SUBARU IMPREZA 2002 2.G Owners Manual

Keys and doors
2-16
Note that in this mode, DOORS MUST BE MANUAL-
LY LOCKED. To enter the passive mode
HB2036BA
1. Remove the side sill cover on the driver ’s side.
1)Open the driver ’s door.
2)Remove the clip by prying the edge with screw-
driver.
3)Remove the side sill cover by pulling it up.
HB2038BC
1) Connector for SRS airbag system (yel- low)
2) Blue (1P)
2. Connect the blue (1 pole) connector.
3. Turn the ignition switch from the “LOCK” to the
“ON” position.
4. Install the side sill cover.
To place the system in active arming mode (remote
required for activation), disconnect the white con-
nector.

Keys and doors
2-17
– CONTINUED –
WARNING
Do not disconnect or tamper with any yellow connector and/or any harness covered withyellow insulation and/or tape.Doing so could result in accidental inflation of the SRS airbag or could make the SRS airbag
system inoperative, which may result in seri-
ous injury.
Arming the system
1. Turn the ignition switch to the “ON” position.
HB2031BC
1) ON 2) LOCK 2. Turn the ignition switch from
“ON” to “LOCK”
position and remove the key from the ignition switch.
HB2024DB
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with theinside door lock levers.
5. Close the doors. The system will automatically
arm after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming
will take place immediately regardless of whether ornot the passive mode has been selected.

Keys and doors
2-18
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
below or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing. The indicator light provides the following indications.Flashing one time:
Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position.

Keys and doors
2-19
– CONTINUED –
Child safety locks
Each rear door has a child safety lock that prevents
the doors from being opened even if the inside door
handle is pulled.
HG2006BB
1) Lock 2) Unlock
When the child safety lock lever is in the lock posi-
tion, the door cannot be opened from inside regard-less of the position of the inner door handle lock
lever. The door can only be opened from the out-side.
WARNING
Always use the child safety lock whenever a child rides in the rear seat. Serious injurycould result if a child accidentally opened thedoor and fell out.

Keys and doors
2-20
Windows Power windows
WARNING
When operating the power windows, be ex-
tremely careful to prevent anyone ’s fingers,
arms or head from being caught in the win-
dow. Always lock the passengers ’ windows using
the lock switch when children are riding in thevehicle. Before leaving the vehicle, always remove
the key from the ignition switch for safety and never allow an unattended child to remains inthe vehicle. Failure to follow this procedurecould result in injury to a child operating the
power window.
The power windows operate only when the ignitionswitch is in the “ON” position.
Driver’ s side switches
HG2016BB
1) Lock switch
2) “AUTO” switch for driver ’s window
3) For front passenger ’s window
4) For rear left window
5) For rear right window
All door windows can be controlled by the power
window switch cluster at the driver side door.

Keys and doors
2-21
– CONTINUED –
nOperating the driver ’s window
HG2008DB
1) Open
2) Automatically open
3) Close
AUTO switch: This switch has two functions.
1. Push the switch down until it clicks and release it,
and the window will fully open. To stop the window
halfway, pull the switch up lightly.
2. Push the switch down lightly and hold it. The win- dow will open as long as the switch is held. Pull the switch up lightly and hold it. The window willclose as long as the switch is held. n
Operating the passengers ’ windows
HG2008CA
To open the passengers ’ windows, push the ap-
propriate switch down and hold it until the window
reaches the desired position. To close the window,
pull the switch up and hold it until it reaches the de-
sired position.

Keys and doors
2-22
nLocking the passengers ’ windows
HG2013BB
1) Lock 2) Unlock
To lock the passengers ’ windows, push the lock
switch. When the lock switch is in the “LOCK” posi-
tion, the passengers ’ windows cannot be opened or
closed.
Passengers’ side switches
To open the window, push the switch down and hold
it until the window reaches the desired position. To
close the window, pull the switch up and hold it until
the window reaches the desired position.
When the lock switch on the power window switch
cluster, located on the driver ’s side door, is in the “LOCK”
position, the passengers ’ windows cannot
be operated with the passengers ’ switches.

Keys and doors
2-23
– CONTINUED –
Trunk lid (Sedan)
WARNING
To prevent dangerous exhaust gas from en-
tering the vehicle, always keep the trunk lid
closed while driving. Help prevent young children from locking
themselves in the trunk. When leaving the ve-
hicle, either close all windows and lock all doors or cancel the inside trunk lid release. Also make certain that the trunk is closed.
On hot or sunny days, the temperature in thetrunk could quickly become high enough to
cause death or serious heat-related injuries
including brain damage, particularly for small children.
To open and close the trunk lid from outside
HGF012CA
To open the trunk lid from outside, insert the key and
turn it clockwise. To close the trunk lid, lightly pressthe trunk lid down until the latch engages.

Keys and doors
2-24
To open the trunk lid from inside
HB3000CC
1) Open
Pull the trunk lid release lever upward.
To cancel the trunk lid release
HG2009BA
The inside trunk lid release can be cancelled to help
prevent unauthorized entry into the trunk. To cancel
the trunk lid release, set the lid release cancel lever
(located on the inside of the trunk lid, mounted to the trunk lid latch) to the “CANCEL” position. When
this lock is in the “CANCEL” position, the trunk can
be opened only with the key.

Keys and doors
2-25
– CONTINUED –
Trunk lid release handle
The trunk lid release handle is a device designed to
open the trunk lid from inside the trunk. In the event
children or adults become locked inside the trunk,the handle allows them to open the lid. The handle islocated on the inside of the trunk lid.
To open the trunk lid from inside the trunk, press the
yellow handle downward as indicated by the arrow on the handle.
HBS070BA
This operation unlocks the trunk lid. Then, push up the lid.
The handle is made of material that remains lumi-
nescent for approximately an hour in the dark trunk
space after it is exposed to ambient light even for a short time.
WARNING
Never allow any child to get in the trunk and
play with the release handle. If the driver starts the vehicle without knowing that a child
is inside the trunk and the child opens the lidusing the release handle, the child could fallout and be killed or seriously injured.
CAUTION

Do not close the lid while gripping the re-
lease handle. The handle may be damaged. Do not use the handle as a hook to fasten
straps or ropes to secure your cargo in the trunk. Such use may result in damage of the handle. Load the trunk so that cargo can not strike
the release handle. If the cargo hits the handlewhile the vehicle is being driven, the handlemay be pushed down and the trunk lid may open. That may cause cargo to fall out of the trunk, which could create a traffic safety haz-ard.
