SUBARU BRZ 2017 1.G Quick Reference Guide

11
Driving pattern selector switch (if equipped)C
Vehicle stability control (VSC)/TRAC off switchB
Turning off Traction Control System :
To turn the TR AC system off, quickly press and
release the button.
The Traction Control System OFF indicator light will
come on.
Press the button again to turn the system back on.
Turning off both Traction Control System and Vehicle Stability Control (VSC) systems:
To turn the TR AC and Vehicle Stability Control (VSC) systems
off, press and hold the Vehicle stability control (VSC)/TR AC
off switch for more than 3 seconds while the vehicle is stopped.
However, on vehicles with an automatic transmission, the brake
LSD function will remain on. Press the button again to turn the
systems back on.
Selecting a driving mode
By pressing the driving pattern selector switch,
the following modes can be selected to suit
driving and usage conditions:
1
Normal mode
2
Sport mode:
The SPORT indicator comes on. Use sport mode for sporty driving or when driving in
mountainous regions with lots of curves.
3
Snow mode:
The SNOW indicator comes on. Use snow mode for accelerating and driving on slippery
road surfaces such as snow.
To cancel sport mode or snow mode, press the same side of the switch again. Quickly press
and release
123

12
TR ACK switchD
Press the switch to activate the TR ACK mode.
The TR ACK indicator and Vehicle stability control (VSC)
off indicator come on when in TR ACK mode.
To change back to normal mode while in TR ACK mode,
press
or .
Your vehicle is equipped with two types of control modes to accommodate various driving
preferences. The control modes can be selected with the
TR ACK switch.
Normal mode allows secure and smooth normal driving.
When the switch is pressed and held for 1 second or more, TR ACK mode is activated.
Control characteristics such as the Vehicle stability control (VSC) and TR AC are adjusted
to afford maneuverability closer to what a driver may desire, while a sense of security is
retained.
Modes can be selected to suit your driving conditions as follows:
Driving conditions Indicator lights Switch operation
Rough roads
The Vehicle stability control (VSC)/TRAC
off switch is pressed.
Sport driving
The TR ACK switch is pressed and held
for more than 1 second.

The Vehicle stability control (VSC)/TRAC
off switch is pressed and held
for more than
3 seconds.
Press
0058 Some functions are available on certain models.
00030058 For detailed operating and safety information, please refer to your Own\
er’s Manual.

13
Multi-information display (monochrome display)E
1
km/h MPH switch:
press: The display inside the meter changes between km/h and MPH.
2
ODO TRIP switch:
press: Change displayed item.
press and hold: Reset the trip meter that is currently displayed.
3
DISP switch:
press: Change displayed item.
1
2
3
Outside temperature
Current fuel consumption Average fuel consumption
Setting screen for the shift position indicator
and shift-up indicator (MT models).
Odometer
Trip meter A Trip meter B
Setting screen for tachometer
indicator needle movement function
when starting the vehicle.
Setting screen for the REV indicator

14
Multi-information display (color display)F
Audio remote control switchesG
1
Meter control switches:
: Select menu icons : Change displayed content, scroll
up/down the screen and move the
cursor
: Enter : Return to the previous screen
2
ODO/TRIP switch:
press: Change displayed item
press and hold: Reset the trip meter that is currently displayed.
3
Menu icon
4
Content display area
5
Odometer/trip meter display area
These buttons allow the driver to control audio
functions without taking his/her hands off the
steering wheel.
21
3
5
4
Odometer Trip meter ATrip meter B
0058 Some functions are available on certain models.
00030058 For detailed operating and safety information, please refer to your Own\
er’s Manual.

15
Some warning/indicator lights illuminate for a few seconds in order to check themselves
when the ignition switch is turned ON.
Main W aR ninG an D inDicato R LiGH ts
Warning lights
Refer to your Owner’s Manual for countermeasures when each warning light comes on.
If necessary, consult your authorized SUBARU dealer.
Malfunction indicator
Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system;
• The electronic automatic transmission control system.
Brake system warning
• Low brake fluid
• Malfunction in the brake system
• The parking brake is not released.
Charging system warning
Indicates a malfunction in the
vehicle’s charging system.
ABS warning
Indicates a malfunction in:
• The ABS;
• The brake assist system.
Low engine oil pressure warning
Indicates that the engine oil
pressure is too low.
Electric power steering warning
Indicates a malfunction in the
electric power steering system.
Driver’s seatbelt reminder
Warns the driver to fasten his/
her seatbelt.
Front passenger’s seatbelt reminder
Warns the front passenger
to fasten his or her seatbelt.
Location : On the center panel.
Open door warning
Indicates that a door or the trunk
lid is not fully closed.
Low fuel level warning
Fuel level is low.

16
SRS airbag system warning
• Indicates a malfunction in:
• The SRS airbag system;
• The seatbelt pretensioner system;
• The front passenger occupant detection system.
Automatic transmission fluid temperature warning (if equipped)
Indicates that the automatic transmission fluid temperature is too high.
Keyless access with push button start system indicator (if equipped)

Flashing in YELLOW : Indicates a malfunction in the keyless
access with push button start system.
Illumination in GREEN : The keyless access with push button start
system is activated.
Please see the Owner’s Manual for details.
Cruise Control indicator

lllumination in YELLOW : Indicates a malfunction in the cruise
control system.
Illumination in GREEN : The cruise control system is activated.
Please see the Owner’s Manual for details.
Slip indicator
Illumination : Indicates a malfunction in the TR AC/ Vehicle stability control (VSC)
system or the hill start assist system.
Flashing : The TR AC/ Vehicle stability control (VSC) system are operating.
Automatic headlight leveling system warning
Indicates a malfunction in the automatic headlight leveling system.
High engine coolant temperature warning
Indicates that the engine is almost overheating.
As the engine coolant temperature increases,this warning light will change from
flashing to constantly illuminated.
Master warning
The master warning light also comes on or flashes in order to indicate that a
message is currently being displayed on the multi-information display.
u Some functions are available on certain models.
u For detailed operating and safety information, please refer to your Own\
er’s Manual.

17
indicator lights
The following indicators show the current status of your car. Refer to the Owner’s Manual for
more information.
Turn signal
indicatorHeadlight high
beam indicatorFront fog light
indicator
(if equipped)
Security
indicatorAirbag on- off
indicatorVehicle stability
control (VSC)
off indicator
SPORT
indicator
(AT models)SNOW indicator
(AT models)SET indicator
Upshift/downshift indicator
(AT models)Shift position and shift range
indicator (AT models)
REV indicator Traction Control System OFF
indicator
Shift position indicator
(MT models)Shift-up indicator
(MT models)
Low engine coolant
temperature indicatorTRACK indicator
Hill start assist ON indicatorLow outside temperature
indicator (color display only)

18
Notes
0058 Some functions are available on certain models.
00030058 For detailed operating and safety information, please refer to your Own\
er’s Manual.

19
Notes
