SAAB 9-7X 2008 Owners Manual

When your vehicle has a at tire, use this as a guide to
assist you in the placement of wheel blocks.Removing the Spare Tire and Tools
The jacking equipment you will need is stored under
the rear seat on the passenger’s side of the vehicle. See
Rear Seat Operation on page 1-8for more information.
To release the jack from its holder, turn the knob on the
jack counterclockwise to lower the jack head.
5-87
ProCarManuals.com

The tools you will be using include the wheel wrench (A),
wheel blocks (B), extension(s), (socket end) (C),
handle (jack end) (D), and jack (E).
A. Wheel Wrench
B. Hoist Shaft
C. Extension
D. Retainer
E. Spare or Flat Tire (Valve
Stem Pointed Up)The following instructions explain how to remove the
underbody-mounted spare located underneath your
vehicle.
Notice:If you remove or restow a tire from/to
the storage position under the vehicle while it is
supported by a jack, you could damage the tire
and/or your vehicle. Always remove or restow a
tire when the vehicle is on the ground.
1. Open the liftgate. SeeLiftgate/Liftglass on
page 2-12for more information.
2. Attach the wheel wrench (A) to the extension (C).
3. Insert the socket end of the extension (C) on a
45 degree angle downward into the hoist drive
shaft hole. It is exposed when the rear gate is
open and is just above the rear bumper.
Be sure the socket end of the extension (C)
connects to the hoist shaft (B).
5-88
ProCarManuals.com

4. Turn the wheel wrench counterclockwise to lower
the spare tire. Keep turning the wheel wrench until
the spare tire can be pulled out from under the
vehicle.
If the spare tire does not lower to the ground,
the secondary latch is engaged causing the tire
not to lower. SeeSecondary Latch System
on page 5-94for more information.5. Tilt the retainer at the end of the cable when the
tire has been completely lowered, and pull it
through the wheel opening.
6. Pull the tire out from under the vehicle.
Notice:If you drive away before the spare tire or
secondary latch system cable has been reinstalled,
you could damage your vehicle. Always reinstall
this cable before driving your vehicle.
7. Put the spare tire near the at tire.
5-89
ProCarManuals.com

Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-86for more information.
2. Use the at end of the wheel wrench to carefully
pry off the center cap.
3. Using the wheel
wrench, loosen all the
wheel nuts by turning
the nuts one turn
counterclockwise.
Do not remove
them yet.
4. Turn the jack adjusting knob clockwise by hand to
raise the jack lift head.
5. Place the handle, extension, and wheel wrench
onto the jack.A. Front Frame/Rear Axle
B. Jack
C. HandleD. Extension(s)
E. Wheel Wrench
6. Place the jack in the appropriate position nearest
the at tire.
Front PositionRear Position
5-90
ProCarManuals.com

{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.7. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the spare
tire to t.
5-91
ProCarManuals.com

8. Remove all the wheel
nuts and the at tire.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
CAUTION: (Continued)
CAUTION: (Continued)
In an emergency, you can use a cloth or a
paper towel to do this; but be sure to use a
scraper or wire brush later, if needed, to get all
the rust or dirt off. SeeChanging a Flat Tire on
page 5-86.
9. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
10. Place the spare tire on the wheel-mounting surface.
5-92
ProCarManuals.com

{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose. The
vehicle’s wheel could fall off, causing a crash.
11. Put the nuts on by hand. Make sure the cone
shaped end is toward the wheel.
12. Tighten each nut by hand until the wheel is held
against the hub. If a nut cannot be turned by
hand, use the wheel wrench and see your dealer
as soon as possible.
13. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
5-93
ProCarManuals.com

{CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to come loose
and even come off. This could lead to an
accident. Be sure to use the correct wheel
nuts. If you have to replace them, be sure to
get new original equipment wheel nuts. Stop
somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-122for wheel
nut torque specication.
Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-122for the wheel
nut torque specication.14. Use the wrench to
tighten the wheel nuts
rmly in a crisscross
sequence as shown.
Secondary Latch System
Your vehicle has an underbody-mounted tire hoist
assembly equipped with a secondary latch system.
It is designed to stop the spare tire from suddenly falling
off your vehicle if the cable holding the spare tire is
damaged. For the secondary latch to work, the tire must
be stored with the valve stem pointing up. SeeStoring
a Flat or Spare Tire and Tools on page 5-98for
instructions on storing the spare or at tire correctly.
5-94
ProCarManuals.com

{CAUTION:
Before beginning this procedure read all the
instructions. Failure to read and follow the
instructions could damage the hoist assembly
and you and others could get hurt. Read and
follow the instructions listed next.
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack.
If the spare tire does not slide off the jack
completely, make sure no one is behind you or
on either side of you as you pull the jack out
from the under spare.To release the spare tire from the secondary latch:
1. Check under the
vehicle to see if the
cable is visible. If it is
not visible, proceed
to Step 6.
2. If visible, rst try to tighten the cable by turning the
wheel wrench clockwise until you hear two clicks or
feel it skip twice. You cannot overtighten the cable.
3. Loosen the cable by turning the wheel wrench
counterclockwise three or four turns.
4. Repeat this procedure at least two times.
If the spare tire lowers to the ground, continue with
Step 2 ofRemoving the Spare Tire and Tools on
page 5-87.
5. Turn the wrench counterclockwise until
approximately 6 inches (15 cm) of cable is exposed.
5-95
ProCarManuals.com

6. Attach the jack handle, extension(s) and the wheel
wrench to the jack and place it under the vehicle
towards the front of the rear bumper. Position
the center lift point of the jack under the center
of the spare tire.
7. Turn the wrench clockwise to raise the jack until it
lifts the end tting.
8. Continue raising the jack until the spare tire
stops moving upward and is held rmly in place.
The secondary latch has released and the spare
tire is balancing on the jack.9. Lower the jack by turning the wheel wrench
counterclockwise. Keep lowering the jack until
the spare tire slides off the jack or is hanging by
the cable.
10. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to push
against the spare while rmly pulling the jack out
from under the spare tire with the other hand.
11. If the spare tire is
hanging from the cable,
insert the socket end of
the extension into the
hoist shaft hole on a
45 degree angle
downward.
12. Be sure that the socket end of the extension
connects to the hoist shaft.
5-96
