SATURN SKY 2008 Repair Manual

Matching Transmitter(s) to Your Vehicle
Each RKE transmitter is uniquely coded to prevent
another transmitter from unlocking the vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer/retailer. Remember
to bring any additional transmitters so they can also be
re-coded to match the new transmitter. Once your
dealer/retailer has coded the new transmitter, the lost
transmitter cannot unlock the vehicle. The vehicle
can have a maximum of four transmitters coded to it.
Battery Replacement
Under normal use, the battery in the RKE transmitter
should last about four years.
If the battery is weak the transmitter will not work within
its normal range. It is probably time to change the
battery if you have to be very close to the vehicle before
the transmitter works.
Notice:When replacing the battery, use care not to
touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.To replace the battery do the following:
1. Insert a at object with a thin edge into the notch,
located below the trunk release button, and pry the
front and back apart.
2. Remove the old battery, but do not use a metal
object to do this.
3. Slide the new battery into the transmitter with the
positive side of the battery facing up. Use a type
CR2032 battery, or equivalent type.
4. Snap the front and the back of the transmitter
together.
5. Test the operation of the transmitter with the
vehicle.
2-5
ProCarManuals.com

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. You increase the chance
of being thrown out of the vehicle in a
crash if the doors are not locked. So, wear
safety belts properly and lock the doors
whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.There are several ways to lock and unlock the vehicle.
From the outside, turn the key in the driver’s door
lock cylinder briey counterclockwise to unlock the
driver’s door. Turn and hold it to unlock all the doors.
You can also use the remote keyless entry transmitter.
From the inside use the manual or power door locks.
Power Door Locks
You can use the Remote Keyless Entry (RKE)
transmitter to lock and unlock the doors from inside
or outside the vehicle. SeeRemote Keyless Entry (RKE)
System Operation on page 2-4for more information.
On vehicles with power door locks, the switches
are located on the doors.
Q(Lock):Press to lock all doors.
K(Unlock):Press to unlock all doors.
2-6
ProCarManuals.com

Delayed Locking
If your vehicle has power door locks, it will have the
delayed locking feature. This feature delays the actual
locking of the doors when the Remote Keyless
Entry (RKE) transmitter is used to lock the vehicle.
If any door is open when locking the vehicle using the
RKE transmitter, three chimes will sound signaling
that the delayed locking feature is active. Five seconds
after the last door is closed, both doors will lock and
the parking lamps will ash. To cancel the delay
and lock the doors immediately, press the lock button
on the RKE a second time.
If the key is in the ignition, this feature will not lock
the doors.
Automatic Door Lock
The vehicle’s doors are programmed to lock when the
shift lever is moved into a forward gear.
If someone needs to get in or out of the vehicle after
the doors have been locked, place the shift lever
into PARK (P). You may also unlock all doors using the
power door lock switch or unlock one door using the
inside manual door lock.
The automatic door lock feature cannot be disabled.
Programmable Automatic Door
Unlock
The vehicle’s doors are programmed from the factory to
unlock when the shift lever is moved into PARK (P).
On vehicles with a Driver Information Center (DIC),
there are different programming options for unlocking the
doors automatically. SeeDIC Vehicle Personalization
on page 3-45.
2-7
ProCarManuals.com

Lockout Protection
The lockout protection feature makes it more difficult to
lock the key in the vehicle. If the driver’s door is
open while the key is in the ignition, the door cannot be
locked with the power door lock switch.
This feature cannot guarantee that you will never be
locked out of the vehicle. If the key is not left in
the ignition, or, if the manual door lock is used,
the key could still be locked inside the vehicle.
Always remember to take the key with you.
Trunk
To release the trunk lid use either the Remote Keyless
Entry (RKE) transmitter, or see “Remote Trunk
Release” following.
To close the trunk, push down rmly from the rear
center of the trunk lid.
{CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You cannot see or
smell CO. It can cause unconsciousness and
even death. If you must drive with the trunk lid
open or if electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select the
control setting that will force outside air
into your vehicle. See Climate Control
System.
If you have air outlets on or under the
instrument panel, open them all the way.
SeeEngine Exhaust on page 2-27.
2-8
ProCarManuals.com

Remote Trunk Release
To open the trunk from
inside the vehicle, press
the remote trunk release
button located in the
glovebox.
The remote trunk release will only work when either the
ignition is off or in ACC/ACCESSORY, the parking
brake is engaged, or the vehicle speed is less than
2 mph (3 km/h).
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk release
handle as a tie-down or anchor point when securing
items in the trunk as it could damage the handle.
The emergency trunk release handle is only
intended to aid a person trapped in a latched trunk,
enabling them to open the trunk from the inside.
There is a glow-in-the-dark emergency trunk release
handle located inside the trunk on the driver’s side.
This handle will glow following exposure to light.
If someone is locked in the trunk, they can pull the
release handle and push the trunk lid open from
the inside to open the trunk.
2-9
ProCarManuals.com

Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome by the extreme heat and
suffer permanent injuries or even death from
heat stroke. Never leave a child, a helpless
adult, or a pet alone in a vehicle, especially with
the windows closed in warm or hot weather.
2-10
ProCarManuals.com

Power Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome from extreme heat in
warm or hot weather and suffer permanent
injuries or even death from heat stroke.
Leaving children in a vehicle with the ignition
key is dangerous for many reasons, children or
others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
The windows will function with the keys in the
ignition and they could be seriously injured or
killed if caught in the path of a closing window.
Do not leave keys in a vehicle with children.
When there are children in the rear seat use the
window lockout button to prevent unintentional
operation of the windows.On vehicles with power
windows, the switches on
the driver’s door armrest
control both windows.
The passenger’s door has a window switch that controls
that window. Press the front of the switch to open the
window. Pull the switch up to close it.
2-11
ProCarManuals.com

Express-Down Window
Windows with an express-down feature allow the
window to be lowered fully without pressing and holding
the switch. Press the front of the switch to the rst
position, and the window opens a small amount.
Press the switch down fully and the window goes all the
way down.
To stop the window while it is lowering, pull up the front
of the switch.
Sun Visors
To use the sun visor(s), pull the edge of the visor
nearest to the windshield toward you.
Visor Vanity Mirror
Your vehicle may have a driver’s side vanity mirror.
Swing down the sun visor and slide the cover to expose
the mirror.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft-deterrent
features, we know that nothing we put on it can make it
impossible to steal.
Content Theft-Deterrent
Your vehicle may have a content theft-deterrent alarm
system.
The security light, located
on the instrument panel
cluster, will turn on to
indicate that arming has
been initiated.
Once the system is armed, the security light will ash
once every three seconds.
If the security light is ashing twice per second, this
means that a door is open.
2-12
ProCarManuals.com

Arming the System
While the ignition is off, press the Remote Keyless
Entry (RKE) transmitter lock button, to arm the system.
The system will arm after either of these things occur:
Thirty seconds after all the doors are closed.
Sixty seconds with any door open.
If you press the lock button on the transmitter a second
time while all the doors are closed, the system will
arm immediately. The system arms in 60 seconds if a
door is open, or after the open door is closed.
If you do not want to arm the system, lock the car with
the manual door lock knobs.
Disarming the System
To disarm the system:
Press the unlock button on the RKE transmitter.
Turn the ignition on.
If the system is armed and the trunk is opened using
the trunk release button on the transmitter, the system
will temporarily disarm itself and re-arm when the
trunk has been closed. This allows you to exit the
vehicle, lock the doors using the transmitter, or open the
trunk using the transmitter without having to disarm
and re-arm the system.
Once the system is disarmed, the security light will stop
ashing.
How the System Alarm is Activated
To activate the system if it is armed:
Open the driver’s door or trunk. This causes a ten
second pre-alarm chirping noise followed by the
horn sounding and lights ashing for 30 seconds.
Open a passenger’s door. This immediately causes
a full alarm of the horn sounding and lights ashing
for 30 seconds.
After the 30 second alarm ends, the system will
re-arm itself.
How to Turn Off the System Alarm
To turn off the system alarm, do one of the following:
Press the lock button on the RKE transmitter.
The system will then re-arm itself.
Press the unlock button on the RKE transmitter.
This will also disarm the system.
Insert the key in the ignition and turn it on.
This will also disarm the system.
How to Detect a Tamper Condition
If you hear three chirps when you press the unlock, lock,
or trunk release buttons on the RKE transmitter, it means
that the content theft security system alarm was activated
previously.
2-13
ProCarManuals.com

PASS-Key®III+
The PASS-Key®III+ system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
PASS-Key
®III+ uses a radio frequency transponder in
the key that matches a decoder in your vehicle.
PASS-Key®III+ Operation
Your vehicle has PASS-Key®III+ (Personalized
Automotive Security System) theft-deterrent system.
PASS-Key
®III+ is a passive theft-deterrent system.
The system is automatically armed when the key
is removed from the ignition.
You do not have to manually arm or disarm the system.
The security light will come on if there is a problem
with arming or disarming the theft-deterrent system.
When the PASS-Key
®III+ system senses that someone
is using the wrong key, it prevents the vehicle from
starting. Anyone using a trial-and-error method to start
the vehicle will be discouraged because of the high
number of electrical key codes.
When trying to start the vehicle if the engine does not
start and the security light comes on, there may be
a problem with your theft-deterrent system. Turn the
ignition off and try again.
2-14
ProCarManuals.com
