air filter SATURN ION 2006 Owners Manual

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-6
Other Warning Devices...................................3-6
Horn .............................................................3-6
Tilt Wheel.....................................................3-7
Turn Signal/Multifunction Lever.........................3-7
Turn and Lane-Change Signals........................3-8
Headlamp High/Low-Beam Changer..................3-8
Flash-to-Pass.................................................3-8
Windshield Washer.........................................3-9
Windshield Wiper Lever...................................3-9
Cruise Control..............................................3-10
Headlamps..................................................3-13
Daytime Running Lamps (DRL).......................3-14
Automatic Headlamp System..........................3-14
Fog Lamps ..................................................3-15
Instrument Panel Brightness...........................3-15
Dome Lamp .................................................3-16
Entry Lighting...............................................3-16
Map Lamps .................................................3-16
Battery Run-Down Protection..........................3-16
Accessory Power Outlet(s).............................3-16
Ashtray(s) and Cigarette Lighter......................3-17Climate Controls............................................3-18
Climate Control System
(Without Air Conditioning)...........................3-18
Climate Control System
(With Air Conditioning)...............................3-20
Outlet Adjustment.........................................3-22
Passenger Compartment Air Filter...................3-23
Warning Lights, Gages, and Indicators............3-25
Instrument Panel Cluster................................3-26
Speedometer and Odometer...........................3-27
Trip Odometer..............................................3-27
Tachometer.................................................3-28
Safety Belt Reminder Light.............................3-29
Passenger Safety Belt Reminder Light.............3-29
Airbag Readiness Light..................................3-30
Passenger Airbag Status Indicator...................3-31
Battery Warning Light....................................3-33
Up-Shift Light...............................................3-33
Brake System Warning Light..........................3-34
Anti-Lock Brake System Warning Light.............3-35
Engine Coolant Temperature Gage..................3-36
Malfunction Indicator Lamp.............................3-36
Oil Pressure Light.........................................3-40
Passlock
®Warning Light................................3-40
Section 3 Instrument Panel
3-1
ProCarManuals.com

Passenger Compartment Air Filter
Passenger compartment air is routed through a
passenger compartment lter. The lter removes certain
particles from the air, including pollen and dust particles.
Reductions in airow, which may occur more quickly
in dusty areas, indicate that the lter needs to be
replaced early.
The lter should be replaced as part of routine
scheduled maintenance. SeeScheduled Maintenance on
page 6-4for replacement intervals. See your retailer for
details on changing the lter. To nd out what type of lter
to use, seeNormal Maintenance Replacement Parts
on page 6-15.
To access the passenger compartment air lter you
must go through the glove box.
1. Open the glove box and remove all articles from
the inside.2. Locate the doorstop insulators on each side of the
glove box and remove them.
3. Tilt the glove box door down by squeezing on each
side of the glove box until the door can be lowered
from its track. Lower the glove box door completely.
3-23
ProCarManuals.com

Service............................................................5-3
Accessories and Modications..........................5-3
California Proposition 65 Warning.....................5-3
Doing Your Own Service Work.........................5-4
Adding Equipment to the Outside
of Your Vehicle...........................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-5
Gasoline Specications....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuels in Foreign Countries...............................5-6
Filling the Tank..............................................5-7
Filling a Portable Fuel Container.......................5-9
Checking Things Under the Hood....................5-10
Hood Release..............................................5-10
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-15
Engine Oil Life System..................................5-20
Engine Air Cleaner/Filter................................5-22
Automatic Transaxle Fluid..............................5-24
Manual Transaxle Fluid..................................5-24
Hydraulic Clutch...........................................5-25
Engine Coolant.............................................5-25
Coolant Surge Tank Pressure Cap..................5-29
Engine Overheating.......................................5-29Cooling System............................................5-31
Windshield Washer Fluid................................5-38
Brakes........................................................5-39
Battery........................................................5-42
Jump Starting...............................................5-43
Headlamp Aiming...........................................5-48
Bulb Replacement..........................................5-48
Halogen Bulbs..............................................5-48
Headlamps (Coupe)......................................5-49
Headlamps (Sedan)......................................5-50
Front Turn Signal, Parking and Daytime
Running Lamps (DRL) (Coupe)...................5-52
Front Turn Signal, Parking and Daytime
Running Lamps (DRL) (Sedan)....................5-53
Center High-Mounted Stoplamp (CHMSL).........5-54
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps.........................................5-54
Replacement Bulbs.......................................5-55
Windshield Wiper Blade Replacement..............5-56
Tires..............................................................5-57
Tire Sidewall Labeling...................................5-59
Tire Terminology and Denitions.....................5-62
Ination - Tire Pressure.................................5-64
Tire Inspection and Rotation...........................5-66
When It Is Time for New Tires.......................5-68
Buying New Tires.........................................5-68
Section 5 Service and Appearance Care
5-1
ProCarManuals.com

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
B. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-15.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-15.
D. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-39andHydraulic Clutch
on page 5-25.E. Engine Compartment Fuse Block. SeeEngine
Compartment Fuse Block on page 5-102.
F. Remote Positive (+) Terminal. SeeJump Starting on
page 5-43.
G. Engine Coolant Surge Tank. SeeEngine Coolant on
page 5-25.
H. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-38.
5-13
ProCarManuals.com

A. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-15.
B. Electric Engine Cooling Fan. SeeCooling System on
page 5-31.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-15.
D. Intercooler System Pressure Cap. SeeEngine
Coolant on page 5-25.
E. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-39andHydraulic Clutch
on page 5-25.
F. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
G. Engine Compartment Fuse Block. SeeEngine
Compartment Fuse Block on page 5-102.
H. Remote Positive (+) Terminal. SeeJump Starting on
page 5-43.
I. Engine Coolant Surge Tank. SeeCoolant Surge
Tank Pressure Cap on page 5-29.
J. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-38.Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop. See
Engine Compartment Overview on page 5-12for
the location of the engine oil dipstick.
1. Turn off the engine and give the oil several minutes
to drain back into the oil pan. If you do not do this,
the oil dipstick might not show the actual level.
2. Pull out the dipstick, clean it with a paper towel or
cloth and then push it back in all the way.
3. Pull out the dipstick again, keeping the tip down,
and check the level.
5-15
ProCarManuals.com

Engine Air Cleaner/Filter
Engine Air Cleaner/Filter Replacement
SeeEngine Compartment Overview on page 5-12for
the location of the engine air cleaner/lter.
2.2L L4 Engine shown, 2.4L L4 Engine similar
2.0L L4 Supercharged Engine
5-22
ProCarManuals.com

When to Inspect the Engine
Air Cleaner/Filter
Inspect the air cleaner/lter at the MaintenanceII
intervals and replace it at the rst oil change after each
50,000 mile (83 000 km) interval. SeeScheduled
Maintenance on page 6-4for more information. If you
are driving in dusty/dirty conditions, inspect the lter
at each engine oil change.
How to Inspect the Engine
Air Cleaner/Filter
To inspect the air cleaner/lter remove the lter from
the vehicle and lightly shake the lter to release
loose dust and dirt. If the lter remains caked with dirt,
a new lter is required.To inspect or replace the engine air cleaner/lter, do the
following:
1. Loosen the hose clamp that is on the inlet duct on
the cover and pull off the hose.
2. For vehicles equipped with the 2.2L L4 or 2.4L L4
engine, release the two clips and turn the cover
upward to unhook the hinges. For vehicles equipped
with the 2.0L L4 supercharged engine, remove
the three screws on the cover.
3. Pull the air cleaner/lter box cover out and remove
the air lter element from the air lter box. If the
element is dirty, you should replace it. If the element
is only dusty, it may be cleaned by blowing
compressed air through it from the clean side.
Make sure you are away from your engine
compartment when cleaning the air lter with
compressed air.
4. Wipe all dust from inside the housing and inspect
the air cleaner and air inlet tube for cracks, cuts
and deterioration. The air inlet tube must be
replaced if it is damaged.
5-23
ProCarManuals.com

Capacities and Specications
The following approximate capacities are given in English and metric conversions. SeeRecommended Fluids and
Lubricants on page 6-13for more information.
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134a 0.9 lbs 0.41 kg
Cooling System
2.0L L4 Supercharged Engine 7.4 qt 7.0 L
2.2L L4 Engine 6.8 qt 6.5 L
2.4L L4 Engine 7.2 qt 6.8 L
Intercooler System (2.0L L4 Supercharged) 2.0 qt 1.9 L
Engine Oil with Filter
2.0L L4 Supercharged Engine 6.0 qt 5.7 L
2.2L L4 Engine and 2.4L L4 Engine 5.0 qt 4.7 L
Fuel Tank 13.0 gal 49.2 L
Transaxle, Automatic 7.0 qt 6.6 L
Transaxle, Manual (Complete Drain and Rell)
2.2L L4 and 2.4L L4 Engines 1.7 qt 1.6 L
2.0L L4 Engine Supercharged 1.6 qt 1.5 L
Wheel Nut Torque 100 lb ft 140Y
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
5-109
ProCarManuals.com

Scheduled Maintenance
Service MaintenanceIMaintenanceII
Change engine oil and lter. SeeEngine Oil on page 5-15. Reset oil life system.
SeeEngine Oil Life System on page 5-20.An Emission Control Service.••
Visually check for any leaks or damage.See footnote (j).••
Inspect engine air cleaner lter. If necessary, replace lter. SeeEngine
Air Cleaner/Filter on page 5-22.See footnote (l).•
Rotate tires and check ination pressures and wear. SeeTire Inspection and
Rotation on page 5-66and “Tire Wear Inspection” inAt Least Once a Month
on page 6-10.••
Inspect brake system.See footnote (a).••
Check engine coolant and windshield washer uid levels. If you have the
2.0L L4 supercharged engine, check intercooler uid level. Add uid as needed.••
Perform any needed additional services. See “Additional Required Services”
in this section.••
Inspect suspension and steering components.See footnote (b).•
Inspect engine cooling system.See footnote (c).•
Inspect wiper blades.See footnote (d).•
Inspect restraint system components.See footnote (e).•
Lubricate body components.See footnote (f).•
Replace passenger compartment air lter.See footnote (k).•
Inspect throttle system.See footnote (g).•
6-5
ProCarManuals.com

Additional Required Services
The following services should be performed at the rst maintenance service (IorII) after the indicated miles (kilometers)
shown for each item.
Additional Required Services
Service and Miles (Kilometers)25,000
(40 000)50,000
(80 000)75,000
(120 000)100,000
(160 000)125,000
(200 000)150,000
(240 000)
Inspect fuel system for damage
or leaks.• •••••
Inspect exhaust system for loose or
damaged components.• •••••
Replace engine air cleaner lter. See
Engine Air Cleaner/Filter on page 5-22.•••
Change automatic transaxle uid
(severe service).See footnote (h).•••
Change automatic transaxle uid
(normal service).•
Replace spark plugs.An Emission
Control Service.•
6-6
ProCarManuals.com
