mirror SUBARU BRZ 2017 1.G Quick Reference Guide

3
Ignition switch must be in ACC or ON .
1
Turn the control switch to the side that you want
to adjust. L is for the left mirror, R is for the right
mirror.
2
Move the control switch in the direction you want
to adjust the mirror.
a djust each component
1
Seat position adjustment
2
Seatback angle adjustment
3
Vertical height adjustment (driver’s side only)
4
Seatback fold strap
Front seat
Tilt/telescopic steering wheel
Outside rear view mirror switch
1
Hold the steering wheel and push the lever down.
2
Adjust to the ideal position by moving the steering
wheel horizontally and vertically.
3
After adjustment, pull the lever up to secure the
steering wheel.
1
23
12
124
3
2
4
Getting in the rear seats:
Lift the seatback angle adjustment
lever.Getting out the rear seats:Pull the seatback fold strap.
The seat can be slid forward and backward. (Front passenger seat only)\

7
Hazard warning flasher switchC
Instrument panel light control dialD
All the turn signal lights will flash.
Use the switch to warn other drivers.
Windshield defogger/Rear window defogger switchE
Ty p e A Ty p e B
1
Windshield defogger:
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to outside air mode if the recirculated air
mode is used. (It may switch automatically.)
2
Rear window defogger switch:
The rear window defogger and the outside rear view mirror defogger (if equipped) turns
on. The function will automatically turn off after approximately 15 min.
Press
Brighter
Darker
1
2
1
2
