Keys.............................................................. 95
Remote Keyless Entry (RKE) System.......... 96
Remote Keyless Entry (RKE) System
Operation................................................. 97
Doors and Locks........................................ 100
Door Locks................................................ 100
Power Door Locks..................................... 101
Delayed Locking........................................ 101
Programmable Automatic Door Locks........ 101
Rear Door Security Locks......................... 102
Lockout Protection..................................... 103
Liftgate...................................................... 103
Windows...................................................... 104
Power Windows........................................ 105
Sun Visors................................................ 106
Theft-Deterrent Systems............................. 107
Content Theft-Deterrent............................. 107
Passlock
®.................................................. 108Starting and Operating Your Vehicle......... 109
New Vehicle Break-In................................ 109
Ignition Positions....................................... 109
Starting the Engine.................................... 111
Engine Coolant Heater.............................. 113
Automatic Transaxle Operation.................. 114
Manual Transaxle Operation...................... 117
Parking Brake........................................... 119
Shifting Into Park (P)
(Automatic Transaxle)............................ 120
Shifting Out of Park (P)............................. 121
Parking Your Vehicle (Manual Transaxle) ... 122
Parking Over Things That Burn................. 122
Engine Exhaust......................................... 123
Running the Engine While Parked............. 124
Mirrors......................................................... 125
Automatic Dimming Rearview Mirror
with OnStar
®, Compass and
Temperature Display.............................. 125
Section 2 Features and Controls
93
ProCarManuals.com

Keys
{CAUTION:
Leaving children in a vehicle with the
ignition key is dangerous for many
reasons, children or others could be badly
injured or even killed. They could operate
the power windows or other controls or
even make the vehicle move. The windows
will function with the keys in the ignition
and they could be seriously injured or
killed if caught in the path of a closing
window. Do not leave the keys in a vehicle
with children.
95
ProCarManuals.com

When you want to open a rear door when the
security lock is on, do the following:
1. Unlock the door using the remote keyless entry
transmitter, the power door lock switch, or by
lifting the rear door manual lock.
2. Open the door from the outside.
To cancel the rear door security lock, do the
following:
1. Unlock the door and open it from the outside.
2. Insert the key into the lock and turn it
clockwise (right) for the driver’s side
and counterclockwise (left) for the
passenger’s side.
Lockout Protection
If you press the power door lock switch when the
key is in the ignition and any door is open, all
the doors will lock and then the driver’s door will
unlock. Be sure to remove the key from the ignition
when locking your vehicle.
If the remote keyless entry transmitter is used
to lock the doors while the key is in the ignition,
a chime will sound three times. All doors will
then lock.
Liftgate
{CAUTION:
It can be dangerous to drive with the
liftgate open because carbon monoxide
(CO) gas can come into your vehicle.
You cannot see or smell CO. It can cause
unconsciousness and even death. If you
must drive with the liftgate open or if
electrical wiring or other cable
connections must pass through the
seal between the body and the liftgate:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle. See
Climate Control System on page 155.
If you have air outlets on or under the
instrument panel, open them all the
way. SeeEngine Exhaust on page 123.
103
ProCarManuals.com

Use your remote keyless entry transmitter or
power door lock switches to unlock the liftgate.
To open the liftgate, lift the handle located in the
center of the liftgate.
Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by
the extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
104
ProCarManuals.com

Power Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome from
extreme heat in warm or hot weather and
suffer permanent injuries or even death
from heat stroke.
Leaving children in a vehicle with the
ignition key is dangerous for many
reasons, children or others could be badly
injured or even killed. They could operate
the power windows or other controls or
even make the vehicle move. The windows
will function with the keys in the ignition
and they could be seriously injured or
killed if caught in the path of a closing
window. Do not leave keys in a vehicle
with children.
CAUTION: (Continued)
CAUTION: (Continued)
When there are children in the rear seat
use the window lockout button to prevent
unintentional operation of the windows.
The window switches
are located on each
side of the shift lever
on the center console.
To lower a window, press the switch down.
To raise a window, pull the switch up.
The power windows operate when the ignition
is in RUN or ACC.
105
ProCarManuals.com

A window switch is also located on each rear
door. Press the bottom of the switch to lower the
window. Press the top of the switch to raise
the window.
Express-Down Window
The driver’s window switch has an express-down
feature that is labeled AUTO. This allows the
driver’s window to open fully without having
to continuously press the switch. Press the switch
to the second position and the driver’s window
will go all the way down. To stop the window
from lowering, lift the switch all the way up and
release it.
Window Lockout
The driver’s window switches also include a lockout
switch. Press the left side of the switch to prevent
rear passengers from using their window switches.
The driver can still control all the windows with the
lockout on. Press the right side of the window
lockout switch to return to normal window
operation.
Sun Visors
To block out glare swing the visors down or to
the side. The driver’s sun visor can be detached
from the center mount and slid along the rod
to block different areas of the front window.
Visor Vanity Mirrors
Your vehicle has covered visor vanity mirrors.
106
ProCarManuals.com

Engine Exhaust
{CAUTION:
Engine exhaust can kill. It contains the
gas carbon monoxide (CO), which you
cannot see or smell. It can cause
unconsciousness and death.
You might have exhaust coming in if:
The exhaust system sounds strange
or different.
Your vehicle gets rusty underneath.
Your vehicle was damaged in a
collision.
CAUTION: (Continued)
CAUTION: (Continued)

Your vehicle was damaged when
driving over high points on the road
or over road debris.
Repairs were not done correctly.
Your vehicle or the exhaust system
has been modied improperly.
If you ever suspect exhaust is coming into
your vehicle:
Drive it only with all the windows
down to blow out any CO; and
Have your vehicle xed immediately.
123
ProCarManuals.com

To adjust between Fahrenheit and Celsius, do the
following:
1. Press and hold the on/off button until either a
ashing °F or °C appears.
2. Press the button again to change the display
to the desired unit of measurement. After
approximately four seconds of inactivity, the
new unit will be locked in and the display
will return.
Compass Calibration
The compass may need calibration from time
to time.
In order to calibrate, CAL must be displayed in the
mirror compass windows. If CAL is not displayed,
push in the on/off button for approximately
nine seconds or until CAL is displayed.
The compass can be calibrated by driving the
vehicle in circles at 5 mph (8 km/h) or less until
the display reads a direction, or the word CAL
disappears.
Compass Variance
The mirror is set in zone eight upon leaving the
factory. It will be necessary to adjust the compass
to compensate for compass variance if you live
outside of zone eight. Under certain circumstances,
as during a long distance cross-country trip, it will
be necessary to adjust for compass variance.
Compass variance is the difference between earth’s
magnetic north and true geographic north. If not
adjusted to account for compass variance, your
compass could give false readings.
To adjust for compass variance do the following:
1. Find your current location and variance
zone number on the following zone map.
126
ProCarManuals.com

Instrument Panel Overview........................ 140
Hazard Warning Flashers.......................... 142
Horn.......................................................... 142
Tilt Wheel.................................................. 142
Turn Signal/Multifunction Lever.................. 143
Turn and Lane-Change Signals................. 143
Headlamp High/Low-Beam Changer.......... 144
Flash-to-Pass............................................ 144
Windshield Wipers..................................... 144
Windshield Washer.................................... 145
Rear Window Wiper/Washer...................... 146
Cruise Control........................................... 146
Headlamps................................................ 149
Daytime Running Lamps (DRL)................. 150
Automatic Headlamp System..................... 151
Fog Lamps................................................ 152
Interior Lamps........................................... 152
Instrument Panel Brightness...................... 152
Dome Lamp.............................................. 153
Entry Lighting............................................ 153
Map Lamps............................................... 153
Footwell Lamps......................................... 153
Battery Run-Down Protection..................... 154
Accessory Power Outlet(s)........................ 154
Cigarette Lighter........................................ 155Climate Controls......................................... 155
Climate Control System............................. 155
Outlet Adjustment...................................... 159
Passenger Compartment Air Filter............. 159
Warning Lights, Gages, and Indicators..... 161
Instrument Panel Cluster........................... 162
Speedometer and Odometer...................... 163
Trip Odometer........................................... 163
Tachometer............................................... 164
Safety Belt Reminder Light........................ 164
Passenger Safety Belt Reminder Light....... 165
Airbag Readiness Light............................. 165
Passenger Airbag Status Indicator............. 166
Battery Warning Light................................ 169
Up-Shift Light............................................ 169
Brake System Warning Light..................... 170
Anti-Lock Brake System Warning Light...... 171
Traction Control System (TCS)
Warning Light........................................ 172
Low Traction Light..................................... 173
Engine Coolant Temperature
Warning Light........................................ 173
Engine Coolant Temperature Gage............ 174
Low Coolant Warning Light....................... 174
Section 3 Instrument Panel
137
ProCarManuals.com

The main components of the instrument panel are the following:
A. Air Outlets. SeeClimate Control System on
page 155.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 143.
C. Cruise Control Buttons. SeeCruise Control on
page 146.
D. Horn. SeeHorn on page 142.
E. Instrument Panel Cluster. SeeInstrument
Panel Cluster on page 162.
F. Audio Steering Wheel Controls. SeeAudio
Steering Wheel Controls on page 223.
G. Windshield Wiper Lever. SeeWindshield
Wipers on page 144.
H. Instrument Panel Brightness Control. See
Instrument Panel Brightness on page 152.
I. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 142.
J. Passenger Air Bag Status Indicator. See
Passenger Airbag Status Indicator on page 166.K. Fog Lamp Button (If Equipped) or Traction
Control System Button (If Equipped). SeeFog
Lamps on page 152orTraction Control
System (TCS) on page 238.
L. Audio System. SeeAudio System(s) on
page 182.
M. Hood Release. SeeHood Release on
page 313.
N. Tilt Wheel Lever. SeeTilt Wheel on page 142.
O. Power Mirror Control. SeeOutside Power
Mirrors on page 127.
P. Power Window Switches. SeePower Windows
on page 105.
Q. Automatic Transaxle Shift Lever. SeeAutomatic
Transaxle Operation on page 114.
R. Heated Seats Buttons or Footwell Lamps
(If Equipped). SeeHeated Seats on page 11or
Footwell Lamps on page 153.
S. Climate Control. SeeClimate Control System
on page 155.
T. Glove Box. SeeGlove Box on page 132.
141
ProCarManuals.com
