Edition 11.96




- Unplug connector from the Hall sender (G40)
-arrow-.
- Unplug connector from the intake manifold
temperature sender (G72) -1-.
- Detach connection hose -2- to the intake hose -5-.
- Detach vacuum hose -3- to the brake servo unit at the throttle valve control unit (J338).
- Detach vent hose -4- to the activated char- coal filter.
- Detach connection hose -6-.
- Remove intake hose -5- between top part of air filter and throttle valve control unit (J338).
- Unplug connector -1- from the air mass me-
ter (G70).
- Slacken the securing bolts -2- and remove air filter housing -3-.

Downloaded from www.Manualslib.com manuals search engine Fuel Supply System20
Edition 11.96




Removing and installing parts of the fuel supply system
Notes:
Hose connections are secured with screw-
type, spring strap or clamp-type clips.
Always replace clamp-type clips by spring
strap clips or screw-type clips.
Fuel hoses at the engine must be securedonly with spring strap clips. It is not permitted
to use clamp-type or screw-type clips.
Always replace seals and gaskets when
carrying out removal and installation work.
Pay attention to safety precautions page 20-4.
Pay attention to rules for cleanliness page 20-4.
Removing and installing parts of the activatedcharcoal filter system page 20-12.
Servicing throttle mechanism page 20-12.
Setting throttle cable page 20-13.
