SUBARU IMPREZA 2003 2.G Owners Manual

In case of emergency
9-20
taching the towing hook.
3. Screw the towing hook into the threaded hole un-
til its thread can no longer be seen.
4. Tighten the towing hook securely with a wheel nut
wrench.
After towing, remove the towing hook from the
vehicle and stow it in the tool bag. Put the threaded
hole cover on the front bumper.
WARNING
Do not use the towing hook except when
towing your vehicle. Be sure to remove the towing hook after
towing. Leaving the towing hook mounted onthe vehicle could interfere with proper opera- tion of the SRS airbag system in a frontal col- lision. Rear towing hook:
CAUTION
Do not apply excessive lateral load to the tow- ing hook.

In case of emergency
9-21
– CONTINUED –
Tie-down hooks:
1) Tie-down hook
2) Towing and tie-down hook
CAUTION
Use only specified towing hook and tie-
down hook. Never use suspension parts or other body parts for towing or tie-down pur- poses. Never use the tie-down hook on the under-
side of the vehicle closest to the muffler fortowing purposes.
Using a flat-bed truck
This is the best way to transport your vehicle. Use
the following procedures to ensure safe transporta-

In case of emergency
9-22
tion.
1. Shift the selector lever into the “P” position for au-
tomatic transmission vehicles or “1st” for manual
transmission vehicles.
2. Pull up the parking brake lever firmly.
3. Secure the vehicle onto the carrier properly with safety chains. Each of safety chain should be
equally tightened and care must be taken not to pull
the chains so tightly that the suspension bottomsout.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), be carefulnot to scrape them when placing the vehicleon the carrier and when removing the vehicle
from the carrier.
Towing with all wheels on the ground
1. Check the transmission and differential oil levels
and add oil to bring it to the upper level if necessary.
2. Release the parking brake and put the transmis-sion in neutral.
3. The ignition switch should be in the “ACC” posi-
tion while the vehicle is being towed.
4. Take up slack in the towline slowly to prevent
damage to the vehicle.

In case of emergency
9-23
– CONTINUED –
WARNING
Never turn the ignition switch to the “LOCK”
position while the vehicle is being towed be-
cause the steering wheel and the direction ofthe wheels will be locked. Remember that the brake booster and pow-
er steering do not function when the engine is not running. Because the engine is turned off,
it will take greater effort to operate the brakepedal and steering wheel.
CAUTION
If transmission failure occurs, transport
your vehicle on a flat-bed truck. Do not run the engine while being towed in
this method. Transmission damage could re- sult if the vehicle is towed with the engine running. For vehicles with automatic transmission,
the traveling speed must be limited to lessthan 20 mph (30 km/h) and the traveling dis-tance to less than 31 miles (50 km). For greater speeds and distances, transport your
vehicle on a flat-bed truck. Maintenance toolsYour vehicle is equipped with the following mainte-
nance tools:
Wheel cover remover (vehicles with wheel covers)
Screwdriver
Towing hook (eye bolt)
Wheel nut wrench

In case of emergency
9-24
Jack and jack handleThe jack is stored on the left side of the trunk or
cargo area.
To take out the jack, turn the jackscrew counter-
clockwise to loosen it, then remove the jack.
Sedan
1) Jack
2) Jack handle 3) Spare tire

In case of emergency
9-25
– CONTINUED –
Wagon
1) Jack
2) Jack handle 3) Spare tire
The jack handle is stored under the spare tire cover.
For how to use the jack, refer to “Flat tires ”.

In case of emergency
9-26

10
10-1
– CONTINUED –
Exterior care 10-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washing 10-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Waxing and polishing 10-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning aluminum wheels 10-3 . . . . . . . . . . . . . . . . . . . . . .
Corrosion protection 10-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Most common causes of corrosion 10-4 . . . . . . . . . . . .
To help prevent corrosion 10-4 . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the interior 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat fabric 10-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leather seat materials 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Synthetic leather upholstery 10-6 . . . . . . . . . . . . . . . . . . . .
Appearance care

Appearance care
10-2
Exterior care Washing
The best way to preserve your vehicle ’s beauty is
frequent washing. Wash the vehicle at least once a
month to avoid contamination by road grime.
Wash dirt off with a wet sponge and plenty of luke-
warm or cold water. Do not wash the vehicle with hot
water and in direct sunlight.
Salt, chemicals, insects, tar, soot and bird droppings
should be washed off by using a light detergent, as
required. If you use a light detergent, make certain
that it is a neutral detergent. Do not use strong soap or chemical detergents. All cleaning agents should
be promptly flushed from the surface and not al-
lowed to dry there. Rinse the vehicle thoroughly with
plenty of lukewarm water. Wipe the remaining water
off with a chamois or soft cloth. NOTE When having your vehicle washed in an auto- matic car wash, make sure beforehand that thecar wash is of suitable type. If the vehicle is
equipped with a rear/roof spoiler or rear wiper, itmay be damaged by car wash brushes or otherequipment.
CAUTION
When washing the vehicle, the brakes may
get wet. As a result, the brake stopping dis-
tance will be longer. To dry the brakes, drivethe vehicle at a safe speed while lightly press- ing the brake pedal to heat up the brakes. Do not wash the engine compartment and
area adjacent to it. If water enters the engineair intake, electrical parts or the power steer-
ing fluid reservoir, it will cause engine trouble
or faulty power steering respectively.
Washing the underbody
Chemicals, salts and gravel used for deicing road
surfaces are extremely corrosive, accelerating the
corrosion of underbody components, such as theexhaust system, fuel and brake lines, brake cables,floor pan and fenders, and suspension.
Thoroughly flush the underbody and inside of the
fenders with lukewarm or cold water at frequent in-
tervals to reduce the harmful effects of such agents.
Using a warm water washer
Keep a good distance of 12 in (30 cm) or more
between the washer nozzle and the vehicle.

Appearance care
10-3
– CONTINUED –
Do not wash the same area continuously.
If a stain will not come out easily, wash by hand.
Some warm water washers are of the high tempera-
ture, high pressure type, and they can damage or
deform the resin parts such as mouldings, or causewater to leak into the vehicle. Waxing and polishing
Always wash and dry the vehicle before waxing and polishing.Use a good quality polish and wax and apply them
according to the manufacturer ’s instructions. Wax or
polish when the painted surface is cool.
Be sure to polish and wax the chrome trim, as well
as the painted surfaces. Loss of wax on a painted
surface leads to loss of the original luster and also
quickens the deterioration of the surface. It is rec-
ommended that a coat of wax be applied at least
once a month, or whenever the surface no longer re-
pels water. If the appearance of the paint has diminished to the
point where the luster or tone cannot be restored,
lightly polish the surface with a fine-grained com-
pound. Never polish just the affected area, but in-
clude the surrounding area as well. Always polish in
only one direction. A No. 2000 grain compound is recommended. Never use a coarse-grained com-
pound. Coarser grained compounds have a smallergrain-size number and could damage the paint. Af-
ter polishing with a compound, coat with wax to re-
store the original luster. Frequent polishing with a
compound or an incorrect polishing technique will
result in removing the paint layer and exposing the
undercoat. When in doubt, it is always best to con-tact your SUBARU dealer or an auto paint specialist. NOTE Be careful not to block with windshield washer nozzles with wax when waxing the vehicle.
Cleaning aluminum wheels
Promptly wipe the aluminum wheels clean of any
kind of grime or agent. If dirt is left on too long, it
may be difficult to clean off. Do not use soap containing grit to clean the
wheels. Be sure to use a neutral cleaning agent, and
later rinse thoroughly with water. Do not clean the
wheels with a stiff brush or expose them to a high- speed washing device. Clean the vehicle (including the aluminum wheels)
with water as soon as possible when it has been
splashed with sea water, exposed to sea breezes, or
driven on roads treated with salt or other agents.
