SUBARU IMPREZA 2002 2.G Owners Manual

In case of emergency
9-12
Jump starting
WARNING
Battery fluid is SULFURIC ACID. Do not let it
come in contact with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush
the exposed area with water immediately. Get
medical help if the fluid has entered your
eyes.
If battery fluid is accidentally swallowed, im-
mediately drink a large amount of milk or wa-
ter, and obtain immediate medical help. Keep everyone including children away from
the battery. The gas generated by a battery explodes if a
flame or spark is brought near it. Do not
smoke or light a match while jump starting. Never attempt jump starting if the dis-
charged battery is frozen. It could cause thebattery to burst or explode. Whenever working on or around a battery,
always wear suitable eye protectors, and re- move metal objects such as rings, bands or
other metal jewelry.
Be sure the jumper cables and clamps on
them do not have loose or missing insulation.
Do not jump start unless cables in suitablecondition are available. A running engine can be dangerous. Keep
your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other
moving engine parts. Removing rings,watches and ties is advisable.
When your vehicle does not start due to a run down
(discharged) battery, the vehicle may be jump
started by connecting your battery to another bat-
tery (called the booster battery) with jumper cables.
Jump starting is dangerous if it done incorrectly. If
you are unsure about the proper procedure for jump
starting, consult a competent mechanic. How to jump start
1. Make sure the booster battery is 12 volts and the
negative terminal is grounded.
2. If the booster battery is in another vehicle, do notlet the two vehicles touch.
3. Turn off all unnecessary lights and accessories.
4. Connect the jumper cables exactly in the se-
quence illustrated.

In case of emergency
9-13
– CONTINUED –
HB8007BC
1) Booster battery
2) Engine lifting bracket

In case of emergency
9-14
(1) Connect one jumper cable to the positive (+)
terminal on the discharged battery.
(2) Connect the other end of the jumper cable to
the positive (+) terminal of the booster battery.
(3) Connect one end of the other cable to thenegative (–) terminal of the booster battery.
(4) Connect the other end of the cable to the en-gine lifting bracket.
Make sure that the cables are not near any mov-
ing parts and that the cable clamps are not in
contact with any other metal.
5. Start the engine of the vehicle with the booster
battery and run it at moderate speed. Then start the
engine of the vehicle that has the discharged bat-
tery.
6. When finished, carefully disconnect the cables in
exactly the reverse order. Engine overheating
WARNING
Never attempt to remove the radiator cap until the engine has been shut off and has fullycooled down. When the engine is hot, thecoolant is under pressure. Removing the cap
while the engine is still hot could release aspray of boiling hot coolant, which could burn
you very seriously.
If the engine overheats, safely pull off the road and stop the vehicle in a safe place. If steam is coming from the engine compartment
Turn the engine off and get everyone away from the
vehicle until it cools down. If no steam is coming from the engine compartment
1. Keep the engine running at idling speed.
2. Open the hood to ventilate the engine compart-ment.

In case of emergency
9-15
– CONTINUED –
Confirm that the cooling fan is turning. If the fan is
not turning, immediately turn the engine off and con-
tact your authorized dealer for repair.
3. After the engine coolant temperature has
dropped, turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.If the coolant level is below the “MIN” mark, add
coolant up to the “MAX” mark.
5. If there is no coolant in the reserve tank, add
coolant to the reserve tank. Then remove the radia- tor cap and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator,
first wrap a thick cloth around the radiator cap, then
turn the cap counterclockwise slowly without press-
ing down until it stops. Release the pressure from
the radiator. After the pressure has been fully re-
leased, remove the cap by pressing down and turn-ing it. Towing
If towing is necessary, it is best done by your
SUBARU dealer or a commercial towing service.
Observe the following procedures for safety.
HG9000BA
WARNING
Never tow AWD vehicles (both AT and MT) with the front wheels raised off the groundwhile the rear wheels are on the ground, orwith the rear wheels raised off the ground while the front wheels are on the ground. This will cause the vehicle to spin away due to the

In case of emergency
9-16
operation or deterioration of the center differ- ential.
Towing and tie-down eyes
The towing eyes should be used only in an emer-
gency (e.g., to free a stuck vehicle from mud, sand or snow). Front towing eye:
HG9006BA

In case of emergency
9-17
– CONTINUED –
1. Take out the towing eye, screwdriver and wheel
nut wrench from the on board tool bag.
2. Pry off the cover on the front bumper using a
screwdriver, and you will find a threaded hole for at-
taching the towing eye.
3. Screw the towing eye into the threaded hole until
its thread can no longer be seen.
4. Tighten the towing eye securely with a wheel nut
wrench.
After towing, remove the towing eye from the vehicle
and stow it in the tool bag. Put the threaded hole
cover on the front bumper.
WARNING
Do not use the towing eye except when tow-
ing your vehicle. Be sure to remove the towing eye after tow-
ing. Leaving the towing eye mounted on the
vehicle could interfere with proper operationof the SRS airbag system in a frontal collision. Rear towing eye:
HG9004CA
CAUTION
Do not apply excessive lateral load to the tow- ing eyes.

In case of emergency
9-18
Tie-down eyes:
HG9011BB
1) Tie-down eye
2) Towing and tie-down eye
CAUTION
Never use the tie-down eye on the underside of the vehicle closest to the muffler for towing purposes.
Using a flat-bed truck
HG9002AA
This is the best way to transport your vehicle. Use
the following procedures to ensure safe transporta-tion.
1. Shift the selector lever into the “P” position for au-
tomatic transmission vehicles or “1st” for manual
transmission vehicles.
2. Pull up the parking brake lever firmly.

In case of emergency
9-19
– CONTINUED –
3. Secure the vehicle onto the carrier properly with safety chains. Each of safety chain should be
equally tightened and care must be taken not to pull
the chains so tightly that the suspension bottomsout.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), be carefulnot to scrape them when placing the vehicleon the carrier and when removing the vehicle
from the carrier.
Towing with all wheels on the ground
HG9001AA
1. Check the transmission and differential oil levels
and add oil to bring it to the upper level if necessary.
2. Release the parking brake and put the transmis-sion in neutral.
3. The ignition switch should be in the “ACC” posi-
tion while the vehicle is being towed.
4. Take up slack in the towline slowly to prevent
damage to the vehicle.
WARNING
Never turn the ignition switch to the “LOCK”
position while the vehicle is being towed be-
cause the steering wheel and the direction ofthe wheels will be locked. Remember that the brake booster and pow-
er steering do not function when the engine is not running. Because the engine is turned off,
it will take greater effort to operate the brakepedal and steering wheel.

In case of emergency
9-20
CAUTION
If transmission failure occurs, transport
your vehicle on a flat-bed truck. Do not run the engine while being towed in
this method. Transmission damage could re- sult if the vehicle is towed with engine run-ning. For vehicles with automatic transmission,
the traveling speed must be limited to less than 20 mph (30 km/h) and the traveling dis- tance to less than 31 miles (50 km). Forgreater speeds and distances, transport your
vehicle on a flat-bed truck. Maintenance tools
HG9010AA
Your vehicle is equipped with the following mainte-
nance tools:
Wheel cover remover (vehicles with wheel covers)
Screwdriver
Towing eye
Wheel nut wrench

In case of emergency
9-21
– CONTINUED –
Jack and jack handle
HGS042BA
The jack is stored on the left side of the trunk or
cargo area.
To take out the jack, turn the jackscrew counter-
clockwise to loosen it, then remove the jack.
HGF014BB
Sedan
1) Jack
2) Jack handle 3) Spare tire
