SUBARU IMPREZA WRX 2003 2.G Owners Manual

Maintenance and service
11-58
1) Fuse puller 2) Spare fuse
The fuse puller and spare fuses are stored in the
main fuse box cover in the engine compartment.A) Good B) Blown
If any lights, accessories or other electrical controls
do not operate, inspect the corresponding fuse. If a
fuse has blown, replace it.
1. Turn the ignition switch to the “LOCK” position
and turn off all electrical accessories.
2. Remove the cover.
3. Determine which fuse may be blown. The backside of each fuse box cover and the “Fuse and cir-
cuits” section in chapter 12 in this manual show the
circuit for each fuse.

Maintenance and service
11-59
– CONTINUED –
1) Fuse puller
4. Pull out the fuse with the fuse puller.
5. Inspect the fuse. If it has blown, replace it with a
spare fuse of the same rating.
6. If the same fuse blows again, this indicates that
its system has a problem. Contact your SUBARU
dealer for repairs. Main fuse
Main fuse box
The main fuses are designed to melt during an over-
load to prevent damage to the wiring harness and
electrical equipment. Check the main fuses if any
electrical component fails to operate (except the
starter motor) and other fuses are good. A melted
main fuse must be replaced. Use only replacementswith the same specified rating as the melted main
fuse. If a main fuse blows after it is replaced, have
the electrical system checked by your nearest
SUBARU dealer.

Maintenance and service
11-60
Installation of accessories
Always consult your SUBARU dealer before instal- ling fog lights or any other electrical equipment inyour vehicle. Such accessories may cause the elec-
tronic system to malfunction if they are incorrectly
installed or if they are not suited for the vehicle.

Maintenance and service
11-61
– CONTINUED –
Replacing bulbs

Maintenance and service
11-62
Wattage Bulb No.
1) Front turn signal 12V –21W —
2) Spot light 12V –8W —
3) Room light 12V –8W —
4) Side marker light (Front) 12V–5W 168
5) Parking light 12V –5W 168
6) Front fog light 12V –55W —
7) Headlight 12V–60/55W 9007 (HB3)
8) Trunk room light 12V –16W W16W
9) High mount stop light Sedan (in compartment) 12V-18W 921
Sedan (in rear spoiler) 12V-1.2W —
Wagon 12V-13W 912
10) Backup light 12V –21W 7440
11) Rear turn signal 12V –21W —
(Amber)
12) Brake light 12V –21W 7440
13) Licence plate light 12V –5W 168
14) Tail light 12V –21/5W 7443
15) Brake/tail light 12V –21/5W 7443
16 )Cargo area light 12V –13W —
17) Side marker light (Rear) 12V –5W 168
Headlight
CAUTION
Halogen headlight bulbs become very hot while in use. If you touch the bulb surfacewith bare hands or greasy gloves, fingerprints or grease on the bulb surface developinto hot spots, causing the bulb to break. If there are finger prints or grease on the bulb
surface, wipe them away with a soft cloth
moistened with alcohol.
NOTE If headlight aiming is required, consult your
SUBARU dealer for proper adjustment of the headlight aim.

Maintenance and service
11-63
– CONTINUED –
1) Push 2) Pull
1. Disconnect the electrical connector while press-
ing the lock release tab.2. Remove the bulb holder from the headlight as-
sembly by turning it counterclockwise.

Maintenance and service
11-64
3. Remove the bulb from the headlight assembly.
4. Install the new bulb.
5. Install the bulb holder in the headlight assembly
by turning it clockwise until it locks.
6. Reconnect the electrical connector.
Front turn signal light and parking light
1) Front turn signal light
2) Parking light

Maintenance and service
11-65
– CONTINUED –
Front turn signal light bulbs
1. Remove the bulb socket from the headlight as-
sembly by turning it counterclockwise.
2. Pull the bulb out of the socket. Install a new bulb.
3. Set the bulb socket into the headlight assembly
and turn it clockwise until it locks.
Parking light bulbs
The headlight assembly must be removed before
the parking light bulbs can be replaced. When the
headlight assembly has been removed and then re-
installed, it may become necessary to make a head-
light aiming adjustment. It may be difficult to replace
the bulbs. Have your SUBARU dealer replace the bulbs if necessary.
: Clip : Hook

Maintenance and service
11-66
1. Remove the front grille. Use a screwdriver to de-
tach the four clips at the top and the two hooks on
each side.2. Loosen three clips to remove the grille side cover.

Maintenance and service
11-67
– CONTINUED –
3. Remove three bolts and disconnect connectors, and then detach headlight assembly.
4. Remove the bulb socket from the headlight as-
sembly by turning it counterclockwise.
5. Pull the bulb out of the socket. Install a new bulb.
6. Set the bulb socket into the headlight assembly
and turn it clockwise until it locks.
