ignition SATURN VUE 2007 Owner's Guide

)(Bi-Level):This mode directs air to the
instrument panel outlets and to the oor outlets.
Cooler air is directed to the upper outlets and
warmer air to the oor outlets.
6(Floor):This mode directs most of the air to
the oor outlets with some air directed to the
windshield.
When you select this mode, the system will turn
recirculation mode off and run the air conditioning
compressor unless the outside air is at or below
freezing. Recirculation mode cannot be selected
while in oor mode. This helps prevent window
fogging and moisture building up within the cabin.
The right knob can also be used to select defog or
defrost mode. See “Defogging and Defrosting”
later in this section.
A(Fan):Turn the left knob clockwise to increase
the fan speed or counterclockwise to decrease
the fan speed. To turn the fan off, turn the left knob
all the way counterclockwise. In any setting
other than off, the fan will run continuously with
the ignition on. The fan must be turned on to run
the air conditioning compressor. There will besome airow noticeable from the various outlets
when driving, even with the fan in the off position.
This is to ensure some fresh air is always
available in the vehicle.
Temperature Control:Turn the center knob
clockwise to increase or counterclockwise
to decrease the temperature inside your vehicle.
@(Recirculate):Press this button to toggle
between recirculate and outside air modes. The
indicator light turns on when recirculate mode is
selected. This mode can be used to prevent
outside air and odors from entering your vehicle
or to help heat or cool the air inside your vehicle
more quickly. Avoid using the recirculate mode on
during high periods of humidity or cool outside
temperatures since this may result in increased
window fogging. If window fogging is experienced,
select the defrost mode.
Recirculation mode is not available in oor, defog,
or defrost modes and will shut off automatically and
change to outside air until a mode other than oor,
defog, or defrost is selected. This helps prevent
window fogging and moisture building up within
the cabin.
156
ProCarManuals.com

0(Defrost):This mode directs most of the air to
the windshield, with some air directed to the side
window outlets and the oor outlets. When you
select this mode, the system will turn recirculation
mode off automatically and will run the air
conditioning compressor unless the outside air is
at or below freezing. Recirculation mode cannot be
selected while in defrost mode. This helps prevent
window fogging and moisture building up within
the cabin. To defrost the windows faster, turn the
temperature knob clockwise to the warmest setting.
Rear Window Defogger
The rear window defogger uses a warming grid to
remove fog from the rear window.
The rear window defogger will only work when the
ignition is in RUN.
<(Rear Window Defogger):Press the button to
turn the rear window defogger on or off. An indicator
light above the button will come on to let you know
that the rear window defogger is activated.
The rear window defogger will stay on for
approximately 15 minutes after the button is
pressed, unless the ignition is turned to ACC or
LOCK. If turned on again, the defogger will only run
for approximately seven minutes before turning off.
The defogger can also be turned off by pressing the
button again or by turning off the engine.
Notice:Do not use anything sharp on the
inside of the rear window. If you do, you could
cut or damage the warming grid, and the
repairs would not be covered by your warranty.
Do not attach a temporary vehicle license,
tape, a decal or anything similar to the
defogger grid.
158
ProCarManuals.com

If the airbag readiness light stays on after you
start the vehicle or comes on when you are driving,
your airbag system may not work properly.
Have your vehicle serviced right away.
{CAUTION:
If the airbag readiness light stays on after
you start your vehicle, it means the airbag
system may not be working properly. The
airbags in your vehicle may not inate in
a crash, or they could even inate without
a crash. To help avoid injury to yourself
or others, have your vehicle serviced right
away if the airbag readiness light stays on
after you start your vehicle.
The airbag readiness light should ash for a
few seconds when you turn the ignition key to
RUN. If the light does not come on then, have it
xed so it will be ready to warn you if there is
a problem.
Passenger Airbag Status Indicator
Your vehicle has the passenger sensing system.
Your instrument panel has a passenger airbag
status indicator.
When the ignition key is turned to RUN or START,
the passenger airbag status indicator will light
ON and OFF, or the symbol for on and off,
for several seconds as a system check. Then,
after several more seconds, the status indicator
will light either ON or OFF, or either the on
or off symbol to let you know the status of the
right front passenger’s frontal airbag.
United StatesCanada
166
ProCarManuals.com

Battery Warning Light
The battery warning light
will come on briey as a
check, when you turn on
the ignition. Then it
should go out when the
engine is started.
If the light does not come on when you start your
vehicle, have your vehicle serviced right away. This
condition may indicate your battery warning light is
not functioning properly. If this light comes on while
you are driving, be sure to turn off accessories such
as the radio and climate control system. Have your
vehicle serviced right away.
Up-Shift Light
Your vehicle may have an up-shift light. When
this light comes on, you should shift to the
next higher gear if weather, road, and traffic
conditions allow you to.
This light is located in
your instrument panel
cluster under your
temperature gage.
SeeManual Transaxle Operation on page 117for
more information.
United States Only
169
ProCarManuals.com

Brake System Warning Light
Your vehicle’s hydraulic brake system is divided
into two parts. If one part is not working, the
other part can still work and stop you. For good
braking, though, you need both parts working well.
If the brake system warning light comes on,
there is a brake problem. Have your brake system
inspected right away.
The brake light is located in the instrument
panel cluster.
This light should come on briey when you turn
the ignition key to RUN. If it does not come
on then, have it xed so it will be ready to
warn you if there is a problem.
When the ignition is on, the brake light will come
on when you set your parking brake. The light
will stay on if your parking brake does not releasefully. A chime will also sound if the parking brake
is not fully released and the vehicle is moving.
If it stays on after your parking brake is fully
released, it means you have a brake problem.
The brake light will also come on to indicate a
low brake uid level. SeeBrakes on page 343
for more information.
If the light comes on while you are driving, pull off
the road and stop carefully. You may notice that the
pedal is harder to push or the pedal may go closer
to the oor. It may take longer to stop. If the light is
still on, have the vehicle towed for service. See
Towing Your Vehicle on page 284.
{CAUTION:
Your brake system may not be working
properly if the brake system warning light
is on. Driving with the brake system
warning light on can lead to an accident.
If the light is still on after you have pulled
off the road and stopped carefully, have
the vehicle towed for service.
United StatesCanada
170
ProCarManuals.com

Anti-Lock Brake System
Warning Light
If your vehicle has anti-lock brakes, the anti-lock
brake system (ABS) warning light will come
on briey, as a check, when you start your vehicle.
If it does not, have your vehicle serviced so that
the light works properly when it needs to.
The ABS light is located
in the instrument panel
cluster, to the left of
the engine coolant
temperature gage.
If the light stays on longer than a few seconds
after you start your engine, or comes on and stays
on while you are driving, try resetting the system.To reset the system, do the following:
1. If you are driving, pull over when it is safe
to do so.
2. Be sure the vehicle is in PARK (P).
3. Turn off the ignition.
4. Then restart the engine.
If the light remains on after resetting the system
or comes on again while driving, your vehicle
needs service. If the ABS light is on, but the
regular brake system warning light is not on, the
anti-lock brakes are not working properly, but
the regular brakes are still functioning. Have your
vehicle serviced right away. If both brake lights
are on, you do not have anti-lock brakes, and
there’s a problem with your regular brakes as well.
Have your vehicle towed for service. SeeTowing
Your Vehicle on page 284.
The anti-lock brake system warning light should
come on briey when you turn the ignition key to
RUN. If the light does not come on then, have it
xed so it will be ready to warn you if there is a
problem.
171
ProCarManuals.com

Engine Coolant Temperature Gage
This gage displays the
temperature of the
vehicle’s engine.
If the indicator needle moves into the shaded
area, the engine is too hot. The engine coolant
temperature warning light will also come on when
the engine has overheated. SeeEngine Coolant
Temperature Warning Light on page 173for more
information.
If you have been operating your vehicle under
normal driving conditions, and the engine coolant
temperature warning light comes on, you should
pull off the road, stop your vehicle and turn off the
engine as soon as possible.
Low Coolant Warning Light
This light comes on
briey when you turn
your ignition on.
If this light comes on and stays on, the coolant level
in your vehicle is low. If the light is on along with
an overheat warning, you may have a serious
overheating problem. SeeEngine Coolant
Temperature Gage on page 174.
Notice:Driving with the low coolant warning
light on could cause your vehicle to overheat.
See “Engine Overheating” underEngine
Coolant on page 331. Your vehicle could be
damaged and the damages might not be
covered by your warranty.
SeeEngine Coolant on page 331for information
on what to do. Your vehicle should be serviced as
soon as possible.
174
ProCarManuals.com

Malfunction Indicator Lamp
Check Engine Light
Your vehicle has
a computer which
monitors operation
of the fuel, ignition,
and emission control
systems.
This system is called OBD II (On-Board
Diagnostics-Second Generation) and is intended
to assure that emissions are at acceptable
levels for the life of the vehicle, helping to produce
a cleaner environment. The check engine light
comes on to indicate that there is a problem and
service is required. Malfunctions often will be
indicated by the system before any problem is
apparent. This may prevent more serious damage
to your vehicle. This system is also designed to
assist your service technician in correctly
diagnosing any malfunction.Notice:If you keep driving your vehicle with
this light on, after awhile, the emission controls
might not work as well, your vehicle’s fuel
economy might not be as good, and the engine
might not run as smoothly. This could lead
to costly repairs that might not be covered by
your warranty.
Notice:Modications made to the engine,
transaxle, exhaust, intake, or fuel system
of your vehicle or the replacement of the
original tires with other than those of the same
Tire Performance Criteria (TPC) can affect
your vehicle’s emission controls and may
cause this light to come on. Modications to
these systems could lead to costly repairs
not covered by your warranty. This may also
result in a failure to pass a required Emission
Inspection/Maintenance test. SeeAccessories
and Modifications on page 304.
175
ProCarManuals.com

This light should come on, as a check to show
you it is working, when the ignition is on and
the engine is not running. If the light does
not come on, have it repaired. This light will also
come on during a malfunction in one of two ways:
Light Flashing— A misre condition has
been detected. A misre increases vehicle
emissions and may damage the emission
control system on your vehicle. Diagnosis
and service may be required.
Light On Steady— An emission control
system malfunction has been detected on
your vehicle. Diagnosis and service may be
required.
If the Light Is Flashing
The following may prevent more serious damage
to your vehicle:
Reducing vehicle speed
Avoiding hard accelerations
Avoiding steep uphill grades
If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possibleIf the light stops ashing and remains on steady,
see “If the Light Is On Steady” following.
If the light continues to ash, when it is safe to do
so, stop the vehicle. Find a safe place to park
your vehicle. Turn the key off, wait at least
10 seconds and restart the engine. If the light
remains on steady, see “If the Light Is On Steady”
following. If the light is still ashing, follow the
previous steps, and see your retailer for service
as soon as possible.
If the Light Is On Steady
You may be able to correct the emission system
malfunction by considering the following:
Did you recently put fuel into your vehicle?
If so, reinstall the fuel cap, making sure to fully
install the cap. SeeFilling the Tank on page 309.
The diagnostic system can determine if the fuel cap
has been left off or improperly installed. A loose or
missing fuel cap will allow fuel to evaporate into
the atmosphere. A few driving trips with the cap
properly installed should turn the light off.
176
ProCarManuals.com

Oil Pressure Light
If you have a low
engine oil pressure
problem, this light
will stay on after you
start your engine,
or come on when you
are driving.
This indicates that your engine is not receiving
enough oil. The engine could be low on oil,
or could have some other oil problem. Have it
xed immediately.
The oil light may also come on when the ignition
is on but the engine is not running, the light
will come on as a test to show you it is working,
but the light will go out when you turn the
ignition to START. If it does not come on with
the ignition on, you may have a problem with the
fuse or bulb. Have it xed right away.{CAUTION:
Do not keep driving if the oil pressure is
low. If you do, your engine can become so
hot that it catches re. You or others could
be burned. Check your oil as soon as
possible and have your vehicle serviced.
Notice:Lack of proper engine oil maintenance
may damage the engine. The repairs would
not be covered by your warranty. Always follow
the maintenance schedule in this manual for
changing engine oil.
178
ProCarManuals.com
