Page 171 of 420
4-18
Climate control
Air filtration system (if equipped)
If your vehicle’s air conditioning system is equipped
with an air filtration system, replace the filter element
according to the replacement schedule shown below.
This schedule should be followed to maintain the fil-
ter’s dust collection ability. Under extremely dusty con-
ditions, the filter should be replaced more frequently. It
is recommended that you have your filter checked or
replaced by your SUBARU dealer. For replacement,
use only a genuine SUBARU air filter kit.
Replacement schedule:
Every 12 months or 7,500 miles (12,000 km) whichev-
er comes first
Replacing an air filter
0
1. Remove the glove box.
1) Open the glove box.
2) Remove the nine screws securing the glove box.
HS4024BA
Page 172 of 420
4-19
Climate control
– CONTINUED –
1) Air filter cover
2. Remove the air filter cover. 1) Air filter
2) Arrow mark
3. Replace the air filter with new one.
The arrow mark on the filter must point UP.
1HS4025BB1 2HS4026BB
Page 173 of 420
4-20
Climate control
1) Air filter cover
4. Reinstall the air filter cover. 5. Reinstall the glove box.
6. Close the glove box.
1HS4025CBHS4024BA
Page 174 of 420
4-21
Climate control
– CONTINUED –
1) Service label
2) Caution label
7. LABEL installation 1) Fill out the information on the service label (small).
2) Attach service and caution labels on the door pil-
lar on the driver’s side.
Contact your dealer if the following occurs,
even if it is not yet time to change the filter:
– Reduction of the air flow through the vents.
– Windshield gets easily fogged or misted.
NOTE
The filter can influence the air conditioning, heat-
ing and defroster performan ce if not properly
maintained.
1
2
HS4027BB
Page 175 of 420
Page 176 of 420

5-1
5
Audio
Antenna system ........................................... 5-2 FM reception ................................................... 5-2
Installation of accessories .......................... 5-3
Audio set ....................................................... 5-3 Type A audio set ............................................. 5-3
Type B audio set ............................................. 5-4
In-dash 6 CD auto changer (Optional audio
unit – if equipped) ........................................... 5-4
Type A audio set (if equipped) .................... 5-5 Radio operation .............................................. 5-5
Compact disc player operation ..................... 5-10
CD changer control (If optional in-dash CD
changer is connected) .................................... 5-13
Type B audio set (if equipped) ................... 5-16 Radio operation .............................................. 5-16
Cassette player operation .............................. 5-22
Built in CD changer operation ....................... 5-26
In-dash 6 CD auto changer (if equipped) ... 5-31 Loading and unloading compact discs ........ 5-31
Precautions to observe when handling
a compact disc (CD) .................................... 5-34
Page 177 of 420
5-2
Audio
Audio
Antenna system
The antenna is printed on the inside of the left side
rear quarter window glass.
Do not use sharp instruments or window clean-
er containing abrasives to clean the inner sur-
face of the window on which the antenna is
printed. Doing so may damage the antenna
printedonthewindow.
FM reception
Although FM is normally static free, reception can be
affected by the surrounding area, atmospheric condi-
tions, station strength and transmitter distance. Build-
ings or other obstructions may cause momentary
static, flutter or station interference. If reception contin-
ues to be unsatisfactory, switch to a stronger station.
HS5008BA
Page 178 of 420
5-3
Audio
– CONTINUED –
Installation of accessories
Always consult your SUBARU dealer before installing
a citizen band radio or other transmitting device in
your vehicle. Such devices may cause the electronic
control system to malfunction if they are incorrectly in-
stalled or if they are not suited for the vehicle.Audio set
Your SUBARU may be equipped with one of the fol-
lowing audio sets. See the pages indicated in this sec-
tion for operating details. Type A audio set
Radio operation: refer to page 5-5
Compact disc player operation: refer to page 5-10
CD changer control: refer to page 5-13
HS5009AA
Page 179 of 420
