stop start SUBARU BRZ 2017 1.G Quick Reference Guide

4
start/stop engine
Push-button ignition switch (if equipped)
Engine (ignition) switch (if equipped)
Performing the following operations when carrying the access key on your person starts the
engine or changes push-button ignition switch modes.
Starting the engine;
STEP1: Check that the parking brake is set.
STEP2: Check that the select lever is set in P (AT models).
Check that the shift lever is set in neutral (MT models).
STEP3: Firmly depress the brake pedal (AT models).
Firmly depress the clutch pedal (MT models).
The push button start system indicator light (green) will
turn on.
STEP4: Press the push-button ignition switch.
Stopping the engine;
STEP1: Stop the vehicle (AT models). While depressing the
clutch pedal, stop the vehicle (MT models).
STEP2: Shift the select lever to P (AT models). Shift the shift lever to neutral (MT models).
STEP3: Set the parking brake.
STEP4: Release the brake pedal (AT models). Release the clutch pedal (MT models).
STEP5: Press the push-button ignition switch.
STEP6: Check that the keyless access with push button start system indicator light (green) is off.
Off ( Tu r n e d o f f ) ACC (G r e e n) ON (G r e e n)
Modes can be changed by pressing the push-button ignition switch with the brake
pedal (vehicles with an automatic transmission) or clutch pedal (vehicles with a manual
transmission) released. (The mode changes each time the switch is pressed)
Changing push-button ignition switch mode
LOCK : The steering wheel is locked and the key can be
removed. (Vehicles with an automatic transmission:
The key can be removed only when the select lever
is in P.)
ACC : Some electrical components such as the power
outlet can be used.
ON : All electrical components can be used.
START : The engine can be started.
Flashes slowly
Flashes slowly
0058 Some functions are available on certain models.
00030058 For detailed operating and safety information, please refer to your Own\
er’s Manual.
