SATURN VUE 2006 Owners Manual

Mirrors
Automatic Dimming Rearview
Mirror with OnStar
®, Compass
and Temperature Display
When on, an automatic dimming mirror automatically
dims to the proper level to minimize glare from
lights behind you after dark.
The mirror also includes a dual display in the upper
right corner of the mirror face. The compass reading
and the outside temperature will both appear in
the display at the same time.
P(On/Off):This is the on/off button.
Temperature and Compass Display
Press the on/off button, located to the far left, briey
to turn the comp/temp display on or off.
If the display reads CAL, the compass needs to be
calibrated. See the information following on calibration.To adjust between Fahrenheit and Celsius do
the following:
1. Press and hold the on/off button for approximately
four seconds until either a ashing °F, or °C appears.
2. Press the button again to change the display to the
desired unit of measurement. After approximately
four seconds of inactivity, the new unit will be locked
in and the compass/temperature display will return.
Automatic Dimming Mirror Operation
The automatic dimming mirror function is turned
on automatically each time the ignition is started.
To operate the automatic dimming mirror do the
following:
1. Make sure the green indicator light, located to the
left of the on/off button, is lit. If it’s not, press and
hold the on/off button for approximately six seconds
until the green light comes on, indicating that the
mirror is in automatic dimming mode.
2. Turn off the automatic dimming mirror function
by pressing and holding the on/off button for
approximately six seconds until the green indicator
light turns off.
2-29
ProCarManuals.com

Compass Calibration
The compass may need calibration from time to time.
In order to calibrate, CAL must be displayed in the mirror
compass windows. If CAL is not displayed, push in
the on/off button for approximately nine seconds or
until CAL is displayed.
The compass can be calibrated by driving the vehicle
in circles at 5 mph (8 km/h) or less until the display
reads a direction, or the word CAL disappears.
Compass Variance
The mirror is set in zone eight upon leaving the
factory. It will be necessary to adjust the compass to
compensate for compass variance if you live outside of
zone eight. Under certain circumstances, as during a
long distance cross-country trip, it will be necessary
to adjust for compass variance. Compass variance is
the difference between earth’s magnetic north and
true geographic north. If not adjusted to account
for compass variance, your compass could give
false readings.To adjust for compass variance do the following:
1. Find your current location and variance zone
number on the following zone map.
2. Press and hold the on/off button until a zone
number appears in the display. The compass is
now in zone mode.
3. Keep pressing the on/off button until the desired
zone number appears in the display. Release
the button. After approximately four seconds of
inactivity, the new zone number will be locked
in and the comp/temp display will return.
2-30
ProCarManuals.com

Cleaning the Mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.
Outside Power Mirrors
The outside power mirror
controls are located on the
driver’s side of the vehicle
next to the shift lever.
Move the selector switch to the left or right to choose
the mirror to be adjusted; then press the four-way control
pad to adjust the direction of the mirror.
Outside Convex Mirror
{CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
The passenger’s side mirror is convex. A convex
mirror’s surface is curved so more can be seen from
the driver’s seat. It also makes things appear farther
away than they really are.
2-31
ProCarManuals.com

OnStar®System
OnStar®uses several innovative technologies and live
advisors to provide you with a wide range of safety,
security, information, and convenience services.
If your airbags deploy, the system is designed to make
an automatic call to OnStar
®Emergency where we can
request emergency services be sent to your location.
If you lock your keys in the car, call OnStar
®at
1-888-4-ONSTAR and they can send a signal to
unlock your doors. If you need roadside assistance,
press the OnStar
®button and they can contact
Roadside Service for you.A complete OnStar
®Owner’s Guide and the Terms
and Conditions of the OnStar®Subscription Service
Agreement are included in the vehicle’s OnStar®
Subscriber Information packet located in your vehicle.
For more information, visit www.onstar.com or
www.onstar.ca, contact OnStar
®at 1-888-4-ONSTAR
(1-888-466-7827), or press the OnStar®button to speak
with an OnStar®advisor 24 hours a day, 7 days a week.
OnStar®Services
For new vehicles equipped with OnStar®, the
Safe & Sound Plan is included for one year from the
date of purchase. You can extend this plan beyond the
rst year, or upgrade to the Directions & Connections
®
Plan to meet your needs. For more information,
press the OnStar®button to speak to an advisor.
2-32
ProCarManuals.com

Safe & Sound Plan

Advanced Automatic Crash Notication
Automatic Notication of Airbag Deployment
Emergency Services
Roadside Assistance
Stolen Vehicle Location Assistance
AccidentAssist
Remote Door Unlock/Vehicle Alert
OnStar®Vehicle Diagnostics
OnStar®Hands-Free Calling
OnStar®Virtual Advisor
Directions & Connections®Plan

All Safe & Sound Plan Services
Driving Directions
RideAssist
Information and Convenience Services
OnStar®Hands-Free Calling
OnStar®Hands-Free Calling allows OnStar®subscribers
to make and receive calls using voice commands at
the touch of a button. Hands-Free Calling is fully
integrated into the vehicle, and may be used with
Pre-Paid Packages or linked to a cell phone through
OnStar
®Shared Minutes Plan. To nd out more, refer
to the OnStar®Owner’s Guide in the vehicle’s glove box,
visit www.onstar.com or www.onstar.ca, or speak with
an OnStar
®advisor by pressing the OnStar®button
or calling 1-888-4-ONSTAR (1-888-466-7827).
OnStar®Virtual Advisor
Your vehicle may have Virtual Advisor. It is a feature
of OnStar®Hands-Free Calling that uses your minutes
to access weather, local traffic reports, and stock
quotes. By pressing the phone button and giving a
few simple voice commands, you can browse through
the various topics. Customize your information prole
at www.myonstar.com. See the OnStar
®Owner’s Guide
for more information.
2-33
ProCarManuals.com

Storage Areas
Glove Box
To open the glove box, lift up on the lever.
Cupholder(s)
Your vehicle is equipped with a removable cupholder
liner and cupholder located inside the center console
storage area. To access, pull the cover towards the
rear of the vehicle. To remove the liner, pull it out
of the cupholder. To replace, push the liner back in.
To remove the cupholder, push the tab in near the
passenger’s seat and pull straight up. To replace,
slide the two tabs at the rear of the cupholder into
the slots at the rear of the center console and push
the cupholder gently into place. There is additional
storage underneath the cupholders. There are
two more cupholders located at rear of the center
console. Push button to access.
Floor Console Storage Area
Your vehicle may be equipped with a oor console
storage area. Push button to open.
Center Console Storage Area
Your vehicle has a center console storage area.
To access, slide the cover back towards the rear of
the vehicle. It is equipped with two accessory power
outlets. One is located inside the storage area and
another hidden under the cupholders. There is a
hole in the storage area for a cellphone wire to be
routed through.
Cargo Area
Your vehicle is equipped with a cargo area organizer,
which is located in the rear of the vehicle. This storage
space is designed to hold small items and includes
integrated storage bins.
2-34
ProCarManuals.com

Use the following procedure to access and assemble
the rear cargo organizer.
1. Pull up on the latch of the rear panel lid of the
cargo organizer to open it.
2. Lift the front of the cargo organizer and fold out
the end panels.3. Rotate the end panels forward and snap them into
the rear panel lid.
4. Pull the center divider out from the rear panel lid.
2-35
ProCarManuals.com

5. Rotate the center divider rearward and snap it into
the panel lid.
6. Reverse the above steps to stow the dividers and
close the cargo organizer.
Make sure to push rmly on the rear panel lid to
engage the latch of the organizer.
Roof Rack System
Your vehicle may be equipped with a roof rack system.
To adjust the crossrails, turn both knobs on each
side of the crossrail counterclockwise until it moves
freely. Once the crossrail is in place, turn both knobs
on each of side of the crossrail clockwise until it
is secure.
2-36
ProCarManuals.com

{CAUTION:
If you try to carry something on top of your
vehicle that is longer or wider than the luggage
carrier — like paneling, plywood, a mattress
and so forth — the wind can catch it as you
drive along. This can cause you to lose
control. What you are carrying could be
violently torn off, and this could cause you or
other drivers to have a collision, and of course
damage your vehicle. You may be able to carry
something like this inside. But, never carry
something longer or wider than the luggage
carrier on top of your vehicle.Notice:Loading cargo on the luggage carrier that
weighs more than 100 lbs (45 kg) or hangs over the
rear or sides of the vehicle may damage your vehicle.
Load cargo so that it rests on the slats as far forward
as possible and against the side rails, making sure to
fasten it securely.
Do not exceed the maximum vehicle capacity when
loading your vehicle. For more information on vehicle
capacity and loading, seeLoading Your Vehicle
on page 4-44.
To prevent damage or loss of cargo as you are driving,
check frequently to ensure your cargo is securely
fastened.
2-37
ProCarManuals.com

Sunroof
If the vehicle has an express-open sunroof, the controls
to operate it are located on the headliner above the
rearview mirror. The ignition must be in RUN or ACC to
operate the sunroof. SeeIgnition Positions on page 2-15.
To express-open the
sunroof glass panel and
sunshade, press the switch
rearward and release it.To stop the sunroof before it is completely open, press
the switch rearward again. The sunshade cannot be
closed with the sunroof open. To close the sunroof,
press forward on the switch until it stops. The sunshade
must be manually closed.
To put the sunroof in the vent position, pull down on the
front of the switch. Push up on the front of the switch
to close it. The sunshade must be manually opened and
closed when the sunroof is in the vent position.
2-38
ProCarManuals.com
