Driving on Snow or Ice
Most of the time, those places where your tires meet
the road probably have good traction.
However, if there is snow or ice between your tires and
the road, you can have a very slippery situation. You
will have a lot less traction or “grip” and will need to be
very careful.What is the worst time for this? “Wet ice.” Very cold
snow or ice can be slick and hard to drive on. But wet
ice can be even more trouble because it may offer
the least traction of all. You can get wet ice when it is
about freezing (32°F; 0°C) and freezing rain begins
to fall. Try to avoid driving on wet ice until salt and sand
crews can get there.
Whatever the condition — smooth ice, packed, blowing
or loose snow — drive with caution.
If you have a traction control system, keep the system
on. It will improve your ability to accelerate when driving
on a slippery road. Even though your vehicle has this
system, you will want to slow down and adjust your
driving to the road conditions. SeeTraction Control
System (TCS) on page 4-8.
If you do not have a traction control system, accelerate
gently. Try not to break the fragile traction. If you
accelerate too fast, the drive wheels will spin and polish
the surface under the tires even more.
4-27
ProCarManuals.com

Buying New Tires
To nd out what kind and size of tires your vehicle
needs, look at the tire and loading information label.
For more information about this label and its location on
your vehicle, seeLoading Your Vehicle on page 4-33.
The tires installed on your vehicle when it was new had
a Tire Performance Criteria Specication (TPC Spec)
number on each tire’s sidewall. When you get new tires,
GM recommends that you get tires with that same
TPC Spec number. That way your vehicle will
continue to have tires that are designed to give proper
endurance, handling, speed rating, load range,
traction, ride and other things during normal service on
your vehicle. If your tires have an all-season tread
design, the TPC number will be followed by an “MS”
(for mud and snow).
If you ever replace your tires with those not having a
TPC Spec number, make sure they are the same
size, load range, speed rating and construction type
(bias, bias-belted or radial) as your original tires.{CAUTION:
Mixing tires could cause you to lose control
while driving. If you mix tires of different sizes
or types (radial and bias-belted tires), the
vehicle may not handle properly, and you
could have a crash. Using tires of different
sizes may also cause damage to your vehicle.
Be sure to use the same size and type tires
on all wheels. It’s all right to drive with your
compact spare temporarily, it was developed
for use on your vehicle. SeeCompact Spare
Tire on page 5-86.
{CAUTION:
If you use bias-ply tires on your vehicle, the
wheel rim anges could develop cracks after
many miles of driving. A tire and/or wheel
could fail suddenly, causing a crash. Use only
radial-ply tires with the wheels on your vehicle.
5-70
ProCarManuals.com

Uniform Tire Quality Grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
Treadwear 200 Traction AA Temperature A
The following information relates to the system
developed by the United States National Highway
Traffic Safety Administration, which grades tires by
treadwear, traction and temperature performance.
(This applies only to vehicles sold in the United States.)
The grades are molded on the sidewalls of most
passenger car tires. The Uniform Tire Quality Grading
system does not apply to deep tread, winter-type
snow tires, space-saver or temporary use spare tires,
tires with nominal rim diameters of 10 to 12 inches
(25 to 30 cm), or to some limited-production tires.
While the tires available on General Motors passenger
cars and light trucks may vary with respect to these
grades, they must also conform to federal safety
requirements and additional General Motors Tire
Performance Criteria (TPC) standards.
Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specied government test course.
For example, a tire graded 150 would wear one and
a half (1.5) times as well on the government course as
a tire graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart signicantly from the norm
due to variations in driving habits, service practices and
differences in road characteristics and climate.
Traction – AA, A, B, C
The traction grades, from highest to lowest, are AA, A,
B, and C. Those grades represent the tire’s ability
to stop on wet pavement as measured under controlled
conditions on specied government test surfaces of
asphalt and concrete. A tire marked C may have poor
traction performance. Warning: The traction grade
assigned to this tire is based on straight-ahead braking
traction tests, and does not include acceleration,
cornering, hydroplaning, or peak traction characteristics.
5-71
ProCarManuals.com

Tire Chains
{CAUTION:
If your vehicle has P195/60R15, P205/55R16 or
215/45ZR17 size tires, don’t use tire chains,
there’s not enough clearance.
Tire chains used on a vehicle without the
proper amount of clearance can cause damage
to the brakes, suspension or other vehicle
parts. The area damaged by the tire chains
could cause you to lose control of your vehicle
and you or others may be injured in a crash.
Use another type of traction device only if its
manufacturer recommends it for use on your
vehicle and tire size combination and road
conditions. Follow that manufacturer’s
instructions. To help avoid damage to your
CAUTION: (Continued)
CAUTION: (Continued)
vehicle, drive slowly, readjust or remove the
device if it’s contacting your vehicle, and don’t
spin your wheels.
If you do nd traction devices that will t,
install them on the front tires.
Notice:If your vehicle has a tire size other than
P195/60R15, P205/55R16 or 215/45ZR17 size
tires, use tire chains only where legal and only
when you must. Use only SAE Class “S” type
chains that are the proper size for your tires.
Install them on the front tires and tighten them as
tightly as possible with the ends securely fastened.
Drive slowly and follow the chain manufacturer’s
instructions. If you can hear the chains contacting
your vehicle, stop and retighten them. If the contact
continues, slow down until it stops. Driving too
fast or spinning the wheels with chains on will
damage your vehicle.
5-74
ProCarManuals.com

Engine Compartment Fuse Block
(2.2L L4 Engine)
Some fuses are in a fuse block in the engine
compartment on the driver’s side of the vehicle.
SeeEngine Compartment Overview on page 5-12for
more information on location.
Fuses Usage
1 ECM/TCMEngine Control Module,
Transmission Control Module
4 HDLP-RH Passenger’s Side Headlamp
5 A/C Air Conditioning Clutch Relay
8 ABS2Anti-Lock Brake System,
Traction Control Module
9 ECM Engine Control Module
10 ERLSCanister Purge Solenoid, Canister
Vent Solenoid, Low Coolant
Switch, Oxygen Sensors
11 IGNElectric Ignition Control Module,
Charging System, Neutral Stop
Back-Up Switch
13 TRANS2 Transaxle (VTi Variable)
14 TRANS1Transmission Control Module,
Neutral Stop Back-Up
15 BACK-UP PRNDIL, Back-up Switch
16 INJECTORS Fuel Injectors (Cylinder 1, 2, 3, 4)
17 FOG Fog Lamp Micro Relay
5-98
ProCarManuals.com

Fuses Usage
18 HDLP-LH Driver’s Side Headlamp
19 WIPER Wiper Mini Relay
20 HORN Horn Micro Relay
21 PREM AUDIOEntertainment, Premium Radio
Amplier
22 ABSAnti-Lock Brake System,
Traction Control Module
23 RR DEFOG Rear Defog Mini Relay
38 RUN/CRANK Ignition 1 Mini Relay
39 IP BATT1 Body Control Module
40 ABSAnti-Lock Brake System,
Traction Control Module
41 IP BATT2 Body Control Module
42 EPS2 Electric Power Steering
43 EPS1 Electric Power Steering
45 COOLING
FANCooling Fan Mini Relay
46 CRANKPowertrain Control Module
Mini RelayFuses Usage
47 IP BATT 1A Body Control Module
48 RUN (IGN 3) Body Control Module
Relays Usage
24 A/C Air Conditioning Clutch
25 HORN Horn
26 FOG LAMP Fog Lamps
28 RUN/CRANK Body Control Module
30 COOLING
FANEngine Cooling Fan
31 PCM CONT ECM
32 WIPER1 Wiper System
33 WIPER2 Wiper System
34 REAR DEFOG Rear Window Defroster
Diodes Usage
35 A/C Air Conditioning Diode
37 WIPER Wiper Diode
5-99
ProCarManuals.com

M
Maintenance Schedule
Additional Required Services........................... 6-6
At Each Fuel Fill.........................................6-10
At Least Once a Month................................6-10
At Least Once a Year..................................6-11
Introduction.................................................. 6-2
Maintenance Footnotes.................................. 6-8
Maintenance Record....................................6-18
Maintenance Requirements............................. 6-2
Normal Maintenance Replacement Parts.........6-16
Owner Checks and Services........................... 6-9
Recommended Fluids and Lubricants.............6-14
Scheduled Maintenance................................. 6-4
Using Your................................................... 6-2
Your Vehicle and the Environment................... 6-2
Maintenance When Trailer Towing.....................4-46
Making Turns.................................................4-43
Malfunction Indicator Light................................3-36
Manual Seats................................................... 1-2
Manual Transaxle............................................2-20
Fluid..........................................................5-25
Operation...................................................2-28
Manual Windows............................................2-15
Map Lamps....................................................3-18
Matching Transmitter(s) to Your Vehicle............... 2-7Message
Center.......................................................3-41
Change Engine Oil......................................3-43
Check Gage...............................................3-44
Cruise Control.............................................3-42
Error..........................................................3-45
Low Coolant Level Warning..........................3-43
Low Fuel Warning.......................................3-45
Low Traction...............................................3-42
Power Steering...........................................3-44
Service Vehicle...........................................3-45
Traction Off................................................3-42
Transaxle Fluid Cold....................................3-43
Transaxle Fluid Hot......................................3-42
Trunk Ajar Warning......................................3-44
Mirrors
Automatic Dimming Rearview with
Compass and Temperature Display.............2-40
Automatic Dimming Rearview with OnStar
®,
Compass and Temperature Display.............2-37
Manual Rearview Mirror................................2-36
Manual Rearview Mirror with OnStar
®.............2-36
Outside Convex Mirror.................................2-42
Outside Power Mirrors..................................2-42
Outside Remote Control Mirror......................2-42
MyGMLink.com................................................ 7-4
9
ProCarManuals.com

Theft-Deterrent System...................................... 2-6
Theft-Deterrent Systems...................................2-17
Passlock
®...................................................2-17
Tilt Wheel........................................................ 3-7
Tire Ination Check.........................................6-10
Tire Sidewall Labeling......................................5-60
Tire Size.......................................................5-62
Tire Terminology and Denitions........................5-63
Tires.............................................................5-58
Buying New Tires........................................5-70
Chains.......................................................5-74
Changing a Flat Tire....................................5-76
Compact Spare Tire.....................................5-86
If a Tire Goes Flat.......................................5-75
Ination - Tire Pressure................................5-66
Inspection and Rotation................................5-68
Uniform Tire Quality Grading.........................5-71
Wheel Alignment and Tire Balance.................5-72
Wheel Replacement.....................................5-72
When It Is Time for New Tires......................5-69
To Use the Engine Coolant Heater....................2-22
Top Strap......................................................1-39
Top Strap Anchor Location...............................1-41
Torque Lock...................................................2-32
Total Weight on Your Vehicle’s Tires..................4-42Towing
Recreational Vehicle.....................................4-31
Towing a Trailer..........................................4-39
Your Vehicle...............................................4-31
Traction
Control System (TCS).................................... 4-8
Low Message.............................................3-42
Traction Off Message......................................3-42
Trailer Brakes.................................................4-42
Transaxle
Fluid, Automatic...........................................5-24
Fluid Cold Message.....................................3-43
Fluid Hot Message......................................3-42
Fluid, Manual..............................................5-25
Transaxle Operation, Automatic.........................2-23
Transaxle Operation, Manual............................2-28
Transmission
Up-Shift Light..............................................3-32
Trunk............................................................2-12
Trunk Ajar Warning Message............................3-44
Turn and Lane-Change Signals.......................... 3-8
Turn Signal/Multifunction Lever........................... 3-8
Turn Signals When Towing a Trailer..................4-44
14
ProCarManuals.com
