warning SKODA SCALA 2020 Owner´s Manual

ignition is switched on or after the engine has been
started.SymbolMeaningIndicates a warning together with
another warning light

Steering wheelAdjust the steering wheel
WARNING
Risk of an accident!

WARNING

GroupPassenger seat withactivated front air- bagPassenger seat with
deactivated front air- bagOuter rear seatsMiddle rear seat a)0
up to 10 kgXU b)UU0+
up to 13 kgXU b)UU1
9-18 kgUFUUU2
15-25 kgUFUUU3
22-36 kgUFUUUa) It is forbidden to install a child seat with a support foot in the middle rear seat.b)Adjust the height-adjustable front passenger seat as much as possible.
U The seat is suitable for the child seat category “Universal” and is permitted for use in this weight group.
UF The seat is suitable for forward-facing child seats in the “Universal” category and is permitted for use in
this weight group.
X The seat is not suitable for children in this weight group.
Overview
ISOFIX
WARNING

Fog lightPositions for pulling out
the light switch1
Fog lights - the
warning light in the
instrument cluster il-
luminates
2
Rear fog light - the
warning light in the
instrument cluster il-
luminates

Automatic switching on/off of the footwell light-
ing
The lighting only works when the dipped or parking
lights are on.
The lighting is also switched on automatically after
opening the door (e.g. when getting in or out).
Settings
The footwell lighting is set in the following menu in
the Infotainment system.

Or:

Interior ambient light
Usage
The ambient lighting ensures a comfortable atmos-
phere in the vehicle interior.
The lighting only works when the dipped or parking
lights are on.
The lighting is also switched on automatically after
opening the door.
Settings
The ambient lighting is set in the Infotainment sys-
tem, in the following menu.

Or:

Windscreen wipers and washers
Operating conditions
Operating conditions for windscreen wipers
q Engine compartment flap closed.
q Boot door closed.
q Ignition is switched on.
Operating conditions for the windscreen washer
system
q Engine compartment flap closed.
q Boot door closed.
Operation
WARNING
Risk of an accident!
At low temperatures, windscreen washer fluid can
freeze on the windscreen and restrict visibility.

Lane change assist system Side AssistUsage
Side Assist monitors the area both beside and behindthe vehicle.
The system uses optical signals in the exterior mirror
to alert the driver to vehicles that could be danger-
ous when changing lanes.
Functionality
The system warns of an approaching vehicle through
the illumination of the indicator light in the exteri-
or mirror cover on the vehicle side where the vehicle
is detected.
Driving situations in which a system warning oc-
curs
Your vehicle is overtaken by vehicle
A
. The faster
vehicle
A
approaches, the sooner the warning is giv-
en by the indicator light.
Vehicle
B
is overtaken by your vehicle at a speed
that is faster by max. 10 km/h. If the speed is higher
during the overtaking process, no warning will be
provided by the indicator light.
Indicator light
illuminated - There is another vehicle behind your
vehicle
flashing - There is another vehicle behind your ve-
hicle, and the turn signal on the same side is switch-
ed on
For vehicles with Lane Assist, the indicator light will
also flash if your vehicle crosses the lane markings in
the direction of the approaching vehicle. The system
will trigger a steering wheel vibration in this case.
For this, Lane Assist must be activated and the lane
marking between the vehicles must be detected.
Operating conditions
q The driving speed is higher than 15 km/h.
q No accessories are connected to the trailer sock-
et.
Function restriction
The system cannot detect lane width. For this rea-
son, it may, for example, draw attention to a vehicle
in a distant lane in the following cases.

WARNING
Risk of an accident!

Storage space and interior
equipment
Equipment in the boot
Overview
Boot of a vehicle without natural gas drive
ARemovable partition of the storage compart-
ment
Max. load 2.5 kgBTrailer hitch switchCUnder the floor covering: Storage compartment
for spare or emergency wheel and vehicle tools
Load on floor covering max. 75 kgD12 volt socketEStorage tray
Max. load 1.5 kg
Boot of a natural gas vehicle
APartition wall of storage compartment
Max. load 2.5 kgBTrailer hitch switchCUnder the floor covering: Storage compartment
for on-board tools
Load on floor covering max. 75 kgD12 volt socketEmergency equipment
Overview of the emergency equipment
Emergency equipment in the boot of a vehicle
without natural gas drive
APositioning of the warning triangle (depending
on equipment)BTool kitCPlacing of the first-aid kit
Emergency equipment in the boot of a natural gas
vehicle
APlacing of the first-aid kitBTool kitCPlacing of the warning triangle
Storage compartment for the reflective vest
The storage compartment for the reflective vest is in
the storage compartment of the front door.
Fire extinguisher under the passenger seat
Tool kit
Depending on the equipment, not all of the following
components may be included in the tool kit.
160Storage space and interior equipment

The USB connection is for charging only.
Hook on the centre body pillar
The maximum load for the hook is 2 kg.
WARNING
