CD player SAAB 9-7X 2005 Owner's Manual

Problem Recommended Action
In auxiliary mode, the
picture moves or scrolls.Check the auxiliary input
connections at both
devices.
Change the Video Format
to PAL or NTSC. See
“Stereo RCA Jacks”
previously for how to
change the video format.
The language in the audio
or on the screen is wrong.Check the audio or
language selection in the
main DVD menu.
The remote control does
not work.Check to make sure there
is no obstruction between
the remote control and the
transmitter window.
Check the batteries to
make sure they are not
dead or installed
incorrectly.
The parental control
button might have been
turned on. The power
indicator light will ash.Problem Recommended Action
After stopping the player, I
push Play but sometimes
the DVD starts where I
left off and sometimes at
the beginning.If the stop button was
pressed one time, the
DVD player will resume
playing where the DVD
was stopped. If the stop
button was pressed two
times the DVD player will
begin to play from the
beginning of the DVD.
The auxiliary source is
running but there is no
picture or sound.Check that the DVD
player is in the auxiliary
source mode.
Check the auxiliary input
connections at both
devices.
My disc is stuck in the
player. The Load/Eject
button does not work.Turn the DVD power off,
then on, then press the
load/eject button on the
DVD player.
Do not attempt to forcibly
remove the disc from the
DVD player. This could
permanently damage the
disc and DVD player.
3-90
2005 - Saab 97X Owner Manual
ProCarManuals.com

Problem Recommended Action
Sometimes the wireless
headphone audio cuts out
or buzzes.Check for obstructions,
low batteries, reception
range, and interference
from cellular telephone
towers or by using your
cellular telephone in the
vehicle.
Check that the
headphones are facing
the front of the vehicle.
I lost the remote and/or
the headphones.See your dealer for
assistance.
The DVD is playing, but
there is no picture or
sound.Check that the DVD
player is in DVD mode.
The audio/video skips or
jumps.The DVD or CD could be
dirty, scratched, or
damaged.
The audio from the radio
for the Radio with
Six-Disc CD and XM™
has taken over the audio
from the DVD or CD when
using the wired
headphones.The RSE is working
correctly.
Use the wireless
headphones or have the
front seat passengers
listen to another audio
source.DVD Messages
The following errors may be displayed on the video
screen:
Disc Format Error:This message will be displayed if a
disc is inserted upside down, if the disc is not readable,
or if the format is not compatible with the DVD player.
Load/Eject Error:This message will be displayed if the
disc is not properly loaded or ejected.
Disc Play Error:This message will be displayed if the
DVD player cannot play the disc. Scratched or
damaged discs will cause this error.
Region Code Error:This message will be displayed if
the region code of the DVD is not compatible with
the region code of the DVD player.
No Disc:This message will be displayed if any of the
buttons on the DVD faceplate or remote control are
pressed and no disc is present in the DVD player.
3-91
2005 - Saab 97X Owner Manual
ProCarManuals.com

DVD Distortion
There may be an experience with audio distortion in the
wireless headphones when operating cellular phones,
scanners, CB radios, Global Positioning Systems
(GPS)*, two-way radios, mobile fax, or walkie talkies.
It may be necessary to turn off the DVD player
when operating one of these devices in or near the
vehicle.
* Excludes the OnStar
®System.
Cleaning the Video Screen
Pour some isopropyl or rubbing alcohol on a clean cloth
and gently wipe the video screen. Do not spray
directly onto the screen and do not press too hard or
too long on the video screen.
Rear Seat Audio (RSA)
This feature allows rear seat passengers to select and
listen to any of the available radio sources: AM/FM,
XM, CD, or DVD. However, a rear seat passenger
cannot control a source selected on the radio by
someone in the front of the vehicle. For example, the
RSA cannot be used to change CD tracks if the radio is
set to CD. Also, if the radio is switched to a source
the RSA has control of, sound will not be lost, but the
RSA will lose control of that sourse.Rear seat passengers always have control of the
volume for each set of headphones.
The RSA will run when the radio is off if the ignition key
is positioned in the power mode, seeIgnition Positions
on page 2-20in this manual.
P(Power):Press this button to turn the RSA on or
off. The rear speakers are muted when the power
is turned on.
u(Volume):The left-hand knob controls the
headphone outlet on the left and the right-hand knob
controls the headphone outlet on the right. Turn
either knob clockwise to increase the volume and
counterclockwise to decrease the volume.
3-92
2005 - Saab 97X Owner Manual
ProCarManuals.com

SRCE (Source):Press this button to select an audio
source: AM/FM, XM, CD, or DVD. The inactive CD,
or DVD will remain safely inside the radio for future
listening. There are sources that are internal to the radio,
such as AM/FM, and CD and other sources to radio
that are external, such as XM™, DVD, and OnStar
®.If
an external source has been selected, the rear seat
passengers cannot select a different external source.
SEEK:Press this button to go to the next station or CD
track and stay there. The display will show the
selection. This function is inactive if the radio is set to
the same source.
To scan preset radio stations, press and hold the SEEK
button for two seconds and the radio will go to the
next preset station. Hold this button down and the radio
will continue to go through all available preset stations.
This function is inactive if the front seat passengers
are listening to the radio.When a CD is playing, press the SEEK button to go to
the next track on the CD. This function is inactive if
the front seat passengers are listening to a CD.
When a CD is playing in the six-disc CD player, press and
hold the SEEK button for two seconds to go you to the
next CD, if multiple CDs are loaded. This function is
inactive if the front seat passengers are listening to a CD.
Theft-Deterrent Feature
THEFTLOCK®is designed to discourage theft of your
vehicle’s radio. The feature works automatically by
learning a portion of the Vehicle Identication Number
(VIN). If the radio is moved to a different vehicle, it
will not operate and LOCKED will appear on the display.
When the radio and vehicle are turned off, the blinking
red light indicates that THEFTLOCK
®is armed.
With THEFTLOCK
®activated, the radio will not operate
if stolen.
3-93
2005 - Saab 97X Owner Manual
ProCarManuals.com

Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range can cause
station frequencies to interfere with each other. Static
can occur on AM stations caused by things like
storms and power lines. Try reducing the treble to
reduce this noise.
FM Stereo
FM stereo will give the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km).
Tall buildings or hills can interfere with FM signals,
causing the sound to fade in and out.
XM™ Satellite Radio Service
XM™ Satellite Radio Service gives digital radio
reception from coast to coast. Just as with FM, tall
buildings or hills can interfere with satellite radio signals,
causing the sound to fade in and out. The radio may
display NO SIGNAL to indicate interference.
Care of Your CDs and DVDs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen
a clean, soft cloth in a mild, neutral detergent solution
and clean it, wiping from the center to the edge.
Be sure never to touch the side without writing when
handling discs. Pick up discs by grasping the outer
edges or the edge of the hole and the outer edge.
Care of the CD and DVD Player
The use of CD lens cleaners for CDs is not advised,
due to the risk of contaminating the lens of the CD optics
with lubricants internal to the CD mechanism.
3-95
2005 - Saab 97X Owner Manual
ProCarManuals.com

A
Accessory Inator...........................................5-68
Accessory Power Outlet(s)...............................3-19
Adding Equipment to Your Airbag-Equipped
Vehicle.......................................................1-58
Additives, Fuel................................................. 5-5
Add-On Electrical Equipment............................5-94
Adjustable Throttle and Brake Pedal..................2-22
Air Cleaner/Filter, Engine.................................5-19
Air Conditioning..............................................3-20
Air Suspension...............................................4-34
Airbag
Passenger Status Indicator...........................3-30
Readiness Light..........................................3-29
Airbag Sensing and Diagnostic Module (SDM)...... 7-5
Airbag System................................................1-45
Adding Equipment to Your Airbag-Equipped
Vehicle...................................................1-58
How Does an Airbag Restrain?......................1-52
Passenger Sensing System...........................1-54
Servicing Your Airbag-Equipped Vehicle..........1-58
What Makes an Airbag Inate?......................1-51
What Will You See After an Airbag Inates?....1-52
When Should an Airbag Inate?....................1-50
Where Are the Airbags?...............................1-47
All-Wheel Drive...............................................5-44
All-Wheel-Drive (AWD) System........................... 4-8All-Wheel-Drive Service Light............................3-41
Antenna, Fixed Mast.......................................3-96
Antenna, XM™ Satellite Radio Antenna System.....3-96
Anti-Lock Brake System (ABS)........................... 4-6
Anti-Lock Brake, System Warning Light..............3-34
Appearance Care............................................5-85
Aluminum Wheels........................................5-91
Care of Safety Belts....................................5-88
Chemical Paint Spotting...............................5-92
Cleaning Exterior Lamps/Lenses....................5-89
Cleaning the Inside of Your Vehicle................5-85
Fabric/Carpet..............................................5-87
Finish Care.................................................5-89
Finish Damage............................................5-92
Instrument Panel, Vinyl, and Other Plastic
Surfaces.................................................5-88
Leather......................................................5-87
Sheet Metal Damage...................................5-92
Tires..........................................................5-91
Underbody Maintenance...............................5-92
Vehicle Care/Appearance Materials................5-93
Washing Your Vehicle...................................5-89
Weatherstrips..............................................5-88
Windshield, Backglass, and Wiper Blades.......5-90
Audio System(s).............................................3-56
Audio Steering Wheel Controls......................3-94
Care of Your CD and DVD Player..................3-95
Care of Your CDs and DVDs........................3-95
1
2005 - Saab 97X Owner Manual
ProCarManuals.com

Audio System(s) (cont.)
Fixed Mast Antenna.....................................3-96
Navigation/Radio System, see Navigation
Manual...................................................3-81
Radio with CD............................................3-57
Radio with Six-Disc CD................................3-69
Rear Seat Audio (RSA)................................3-92
Setting the Time..........................................3-56
Theft-Deterrent Feature................................3-93
Understanding Radio Reception.....................3-95
XM™ Satellite Radio Antenna System............3-96
Automatic Headlamp System............................3-16
Automatic Transmission
Fluid..........................................................5-20
Operation...................................................2-24
B
Battery..........................................................5-38
Run-Down Protection...................................3-19
Before Leaving on a Long Trip.........................4-20
Brake
Anti-Lock Brake System (ABS)........................ 4-6
Emergencies................................................ 4-8
Parking......................................................2-27
System Warning Light..................................3-33
Brake Pedal, Throttle.......................................2-22Brakes..........................................................5-35
Braking........................................................... 4-5
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-19
Bulb Replacement...........................................5-47
Halogen Bulbs............................................5-48
Headlamp Aiming........................................5-47
Headlamps, Front Turn Signal, Sidemarker,
and Parking Lamps..................................5-48
High Intensity Discharge (HID) Lighting...........5-47
Replacement Bulbs......................................5-51
Taillamps, Turn Signal, Sidemarker,
Stoplamps, and Back-Up Lamps.................5-50
Buying New Tires...........................................5-64
C
California Fuel.................................................. 5-4
Canadian Owners................................................ ii
Capacities and Specications..........................5-106
Carbon Monoxide...................2-13, 2-30, 4-24, 4-35
Care of
Safety Belts................................................5-88
Your CD and DVD Player.............................3-95
Your CDs and DVDs....................................3-95
Cargo Cover..................................................2-44
Cargo Tie Downs............................................2-44
2
2005 - Saab 97X Owner Manual
ProCarManuals.com

P
Park (P)
Shifting Into................................................2-28
Shifting Out of............................................2-29
Parking
Brake........................................................2-27
Over Things That Burn.................................2-29
Passenger Airbag Status Indicator.....................3-30
Passenger Sensing System..............................1-54
Passing.........................................................4-11
PASS-Key
®III ................................................2-17
PASS-Key®III Operation..................................2-18
Power
Accessory Outlet(s)......................................3-19
Door Locks.................................................. 2-9
Electrical System.........................................5-95
Lumbar Controls........................................... 1-2
Reclining Seatbacks...................................... 1-4
Reduced Engine Light..................................3-40
Retained Accessory (RAP)............................2-20
Seat............................................................ 1-2
Steering Fluid.............................................5-33
Windows....................................................2-15Pretensioners, Safety Belt................................2-15
Programmable Automatic Door Locks.................2-10
Q
Questions and Answers About Safety Belts.........1-11
R
Radiator Pressure Cap....................................5-25
Radios..........................................................3-56
Care of Your CD and DVD Player..................3-95
Care of Your CDs and DVDs........................3-95
Navigation/Radio System, see Navigation
Manual...................................................3-81
Radio with CD............................................3-57
Radio with Six-Disc CD................................3-69
Rear Seat Audio..........................................3-92
Setting the Time..........................................3-56
Theft-Deterrent............................................3-93
Understanding Reception..............................3-95
Reading Lamps..............................................3-18
Rear Axle......................................................5-45
Limited-Slip.................................................. 4-8
10
2005 - Saab 97X Owner Manual
ProCarManuals.com
