45 Security
Locking/unlocking the carWhen the car is locked and unlocked the
theft alarm is also affected.
Remote locking
Press once on the control: all doors
locked.
The hazard warning lights will flash once.
The trunk/tailgate release switch on the
driver´s door will not work when all doors are
locked.
It is now not possible to unlock the doors
from within using the button on the
centre console.
Remote unlocking
Press once on the control: the driver´s
door is unlocked. Press a second time to
unlock the rest of the doors but not the
trunk/tailgate.
The hazard warning lights will flash twice.The central locking can also be operated
from inside the car by means of the
switch on the center console.
This switch is inoperative when the car is
locked from the outside using the remote
control.
The interior locking buttons on each door
affect only the respective door.
If the car is left with the doors open, the inte-
rior lighting and the courtesy lights in the
doors will be switched off automatically after
20 minutes, to prevent a drain on the bat-
tery. In such cases the electrically operated
seats will not function.
IB3153
3
2 1
Key / Remote control1To lock
2 To unlock
3 Opening the trunk (9-5 Sedan)
Unlocking the tailgate (9-5 SportCombi)
IB451
Switch for operation of central locking
95usM06.book Page 45 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

115 Interior equipment and trunk
Electric windowsThe electric motors of the front windows are
equipped with overload protection (inte-
grated thermal protection). This protection
operates when the windows are wound
down automatically (switch pressed fully
down).To open:
Front windows: press the front of the switch
Rear windows: Press the back of the switch.
The switches for the front windows have a
third position for automatic opening of the
window. Press the switch fully down to lower
the window completely.
To cancel automatic lowering of the win-
dow, lift the switch briefly.To close:
Front windows: Lift the front of the switch.
Rear windows: Lift the back of the switch.
The actuating motor will be switched off
automatically when the window is fully
closed or when the switch is released.
WARNING
Bear in mind the pinch hazard when the
side windows are being wound up.
Always remove the ignition key when
you leave the car. This prevents per-
sonal injury caused by the electric win-
dows, for example, due to children
playing.
 The person operating the electric win-
dows is responsible for ensuring that
no one, especially children, has their
head, hands or fingers in the window
openings, before raising the windows.
Raising the windows could otherwise
cause serious or fatal injuries.
 Do not extend your arm, head etc. out
of an open window while driving.
IB3231
1 Window switches
2 Switch for rendering rear door window switches inoperative
