brake light SUBARU IMPREZA WRX 2002 2.G Owners Manual

19
– CONTINUED –
Warning and indicator light
Mark
NamePage
Seatbelt warning light3-9
AIRBAGSRS airbag system warn- ing light3-10
CHECK ENGINE warning light/Malfunction indicatorlamp3-10
Charge warning light3-11
Oil pressure warning light3-11
AT OIL temperature warn- ing light (if equipped)3-12
orABS warning light3-12
orBrake system warning light3-13
Door open warning light3-13
MarkNamePage
Front-wheel drive warning light (if equipped)3-14
Turn signal indicator lights3-14
High beam indicator light3-14
Security system indicator light (if equipped)2-12

3
3-1
– CONTINUED –
Ignition switch 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LOCK 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ON 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
START 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder chime 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key interlock release (AT vehicles only) 3-4 . . . . . .
Hazard warning flasher 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Meters and gauges 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator
(if equipped) 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-9 . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 3-9 . . . . . . . . . . . . . . .
SRS airbag system warning light 3-10 . . . . . . . . . . . . . . .
CHECK ENGINE warning light/ Malfunction indicator lamp 3-10 . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light
(for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . .
Door open warning lights 3-13 . . . . . . . . . . . . . . . . . . . . . . . . Front-wheel drive warning light
(for AT vehicles – if equipped) 3-14 . . . . . . . . . . . . . . . .
Shift position indicator (AT vehicles) 3-14 . . . . . . . . . .
Turn signal indicator lights 3-14 . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-14 . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/low beam change (dimmer) 3-16 . . . . . . . . . . . . . . .
Headlight flasher 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime running light system 3-17 . . . . . . . . . . . . . . . . . . .
Turn signal lever 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-18 . . . . . . . . . . . . . . . .
Parking light switch 3-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-19 . . . . . . . . . . . . . . . . . .
Wiper and washer 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 3-21 . . . . . . .
Rear window wiper and washer switch
(if equipped) 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-24 . . . . . . . . . . . . . . . . . .
Mirrors 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheel 3-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instruments and controls

Instruments and controls
3-9
– CONTINUED –
and high revving operation when engine is not
warmed up enough should be avoided.
CAUTION
If the pointer exceeds the normal operating range, safely stop the vehicle as soon as pos- sible. See the “In case of emergency ” in chapter 9.
Outside temperature indicator (if equipped)
The outside temperature indicator shows the outside
temperature in a range from –22°F to 122 °F ( –30 °C
to 50 °C).
The indicator can give a false reading under any of the following conditions: When there is too much sun.
During idling; while running at low speeds in a
traffic jam; when the engine is restarted immediately
following a shutdown. When the actual outside temperature falls outside
the specified indicator range. Warning and indicator lights
Several of the warning and indicator lights come on
momentarily and then go out when the ignition
switch is initially turned to the
“ON” position. This
permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the “ON” position. The following lights come on:
Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light/Malfunction indica- tor lamp
Charge warning light
Oil pressure warning light
AT OIL temperature warning light (AT vehicles)
ABS warning light
Brake system warning light
If any lights fail to come on, it indicates a burned-out
bulb or a malfunction of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” posi-
tion, the seatbelt warning light will come on and the
reminder chime will sound for about six seconds to
remind the driver to fasten the seatbelt.

Instruments and controls
3-12
CAUTION
Do not operate the engine with the oil pres- sure warning light on. This may cause serious engine damage.
AT OIL TEMPerature warning
light (for AT vehicles)
If this light comes on when the engine is running, it may indicate that the automatic transmission fluid
temperature is too hot.
If the light comes on while driving, it is unnecessary
to stop the vehicle, but avoid driving up steep
grades or in stop and go traffic.
Automatic transmission control system warn- ing
If the light flashes after the engine starts, it may indi-
cate that the automatic transmission control system
is not working properly. Contact your nearest
SUBARU dealer for service immediately. ABS warning light
The ABS warning light comes on when the ignition
switch is turned to the “ON” position and goes out after about two seconds.This is an indication that the ABS system is working
properly.
CAUTION
If the warning light behaves as follows, the
ABS system may not work properly. When the warning light is on, the ABS func-
tion shuts down; however, the conventional
brake system continues to operate normally.
The warning light does not come on when
the ignition switch is turned to the “ON” posi-
tion. The warning light comes on when the igni-
tion switch is turned to the “ON” position, but
it does not go out even when the vehiclespeed exceeds approximately 8 mph (12km/h). The warning light comes on during driving.
If these occur, have the ABS system repaired at the first available opportunity by your
SUBARU dealer.
NOTE
If the warning light behavior is as shown below, the ABS system may be considered normal.
(U.S.) (Canada)

Instruments and controls
3-13
– CONTINUED –
The warning light comes on right after the
engine is started but goes out immediately, remaining off. The warning light remains on after the engine
has been started, but it goes out when the
vehicle speed reaches about 8 mph (12 km/h). The warning light comes on during driving, but
it goes out immediately and remains off.
When driving with an insufficient battery voltage
such as when the engine is jump started, the ABS
warning light may come on. This is due to the low
battery voltage and does not indicate a malfunction.
When the battery becomes fully charged, the lightwill go out. Brake system warning light
CAUTION
Driving with the brake system warning light
on is dangerous. This indicates your brake
system may not be working properly. If thelight remains on, have the brakes inspected
by a SUBARU dealer immediately. If at all in doubt about whether the brakes are operating properly, do not drive the ve-
hicle. Have your vehicle towed to the nearest
SUBARU dealer for repair.
This light has the following two functions: Parking brake warning
The light comes on with the parking brake applied while the ignition switch is in the “ON” position. It
goes out when the parking brake is fully released.
Brake fluid level warning
This light comes on when the brake fluid level has
dropped to near the “MIN” level of the brake fluid
reservoir with the ignition switch in the “ON” position
and with the parking brake fully released.
If the brake system warning light should come on
while driving (with the parking brake fully releasedand with the ignition switch positioned in “ON”), it
could be an indication of leaking of brake fluid or
worn brake pads. Have your vehicle checked by a
SUBARU dealer immediately. Door open warning lights
The door open warning light comes on if any door or
the rear gate is not fully closed.
(U.S.)
(Canada)

Instruments and controls
3-17
– CONTINUED –
Daytime running light system
WARNING
The tail lights, parking lights, and side marker
lights are not turned on by the daytime run-ning light system. The light switch must al- ways be turned to the “a ” position when it
is dark outside.
The low beam headlights will automatically come on
at reduced brightness when the engine has started,
under the following conditions: The parking brake is fully released.
The light switch is in the “OFF” or “p ” position.
The automatic transmission selector lever is set at
other than the “P” position. Turn signal lever
HB2015BC
1) Right turn
2) Left turn
3) Lane change for right
4) Lane change for left
To activate the right turn signal, push the turn signal
lever up. To activate the left turn signal, push the
turn signal lever down. When the turn is finished, the
lever will return automatically. If the lever does not
return after cornering, return the lever to the neutralposition by hand.
To signal a lane change, push the turn signal lever up or down slightly and hold it during the lane
change. The turn signal indicator lights will flash in

Interior equipment
6-8
sory power socket for a long period of time while the engine is not running can cause bat-tery discharge.Before driving your vehicle, make sure that
the plug and the cord on your electrical ap-
pliance will not interfere with your shifting gears and operating the accelerator and brake
pedals. If they do, do not use the electrical ap-
pliance while driving.
HG6013BA
Electrical power (12V DC) from the battery is on tap at the socket when the ignition switch is either in the
“ACC” or “ON” position.
You can use an in-car use electrical appliance by
connecting it to the socket.
Electrical power socket located on the lower part of the instrument panel
CAUTION
The electrical power socket located on the lower part of the instrument panel is designedto use only a SUBARU genuine cigarettelighter plug. Do not use non-genuine cigarettelighter plugs or any “plug-in” type electrical
accessories in the socket. Doing so may
cause a short-circuit and overheating, result-ing in a fire.Refer to the “Cigarette lighter ” section in this
chapter.

7
7-1
– CONTINUED –
Fuel 7-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel requirements 7-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel filler lid and cap 7-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
State emission testing (U.S. only) 7-6 . . . . . . . . . . . . .
Preparing to drive 7-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the engine 7-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the engine for a manual transmission vehicle 7-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the engine for an automatic
transmission vehicle 7-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the engine during cold weather below –4 °F ( –20 °C) 7-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting a flooded engine 7-9 . . . . . . . . . . . . . . . . . . . . . . . .
Stopping the engine 7-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission 7-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting speeds 7-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving tips 7-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Selector lever for automatic transmission 7-14 . . . .
Shift lock release 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear viscous limited slip differential
(LSD) (if equipped) 7-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering 7-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disc brake pad wear warning indicators 7-22 . . . . . .
ABS (Anti-lock Brake System) 7-22 . . . . . . . . . . . . . . . . . ABS system self-check 7-23
. . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking your vehicle 7-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control (if equipped) 7-27 . . . . . . . . . . . . . . . . . . . . .
To set cruise control 7-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To temporarily cancel the cruise control 7-28 . . . . . .
To turn off the cruise control 7-28 . . . . . . . . . . . . . . . . . . . .
To change the cruising speed 7-28 . . . . . . . . . . . . . . . . . . .
Starting and operating

Starting and operating
7-7
– CONTINUED –
CAUTION
Resultant vehicle damage due to improper testing is not covered under the SUBARU Lim-
ited Warranty and is the responsibility of the state inspection program or its contractors orlicensees. Preparing to drive
You should perform the following checks and adjust-
ments every day before you start driving.
1. Check that all windows, mirrors, and lights are
clean and unobstructed.
2. Check the appearance and condition of the tires.
Also check tires for proper inflation.
3. Look under the vehicle for any sign of the leaks.
4. Check that the hood, trunk and rear gate are fullyclosed.
5. Check the adjustment of the seat.
6. Check the adjustment of the inside and outside
mirrors.
7. Fasten your seatbelt. Check that your passen-gers have fastened their seatbelts.
8. Check the operation of the warning and indicator
lights when the ignition switch is turned to the
“ON”
position.
9. Check the gauges, indicator and warning lights
after starting the engine. NOTE Engine oil, engine coolant, brake fluid, washer
fluid and other fluid levels should be checked
daily, weekly or at fuel stops.

Starting and operating
7-8
Starting the engine
CAUTION
Do not operate the starter motor continuously
for more than ten seconds. If the engine fails to start after operating the starter for five to ten seconds, wait for ten seconds or more be-fore trying again.
Starting the engine for a manual transmission vehicle
1. Apply the parking brake.
2. Turn off unnecessary lights and accessories.
3. Press the clutch pedal to the floor and shift the
shift lever into neutral. Hold the clutch pedal to the
floor while starting the engine.
The starter motor will only operate when the clutch
pedal is pressed fully to the floor.
4. Turn the ignition switch to the “ON” position and
check the operation of the warning and indicatorlights. Refer to the “Warning and indicator light ” sec-
tion (chapter 3).
5. Turn the ignition switch to the “START” position
without depressing the accelerator pedal. Release the key immediately after the engine has started.
If the engine does not start within ten seconds, wait
a while and then turn the ignition switch to the
“START”
position again while depressing the accel-
erator pedal half way down.
6. Confirm that all warning and indicator lights have
gone off after the engine has started. The fuel injec-
tion system automatically lowers the idle speed as
the engine warms up.
Starting the engine for an automatic transmission vehicle
1. Apply the parking brake.
2. Turn off unnecessary lights and accessories.
3. Shift the selector lever to the “P” or “N” position
(preferably “P” position).
The starter motor will only operate when the select lever is at the “P” or “N” position.
4. Turn the ignition switch to the “ON” position and
check the operation of the warning and indicator lights. Refer to the “Warning and indicator lights ”
section (chapter 3).
5. Turn the ignition switch to the “START” position
without depressing the accelerator pedal. Release
the key immediately after the engine has started.
If the engine does not start within ten seconds, wait
