Page 85 of 306
MEDIA OPERATION
84
WARNING
ODo not operate the player’s controls or connect the USB
memory while driving.
CAUTION
ODo not leave your portable player in the car. In particular, high
temperatures inside the vehicle may damage the portable
player.
O Do not push down on or apply unnecessary pressure to the
portable player while it is connected as this may damage the
portable player or its terminal.
O Do not insert foreign objects into the port as this may damage
the portable player or its terminal.
NOTE
O $ X G L R
Page 98 of 306
AUDIO/VISUAL REMOTE CONTROLS
97
AUDIO
3
X“/ ” switch
Mode Operation Function
AM/FM Radio,
SiriusXM
®
Press Preset channel up/down
Press and hold Seek up/down continuously
aha Press
Content up/down
Press and hold Rewind the current content
item for 15 seconds/ Fast
forward the current content
item for 30 seconds
Audio CD, MP3/
WMA/AAC disc,
SD*
1,USB, iPod,
Bluetooth audio Press
6 H O H F W D W U D F N ¿ O H
Press and hold Fast forward/rewind
Pandora*
2Press Track up (“”only)
Press and hold Thumbs up/down
List screen Press Cursor left/right
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
X Mute/enter switch
Mode Operation Function
Except list
screen Press
Mute/unmute
List screen Press Select cursor entry
XBack switch
Mode Operation Function
All Press
Return to the previous screen
when
is displayed on
the screen.
Press and hold Return to the “HOME
(HOME)” screen
X
List switch
Mode Operation Function
Audio screen,
Navigation*
screen Press
Show list screen
*: With navigation function
Page 101 of 306
SETUP
100
No.Function Page
Select to specify the iPod/SD*/USB auto play
settings on/off. -
Select to specify the iPod sound signal input
settings.101
Unsupported.
-
Select to specify cover art settings on/off. -
Select to specify automatic sound levelizer
settings.101
Select to enable cache radio.
-
Select to reset all setup items. -
*: With navigation function
DISPLAYING THE “Audio Settings (Audio
Settings)” SCREEN IN A DIFFERENT WAY
XUSB video/SD video*
*: With navigation function
1.Select on the audio control screen.
2.SelectSettings (Settings).
SETTING THE NUMBER OF RADIO PRESETS
1.Display the “Audio Settings (Audio Settings)” screen.
: 3
2.SelectNumber of Radio Presets (Number of Radio
Presets).
3.Select the button with the desired number to be
displayed.
Page 108 of 306
TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM
107
AUDIO
3
USB MEMORY
”USB communication formats: USB 2.0 HS (480
Mbps) and FS (12 Mbps)
” File formats: FAT 16/32
” Correspondence class: Mass storage class
iPod
The following iPod®, iPod nano®, iPod classic®, iPod
touch® and iPhone® devices can be used with this system.
Made for
”iPod touch (5th generation)
” iPod touch (4th generation)
” iPod touch (3rd generation)*
” iPod touch (2nd generation)*
” iPod touch (1st generation)*
” iPod classic
” iPod with video* ”
iPod nano (7th generation)
” iPod nano (6th generation)
” iPod nano (5th generation)
” iPod nano (4th generation)
” iPod nano (3rd generation)
” iPod nano (2nd generation)*
” iPod nano (1st generation)*
” iPhone 5
” iPhone 4S
” iPhone 4*
” iPhone 3GS*
” iPhone 3G*
” iPhone*
*: The voice recognition system not supported
”Depending on differences between models or
software versions etc., some models might be
incompatible with this system.
” iPod video is not supported.
” For USA customers, please visit www.subaru.com for
details. Outside of the USA customers, contact your
local dealer to arrange a demonstration in order to
F R Q
Page 151 of 306
BEFORE USING THE APPLICATION
150
BEFORE USING THE APPLICATION
BEFORE USING THE APPLICATION
Precautions to be aware of when using the application are
shown below.
In this chapter, iPhone or Android devices will be referred to
as a smartphone.
WARNING
ODo not connect or operate the smartphone while driving.
O Be sure to park the vehicle in a safe location before
connecting or operating the smartphone.
CAUTION
ODo not leave your smartphone in the car. In particular, high
temperatures inside the vehicle may damage the smartphone.
O Do not push down on or apply unnecessary pressure to the
smartphone while it is connected as this may damage the
smartphone or its terminal.
O If connecting your smartphone via USB, do not insert foreign
objects into the USB port as this may damage the smartphone
or its terminal.
NOTE
O Depending on the application, certain functions are not available
while driving for reasons of safety.
O In order to maximize signal reception, performance and precision
of the smartphone, please ensure the smartphone is placed as
close to the system as possible, while ensuring it is stowed and
secure while driving.
O When connecting your smartphone via USB, use the original
cables provided with your smartphone or equivalent third-party
F H U W L ¿ H G F D E O H V
O When the ignition switch is in the “ACC” or “ON” position, t\
he
battery of the connected smartphone is charged.
O If connecting your smartphone via USB, smartphone may not
be recognized when the ignition switch is in the “ACC” or “ON”\
position. In this case, remove the smartphone and reconnect it.
O The accuracy of the displayed information or the signal reception
performance depends on the smartphone or the connected
device, and its wireless connection.
O For operating the smartphone, see the instruction manual that
comes with it.
O ) R O O R Z W K H V S H F L
Page 155 of 306
MirrorLink™
154
MirrorLink™
MirrorLink™
The MirrorLinkTM function allows smartphone content to be
operated via the system.
To use the MirrorLink
TM application, connect your
Android device to the USB port.
Depending on differences between models or software
version etc., some models might be incompatible with this
system.
When using the application, read the precautions indicated
L Q
Page 156 of 306
MirrorLink™
155
APPS
5
XControl screen
*: The displayed screen will differ depending on the connected smartphone.
No. Function
Select to choose a MirrorLink™ device.
6 H O H F W W R F K D Q J H W K H V F U H H Q V L ] H : 3
Select to return the application list screen.
No.Function
Displays software buttons that function as the buttons
on the smartphone.
Select to change the other audio source (Radio, Disc
etc.).
NOTE
OThis function cannot be used while USB audio, video or photo is
in use.
O The video displayed on the screen may differ from that displayed
on the smartphone.
O It may not be possible to use certain applications while driving.
ABOUT THE SUPPORTED DEVICES
”Your smartphone must support the MirrorLinkTM
version 1.1, 1.0 function.
” Available operations will differ depending on your
smartphone. Refer to your smartphone owner’s
manual, or consult the manufacturer.
Page 157 of 306
ahaTM by HARMAN
156
ahaTM by HARMAN
ahaTM by HARMAN
aha is a cloud-based application that connects to the system
and gives you access to your favorite web content safely
and easily. There are over 40,000 stations spanning internet
radio, personalized music, audiobooks, Facebook, Twitter,
restaurant and hotel searches, weather and more. For more
about aha, go to the aha site (http://www.aharadio.com).
When connecting iPhone or Android devices with the aha
application installed, you can control, view, and hear aha
content through the system.
To use the aha application, connect your iPhone to the
USB port, or connect your Android device via Bluetooth.
When using the application, read the precautions indicated
L Q
Page 163 of 306
Pandora®
162
Pandora®
Pandora®
Pandora is free personalized radio that offers effortless and
endless music enjoyment and discovery.
To use the Pandora application, connect your iPhone
to the USB port, or connect your Android device via
Bluetooth.
Depending on differences between models or software
version etc., some models might be incompatible with this
system.
This function is not available if the Pandora application has
not been installed on the smartphone.
When using the application, read the precautions indicated
L Q
Page 192 of 306
OTHER SETTINGS
191
SETTINGS
7
No.Function
*1 6 H O H F W W R F K D Q J H W K H Y H K L F O H F O R F N V H W W L Q J V : 3
Select to change the language.
Select to change the unit for measuring distance.
Select to turn the beep sound on/off.
Select to change the button and screen color.
Select to change the keyboard layout.
Select to turn on/off the setting that returns the display
to the split screen automatically after 20 seconds when
a screen other than the split screen is displayed.
Select to turn the animation function on/off.
6 H O H F W W R F X V W R P L ] H W K H V F U H H Q R I I L P D J H : 3
6 H O H F W W R G H O H W H S H U V R Q D O G D W D : 3
Select to set the connected device when using aha.
Select
USB (USB) when using an iPhone, and then
select
Bluetooth (Bluetooth) when using Android
devices.
No. Function
Select to set the connected device when using
Pandora*2. Select USB (USB) when using an iPhone,
and then select
Bluetooth (Bluetooth) when using
Android devices.
Select to update the Gracenote® database. For details,
contact your SUBARU dealer.
Select to display the software information. Notices
related to third party software used in this product are
enlisted. (This includes instructions for obtaining such
software, where applicable.)
Select to set the back camera delay control on/off.
When set to on, the back camera image displays for
approximately 6 seconds after moving the shift lever/
select lever “R” to any position other than “R”.
The display disappears when the shift lever/select lever
is moved to “P”, or when the vehicle speed reaches
approximately 5 mph (8 km/h) or faster.
Select to reset all setup items.
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
