How to use this owner’s manual
Using your Owner ’s manual
Before you operate your vehicle, carefully read this
manual. To protect yourself and extend the service
life of your vehicle, follow the instructions in this
manual. Failure to observe these instructions may
result in serious injury and damage to your vehicle.
This manual is composed of fourteen chapters. Each chapter begins with a brief table of contents,so you can usually tell at a glance if that chapter
contains the information you want. Chapter 1: Seat, seatbelt and SRS airbags
This chapter informs you how to use the seat and
seatbelt and contains precautions for the SRS air- bags.Chapter 2: Keys and doors
This chapter informs you how to operate the keys,locks and windows.Chapter 3: Instruments and controls
This chapter informs you about the operation of
instrument panel indicators and how to use theinstruments and other switches.Chapter 4: Climate Control
This chapter informs you how to operate the climate control.Chapter 5: Audio
This chapter informs you how to operate your audiosystem.Chapter 6: Interior equipment
This chapter informs you how to operate interior equipment. Chapter 7: Starting and operating
This chapter informs you how to start and operateyour SUBARU.Chapter 8: Driving tips
This chapter informs you how to drive your SUBARU in various conditions and explains some safety tips on driving.Chapter 9: In case of emergency
This chapter informs you what to do if you have a
problem while driving, such as a flat tire or engineoverheating. Chapter 10: Appearance care
This chapter informs you how to keep your SUBARUlooking good.
Chapter 11: Maintenance and service
This chapter informs you when you need to take
your SUBARU to the dealer for scheduled mainte-
nance and informs you how to keep your SUBARU
running properly.

5
– CONTINUED –
and weight. If a child is too big for a child re- straint system, the child should sit in the
REAR seat and be restrained using the seat-
belts. According to accident statistics, chil-dren are safer when properly restrained in therear seating positions than in the front seating positions. Never allow a child to stand up or
kneel on the seat.Put children aged 12 and under in the REAR
seat properly restrained at all times in a childrestraint device or in a seatbelt. The SRS air-bag deploys with considerable speed and force and can injure or even kill children, es-
pecially if they are 12 years of age and underand are not restrained or improperly re-strained. Because children are lighter and
weaker than adults, their risk being injured
from deployment is greater. NEVER INSTALL A REARWARD FACING
CHILD SEAT IN THE FRONT SEAT. DOING SO
RISKS SERIOUS INJURY OR DEATH TO THE
CHILD BY PLACING THE CHILD ’S HEAD TOO
CLOSE TO THE SRS AIRBAG. Always use the child safety locks whenever
a child rides in the rear seat. Serious injurycould result if a child accidentally opened thedoor and fell out. Refer to the “Child safety locks”
section in chapter 2.
Always lock the passenger ’s windows using
the lock switch when children are riding in the
vehicle. Failure to follow this procedure couldresult in injury to a child operating the power
window. Refer to the “Windows” section in
chapter 2. Never leave unattended children in the ve-
hicle. They could accidentally injure them-
selves or others through inadvertent opera-tion of the vehicle. Also, on hot or sunny
days, temperature in a closed vehicle could
quickly become high enough to cause severe or possibly fatal injuries to them. Help prevent young children from locking
themselves in the trunk. When leaving the ve-
hicle, either close all windows and lock alldoors or cancel the inside trunk lid release. Also make certain that the trunk is closed. On hot or sunny days, the temperature in a trunkcould quickly become high enough to cause
death or serious heat-related injuries includ-ing brain damage, particularly for small chil-dren.
Carefully read the sections “Child restraint systems ”,
“ SRS airbag ”, and “Seatbelts” in chapter 1 of this

12
Illustrated index Exterior
HGF024BB
1) Engine hood (page 11-5)
2) Headlight switch (page 3-15)
3) Replacing bulbs (page 11-56)
4) Wiper switch (page 3-21)
5) Door locks (page 2-3)
6) Tire pressure (page 11-38)
7) Flat tires (page 9-5)
8) Tire chains (page 8-14)
9) Front fog light switch (page
3-19)
10) Tie-down eyes (page 9-15)
11) Towing eye (page 9-15)

16
Instrument panel
HGF032BB
1) Door locks (page 2-3)
2) Light control lever (page 3-15)
3) Combination meter (page 3-6)
4) Wiper control lever (page 3-20)
5) Hazard warning flasher switch
(page 3-5)
6) Audio (page 5-1)
7) Gear shift lever (MT) (page
7-10)/Selector lever (AT) (page7-13)
8) Outside mirror switch (page 3-28)
9) Climate control (page 4-1)
10) Cruise control (page 7-27)
11) Horn (page 3-31)
12) SRS airbag (page 1-38)
13) Tilt steering (page 3-30)
14) Fuse box (page 11-51)
15) Hood lock release (page 11-5)
16) Power window (page 2-20)

Seat, seatbelt and SRS airbags
1-16
WARNING
When wearing the seatbelts, make sure the
shoulder portion of the webbing does notpass over your neck. If it does, adjust the
seatbelt anchor to a lower position. Placing the shoulder belt over the neck may result in
neck injury during sudden braking or in a col-lision.
n Unfastening the seatbelt
Push the button on the buckle.
HB0303
Before closing the door, make sure that the belts are
retracted properly to avoid catching the belt web- bing in the door.
Rear seatbelts (except rear center seatbelt on
Wagon)
1. Sit well back in the seat.
2. Pick up the tongue plate and pull the belt out
slowly. Do not let it get twisted. If the belt stops be-
fore reaching the buckle, return the belt slightly and
pull it out more slowly. If the belt still cannot be
unlocked, let the belt retract slightly after giving a
strong pull on it, then pull it out slowly again.
3. Insert the tongue plate into the buckle until youhear a click.
OM-H0043
4. 1) To make the lap part tight, pull up on the shoulder belt.

2
2-1
– CONTINUED –
Keys 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key number 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door locks 2-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locking and unlocking from the outside 2-3 . . . . . .
Locking and unlocking from the inside 2-4 . . . . . . .
Power door locking switches
(if equipped) 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless entry system (if equipped) 2-6 . . . . . . . . . . .
Locking the doors 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unlocking the doors 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sounding a panic alarm 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting audible signal operation 2-8 . . . . . . . . . . . . .
Replacing the battery 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing lost transmitters 2-9 . . . . . . . . . . . . . . . . . . . . . .
Security system (if equipped) 2-12 . . . . . . . . . . . . . . . . . .
System operation 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the system 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming the system 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sounding a panic alarm 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Valet mode 2-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passive arming 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child safety locks 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid (Sedan) 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To open and close the trunk lid from outside 2-23
To open the trunk lid from inside 2-24 . . . . . . . . . . . . . . . To cancel the trunk lid release 2-24
. . . . . . . . . . . . . . . . . .
Trunk lid release handle 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear gate (Wagon) 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys and doors

Keys and doors
2-2
Keys
HS0009
1) Master key
2) Submaster key
3) Valet key4) Key number
plate
Three types of keys are provided for your vehicle.
Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle. Ignition switch
Doors
Trunk (sedan) or Rear gate (wagon)
Glove compartment
The valet key fits only the ignition switch and door locks. You can keep the trunk and glove compart-
ment locked when you leave your vehicle and valet
key at a parking facility.
Key number
The key number is stamped on the metal plate
attached to the key set. Write down the key numberand keep it in another safe place, not in the vehicle.
This number is needed to make a replacement key if you lose your key or lock it inside the vehicle.

Keys and doors
2-3
– CONTINUED –
Door locks Locking and unlocking from the out- side
HS0010
1) Lock 2) Unlock
To lock the door from the outside with the key, turn
the key toward the rear. To unlock the door, turn the
key toward the front. Pull the outside door handle to open an unlocked
door.
HB2024BC
1) Rotate the lock lever rearward.
2) Close the door.
To lock the door from the outside without the key,
rotate the lock lever rearward and then close the
door.
To lock the door from the outside using the power
door locking switch, push the front side of the switch
(“LOCK” side) and then close the door. In this case,
all closed doors and the rear gate (for wagon) arelocked at the same time.
Always make sure that all doors and the rear gate
(wagon) are locked before leaving your vehicle.

Keys and doors
2-4
NOTE
Make sure that you do not leave the key inside the vehicle when locking the doors from the out-
side without the key. Locking and unlocking from the inside
HB2001BC
1) Lock 2) Unlock
To lock the door from the inside, rotate the lock lever
rearward. To unlock the door from the inside, rotate
the lock lever forward.
The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked
door.
Always make sure that all doors and the rear gate
(wagon) are closed before starting to drive.
WARNING
Keep all doors locked when you drive, espe-
cially when small children are in your vehicle.Along with the proper use of seat belts and child restraints, locking the doors reduces the
chance of being thrown out of the vehicle inan accident.It also helps prevent passengers from fallingout if a door is accidentally opened, and in-
truders from unexpectedly opening doors and entering your vehicle.

Keys and doors
2-5
– CONTINUED –
Power door locking switches (if equipped)
HG2012BB
1) Lock 2) Unlock
All doors and the rear gate (wagon) can be locked and unlocked by the power door locking switches
located at the driver ’s side and the front passenger ’s
side doors.
To lock the doors, push the front side of the switch.
To unlock the doors, push the rear side of the switch.
When you close the doors after you set the door
locks, the doors remain locked. NOTE
Make sure that you do not leave the key inside the vehicle before locking the doors from theoutside using power door locking switches.
