________________________ 36.3 in
 (234 cm
)
Rear ___________________________ 15.5 in
 (100 cm
)
95usM06.book Page 267 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

268 SpecificationsWheels and tires(recommended dimensions)
2.3 Turbo
All season tires
215/55 R16 93 H X
235/45 R17 94 V X
Winter tires
215/55 R16 93 Q X
225/45 R17 94 Q XL/RF X
235/45 R17 94 Q X
Wheel sizes
6.5 x 16” X
7 x 17” X
7.5 x 17” X
Speed ratings and load indexes, see page 233.
Always contact an authorized Saab dealer if you wish to fit other wheels
or tires than those fitted as standard.Compact spare:
Wheel __________________________ 4 x 16”
Tire ____________________________ T115/70 R16
Pressure ________________________ 60 psi (420 kPa)
Maximum life ____________________ 2,200 miles
(3500 km)
Maximum speed _________________ 50 mph (80 km/h)
NOTICESnow chains:
Snow chains must not be fitted to the rear wheels, and may only
be used with the following wheel-tire combinations:
Wheels Tires
6.5 x 16”_______ 215/55 R16
Snow chains must not be fitted to 17" wheels.
Max. permissible speed with snow chains fitted is 30 mph
(50 km/h).
Contact an authorized Saab dealer for advice on snow chains.NOTICEWheels larger than 17” must not be fitted.
Wheel offset must be 49 mm.
95usM06.book Page 268 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

269 Specifications
Lowest recommended tire pressure, cold tiresTire size Load/speed
mph (km/h)

Front
kPa/psiRear
kPa/psi
All season tires
215/55 R16 93 H 1–3 pers./0–100 (0–160) 250/36 230/33
4–5 pers./0–100 (0–160) 250/36 230/33
1–5 pers./100– (160–) 290/42 270/39
235/45 R17 94 V 1–3 pers./0–120 (0–190) 240/35 240/35
4–5 pers./0–120 (0–190) 240/35 240/35
1–5 pers./120– (190–) 280/41 280/41
Tire size Load/speed
mph (km/h)

Front
kPa/psiRear
kPa/psi
Winter tires
215/55 R16 93 Q 1–3 pers./0–100 (0–160) 240/35 240/35
4–5 pers./0–100 (0–160) 260/38 260/38
225/45 R17 94 Q
XL/RF1–3 pers./0–100 (0–160) 250/36 250/36
4–5 pers./0–100 (0–160) 270/39 270/39
235/45 R17 94 Q 1–3 pers./0–100 (0–160) 240/35 240/35
4–5 pers./0–100 (0–160) 260/38 260/38
Compact spare
T115/70 R16
Spare wheelMax 50 (80) 420/60 420/60
1) Do not exceed posted speed limits.
By cold tires is meant tires that are the same temperature as the surround-
ing air temperature.
The values for tire pressure in the table above are for tires at 68°F (20°C).
The tire pressure will increase as the tires become warm (e.g. during
motorway driving), and decrease as they cool.
When the temperature of the tires increase or decrease by 10 degrees the
tire pressure will correspondingly increase or decrease by 10 kPa/2 psi
(0.1 bar).
95usM06.book Page 269 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

270 SpecificationsPlates and labels When consulting your Saab dealer, it may be
necessary to quote the car’s V.I.N., engine
and gearbox numbers.
1 V.I.N. number, inside windshield.
2 V.I.N. label and certification label.
3 Gearbox number.
4 Engine number.
5Canada: Label for tire pressure and color
codes (trim and body).
USA: color codes (trim and body) can be
found on the V.I.N. label on the B-pillar.
6 Chassis number, stamped on body.
7 Vehicle Emission Control Information.
IB4156
1
2
6
7
5
4
3
95usM06.book Page 270 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com
