trunk release SATURN SKY 2007 Owners Manual

Remote Keyless Entry (RKE)
System Operation
The vehicle’s doors
can be locked and
unlocked, and the trunk
can be unlatched
from about 3 feet (1 m)
up to 60 feet (18 m)
away with the Remote
Keyless Entry (RKE)
transmitter.
Q(Lock):Press the lock button to lock all the
doors. If enabled through the Driver Information
Center (DIC), the parking lamps may ash
once and the horn may chirp to indicate
locking has occurred. See “LOCK HORN” under
DIC Vehicle Personalization on page 152.
"(Unlock):Press the unlock button one time
to unlock the driver’s door. Press the unlock button
again within ve seconds to unlock the other
door. The interior lamps will come on and stay on
for 20 seconds or until the ignition is turned on.
If enabled through the DIC, the parking lamps will
ash once to indicate unlocking has occurred.
See “UNLOCK HORN” underDIC Vehicle
Personalization on page 152.
V(Trunk Release):Press and hold this
button for approximately one second to release
the trunk lid. The trunk release will only work if
the ignition is off or the vehicle speed is less
than 2 mph (3 k/h).
63
ProCarManuals.com

Battery Replacement
Under normal use, the battery in the RKE
transmitter should last about four years.
If the battery is weak the transmitter will not work
within its normal range. It is probably time to
change the battery if you have to be very close
to the vehicle before the transmitter works.
Notice:When replacing the battery, use
care not to touch any of the circuitry.
Static from your body transferred to these
surfaces may damage the transmitter.
To replace the battery, do the following:
1. Insert a at object with a thin edge into the
notch, located below the trunk release
button, and pry the front and back apart.
2. Remove the old battery, but do not use a
metal object to do this.
3. Slide the new battery into the transmitter with
the positive side of the battery facing up. Use
a type CR2032 battery, or equivalent type.
4. Snap the front and the back of the transmitter
together.
5. Test the operation of the transmitter with
the vehicle.
65
ProCarManuals.com

Automatic Door Lock
If your vehicle has power door locks, the doors will
automatically lock when the shift lever is moved
out of PARK (P) for a vehicle with an automatic
transmission. For a vehicle with a manual
transmission, the speed must be greater than
5 mph (8 km/h).
The automatic door locking feature cannot be
disabled.
Automatic Door Unlock
If your vehicle has an automatic transmission and
power door locks, the doors with automatically
unlock when the shift lever is moved into
PARK (P).
If your vehicle has a manual transmission and
power door locks, the doors will automatically
unlock when the key is removed from the ignition.The automatic unlock feature can be disabled or
programmed in different ways if the vehicle has
an automatic transmission. SeeDIC Vehicle
Personalization on page 152for more information.
Trunk
To release the trunk lid use either the Remote
Keyless Entry (RKE) transmitter, or see “Remote
Trunk Release” following.
{CAUTION:
It can be dangerous to drive with
the trunk lid open because carbon
monoxide (CO) gas can come into your
vehicle. You cannot see or smell CO.
CAUTION: (Continued)
68
ProCarManuals.com

CAUTION: (Continued)
It can cause unconsciousness and even
death. If you must drive with the trunk
lid open or if electrical wiring or other
cable connections must pass through
the seal between the body and the
trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle.
See Climate Control System.
If you have air outlets on or under
the instrument panel, open them all
the way.
SeeEngine Exhaust on page 91.
Remote Trunk Release
To open the trunk from
inside the vehicle, press
the remote trunk
release button located
in the glovebox.
The remote trunk release will only work when
either the ignition is off or in ACC, the parking
brake is engaged, or the vehicle speed is less
than 2 mph (3 km/h).
69
ProCarManuals.com

Emergency Trunk Release HandleNotice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it
could damage the handle. The emergency
trunk release handle is only intended to aid a
person trapped in a latched trunk, enabling
them to open the trunk from the inside.
There is a glow-in-the-dark emergency trunk
release handle located inside the trunk on
the driver’s side. This handle will glow following
exposure to light. If someone is locked in the trunk,
they can pull the release handle and push the
trunk lid open from the inside to open the trunk.
70
ProCarManuals.com

If the system is armed and the trunk is opened
using the trunk release button on the transmitter,
the system will temporarily disarm itself and re-arm
when the trunk has been closed. This allows you to
exit the vehicle, lock the doors using the transmitter,
or open the trunk using the transmitter without
having to disarm and re-arm the system.
Once the system is disarmed, the security light will
stop ashing.
How the System Alarm is Activated
If the system is armed, it can be activated by:
Opening the driver’s door or trunk. This causes
a ten second pre-alarm chirping noise followed
by the horn sounding and lights ashing for
30 seconds.
Opening a passenger’s door. This immediately
causes a full alarm of the horn sounding and
lights ashing for 30 seconds.
After the 30 second alarm ends, the system will
re-arm itself.
How to Turn Off the System Alarm
To turn off the system alarm, do one of the
following:
Press the lock button on the remote keyless
entry transmitter. The system will then
re-arm itself.
Press the unlock button on the remote keyless
entry transmitter. This will also disarm the
system.
Insert the key in the ignition and turn it on.
This will also disarm the system.
How to Detect a Tamper Condition
If you hear three chirps when you press the
unlock, lock, or trunk release buttons on the
remote keyless transmitter, it means that
the content theft security system alarm was
activated previously.
74
ProCarManuals.com

Center Console Storage Area
There is also an upright center console storage
area between the seatbacks. To open the storage
area, press and release the button near the top
so it extends out. Then, turn the button in
either direction to unlatch the lid and pull the
console lid down. Press the release button back
in after you close the lid.
Convertible Top
For care and cleaning of the convertible top,
seeConvertible Top on page 320under “Service
and Appearance Care”. High pressure car
washes may cause water to enter the vehicle.
The following procedures explain the proper
operation of the manual convertible top.
The parts of the manual convertible top that are
used when lowering and raising it are:
A. Front Edge
B. Side EdgeC. Rear Buttresses
D. Trunk
100
ProCarManuals.com

Lowering the Manual Convertible Top
1. Park on a level surface and set the parking
brake. Shift an automatic transmission into
PARK (P). Shift a manual transmission
into FIRST (1) or REVERSE (R).
2. Make sure the ignition is turned off.
3. Push the trunk release button located in
the glove box, or on the remote keyless
entry, if equipped.
4. Lift the trunk.
5. The convertible top front latch, located above
the inside rearview mirror, must be unlatched.
Pull the latch down and turn it counterclockwise
to unlatch it.
Leave the latch open and turned to prevent
damage.
6. Pull rearward on the side edge (B) of the
convertible top and pull it off of the windshield
frame.
7. Push the convertible top down into the
trunk (D).
102
ProCarManuals.com

8. After the top is stored, apply one even push,
as shown, on the convertible top to ensure that
the top is fully retracted and securely stored.
9. Close the trunk (D) by pressing down on it
with a swift, rm motion.
Do not operate rear defogger when convertible
top is down.A clear Mylar
®protective lm has been installed
at the factory on the trunk lid surface under the
convertible top buttresses. This lm is designed
to help prevent paint damage to the trunk lid.
Do not remove this protective lm. It is intended to
remain permanently affixed to the trunk lid surface.
Raising the Manual Convertible Top
1. Park on a level surface, set the parking brake
rmly and shift an automatic transmission into
PARK (P). Shift a manual transmission into
FIRST (1) or REVERSE (R).
2. Make sure the ignition is turned off, and lower
the windows.
3. Push the trunk release button located in the
glove box, or on the remote keyless entry,
if equipped.
4. Lift the trunk.
103
ProCarManuals.com

The main components of your instrument panel are the following:
A. Side Window Outlets. SeeClimate Control
System on page 122.
B. Air Outlets. SeeOutlet Adjustment on page 126.
C. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 111.
D. Cruise Control Buttons (If Equipped).
SeeCruise Control on page 115.
E. Instrument Panel Cluster. SeeInstrument
Panel Cluster on page 128.
F. Audio Steering Wheel Controls (If Equipped).
SeeAudio Steering Wheel Controls on
page 188.
G. Hazard Warning Flashers Button. SeeHazard
Warning Flashers on page 110.
H. Fog Lamp Button. SeeFog Lamps on page 120.
I. Instrument Panel Brightness Control. See
Instrument Panel Brightness on page 120.
J. Driver Information Center (DIC) Controls. See
Driver Information Center (DIC) on page 144.
K. Horn. SeeHorn on page 110.
L. Windshield Wiper/Washer Controls. See
Windshield Wipers on page 113and
Windshield Washer on page 114.M. Climate Controls. SeeClimate Control System
on page 122.
N. Passenger Air Bag Status Indicator. See
Passenger Airbag Status Indicator on page 131.
O. Shift Lever. SeeManual Transmission
Operation on page 85. SeeAutomatic
Transmission Operation on page 82
(If Equipped).
P. Parking Brake Lever. SeeParking Brake
on page 86.
Q. Audio System. SeeAudio System(s) on
page 158.
R. Electronic Stability Control/Traction Control
System Button. SeeElectronic Stability Control
on page 201.
S. Cigarette Lighter (If Equipped). Accessory
Power Outlet (If Equipped). SeeAshtray(s) and
Cigarette Lighter on page 122andAccessory
Power Outlet(s) on page 121.
T. Cupholder. SeeCupholder(s) on page 99.
U. Trunk Release. SeeTrunk on page 68.
V. Glove Box. SeeGlove Box on page 99.
109
