SUBARU IMPREZA WRX 2005 2.G Owners Manual

5-18
Audio
Display Control mode
Turn counterclockwise Turn clockwise
BASS Bass control For less bass sound For more bass sound
MIDDLE Midrange control For less midrange sound For more midrange sound
TREBLE Treble control For less treble sound For more treble sound
BALANCE Balance control To increase left speaker volume and
decrease right speaker volume To increase right speaker volume and
decrease left speaker volume
FADER Fader control To increase rear speaker volume and
decrease front speaker volume To increase front speaker volume and
decrease rear speaker volume
VOLUME Volume control For less volume For more volume
HS5014BA

5-19
Audio
– CONTINUED –
VTone control
The volume control dial (8) normally function as vol-
ume control. The dial become a control for Bass,
Midrange or Treble when you select the appropriate
tone control mode.
Choose desired level for each mode by turning the vol-
ume control dial. The control function returns to vol-
ume control mode after about 5 seconds.
To change control modes: Each brief press of the
“TONE” button (3) changes control modes in the fol-
lowing sequence starting from bass control mode.
(When the radio is first turned on, the control mode is
in the volume control.) V Fader and balance control
The volume control dial (8) normally function as vol-
ume control. The dial become the controls for Fader or
Balance when you select the appropriate fader and
balance control mode.
Choose desired setting for each mode by turning the
volume control dial. The control function returns to vol-
ume control mode after about 5 seconds.
To change control modes: Each brief press of the “BAL” button (4) changes control modes in the follow-
ing sequence starting from fader control mode. (When
the radio is turned on, the control mode is in the vol- ume control.) V
Display illumination dimness cancellation (BRIGHT)
The brightness of the radio display dims when the light
switch is in the “ ” or “ ” positions. If this
makes the display difficult to read, press the volume
dial for more than 1.5 seconds to return the display to
original brightness.
Subsequently pressing the volume dial again for more
than 1.5 seconds or if you can safely do so, turning the
light switch to the OFF position and back to the
“ ” or “ ” position makes the radio display
dim again. T FM/AM selection button
Push the “FM” (1) or “AM” (2) button when the radio is
off to turn on the radio.
Push the “FM” or “AM” button when the radio is on to
select FM1, FM2 or AM reception.
VOLUME
BASS TREBLE MIDDLE
FADER BALANCE VOLUME

5-20
Audio
T
Stereo indicator
The stereo indicator “ST” will come on when an FM
stereo broadcast is received. T Manual tuning (TUNE)
: Tuning to a higher frequency
: Tuning to a lower frequency
: Seeking the next higher station
: Seeking the next lower station
V Manual tuning
Turn the tuning knob (6) clockwise and release it im-
mediately to increase the tuning frequency and turn
the tuning knob counterclockwise and release it imme- diately to decrease the tuning frequency.
Each time the knob is turned, the frequency changes
10 kHz in the AM waveband and 0.2 MHz in the FM
waveband. V
Seek tuning
Turn the tuning knob (6) and hold it for more than a
half second. Seek tuning will operate and stop auto-
matically on the next station.
Continue this operation until you find the desired sta-tion. T Automatic tuning (SCAN)
Press the “SCAN” button (5) to change the radio to the
SCAN mode. In this mode, the radio scans through the
radio band until a station is found. The radio will stop
at the station for five seconds while displaying the fre-
quency, after which scanning will continue until the en-
tire band has been scanned from the low end to the
high end.
Press the “SCAN” button again to cancel the SCAN
mode and to stop on any displayed frequency.
When the “SCAN” button is pressed for automatic tun-
ing, stations are scanned in the direction of low fre-
quencies to high frequencies only.
Automatic tuning may not function properly if the sta-
tion reception is weakened by distance from the sta-
tion or proximity to tall buildings and hills.
UG5037BA

5-21
Audio
– CONTINUED –
TSelecting preset stations
Presetting a station with a “Preset” button (7) allows
you to select that station in a single operation. Up to
six AM, FM1 and FM2 stations each may be preset. T How to preset stations
1. Press the “FM/AM” selection button to select AM,
FM1 or FM2 reception.
2. Press the “SCAN” button (5) or tune the radio man-
ually until the desired station frequency is displayed.
3. Press one of the “Preset” buttons (7) for at least 1.5
seconds to store the frequency. The frequency of the
station will flash once on the display at this time. If the
button is pressed for less than 1.5 seconds, the pre-
ceding selection will remain in memory.
NOTE y If the connection between the radio and battery
is broken for any reason such as vehicle mainte-
nance or radio removal, all stations stored in the
preset buttons are cleared. If this occurs, it is nec-
essary to reset the preset buttons.y If a mobile telephone is placed near the radio, it
may cause the radio to emit noise when it receives
calls. This noise does not indicate a radio fault.

5-22
Audio „
Built in CD changer operation
(9)
(17) (16)(12)
(11)
(10) (13) (14) (15)
UG5036CB
(9) LOAD button
(10) Disc slot
(11) Repeat button
(12) Random button
(13) SCAN button
(14) CD button
(15) Eject button
(16) Fast-forwarding/Fast-reversing
and track UP/DOWN knob
(17) Disc select button

5-23
Audio
– CONTINUED –
NOTE
Make sure to always insert a disc with the label
side up. If a disc is inserted with the label side
down, it might be ejected or the player might shut off. THow to insert a CD(s)
V Inserting a CD
1. Press “LOAD” button (9). If the magazine in the
player has an idle position where you can insert a disc,
the “DISC” indicator associated with the idle position
will blink.
If no indicator blinks, it means that there is no idle po-
sition in the magazine.
2. As soon as the “DISC” indicator begins to blink, the
“LOAD” will appear on display for a period of 15 sec-
onds. Insert a disc during the period. The disc will be
then automatically drawn in, and the player will begin
to play back the first track of the disc. y To insert more discs in succession, repeat Steps 1
and 2. The magazine will be loaded with discs in the
ascending order of position number.
If you do not insert any disc in 15 seconds after you
have pressed the “LOAD” button, the player will begin
to play back the first track of the last disc you have in- serted. y
The disc indicator steadily lights up if a disc is al-
ready inserted in the corresponding position of the
magazine. y While the player is in the loading mode, if you press
any of the other mode buttons “FM” (1), “AM” (2), the
player will enter the standby mode. Press the “CD”
button (14) to start playback. V Inserting a disc in a desired position
1. Press the “LOAD” button (9). If the magazine in the
player has an idle position where you can insert a disc,
the “DISC” indicator associated with the idle position
will blink.
The positions in the magazine the indicator of which
steadily lights up are already loaded with discs.
2. Press the “Disc select” button (17) at the position
where you want to insert a disc. The associated
“DISC” indicator will blink, and the “LOAD” will be dis-
played.
3. If you insert a disc during the 15-second period
while the “LOAD” is on display, the disc will be auto-
matically drawn in, and the player will start playback of
the disc, beginning with the first track. y To insert more discs in succession, repeat Steps 1
and 2. y While the player is in the loading mode, if you press
any of the other mode buttons “FM” (1), “AM” (2), the

5-24
Audio
player will enter standby mode. Press the “CD” button
(14) to start playback. V
Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button (9) for
more than 1.5 seconds, the player will produce beep
sound and will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the “ALL LOAD”
will be on display for a period of 15 seconds. If a disc
is successfully loaded during this period, the “DISC”
indicator will stop blinking and will steadily light.
3. When the loading of a disc is complete, the next
“DISC” indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeating
Steps 2 and 3, the player will start playback of the
discs, beginning with the one inserted first.
If you fail to insert any disc during each 15 seconds in-
terval, the full disc loading mode will be canceled, and
the player will start playback of the disc inserted first. T How to play back a CD or make a pause
V When there is no CD inserted:
Insert a CD by referring to “How to Insert a CD(s)”.
When a CD is loaded, the player will start playback of
the CD, beginning with the first track. V
When there are CDs loaded:
Press a desired one of the “Disc select” buttons (17)
the “DISC” indicator of which steadily lights up. The
player will then start playback of the selected CD, be-
ginning with the first track. T Selecting a desired track (TRACK)
: Skipping forward
: Skipping backward
: Fast-forwarding
: Fast-reversing
V Skipping forward
Turn the “TRACK” knob (16) clockwise and release it
UG5037BA

5-25
Audio
– CONTINUED –
immediately to skip to the beginning of the next track.
Each time the knob is turned and released, the indicat-
ed track number will increase. VSkipping backward
Turn the “TRACK” knob (16) counterclockwise and re-
lease it immediately to skip to the beginning of the cur-
rent track. If you continue to turn and release the knob,
the indicated track number will decrease. V Fast-forwarding
Turn the “TRACK” knob (16) clockwise and hold it con-
tinuously for more than 2 seconds to fast-forward the disc.
Release the knob to stop fast-forwarding. V Fast-reversing
Turn the “TRACK” knob (16) counterclockwise and
hold it continuously for more than 2 seconds to fast-re-
verse the disc.
Release the knob to stop fast-reversing. T Repeat playback
Press the “RPT” button (11) while a song is playing to
play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To
cancel the repeat mode, press the button again. Then
the “RPT” indicator goes out, and normal playback mode is restored. T
Random playback
Press the “RDM” button (12) while a disc is being
played back to play all songs on the disc in a random
order. The “RDM” indicator will come on and all songs
on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal play-
back mode is restored. T Scan
When the “SCAN” button (13) is pressed while the disc
is being played back, you can hear the first 10 seconds
of each track to search for the desired program. To
continue listening to the program, press the “SCAN”
button again. After all tracks on the disc have been
scanned, normal playback mode is restored. T How to unload CDs from the player
V Ejecting a CD from the player
Of the discs loaded, you can select and remove only
one disc.
1. Press the “Disc select” button (17) of the disc
whose “DISC” indicator is ON.
2. Press the “Eject” button (15). Then the “DISC” indi-
cator associated with the disc you have selected will

5-26
Audio
blink, and the disc will be ejected.
To remove more discs in succession, repeat Steps 1
and 2. V
Ejecting all discs from the player (All disc ejec-
tion mode)
1. If you continue to press the “Eject” button (15), the
player will produce beep sound and will enter the all
disc ejection mode.
2. Remove the disc that has been ejected. The other
discs loaded will then be ejected one after another. If
you do not remove the disc that has been ejected, the
“All disc ejection mode” will be canceled.
NOTE
Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out.

5-27
Audio
– CONTINUED –
In-dash 6 CD auto changer 1 (if equipped) „Loading and unloading compact discs
(5) (1) (2)
(4) (3)
HG5022BB
(1) Disc slot
(2) Disc indicators (disc No.1 to 6)
(3) Disc select buttons (disc No.1 to 6)
(4) Eject button
(5) Disc slot indicator
