SATURN OUTLOOK 2008 Owners Manual

Removing the Spare Tire and Tools
The tools needed to remove the spare tire are located
in the storage compartment on the driver side, at
the rear of the vehicle.
1. Open the jack storage compartment by squeezing
down on the latch tab and pulling the cover off.
A. Tool Bag
B. Wing Bolt
C. Jack
2. Remove the wing bolt (B) by turning it
counterclockwise3. Push the jack (C) up out of the holding bracket.
4. Turn the jack on its side, with the bottom facing
toward you.
5. Pull the jack straight out, bottom rst.
The tools you will be using include the jack (A) and lug
wrench (B).
5-85
ProCarManuals.com

Removing the Spare Tire
The compact spare tire is located under the vehicle, in
front of the rear bumper. SeeCompact Spare Tire on
page 5-100for more information about the compact
spare.
A. Rear Convenience
Center
B. Lug wrench
C. Storage
Compartment
Cap HoleD. Hoist Shaft
E. Compact Spare Tire
F. Retainer
G. Hoist Shaft
Assembly1. Open the storage compartment door of the
convenience center that is nearest the liftgate.
2. Move the carpet cutout that is located through the
hole of the storage compartment.
3. Attach the lug wrench into the hoist shaft.
4. Turn the lug wrench counterclockwise to lower
the spare tire to the ground. Continue turning
the wrench until the spare tire can be pulled out
from under the vehicle.
5. Tilt the retainer and slip it through the wheel
opening to remove the spare tire from the cable.
5-86
ProCarManuals.com

6. Turn the wrench clockwise to raise the cable back
up after removing the spare tire.
Do not store a full-size or a at road tire under the
vehicle. SeeStoring a Flat or Spare Tire and
Tools on page 5-96.
To continue changing the at tire, seeRemoving the
Flat Tire and Installing the Spare Tire on page 5-88.
If the spare tire will not lower, the secondary latch could
be engaged.Do the following to check the cable:
1. Check under the vehicle to see if the cable is
visible.
2. If it is not visible, seeSecondary Latch System on
page 5-93.
If it is visible, rst try to tighten the cable by turning
the lug wrench clockwise until you hear two clicks or
feel it skip twice. You cannot over-tighten the cable.
3. Loosen the cable by turning the wrench
counterclockwise three or four turns.
4. If the spare tire did lower to the ground, continue
with Step 5 under “Removing the Spare Tire” listed
previously.
5. If you still cannot lower the spare tire to the ground,
seeSecondary Latch System on page 5-93.
5-87
ProCarManuals.com

Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-84for more information.
2. If the vehicle has a wheel cover, loosen the plastic
nut caps with the lug wrench. They will not come
off. Then, using the at end of the lug wrench,
pry along the edge of the cover until it comes off.
Be careful; the edges may be sharp. Do not
try to remove the cover with your bare hands.
Store the wheel cover securely in the rear of the
vehicle until you have the at tire repaired or
replaced.
If your vehicle has aluminum wheels, remove the
wheel nut caps using the lug wrench.3. Loosen the wheel nuts — but do not remove
them — using the lug wrench. For wheels with
a wheel lock key, use the wheel lock key between
the lock nut and lug wrench.
Notice:If your vehicle has wheel locks and an
impact wrench is used to remove the wheel nuts,
the lock nut or wheel lock key could be damaged.
Do not use an impact wrench to remove the
wheel nuts if your vehicle has wheel locks.
5-88
ProCarManuals.com

4. To identify the appropriate jacking location, nd the
V–shaped locating notches in the molding.
Notice:If a jack is used to raise the vehicle
without positioning it correctly, your vehicle could
be damaged. When raising your vehicle on a jack,
avoid contact with the rear axle control arms.
5. Do not raise the vehicle yet. Put the compact spare
tire near you.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
6. Attach the lug wrench to the jack, and turn
the wrench clockwise to raise the jack head
3 inches (7.6 cm).
5-89
ProCarManuals.com

7. Place the jack under the vehicle as identied in
Step 3. Raise the vehicle by turning the lug wrench
clockwise in the jack. Raise the vehicle far enough
off the ground so that there is enough room for the
spare tire to t under the wheel well.
8. Remove all the wheel nuts and the at tire.9. Remove the spare tire heat shield by pulling the
rubber latch. Store the spare tire heat shield. See
Storing a Flat or Spare Tire and Tools on page 5-96
for more information.
5-90
ProCarManuals.com

{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
In an emergency, you can use a cloth or a
paper towel to do this; but be sure to use a
scraper or wire brush later, if needed, to get
all the rust or dirt off. SeeChanging a Flat
Tire on page 5-84.
{CAUTION:
Never use oil or grease on bolts or nuts.
Because the nuts might come loose. The
vehicle’s wheel could fall off, causing a crash.10. Remove any rust or dirt
from the wheel bolts,
mounting surfaces,
and spare wheel.
11. Place the spare tire on the wheel mounting surface.
12. Put the nuts on by hand by turning the clockwise
until the wheel is held against the mounting surface.
Make sure the rounded end is toward the wheel.
13. Lower the vehicle by attaching the lug wrench to
the jack and turning the wrench counterclockwise.
Lower the jack completely.
5-91
ProCarManuals.com

{CAUTION:
Incorrect or improperly tightened wheel nuts
can cause the wheel to come loose and even
come off. This could lead to a crash. If you have
to replace them, be sure to get new original
equipment wheel nuts. Stop somewhere as
soon as you can and have the nuts tightened
with a torque wrench to the proper torque
specication. SeeCapacities and Specifications
on page 5-120for wheel nut torque
specication.
Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-120for the wheel
nut torque specication.14. Tighten the wheel nuts
rmly in a crisscross
sequence, as shown.
Notice:Wheel covers will not t on your vehicle’s
compact spare. If you try to put a wheel cover
on the compact spare, the cover or the spare
could be damaged.
5-92
ProCarManuals.com

Secondary Latch System
Your vehicle has an underbody mounted tire hoist
assembly that has a secondary latch system. It is
designed to stop the compact spare tire from suddenly
falling off your vehicle if the cable holding the spare tire
is damaged. For the secondary latch to work, the tire
must be stowed with the valve stem pointing down. See
Storing a Flat or Spare Tire and Tools on page 5-96for
instructions on storing the spare tire correctly.
{CAUTION:
Before beginning this procedure read all the
instructions. Failure to read and follow the
instructions could damage the hoist assembly
and you and others could get hurt. Read and
follow the instructions listed next.To release the spare tire from the secondary latch:
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack.
If the spare tire does not slide off the jack
completely, make sure no one is behind you
or on either side of you as you pull the jack
out from the under spare.
1. If the cable is not visible, start this procedure at
Step 3.
5-93
ProCarManuals.com

2. Turn the lug wrench counterclockwise until
approximately 6 inches (15 cm) of cable is exposed.
3. Attach the lug wrench to the jack and raise the jack
at least 10 turns.
4. Place the jack under the vehicle, ahead of the rear
bumper. Position the center lift point of the jack
under the center of the spare tire.
5. Turn the lug wrench clockwise to raise the jack until
it lifts the secondary latch spring.6. Keep raising the jack until the spare tire stops
moving upward and is held rmly in place. This lets
you know that the secondary latch has released and
the spare tire is balancing on the jack.
7. Lower the jack by turning the lug wrench
counterclockwise. Keep lowering the jack until
the spare tire slides off the jack. All-Wheel-Drive Vehicle shown
5-94
