The iPod®1)is a portable MP3 player by
Apple Computer Inc with several models
on the market.
These instructions describe the use of the
iPod
®adaptor and its control through the
car radio2)or the navigator2). Read them
carefully and keep them handy for future
reference.
Consult the manufacturer's instructions
for information on the iPod
®.
From here on, any instructions for the
iPod
®, refer to the compatible authorised
models of iPod®of 3rd, 4th and 5th gen-
eration:
•iPod®with 20 GB capacity
•iPod®with 30 GB capacity
•iPod®with 40 GB capacity
•iPod®with 60 GB capacity
•iPod®mini
•iPod®nano
•iPod®photo with 60 GB capacity
•iPod®video with 30 GB capacity
•iPod®video with 60 GB capacity
•iPod®Special Edition
The iPod®shuffle and the iPod®photo
with 30 GB cannot be used, nor devices
by other brands.
A Au
ut
th
ho
or
ri
is
se
ed
d aan
nd
d cco
om
mp
pa
at
ti
ib
bl
le
e rra
ad
di
io
o
e eq
qu
ui
ip
pm
me
en
nt
t aan
nd
d rra
ad
di
io
o nna
av
vi
ig
ga
at
to
or
r
s sy
ys
st
te
em
ms
s
Connecting the iPod®directly into the
radio equipment or navigation system
enables reproduction of stored music
through the vehicle loudspeakers.
C Co
om
mp
pa
at
ti
ib
bl
le
e mmu
us
si
ic
c ffo
or
rm
ma
at
ts
s
The following formats are compatible:
•AAC (from 8 to 320 Kbit/s)
•AAC protected (from iTunes®Music
Store, M4A, M4B, M4P)
•AIFF
•Apple Lossless
•Audible (formats 2, 3 and 4)
•MP3 (from 8 to 320 Kbit/s)
•MP3 VBR
•WAV
Frequency range: between 20 and 20,000
Hz.
P Po
os
ss
si
ib
bl
le
e ffu
un
nc
ct
ti
io
on
ns
s
The following functions are available
through the sound system controls:
•Direct playback selection up to 6 play-
lists
•Playback of all tracks on iPod®
•Random playback function
•SCAN function (10 seconds of each
track)
•Change one playlist for another
•Forward and rewind in track
•Random playback (MIX play)
1)iPod®is a registered trademark of Apple
Computer, Inc.
2)Optional equipment
