How to use this owner’s manual
Using your Owner ’s manual
Before you operate your vehicle, carefully read this
manual. To protect yourself and extend the service
life of your vehicle, follow the instructions in this
manual. Failure to observe these instructions may
result in serious injury and damage to your vehicle.
This manual is composed of fourteen chapters. Each chapter begins with a brief table of contents,so you can usually tell at a glance if that chapter
contains the information you want. Chapter 1: Seat, seatbelt and SRS airbags
This chapter informs you how to use the seat and
seatbelt and contains precautions for the SRS air- bags.Chapter 2: Keys and doors
This chapter informs you how to operate the keys,locks and windows.Chapter 3: Instruments and controls
This chapter informs you about the operation of
instrument panel indicators and how to use theinstruments and other switches.Chapter 4: Climate Control
This chapter informs you how to operate the climate control.Chapter 5: Audio
This chapter informs you how to operate your audiosystem.Chapter 6: Interior equipment
This chapter informs you how to operate interior equipment. Chapter 7: Starting and operating
This chapter informs you how to start and operateyour SUBARU.Chapter 8: Driving tips
This chapter informs you how to drive your SUBARU in various conditions and explains some safety tips on driving.Chapter 9: In case of emergency
This chapter informs you what to do if you have a
problem while driving, such as a flat tire or engineoverheating. Chapter 10: Appearance care
This chapter informs you how to keep your SUBARUlooking good.
Chapter 11: Maintenance and service
This chapter informs you when you need to take
your SUBARU to the dealer for scheduled mainte-
nance and informs you how to keep your SUBARU
running properly.

Seat, seatbelt and SRS airbags
1-64
Frontal airbag module (Passenger ’s side)
Side airbag sensor (Driver ’s side — if equipped)
Side airbag sensor (Passenger ’s side — if
equipped) Side airbag module (Driver ’s side — if equipped)
Side airbag module (Passenger ’s side — if
equipped) Seatbelt pretensioner (Driver ’s side)
Seatbelt pretensioner (Passenger ’s side)
All related wiring
In the event of a malfunction indicated by any of fol-
lowing, the vehicle should be taken promptly to your
nearest SUBARU dealer to have the system
checked. Unless checked and repaired, the SRS
airbags will not function reliably: Flashing or flickering of the indicator light.
No illumination of the warning light when the igni-
tion switch is first turned to the “ON” position.
Continuous illumination of the warning light.
Illumination of the warning light while driving.
SRS airbag system servicing
WARNING
When discarding an airbag module or scrap-
ping the entire car damaged by a collision,
consult your SUBARU dealer. The SRS airbag has no user-serviceable
parts. Do not use electrical test equipment on any circuit related to the SRS airbag system.For required servicing of the SRS airbag, see
your nearest SUBARU dealer. Tampering withor disconnecting the system ’s wiring could re-
sult in accidental inflation of the SRS airbag
or could make the system inoperative, which
may result in serious injury. The wiring har-
nesses of the SRS airbag system are coveredwith yellow insulation and system connectorsare yellow for easy identification.

Starting and operating
7-8
mination is observed, there is no stored diagnostic
trouble codes, and the OBD system readiness moni-
tors are complete. A vehicle fails
the OBD inspection if the “CHECK
ENGINE ” warning light/MIL is not properly operating
or there is one or more diagnostic trouble codes
stored in vehicle ’s computer with the “CHECK
ENGINE ” warning light/MIL illuminated.
A state emission inspection may reject (not pass
or fail) a vehicle if the number of OBD system readi- ness monitors “Not Ready ” is greater than three.
Under this condition, the vehicle operator should be instructed to drive his/her vehicle for a few days to
set the monitors and return for an emission re-in-spection. Owners of rejected or failing vehicles should con-
tact their Subaru Dealer for service. Preparing to drive
You should perform the following checks and adjust-
ments every day before you start driving.
1. Check that all windows, mirrors, and lights are
clean and unobstructed.
2. Check the appearance and condition of the tires.
Also check tires for proper inflation.
3. Look under the vehicle for any sign of leaks.
4. Check that the hood, trunk and rear gate are fullyclosed.
5. Check the adjustment of the seat.
6. Check the adjustment of the inside and outside
mirrors.
7. Fasten your seatbelt. Check that your passen-gers have fastened their seatbelts.
8. Check the operation of the warning and indicator
lights when the ignition switch is turned to the
“ON”
position.
9. Check the gauges, indicator and warning lights
after starting the engine. NOTE Engine oil, engine coolant, brake fluid, washer
fluid and other fluid levels should be checked
daily, weekly or at fuel stops.

Maintenance and service
11-2
Tire inspection 11-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressures and wear 11-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel balance 11-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wear indicators 11-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire replacement 11-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel replacement 11-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel covers 11-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (If equipped) 11-50 . . . . . . . . . . . . . . . .
Windshield washer fluid 11-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 11-51 . .
Battery 11-54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse 11-59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 11-60 . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 11-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-64 . . . . . .
Front fog light (if equipped) 11-68 . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-69 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-70 . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-72 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome light, map light and cargo area light 11-73 . . .
Trunk light 11-74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High mount stop light 11-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service
11-39
– CONTINUED –
Replacement of brake pad and lining
The front disc brakes and the right rear disc brake have an audible wear indicators on the brake pads. If the brake pads wear close to their service limit,
the wear indicator makes a very audible scrapingnoise when the brake pedal is applied.
If you hear this scraping noise each time you apply the brake pedal, have the brake pads serviced byyour SUBARU dealer as soon as possible.
CAUTION
If you continue to drive despite the scraping noise from the audible brake pad wear indica-
tor, it will result in the need for costly brake rotor repair or replacement.
Breaking-in of new brake pads and linings
When replacing the brake pad or lining, use only
genuine SUBARU parts. After replacement, the new
parts must be broken in as follows:
Brake pad and lining
While maintaining a speed of 30 to 40 mph (50 to 65
km/h), step on the brake pedal lightly. Repeat this
five or more times.
Parking brake lining
1. Drive the vehicle at a speed of about 22 mph (35km/h).
2. With the parking brake release button pushed in,
pull the parking brake lever SLOWLY and GENTLY.
(Pulling with a force of approximately 33 lb [147 N,15 kg].)
3. Drive the vehicle for about 220 yards (200 me- ters) in this condition.

Maintenance and service
11-45
– CONTINUED –
WARNING
Driving at high speeds with excessively low tire pressures can cause the tires to deform
severely and to rapidly become hot. A sharp
increase in temperature could cause tread
separation, and destruction of the tires. The resulting loss of vehicle control could lead toan accident.
Wheel balance
Each wheel was correctly balanced when your ve-
hicle was new, but the wheels will become unbal-
anced as the tires become worn during use. Wheel
imbalance causes the steering wheel to vibrate
slightly at certain vehicle speeds and detracts fromthe vehicle ’s straight-line stability. It can also cause
steering and suspension system problems and ab-
normal tire wear. If you suspect that the wheels are
not correctly balanced, have them checked and ad-
justed by your SUBARU dealer. Also have them ad-
justed after tire repairs and after tire rotation. NOTE Loss of correct wheel alignment* causes the tires to wear on one side and reduces the ve-
hicle’ s running stability. Contact your SUBARU dealer if you notice abnormal tire wear.
* : The suspension system is designed to hold each wheel
at a certain alignment (relative to the other wheels and to
the road) for optimum straight-line stability and cornering
performance.
Wear indicators
A) New tread
B) Worn tread
1) Tread wear indicator
Each tire incorporates a tread wear indicator, which
becomes visible when the depth of the tread
grooves decreases to 0.063 in. (1.6 mm). A tire must

Maintenance and service
11-46
be replaced when the tread wear indicator appears
as a solid band across the tread.
WARNING
When a tire’s tread wear indicator becomes
visible, the tire is worn beyond the acceptable
limit and must be replaced immediately. With atire in this condition, driving at high speeds inwet weather can cause the vehicle to hydro-plane. The resulting loss of vehicle control can lead to an accident.
NOTE
For safety, inspect tire tread regularly and re-
place the tires before their tread wear indicators
become visible.
Tire rotation
Tire wear varies from wheel to wheel. To maximize
the life of each tire and ensure that the tires wear
uniformly, it is best to rotate the tires every 7,500
miles (12,500 km). Rotating the tires involves switch-
ing the front and rear tires on the right-hand side of
the vehicle and similarly switching the front and rear
tires on the left-hand side of the vehicle. (Each tire must be kept on its original side of the vehicle.)
Replace any damaged or unevenly worn tire at the
time of rotation. After tire rotation, adjust the tire
pressures and make sure the wheel nuts are cor-
rectly tightened.
