The following information will tell you how to use
the jack and change a tire.
Removing the Spare Tire and Tools
The tools you will need are located on the
driver’s side of the rear cargo area. To access the
tools, do the following:
1. Remove the
wing-bolt from
the jack.
2. Remove the jack and wheel wrench.
3. Remove the straps holding the bag containing
the wheel wrench. Then remove the wheel
wrench from the bag.
4. Fold out the socket portion of the wrench from
the handle.
387
ProCarManuals.com

To access the spare tire, do the following:
1. Lift the forward oor panel of the load oor
cargo organizer.2. Remove the forward oor panel of the load
oor cargo organizer and place it in the
vehicle while you are removing the spare tire.
388
ProCarManuals.com

5. Remove the wheel retainer bolt holding down
the spare tire by turning it counterclockwise.
6. Remove the compact spare tire. SeeCompact
Spare Tire on page 398for more information.The tools you will be using include the jack (A)
and wheel wrench (B).
390
ProCarManuals.com

Removing the Flat Tire and
Installing the Spare Tire
The wheel cover or hubcap needs to be removed
in order to reach the wheel bolts.
For steel wheels with full plastic covers and
aluminum wheels with large circular center caps,
do the following:
1. It is recommended that a safety check is done
before preceding. SeeChanging a Flat Tire
on page 386for more information.
2. Loosen all plastic
caps by turning the
wheel wrench
counterclockwise.
Do not try to remove
plastic caps from
the cover or
center cap.
3. Pull the cover or center cap away from the
wheel and place it in the trunk.When reinstalling full plastic covers or center
caps, tighten all the plastic caps hand snug, then
tighten with the wheel wrench an additional
one-quarter of a turn.
1. Use the wheel wrench to loosen all the wheel
nuts. Do not remove them yet.
2. Attach the wheel
wrench to the jack
bolt head and
rotate the wheel
wrench clockwise.
That will raise the lift
head a little.
391
ProCarManuals.com

3. Position the lift head at the jack location
nearest the at tire. Make sure all of the
jack lift head is touching the jacking ange
under the body. Do not place the jack under a
body panel. The lower body panel has an
arrow to aid in locating the jacking location.
4. Put the compact spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when
it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall.
To help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising
the vehicle.
392
ProCarManuals.com

8. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces and
spare wheel.
9. Place the compact spare tire on the
wheel-mounting surface.
{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose. The
vehicle’s wheel could fall off, causing a
serious accident.
10. Reinstall the wheel nuts. Tighten each nut by
hand until the wheel is held against the hub.11. Lower the vehicle by turning the jack handle
counterclockwise.
395
ProCarManuals.com

Storing a Flat or Spare Tire
and Tools
{CAUTION:
Storing a jack, a tire, or other equipment
in the passenger compartment of the
vehicle could cause injury. In a sudden
stop or collision, loose equipment could
strike someone. Store all these in the
proper place.
To store the at or spare tire and tools, do the
following:
1. Place the wheel wrench into the bag and use
the straps to secure the bag to the fully
collapsed jack.2. Install the jack in the
driver’s side panel of
the rear cargo
area and secure
with the wing bolt.
3. Remove the wheel stow rod from the upper
left side of the oor compartment.
397
ProCarManuals.com

4. Screw the threaded wheel stow rod onto the
spare tire bracket. The nal position of the
wheel stow rod must be rotated to the farthest
forward position so that the top of the rod
faces forward.
5. Reverse Steps 1 through 4 underRemoving
the Spare Tire and Tools on page 387to
replace the oor cargo organizer and lock
in place.
6. Place the at, or damaged tire, face down, on
the load oor with the threaded wheel stow
rod sticking up through the center hole of the
load oor and center hole of the wheel.
Vehicles equipped with the 3.5L V6 (L66)
engine and aluminum wheels, must remove the
center cap from the wheel prior to placing it on
the load oor. To remove the center cap, tap
the cap from the backside of the wheel, then
place the wheel on the load oor.
7. Place the wheel retainer bolt onto the wheel
stow rod and tighten.
The compact spare is for temporary use only.
Replace the compact spare tire with a full-size tire
as soon as you can.Compact Spare Tire
Although the compact spare tire was fully inated
when the vehicle was new, it can lose air after
a time. Check the ination pressure regularly.
It should be 60 psi (420 kPa).
After installing the compact spare on the vehicle,
stop as soon as possible and make sure the
spare tire is correctly inated. The compact spare
is made to perform well at speeds up to 65 mph
(105 km/h) for distances up to 3,000 miles
(5 000 km), so you can nish your trip and have
the full-size tire repaired or replaced at your
convenience. Of course, it is best to replace the
spare with a full-size tire as soon as possible.
The spare tire will last longer and be in good
shape in case it is needed again.
Notice:When the compact spare is installed,
do not take your vehicle through an automatic
car wash with guide rails. The compact
spare can get caught on the rails. That can
damage the tire and wheel, and maybe
other parts of your vehicle.
Do not use the compact spare on other vehicles.
398
ProCarManuals.com

And do not mix the compact spare tire or wheel
with other wheels or tires. They will not t.
Keep the spare tire and its wheel together.
Notice:Tire chains will not t your compact
spare. Using them can damage your vehicle
and can damage the chains too. Do not use tire
chains on your compact spare.
Appearance Care
Cleaning the Inside of Your Vehicle
Your vehicle’s interior will continue to look its
best if it is cleaned often. Although not always
visible, dust and dirt can accumulate on your
upholstery. Dirt can damage carpet, fabric, leather,
and plastic surfaces. Regular vacuuming is
recommended to remove particles from your
upholstery. It is important to keep your upholstery
from becoming and remaining heavily soiled.
Soils should be removed as quickly as possible.
Your vehicle’s interior may experience extremes
of heat that could cause stains to set rapidly.Lighter colored interiors may require more
frequent cleaning. Use care because newspapers
and garments that transfer color to your home
furnishings may also transfer color to your
vehicle’s interior.
When cleaning your vehicle’s interior, only use
cleaners specically designed for the surfaces
being cleaned. Permanent damage may result
from using cleaners on surfaces for which
they were not intended. Use glass cleaner only on
glass. Remove any accidental over-spray from
other surfaces immediately. To prevent over-spray,
apply cleaner directly to the cleaning cloth.
Notice:If you use abrasive cleaners when
cleaning glass surfaces on your vehicle, you
could scratch the glass and/or cause damage
to the rear window defogger. When cleaning
the glass on your vehicle, use only a soft cloth
and glass cleaner.
Many cleaners contain solvents that may become
concentrated in your vehicle’s breathing space.
Before using cleaners, read and adhere to all
safety instructions on the label. While cleaning your
vehicle’s interior, maintain adequate ventilation by
opening your vehicle’s doors and windows.
399
ProCarManuals.com

At Each Fuel Fill
It is important to perform these underhood checks
at each fuel ll.
Engine Oil Level Check
Check the engine oil level and add the proper oil
if necessary. SeeEngine Oil on page 318for
further details.
Notice:It is important to check the engine
oil regularly and keep it at the proper level.
Failure to keep the engine oil at the proper level
can cause damage to the engine not covered
by your warranty.
Engine Coolant Level Check
Check the engine coolant level and add
DEX-COOL®coolant mixture if necessary. See
Engine Coolant on page 331for further details.
Windshield Washer Fluid Level Check
Check the windshield washer uid level in
the windshield washer uid reservoir and add
the proper uid if necessary.
At Least Once a Month
Tire Ination Check
Inspect your vehicle’s tires and make sure they
are inated to the correct pressures. Do not forget
to check the spare tire. SeeInation - Tire
Pressure on page 374. Check to make sure the
spare tire is stored securely. SeeChanging a Flat
Tire on page 386.
Tire Wear Inspection
Tire rotation may be required for high mileage
highway drivers prior to the Engine Oil Life System
service notication. Check the tires for wear
and, if necessary, rotate the tires. SeeTire
Inspection and Rotation on page 375.
