Headlamp High/Low-Beam Changer
To change the headlamps from low beam to
high or high beam to low, pull the turn signal lever
all the way towards you. Then release it.
When the high beams
are on, this light on
the instrument panel
cluster will also be on.
Flash-to-Pass
This feature lets you use your high-beam
headlamps to signal a driver in front of you
that you want to pass.
To ash the high beams from low beam, pull
the turn signal/multifunction lever all the way
towards you. Then release it.
Windshield Wipers
Be sure to clear ice and snow from the wiper blades
before using them. If the wiper blades are frozen to
the windshield, gently loosen or thaw them. If the
blades do become damaged, install new blades
or blade inserts. SeeWindshield Wiper Blade
Replacement on page 364.
Heavy snow or ice can overload the wiper motor.
A circuit breaker will stop the motor until it cools
down. Clear away snow or ice to prevent an
overload.
United States
144
ProCarManuals.com

Driving in Rain and on Wet Roads
Rain and wet roads can mean driving trouble.
On a wet road, you cannot stop, accelerate,
or turn as well because your tire-to-road
traction is not as good as on dry roads.And, if your tires do not have much tread left, you
will get even less traction. It is always wise to
go slower and be cautious if rain starts to fall
while you are driving. The surface may get wet
suddenly when your reexes are tuned for driving
on dry pavement.
The heavier the rain, the harder it is to see.
Even if your windshield wiper blades are in good
shape, a heavy rain can make it harder to see
road signs and traffic signals, pavement markings,
the edge of the road, and even people walking.
It is wise to keep your wiping equipment in
good shape and keep your windshield washer uid
reservoir lled with washer uid. Replace your
windshield wiper inserts when they show signs of
streaking or missing areas on the windshield,
or when strips of rubber start to separate from
the inserts.
264
ProCarManuals.com

Once you are moving on the freeway, make
certain you allow a reasonable following distance.
Expect to move slightly slower at night.
When you want to leave the freeway, move to the
proper lane well in advance. If you miss your
exit, do not, under any circumstances, stop and
back up. Drive on to the next exit.
The exit ramp can be curved, sometimes quite
sharply. The exit speed is usually posted.
Reduce your speed according to your speedometer,
not to your sense of motion. After driving for any
distance at higher speeds, you may tend to think
you are going slower than you actually are.
Before Leaving on a Long Trip
Make sure you are ready. Try to be well rested.
If you must start when you are not fresh — such as
after a day’s work — do not plan to make too many
miles that rst part of the journey. Wear comfortable
clothing and shoes you can easily drive in.
Is your vehicle ready for a long trip? If you keep it
serviced and maintained, it is ready to go. If it
needs service, have it done before starting out.Of course, you will nd experienced and able
service experts at dealers/retailers all across the
United States and Canada. They are ready
and willing to help if you need it.
Here are some things you can check before a trip:
Windshield Washer Fluid:Is the reservoir
full? Are all windows clean inside and outside?
Wiper Blades:Are they in good shape?
Fuel, Engine Oil, Other Fluids:Have you
checked all levels?
Lamps:Are they all working? Are the lenses
clean?
Tires:They are vitally important to a safe,
trouble-free trip. Is the tread good enough
for long-distance driving? Are the tires
all inated to the recommended pressure?
Weather Forecasts:What is the weather
outlook along your route? Should you
delay your trip a short time to avoid a major
storm system?
Maps:Do you have up-to-date maps?
269
ProCarManuals.com

Windshield Wiper Blade Replacement....... 364
Tires............................................................ 366
Tire Sidewall Labeling............................... 367
Tire Terminology and Denitions............... 371
Ination - Tire Pressure............................. 374
Tire Inspection and Rotation...................... 375
When It Is Time for New Tires.................. 377
Buying New Tires...................................... 377
Different Size Tires and Wheels................ 379
Uniform Tire Quality Grading..................... 380
Wheel Alignment and Tire Balance............ 382
Wheel Replacement.................................. 382
Tire Chains............................................... 384
If a Tire Goes Flat.................................... 385
Changing a Flat Tire................................. 386
Removing the Spare Tire and Tools.......... 387
Removing the Flat Tire and
Installing the Spare Tire......................... 391
Storing a Flat or Spare Tire and Tools...... 397
Compact Spare Tire.................................. 398Appearance Care........................................ 399
Cleaning the Inside of Your Vehicle.......... 399
Fabric/Carpet............................................. 400
Instrument Panel, Vinyl, and
Other Plastic Surfaces........................... 401
Care of Safety Belts.................................. 402
Weatherstrips............................................ 402
Washing Your Vehicle............................... 402
Cleaning Exterior Lamps/Lenses................ 403
Finish Care............................................... 403
Windshield and Wiper Blades.................... 404
Aluminum Wheels...................................... 404
Tires......................................................... 405
Sheet Metal Damage................................. 405
Finish Damage.......................................... 405
Underbody Maintenance............................ 406
Chemical Paint Spotting............................ 406
Vehicle Care/Appearance Materials............ 407
Vehicle Identication.................................. 408
Vehicle Identication Number (VIN)........... 408
Service Parts Identication Label............... 408
Section 5 Service and Appearance Care
302
ProCarManuals.com

License Plate Lamp
To replace one of these bulbs, do the following:
1. Remove the two screws holding each of
the license plate lamps to the fascia.
2. Turn and pull the license plate lamp forward
through the fascia opening.
3. Turn the bulb socket counterclockwise and
pull the bulb straight out of the socket.
4. Install the new bulb.
5. Reverse Steps 1 through 3 to reinstall the
license plate lamp.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up 3156
CHMSL W5W
Front Turn Signal/Parking 3157K
Headlamps
High-beam 9005 or HB3
Low-beam/DRL 9006 or HB4
Rear Turn Signal, Stoplamp and
Taillamp3057
For replacement bulbs not listed here, contact
your dealer/retailer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for
wear and cracking. SeeScheduled Maintenance
on page 420for more information.
Replacement blades come in different types and
are removed in different ways. For proper type and
length, seeNormal Maintenance Replacement
Parts on page 434.
364
ProCarManuals.com

Windshield and Wiper Blades
Clean the outside of the windshield with glass
cleaner.
Clean the rubber blades using a lint free cloth or
paper towel soaked with windshield washer uid or
a mild detergent. Wash the windshield thoroughly
when cleaning the blades. Bugs, road grime,
sap, and a buildup of vehicle wash/wax treatments
may cause wiper streaking. Replace the wiper
blades if they are worn or damaged.
Wipers can be damaged by:
Extreme dusty conditions
Sand and salt
Heat and sun
Snow and ice, without proper removal
Aluminum Wheels
Notice:Chrome wheels and other chrome trim
may be damaged if you do not wash your
vehicle after driving on roads that have been
sprayed with magnesium, calcium or sodium
chloride. These chlorides are used on roads for
conditions such as ice and dust. Always wash
your vehicle’s chrome with soap and water
after exposure.
Notice:If you use strong soaps, chemicals,
abrasive polishes, cleaners, brushes, or
cleaners that contain acid on aluminum or
chrome-plated wheels, you could damage the
surface of the wheel(s). The repairs would not
be covered by your warranty. Use only
approved cleaners on aluminum or
chrome-plated wheels.
Keep the wheels clean using a soft clean cloth
with mild soap and water. Rinse with clean water.
After rinsing thoroughly, dry with a soft clean
towel. A wax may then be applied.
Notice:Using chrome polish on aluminum
wheels could damage the wheels. The repairs
would not be covered by your warranty.
Use chrome polish on chrome wheels only.
404
ProCarManuals.com

Scheduled Maintenance (cont’d)
Service MaintenanceIMaintenanceII
Check engine coolant and windshield washer uid levels and add uid
as needed.••
Perform any needed additional services. See “Additional Required Services”
in this section.••
Inspect suspension and steering components.See footnote (b).•
Inspect engine cooling system.See footnote (c).•
Inspect wiper blades.See footnote (d).•
Inspect restraint system components.See footnote (e).•
Lubricate body components.See footnote (f).•
Automatic Transaxle Only: Check automatic transaxle uid level and
add uid as needed.•
Replace passenger compartment air lter.See footnote (k).•
L4 engine: Inspect throttle system.See footnote (g).•
422
ProCarManuals.com

(c)Visually inspect hoses and have them replaced
if they are cracked, swollen, or deteriorated.
Inspect all pipes, ttings, and clamps; replace with
genuine Saturn parts as needed. To help ensure
proper operation, a pressure test of the cooling
system and pressure cap and cleaning the outside
of the radiator and air conditioning condenser is
recommended at least once a year.
(d)Visually inspect wiper blades for wear or
cracking. Replace wiper blades that appear
worn or damaged or that streak or miss areas
of the windshield.
(e)Make sure the safety belt reminder light and all
your belts, buckles, latch plates, retractors, and
anchorages are working properly. Look for any
other loose or damaged safety belt system parts.
If you see anything that might keep a safety belt
system from doing its job, have it repaired. Have
any torn or frayed safety belts replaced. Also look
for any opened or broken airbag coverings, and
have them repaired or replaced. The airbag system
does not need regular maintenance.
(f)Lubricate all key lock cylinders, door hinges
and latches, hood hinges and latches, glove box
hinges, sunroof (if equipped), and any folding
seat hardware. More frequent lubrication may berequired when exposed to a corrosive
environment. Applying silicone grease on
weatherstrips with a clean cloth will make them
last longer, seal better, and not stick or squeak.
(g)Check system for interference or binding
and for damaged or missing parts. Replace
parts as needed. Replace any components that
have high effort or excessive wear.
(h)Severe service is when the vehicle is mainly
driven under one or more of these conditions:
In heavy city traffic where the outside
temperature regularly reaches 90°F (32°C)
or higher.
In hilly or mountainous terrain.
When doing frequent trailer towing.
Uses such as found in taxi, police, or delivery
service.
(i)Drain, ush, and rell cooling system. This
service can be complex; you should have
your retailer perform this service. See Engine
Coolant on page 331 for what to use. Inspect
hoses. Clean radiator, condenser, pressure cap,
and ller neck. Pressure test the cooling
system and pressure cap.
426
ProCarManuals.com

Normal Maintenance Replacement Parts
Replacement parts identied below by name, part number, or specication can be obtained from your
retailer.
Part Saturn Part Number ACDelco®Part Number
Engine Air Cleaner/Filter 22676970 A1627C
Engine Oil Filter
2.2L L4 12605566 PF457G
3.5L V6 12582255 —
Passenger Compartment Air Filter Element 15822812 —
Spark Plugs
2.2L L4 12607280 41-105
3.5L V6 12582002 —
Wiper Blades
Driver’s Side – 24 inches (60.0 cm) 22703508 —
Passenger’s Side – 19 inches (47.5 cm) 22703507 —
Rear – 11.0 inches (28.0 cm) 22665007 —
434
ProCarManuals.com

A
About Driving Your Vehicle.............................. 3
Accessories and Modications..................... 304
Adding Equipment to Your
Airbag-Equipped Vehicle............................ 89
Additives, Fuel............................................ 307
Add-On Electrical Equipment....................... 409
Air Cleaner/Filter, Engine............................. 324
Air Conditioning........................................... 155
Airbag
Passenger Status Indicator....................... 166
Readiness Light....................................... 165
Airbag System............................................... 71
What Will You See After an
Airbag Inates?...................................... 80
When Should an Airbag Inate?................. 77
Where Are the Airbags?............................. 75
Airbag Systems
Adding Equipment to Your
Airbag-Equipped Vehicle......................... 89
How Does an Airbag Restrain?.................. 80
Passenger Sensing System....................... 82
Servicing Your Airbag-Equipped Vehicle..... 88
What Makes an Airbag Inate?.................. 79
All-Wheel Drive........................................... 353
All-Wheel-Drive (AWD) System.................... 239Antenna, Fixed Mast................................... 225
Antenna, XM™ Satellite Radio Antenna
System.................................................... 225
Anti-Lock Brake System.............................. 235
Anti-Lock Brake, System Warning Light....... 171
Appearance Care
Aluminum Wheels.................................... 404
Care of Safety Belts................................ 402
Chemical Paint Spotting........................... 406
Cleaning Exterior Lamps/Lenses.............. 403
Cleaning the Inside of Your Vehicle.......... 399
Fabric/Carpet........................................... 400
Finish Care.............................................. 403
Finish Damage......................................... 405
Instrument Panel, Vinyl, and Other
Plastic Surfaces.................................... 401
Sheet Metal Damage............................... 405
Tires........................................................ 405
Underbody Maintenance........................... 406
Vehicle Care/Appearance Materials.......... 407
Washing Your Vehicle.............................. 402
Weatherstrips........................................... 402
Windshield and Wiper Blades................... 404
Audio System.............................................. 182
Audio Steering Wheel Controls................. 223
Care of Your CD and DVD Player............ 225
Care of Your CDs and DVDs................... 225
457
ProCarManuals.com
