key battery SUBARU FORESTER 2005 SG / 2.G Owners Manual

2-1
2
Keys and doors
Keys ............................................................... 2-2 Key number ....................................................... 2-3
Immobilizer (if equipped) ............................. 2-3 Security ID plate ................................................ 2-4
Security indicator light ..................................... 2-5
Key replacement ............................................... 2-5
Door locks ..................................................... 2-6 Locking and unlocking from the outside ........ 2-6
Locking and unlocking from the inside .......... 2-7
Power door locking switches ...................... 2-8
Remote keyless entry system (if equipped) .............................................. 2-9Locking the doors ............................................. 2-10
Unlocking the doors ......................................... 2-10
Illuminated entry ............................................... 2-11
Vehicle finder function ..................................... 2-11
Sounding a panic alarm ................................... 2-11
Selecting audible signal operation .................. 2-11
Replacing the battery ....................................... 2-11
Replacing lost transmitters .............................. 2-13
Security system (if equipped) ..................... 2-17 System operation .............................................. 2-17
Arming the system ............................................ 2-17
Disarming the system ....................................... 2-19
Valet mode ......................................................... 2-20
Passive arming .................................................. 2-20
Child safety locks ......................................... 2-23
Windows ........................................................ 2-24 Power windows ................................................. 2-24
Rear gate ....................................................... 2-27 Moonroof (if equipped) ................................. 2-28
To open the moonroof ...................................... 2-28
To close the moonroof ..................................... 2-29
Anti-entrapment function ................................. 2-29

2-9
Keys and doors
– CONTINUED –
Remote keyless entry system (if
equipped)
Two transmitters are provided for your vehicle.
The remote keyless entry system has the following
functions. yLocking and unlocking the doors and rear gate with-
out a key y Sounding a panic alarm
y Arming and disarming the security system (if your
vehicle is equipped with an optional security system).
See the next section “Security system (if equipped)”
for detailed information.
This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada. Oper-
ation is subject to the following two conditions: (1)
This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved
by the party responsible for compliance could
void the user’s authority to operate the equipment.
The operable distance of the keyless entry system is
approximately 30 feet (10 meters). However, this dis- tance will vary depending on environmental condi-
tions. The system’s operable distance will be shorter
in areas near a facility or electronic equipment emitting
strong radio waves such as a power plant, broadcast
station, TV tower, or remote controller of home elec-
tronic appliances.
The keyless entry system does not operate when the key is inserted in the ignition switch to prevent acci-
dental lockout.
y
Do not expose the transmitter to severe
shocks, such as those experienced as a result
of dropping or throwing. y Do not take the transmitter apart except when
replacing the battery.y Do not get the transmitter wet. If it gets wet,
wipe it dry with a cloth immediately.

2-11
Keys and doors
– CONTINUED –
system may not respond. „Illuminated entry
The interior dome light and ignition switch light will illu-
minate when the “ ” button is pressed. These
lights stay illuminated for approximately 30 seconds if
any of the doors or the rear gate is not opened.
If the “ ” button is pressed before 30 seconds have
elapsed, these lights will go out. Also, these lights will
go out if the key is inserted in the ignition switch. The interior light switch must be set to the middle position
in order for this function to operate. „ Vehicle finder function
Use this function to find your vehicle parked among
many vehicles in a large parking lot. Provided you are
within 30 feet (10 meters) of the vehicle, pressing the
“ ” button three times in a five-second period will
cause your vehicle’s horn to sound once and its turn
signal lights to flash three times. „ Sounding a panic alarm
To activate the alarm, keep the “ ” button pressed
for more than two seconds .
The horn will sound and the turn signal lights will flash.
To deactivate it, press the “ ” button or “ ” but- ton. Unless a button on the remote is pressed, the
alarm will be deactivated after approximately 30 sec-
onds. „
Selecting audible signal operation
Using an electronic chirp, the system will give you an
audible signal when the doors lock and unlock. If de-
sired, you may turn the audible signal off.
To turn the audible signal off, unlock the door by
pressing the “ ” button and then simultaneously
depress “ ” and “ ” buttons for more than two
seconds. An electronic chirp will sound twice and the
turn signal lights will flash twice to inform you that the
audible signal has been turned off.
To turn the audible signal on, unlock the door by
pressing the “ ” button and then simultaneously
depress “ ” and “ ” buttons for more than two
seconds. An electronic chirp will sound once and the
turn signal lights will flash once to inform you that the
audible signal has been turned on. „ Replacing the battery
When the transmitter battery begins to get weak,
transmitter range will begin to decrease. Replace the
battery as soon as possible.

2-12
Keys and doors
To replace the battery:0
1. Open the transmitter case using a flat-head screw-
driver.
2. Separate the case.
3. Remove the old battery from the holder.
UG2043BA
UB2209BA

2-13
Keys and doors
– CONTINUED –
A) Negative (–) side facing up
4. Replace with a new battery (Type CR2025 or
equivalent) making sure to install the new battery with
the negative (–) side facing up.
5. Reinstall the back half of the transmitter case by
snapping it back on.
After the battery is replaced, the transmitter must
be synchronized with the keyless entry system’s
control unit. Press either the “ ” or “ ” but- ton six times to synchronize the unit.
yDo not let dust, oil or water get on or in the
transmitter when replacing the battery. y Be careful not to damage the printed circuit
board in the transmitter when replacing the bat-
tery.
„ Replacing lost transmitters
If you lose a transmitter or want to purchase additional
transmitters (up to four can be programmed), you
should re-program all of your transmitters for security
reasons. It is recommended that you have your dealer
program all of your transmitters into your system. T Programming the transmitters
The keyless entry system is equipped with a special
code learning feature that allows you to program new
transmitter codes into the system or to delete old ones. The system can learn up to four unique transmit-
ter codes. The four transmitter codes may be the
same or different.
A
UB2210BB

2-20
Keys and doors
press the “ ” button a second time. T
Emergency disarming
If you cannot disarm the system using the transmitter
(i.e. the transmitter is lost, broken or the transmitter
battery is too weak), you can disarm the system with-
out using the transmitter. To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
„ Valet mode
When you choose the valet mode, the security system
does not operate. In valet mode, the remote transmit-
ter is used only for locking and unlocking the doors
and rear gate and panic activation.
To enter the valet mode, open the driver’s door and
keep the “ ” button depressed for more than two
seconds . The security system status indicator light
will continue to flash twice per second indicating that
the system is in the valet mode. To exit valet mode, open the driver’s door and keep
the “ ” button pressed
for more than two sec-
onds . The indicator will stop flashing.
NOTE If the remote transmitter is used to lock or unlock
the doors while the valet mode is selected, the
turn signal lights do not flash but an electronic
chirp is emitted. „Passive arming
When passive arming mode has been programmed by
the dealer, arming of the system is automatically ac-
complished without using the remote transmitter. Note
that in this mode, DOORS MUST BE MANUALLYLOCKED. T To enter the passive mode
Since programming the passive arming mode is a
complicated procedure, have it done by your nearestSUBARU dealer. T Arming the system
1. Turn the ignition switch to the “ON” position.

2-22
Keys and doors
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically
lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
above or with the key once they have been
closed. Failure to lock the doors manually will
result in a higher security risk.
T Disarming the system
To disarm the system, briefly press the “ ” button
on the transmitter. V Tripped sensor identification (models without immobilizer)
If an electronic chirp sounds four times and the turn
signal lights flash four times when you disarm the sys-
tem, this indicates that the alarm was triggered. The
number of times the indicator light flashes indicates
what sensor caused the alarm condition.
To enter identification mode:
1. Open the driver’s door and leave it open.
2. Turn the ignition switch to the “ON” position twice. (“LOCK” “ON” “LOCK” “ON” “LOCK”)
3. The indicator light will start flashing. The indicator light provides the following indications.
Flashing once:
Any door or the rear gate has been
opened.
Flashing three times: The impact sensor in the sys-
tem’s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person.
Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
NOTE
The battery must be reconnected before the indi-
cator light will flash.
To exit this mode, close the door and turn the ignition
switch to the “ON” position.

2-28
Keys and doors
closed while driving.
Do not jam a plastic bag in or place cellophane
tape on the rear gate stays or scratch the stays
while loading or unloading cargo. That could
cause leakage of gas from the stays, which may
result in their inability to hold the rear gate
open.
NOTE
If the rear gate cannot be unlocked due to a dis-
charged battery, a fault in the door locking/unlock-
ing system or other causes, you can unlock it by
manually operating the rear gate lock release le-
ver.
For the procedure, refer to “Rear gate – if the rear
gate cannot be unlocked” in chapter 9 “In case of
emergency” .
Moonroof (if equipped)
A) Open/close switch
B) Open
C) Close
The moonroof operates only when the ignition switch
is in the “ON” position. „ To open the moonroof
Push and quickly release the rear part of the switch to
open the moonroof. The sun shade also will be
opened together with the moonroof. The moonroof will
stop at a position 20 in (50 cm) away from the fully
A B
CHS2030BC

6-2
Interior equipment
Interior equipmentInterior lights
When leaving your vehicle, make sure the light goes
out to avoid battery discharge. „
Dome light
The dome light switch has three positions: ON: The light stays on continuously.
DOOR (middle position): The dome light comes on
when any of the doors or the rear gate is opened. The
light remains on for several seconds and gradually
goes out after all doors and the rear gate are closed or
if the key is inserted in the ignition switch. The light also can be turned on by use of the keyless
entry transmitter. See the “Remote keyless entry sys-
tem (if equipped)” in chapter 2 for detailed information.
OFF:
The light stays off.
„ Cargo area light
The cargo area light switch has three positions: ON: The light stays on continuously.
OFF: The light stays off.
DOOR: The light comes on only when the rear gate is
opened.
ON
DOOR
OFF
HS6025BB
ON
OFF
DOOR
HS6026BB

11 - 4
Maintenance and service
the materials in the vehicle may be hazardous if
improperly used or handled, for example, bat-tery acid. y
Your vehicle should only be serviced by per-
sons fully competent to do so. Serious person-
al injury may result to persons not experienced
in servicing vehicles. y Always use the proper tools and make certain
that they are well maintained. y Never get under the vehicle supported only
by a jack. Always use a safety stands to sup-
port the vehicle. y Never keep the engine running in a poorly
ventilated area, such as a garage or other
closed areas. y Do not smoke or allow open flames around
the fuel or battery. This will cause a fire. y Because the fuel system is under pressure,
replacement of the fuel filter should be per-
formed only by your SUBARU dealer.y Wear adequate eye protection to guard
against getting oil or fluids in your eyes. If
something does get in your eyes, thoroughly
wash them out with clean water. y Do not tamper with the wiring of the SRS air-
bag system or seatbelt pretensioner system, or
attempt to take its connectors apart, as that may activate the system or it can render it inop-
erative. The wiring and connectors of these
systems are yellow for easy identification. NEV-
ER use a circuit tester for these wiring.
If your SRS airbag or seatbelt pretensioner
needs service, consult your nearest SUBARU
dealer.
„ Before checking or servicing in the en-
gine compartment
yAlways stop the engine and set the parking
brake firmly to prevent the vehicle from mov-
ing. y Always let the engine cool down. Engine
parts become very hot when the engine is run-
ning and remain hot for some time after the en-
gine is stopped.y Do not spill engine oil, engine coolant, brake
fluid or any other fluid on hot engine compo-
nents. This may cause a fire.y Always remove the key from the ignition
switch. When the ignition switch is in the “ON”
position, the cooling fan may operate suddenly
