seat adjustment SATURN AURA HYBRID 2010 Owners Manual

Instrument Panel..............................................1-2
Initial Drive Information....................................1-3
Remote Keyless Entry (RKE) System................1-4
Remote Vehicle Start......................................1-4
Door Locks....................................................1-6
Trunk Release...............................................1-6
Windows.......................................................1-7
Seat Adjustment.............................................1-7
Second Row Seats.......................................1-10
Safety Belt...................................................1-10
Sensing System for Passenger Airbag.............1-11
Mirror Adjustment.........................................1-11
Steering Wheel Adjustment............................1-12
Interior Lighting............................................1-13
Exterior Lighting...........................................1-14
Windshield Wiper/Washer...............................1-15
Climate Controls...........................................1-16
Vehicle Features.............................................1-17
Radio(s)......................................................1-17
Satellite Radio..............................................1-18
Portable Audio Devices
(Auxiliary Input or USB Port).......................1-18Steering Wheel Controls................................1-19
Bluetooth®...................................................1-19
Driver Information Center (DIC).......................1-20
Cruise Control..............................................1-21
Power Outlets..............................................1-21
Hybrid Features..............................................1-22
Charge/Assist Gage......................................1-22
Fuel Economy Light......................................1-22
Automatic Engine Start/Stop Feature...............1-23
Regenerative Braking....................................1-23
Battery........................................................1-24
Service.......................................................1-24
Performance and Maintenance.........................1-24
Traction Control System (TCS).......................1-24
Electronic Stability Control (ESC)....................1-25
Tire Pressure Monitor....................................1-25
Tire Sealant and Compressor Kit....................1-26
Engine Oil Life System..................................1-26
Driving for Better Fuel Economy.....................1-27
Roadside Assistance Program........................1-27
OnStar
®......................................................1-28
Section 1 In Brief
1-1
ProCarManuals.com

Windows
On vehicles with power
windows, the switches are
on the driver door
armrest.
Each passenger door has a switch that controls only
that window.
Press the front of the switch to open the window. Pull
the switch up to close it.
For more information, seePower Windows on
page 3-15.
Seat Adjustment
Manual Seat
1. Lift the bar under the
seat to unlock the seat.
2. Slide the seat to
the desired position
and release the bar.
Try to move the seat to be sure it is locked in place.
SeeManual Seats on page 2-3.
1-7
ProCarManuals.com

Sensing System for Passenger
Airbag
The passenger sensing system will turn off the right
front passenger frontal airbag and seat-mounted
side impact airbag under certain conditions. The driver
airbags and roof-rail airbags are not affected by this.
The passenger airbag status indicator will be visible on
the instrument panel when the vehicle is started.
SeePassenger Sensing System on page 2-66for
important information.
Mirror Adjustment
Exterior Mirrors
Controls for the outside
power mirrors are located
on the inside of the
vehicle near the driver side
mirror.
Use the selector switch to choose either the left or right
outside mirror. Then press the four-way control pad
to move the selected mirror in the desired direction.
SeeOutside Power Mirrors on page 3-35. United States
Canada
1-11
ProCarManuals.com

Lap-Shoulder Belt
All seating positions in the vehicle have a
lap-shoulder belt.
The following instructions explain how to wear a
lap-shoulder belt properly.
1. Adjust the seat, if the seat is adjustable, so you
can sit up straight. To see how, see “Seats” in
the Index.
2. Pick up the latch plate and pull the belt across you.
Do not let it get twisted.
The lap-shoulder belt may lock if you pull the belt
across you very quickly. If this happens, let the belt
go back slightly to unlock it. Then pull the belt
across you more slowly.
If the shoulder portion of a passenger belt is pulled
out all the way, the child restraint locking feature
may be engaged. If this happens, just let the belt go
back all the way and start again.
Engaging the child restraint locking feature in the
right front seating position may affect the passenger
sensing system. SeePassenger Sensing System
on page 2-66for more information.3. Push the latch plate into the buckle until it clicks.
Pull up on the latch plate to make sure it is secure.
If the belt is not long enough, seeSafety Belt
Extender on page 2-30.
Position the release button on the buckle so that the
safety belt could be quickly unbuckled if necessary.
4. If equipped with a shoulder belt height adjuster,
move it to the height that is right for you. Improper
shoulder belt height adjustment could reduce
the effectiveness of the safety belt in a crash. See
“Shoulder Belt Height Adjustment” later in this
section for instruction on use and important safety
information.
2-24
ProCarManuals.com

Shoulder Belt Height Adjuster
Your vehicle has a shoulder belt height adjuster for the
driver and right front passenger position.
Adjust the height so that the shoulder portion of the belt
is centered on the shoulder. The belt should be away
from the face and neck, but not falling off of the
shoulder. Improper shoulder belt height adjustment
could reduce the effectiveness of the safety belt
in a crash.
Squeeze the buttons (A)
on the sides of the height
adjuster and move the
height adjuster to the
desired position.
After the adjuster is set to the desired position, try to
move it down without squeezing the buttons to
make sure it has locked into position.
Safety Belt Pretensioners
This vehicle has safety belt pretensioners for the front
outboard occupants. Although the safety belt
pretensioners cannot be seen, they are part of the
safety belt assembly. They can help tighten the safety
belts during the early stages of a moderate to severe
frontal and near frontal crash if the threshold conditions
for pretensioner activation are met. And, if the vehicle
has side impact airbags, safety belt pretensioners
can help tighten the safety belts in a side crash.
Pretensioners work only once. If they activate in a crash,
they will need to be replaced, and probably other new
parts for the vehicle’s safety belt system. SeeReplacing
Restraint System Parts After a Crash on page 2-74.
Rear Safety Belt Comfort Guides
This vehicle may have rear shoulder belt comfort
guides. If not, they are available through your
dealer/retailer. The guides may provide added safety
belt comfort for older children who have outgrown
booster seats and for some adults. When installed and
properly adjusted, the comfort guide positions the
belt away from the neck and head.
2-26
ProCarManuals.com

Outlet Adjustment
There are four main air outlets on the instrument panel.
Move the lever located in the center of each outlet
side-to-side or up and down, to change the direction and
amount of airflow in the vehicle. The center thumbwheel
does not control the main outlets.
Rear Seat Air Outlet
For vehicles with this feature, the rear seat air outlet is
located in the center of the instrument panel above
the two main center outlets.
Use the thumbwheel in the center of the outlet to turn
the airflow on or off.
Operation Tips
•Clear away any ice, snow, or leaves from the air
inlets at the base of the windshield that can
block the flow of air into the vehicle.
•Do not use non-GM approved hood deflectors as
they could adversely affect the performance of
the system.
•Keep the path under the front seats clear of objects
to help circulate the air inside of the vehicle more
effectively.
Warning Lights, Gages, and
Indicators
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause
an expensive repair or replacement. Paying attention to
the warning lights and gages could prevent injury.
Warning lights come on when there might be or there is
a problem with one of the vehicle’s functions. Some
warning lights come on briefly when the engine is started
to indicate they are working.
Gages can indicate when there might be or there is a
problem with one of the vehicle’s functions. Often gages
and warning lights work together to indicate a problem
with the vehicle.
When one of the warning lights comes on and stays on
while driving, or when one of the gages shows there
could be a problem, check the section that explains what
to do. Follow this manual’s advice. Waiting to do
repairs can be costly and even dangerous.
4-21
ProCarManuals.com

C
California
Perchlorate Materials Requirements................. 6-4
Warning....................................................... 6-4
California Fuel.................................................. 6-7
Call Waiting...................................................4-77
Calling for Assistance........................................ 8-7
Canadian Owners................................................ ii
Canceling a Remote Start.................................. 1-5
Capacities and Specifications............................6-92
Carbon Monoxide
Engine Exhaust...........................................3-33
Trunk.........................................................3-12
Winter Driving.............................................5-17
Care of
Safety Belts................................................6-76
Care of CDs ..................................................4-60
Care of the CD Player.....................................4-60
CD Messages................................................4-59
CD, MP3 .......................................................4-62
Cellular Phone Usage......................................4-82
Center Console Storage...................................3-37
Chains, Tire...................................................6-64
Charge/Assist Gage........................................4-36
Charging System Light....................................4-27
Check
Engine Lamp..............................................4-31Check Engine Light.........................................4-31
Checking Coolant............................................6-25
Checking Engine Oil........................................6-15
Checking Things Under the Hood......................6-12
Chemical Paint Spotting...................................6-80
Child Restraints
Infants and Young Children...........................2-34
Lower Anchors and Tethers for Children..........2-42
Older Children.............................................2-30
Securing a Child Restraint in a Rear Seat
Position..................................................2-49
Securing a Child Restraint in the Right
Front Seat Position...................................2-52
Systems.....................................................2-38
Where to Put the Restraint...........................2-40
Chime Level Adjustment..................................4-83
Cleaning
Aluminum Wheels........................................6-79
Exterior Lamps/Lenses.................................6-77
Fabric/Carpet..............................................6-75
Finish Care.................................................6-78
Instrument Panel, Vinyl, and Other Plastic
Surfaces.................................................6-76
Interior.......................................................6-73
Tires..........................................................6-79
Underbody Maintenance...............................6-80
3
ProCarManuals.com

Manual Seats................................................... 2-3
Message
DIC Warnings and Messages........................4-41
Mirrors
Manual Rearview.........................................3-35
Outside Automatic Dimming Mirror.................3-36
Outside Power Mirrors..................................3-35
MP3 .............................................................4-62
Muting a Call.................................................4-77
My GM Canada (Canada) — www.gm.ca............. 8-5
N
Navigation System, Privacy..............................8-17
Net, Convenience...........................................3-37
New Vehicle Break-In......................................3-21
O
Odometer......................................................4-23
Trip ...........................................................4-23
Off-Road
Recovery....................................................5-11
Oil
Engine.......................................................6-15
Engine Oil Life System.................................6-18
Pressure Light.............................................4-33
Older Children, Restraints................................2-30
Online Owner Center........................................ 8-5Online Owner Center (U.S.) —
www.gmownercenter.com/saturn....................... 8-5
OnStar Steering Wheel Controls........................1-29
Operation Tips................................................4-21
Other Information............................................4-80
Other Rainy Weather Tips................................5-14
Outlet Adjustment............................................4-21
Outlets
Accessory Power.........................................4-15
Outside
Automatic Dimming Mirror.............................3-36
Power Mirrors.............................................3-35
Owner Checks and Services.............................. 7-8
Owner Publications.........................................8-15
Owners, Canadian............................................... ii
P
Paint, Damage...............................................6-80
Pairing..........................................................4-70
Parade Dimming.............................................4-13
Park
Headlamps Off in Park.................................4-11
Shifting Into................................................3-30
Shifting Out of............................................3-32
Parking
Brake........................................................3-29
Over Things That Burn.................................3-32
10
ProCarManuals.com
