{CAUTION:
Airbags plus lap-shoulder belts offer the
best protection for adults, but not for young
children and infants. Neither the vehicle’s
safety belt system nor its airbag system is
designed for them. Young children and infants
need the protection that a child restraint
system can provide. Always secure children
properly in your vehicle. To read how, see
Older Children on page 1-31orInfants and
Young Children on page 1-34.
There is an airbag
readiness light on
the instrument panel
cluster, which shows
the airbag symbol.
The system checks the airbag electrical system for
malfunctions. The light tells you if there is an electrical
problem. SeeAirbag Readiness Light on page 3-29
for more information.
Where Are the Airbags?
The driver’s frontal airbag is in the middle of the
steering wheel.
1-56
ProCarManuals.com

If you ever pull the shoulder portion of the belt out all
the way, you will engage the child restraint locking
feature. This may unintentionally cause the passenger
sensing system to turn the airbag(s) off for some
adult size occupants. If this happens, just let the belt
go back all the way and start again.
{CAUTION:
If the airbag readiness light in the instrument
panel cluster ever comes on and stays on,
it means that something may be wrong with
the airbag system. If this ever happens, have
the vehicle serviced promptly, because an
adult-size person sitting in the right front
passenger’s seat may not have the protection
of the airbag(s). SeeAirbag Readiness Light
on page 3-29for more on this, including
important safety information.A thick layer of additional material, such as a blanket
or cushion, or aftermarket equipment such as seat
covers, seat heaters, and seat massagers can affect
how well the passenger sensing system operates.
We recommend that you not use seat covers or
other aftermarket equipment other than any that GM
has approved for your specic vehicle. SeeAdding
Equipment to Your Airbag-Equipped Vehicle on
page 1-68for more information about modications
that can affect how the system operates.
{CAUTION:
Stowing of articles under the passenger’s
seat or between the passenger’s seat cushion
and seatback may interfere with the proper
operation of the passenger sensing system.
1-67
ProCarManuals.com

PASS-Key®III+ Electronic
Immobilizer Operation
Your vehicle has PASS-Key®III+ (Personalized
Automotive Security System) theft-deterrent system.
PASS-Key
®III+ is a passive theft-deterrent system.
The system is automatically armed when the key
is removed from the ignition.
You do not have to manually arm or disarm the system.
The security light will come on if there is a problem
with arming or disarming the theft-deterrent system.
When the PASS-Key
®III+ system senses that someone
is using the wrong key, it prevents the vehicle from
starting. Anyone using a trial-and-error method to start
the vehicle will be discouraged because of the high
number of electrical key codes.
When trying to start the vehicle if the engine does not
start and the security light on the instrument panel
cluster comes on, there may be a problem with your
theft-deterrent system. Turn the ignition off and try again.If the engine still does not start, and the key appears to
be not damaged, wait about ve minutes and try another
ignition key. At this time, you may also want to check
the fuse, seeFuses and Circuit Breakers on page 5-90.
If the engine still does not start with the other key, your
vehicle needs service. If your vehicle does start, the rst
key may be faulty. See your dealer/retailer who can
service the PASS-Key
®III+ to have a new key made.
In an emergency, contact Roadside Assistance.
SeeRoadside Assistance Program on page 7-6.
It is possible for the PASS-Key
®III+ decoder to “learn”
the transponder value of a new or replacement key.
Up to 10 keys may be programmed for the vehicle.
The following procedure is for programming additional
keys only. If all the currently programmed keys are
lost or do not operate, you must see your dealer/retailer
or a locksmith who can service PASS-Key
®III+ to
have keys made and programmed to the system.
See your dealer/retailer or a locksmith who can service
PASS-Key
®III+ to get a new key blank that is cut
exactly as the ignition key that operates the system.
2-15
ProCarManuals.com

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-6
Horn .............................................................3-6
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-7
Turn and Lane-Change Signals........................3-7
Headlamp High/Low-Beam Changer..................3-8
Flash-to-Pass.................................................3-8
Windshield Wipers..........................................3-8
Rainsense™ II Wipers.....................................3-9
Windshield Washer.......................................3-10
Rear Window Wiper/Washer...........................3-11
Cruise Control..............................................3-11
Exterior Lamps.............................................3-14
Wiper Activated Headlamps............................3-14
Daytime Running Lamps (DRL).......................3-15
Automatic Headlamp System..........................3-15
Instrument Panel Brightness...........................3-16
Dome Lamp .................................................3-16
Entry Lighting...............................................3-16
Reading Lamps............................................3-17
Battery Run-Down Protection..........................3-17
Accessory Power Outlet(s).............................3-17
Climate Controls............................................3-18
Automatic Climate Control System...................3-18
Outlet Adjustment.........................................3-23
Passenger Compartment Air Filter...................3-23Warning Lights, Gages, and Indicators............3-25
Instrument Panel Cluster................................3-26
Speedometer and Odometer...........................3-27
Trip Odometer..............................................3-27
Tachometer.................................................3-27
Safety Belt Reminders...................................3-28
Airbag Readiness Light..................................3-29
Passenger Airbag Status Indicator...................3-30
Charging System Light..................................3-32
Brake System Warning Light..........................3-32
Anti-lock Brake System (ABS) Warning Light. . . .3-33
Traction Control System (TCS) Warning Light . . .3-34
Electronic Stability Program Indicator Light.......3-34
Engine Coolant Temperature Warning Light......3-35
Tire Pressure Light.......................................3-35
Malfunction Indicator Lamp.............................3-36
Oil Pressure Light.........................................3-38
Change Engine Oil Light................................3-39
Security Light...............................................3-40
Cruise Control Light......................................3-40
Highbeam On Light.......................................3-40
Low Washer Fluid Warning Light.....................3-40
Fuel Gage...................................................3-41
Low Fuel Warning Light.................................3-42
Auto Stop Mode...........................................3-42
Charge/Assist Gage......................................3-43
Fuel Economy Light......................................3-43
Section 3 Instrument Panel
3-1
ProCarManuals.com

The main components of the instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on page 3-23.
B. Instrument Panel Brightness Control. SeeInstrument
Panel Brightness on page 3-16.
C. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-7.
D. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-26.
E. Windshield Wiper Lever. SeeWindshield Wipers on
page 3-8.
F. Audio System. SeeAudio System(s) on page 3-59.
G. Auxiliary Input Jack. SeeRadio(s) on page 3-62.
H. Exterior Lamps Control. SeeExterior Lamps
on page 3-14.
I. Instrument Panel Storage Area. SeeInstrument
Panel Storage on page 2-42.
J. Hood Release. SeeHood Release on page 5-11.
K. Cruise Control Buttons. SeeCruise Control on
page 3-11.
L. Tilt Wheel Lever. SeeTilt Wheel on page 3-6.M. Horn. SeeHorn on page 3-6.
N. Audio Steering Wheel Controls. SeeAudio Steering
Wheel Controls on page 3-76.
O. Rear Window Wiper/Washer. SeeRear Window
Wiper/Washer on page 3-11.
P. Traction Control System Button. SeeTraction
Control System (TCS) on page 4-7
Q. Shift Lever. SeeAutomatic Transmission Operation
on page 2-23.
R. Automatic Climate Control System. SeeAutomatic
Climate Control System on page 3-18.
S. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 3-6.
T. Passenger Air Bag Status Indicator. SeePassenger
Airbag Status Indicator on page 3-30.
U. Passenger Safety Belt Reminder Display.
SeeSafety Belt Reminders on page 3-28.
V. Glove Box. SeeGlove Box on page 2-41.
3-5
ProCarManuals.com

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes:
GTurn and Lane-Change Signals. SeeTurn and
Lane-Change Signals on page 3-7.
3Headlamp High/Low-Beam Changer. See
Headlamp High/Low-Beam Changer on page 3-8.
Flash-to-Pass Feature. SeeFlash-to-Pass on
page 3-8.
Turn and Lane-Change Signals
The turn signal has one upward (for right) and one
downward (for left) positions, which allow you to signal
a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is nished, the lever returns automatically
to the original position.
An arrow on the instrument
panel cluster ashes in the
direction of the turn or
lane change.
To signal a lane change, slightly raise or lower the lever
until the arrow starts to ash and release the lever.
The turn signal ashes automatically three times.
As you signal a turn or a lane change, if the arrows
ash rapidly, a signal bulb may be burned out and other
drivers will not see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when you
signal a turn, check the fuse, seeFuses and Circuit
Breakers on page 5-90and for burned-out bulbs.
3-7
ProCarManuals.com

Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high or
high beam to low, push the turn signal lever all the way
towards the instrument panel and release it.
This indicator light turns on
in the instrument panel
cluster when the high
beams are on.
Flash-to-Pass
This feature lets you use your high-beam headlamps to
signal a driver in front of you that you want to pass.
To ash the high beams from low beam, pull the turn
signal/multifunction lever all the way towards you.
Then release it.
Windshield Wipers
Clear ice and snow from the wiper blades before using
them. If the wiper blades are frozen to the windshield,
gently loosen or thaw them. If the blades do become
damaged, install new blades or blade inserts. See
Windshield Wiper Blade Replacement on page 5-46.
Heavy snow or ice can overload the wiper motor.
A circuit breaker will stop the motor until it cools down.
Clear away snow or ice to prevent an overload.
The lever on the right side of the steering column
operates the windshield wipers. Push up or pull down
on the lever to place it in one of the following positions.
3-8
ProCarManuals.com

Setting Cruise Control
{CAUTION:
If you leave your cruise control on when you
are not using cruise, you might hit a button
and go into cruise when you do not want to.
You could be startled and even lose control.
Keep the cruise control switch off until you
want to use cruise control.
The cruise control buttons
are located on the left side
of the steering wheel.
E(On/Off):Press this button to turn the cruise control
system on and off. An indicator light comes on.
RES+ (Resume/Accel):Press the thumbwheel up to
resume a set speed or to accelerate to a higher speed.
−SET (Set/Coast):Press the thumbwheel down to
set a speed or to decrease the speed.
To set a speed do the following:
1. Press the on/off symbol to turn cruise control on.
The indicator light on the button comes on.
2. Get to the speed desired.
3. Press the thumbwheel toward−SET and release it.
4. Take your foot off the accelerator pedal.
When the brakes are applied, the cruise control
shuts off.
Resuming a Set Speed
If the cruise control is set at a desired speed and then
the brakes are applied, the cruise control is disengaged.
The indicator light on the instrument panel cluster goes
out when the cruise is no longer engaged. To return to
the previously set speed, press the thumbwheel up
toward RES+ briey when the vehicle has reached a
speed of about 25 mph (40 km/h) or more.
This accelerates your vehicle to the previously selected
speed.
3-12
ProCarManuals.com

Increasing Speed While Using Cruise
Control
There are two ways to go to a higher speed.
Disengage the cruise control, but do not turn it off.
If the cruise control system is already engaged,
press the thumbwheel up toward RES+ and hold it
until your vehicle accelerates to the desired speed,
and then release the switch. To increase the speed
in very small amounts, press the thumbwheel up
toward RES+ briey and then release it. Each
time this is done, the vehicle will go about 1 mph
(1.6 km/h) faster.
Reducing Speed While Using Cruise
Control
If the cruise control system is already engaged,
Push the thumbwheel toward−SET and hold
until the desired lower speed is reached, then
release it.
To slow down in very small amounts, push the
thumbwheel toward−SET briey. Each time
this is done, the vehicle goes about 1 mph
(1.6 km/h) slower.
Passing Another Vehicle While Using
Cruise Control
Use the accelerator pedal to increase the vehicle’s
speed. When you take your foot off the pedal, the
vehicle will slow down to the previously set cruise
control speed.
Using Cruise Control on Hills
How well the cruise control works on hills depends upon
the vehicle’s speed, load, and the steepness of the hills.
When going up steep hills, you might have to step on the
accelerator pedal to maintain the vehicle’s speed. When
going downhill, you might have to brake or shift to a lower
gear to maintain the vehicle’s speed. Of course, applying
the brakes ends cruise control. Many drivers nd this to
be too much trouble and do not use cruise control on
steep hills.
Ending Cruise Control
There are three ways to disengage the cruise control:
Step lightly on the brake pedal or clutch; when
cruise control disengages, the indicator light on
the instrument panel cluster goes out.
Press the on/off button, this will turn off the cruise
control system.
3-13
ProCarManuals.com

Instrument Panel Cluster
The instrument panel cluster is designed to let you know at a glance how your vehicle is running. You will know how
fast you are going, about how much fuel you have and many other things you will need to know to drive safely
and economically.
United States cluster, Canada similar
3-26
ProCarManuals.com
