SUBARU LEGACY 2000 3.G Owners Manual

Specifications12-3
–
CONTINUED –
OUTBACK station wagon
Overall leng th 187.4 in (4,760 mm)
Overall wid th 68.7 in (1,745 mm)
Overall heig ht 62.2 in (1,580 mm)
Ground c learanc e 7.3 in (185 mm)
Front tread 57.9 in (1,470 mm)
Rear tread 57.7 in (1,465 mm)
Wheelb ase 104.3 in (2,650 mm)
Engine 2.5 liter
Eng ine mod el EJ251
Eng ine typ e Horizontally op p osed , liq uid c ooled
4 c ylind er, 4 stroke g asoline eng ine
Eng ine d isp lac ement 2,457 c c (149.9 c u in.)
Bore 3.92 in (99.5 mm)
Stroke 3.11 in (79.0 mm)
Comp ression ratio 10.0 : 1
Firing ord er 1 - 3 - 2 - 4
Electrical system
Battery typ e and c ap ac ity
MT: 55D23L
AT: 75D23L
Alternator 12V-90A
Sp ark p lug s typ e RC10YC4 (Champion) RC8YC4 (Champ ion)
BKR6E-11 (NGK)
K20PR-U11 (NIPPONDENSO)
Capacities
Fuel tank 16.9 US g al (64 liters, 14.1 Imp g al)
Eng ine oil 4.2 US q t (4.0 liters, 3.5 Imp q t)
Transmission oil (MT) 3.7 US q t (3.5 liters, 3.1 Imp q t)
Transmission fluid (AT) 9.8 US q t (9.3 liters, 8.2 I mp q t)

12-4AT d ifferential g ear oil 1.3 US q t (1.2 liters, 1.1
Imp q t)
Rear d ifferential g ear oil 0.8 US q t (0.8 liter, 0.7 Imp q t)
Power steering g ear fluid 0.7 US q t (0.7 liter, 0.6 Imp q t)
Eng ine c oolant MT 7.2 US q t (6.8 liters, 6.0 Imp q t) AT 7.1 US q t (6.7 liters, 5.9 Imp q t)
Tires Legacy
Typ e Steel b elted rad ial, Tub eless
Size Brig hton P195/60R15 87H L P205/60R15 90H
GT P205/55R16 89H
Temp orary sp are T135/70D16
Pressure
Front Brig hton 33 p si (230 kPa, 2.3 kg /c m 2
)
GT, L 32 p si (220 kPa, 2.2 kg /c m 2
)
Rear Brig hton 32 p si (220 kPa, 2.2 kg /c m 2
)
GT, L 30 p si (210 kPa, 2.1 kg /c m 2
)
Temp orary sp are 60 p si (420 kPa, 4.2 kg /c m 2
)
Wheel size 15 x 6JJ, 16 x 6 1
/2 JJ
OUTBACK
Typ e Steel b elted rad ial, Tub eless Size P225/60R16 97H
Temp orary sp are T145/80R16
Pressure
Front 30 p si (210 kPa, 2.1 kg /c m 2
)
Trailer towing 30 p si (210 kPa, 2.1 kg /c m 2
)
Rear 29 p si (200 kPa, 2.0 kg /c m 2
)
Trailer towing 32 p si (220 kPa, 2.2 kg /c m 2
)
Temp orary sp are 60 p si (420 kPa, 4.2 kg /c m 2
)
Wheel size 16 x 6 1
/2 JJ

Specifications12-5
–
CONTINUED –

Wheel alignment
Legacy sedan
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camb er Front –0 05 ’ 30 ’
Rear –0 30 ’ 45 ’
Legacy station wagon
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camb er Front –0 05 ’ 30 ’
Rear –0 20 ’ 45 ’
OUTBACK sedan
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camb er Front 0 20 ’ 30 ’
Rear –0 10 ’ 45 ’
OUTBACK station wagon
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camb er Front 0 20 ’ 30 ’
Rear –0 10 ’ 45 ’

12-6Fuses and circuits
Fuse panel located behind the coin tray
HBC001BB
Fuse panelFuse ratingCircuit
115AHeater fan
215AHeater fan
315APower d oor loc k
Keyless entry
420ACig arette lig hter
Remote c ontrolled rear view mirrors
510ATail lig ht
Parking lig ht
615ASRS airb ag

Specifications12-7
–
CONTINUED –
Fuse panel Circuit
Fuse rating
715AFront fog lig ht
830AABS solenoid
915ARad io
Cloc k
1015ATrailer
1115AEng ine ig nition system
SRS airb ag
1210AIllumination b rig htness c ontrol
1315AFuel p ump
1410ARear wind ow wip er and washer
1530AWind shield wip er and washer
1620ABrake lig ht
1715AAir c ond itioner
1815ABac kup lig ht
Cruise c ontrol
ABS c ontrol
1920AMirror heater
Wip er d eic er
2020AAc c essory p ower soc ket
Seat heater

12-8
Fuse panel located in the engine compartment
HS0225Main fuse FWD socket L
D
FH
S
GJ KZ X C
Fuse panel
Fuse ratingCircuit
2120A Rad iator c ooling fan (Main)
2220ARad iator c ooling fan (Sub )
2320ARear wind ow d efog g er
2415AHazard warning flasher
Horn
2515AMeter
SRS airb ag system warning lig ht
2610AAutomatic transmission c ontrol unit
ABS UNIT
2710AAlternator
2815AHead lig ht (rig ht sid e)
2915AHead lig ht (left sid e)
3020ALig hting switc h

Specifications12-9
–
CONTINUED –
Fuse panel Circuit
Fuse rating
3115ACloc k
Interior lig ht

12-10Bulb chart
Wattage Bulb No.
Head lig ht
GT and OUTBACKLow b eam 12V –55W H1
Hig h b eam 12V –60W 9005 (HB3)
Exc ep t GT and OUTBACK 12V –60/55W 9007 (HB5)
Front turn sig nal 12V –27W 1156NA (Amb er)
Sp ot lig ht 12V –8W —
Dome lig ht 12V –8W —
Dome lig ht/Rear map read ing lig hts (if eq uip p ed ) Dome lig ht (room lig ht) 12V –8W —
Rear map read ing lig hts 12V –3.8W 194
Door step lig ht 12V –3.4W —
Parking and front sid e marker lig ht 12V –27/8W 1157NA (Amb er)
Front fog lig ht Exc ep t OUTBACK 12V –55W H3
OUTBACK 12V –51W 9006 (HB4)
Bac kup lig ht
Sed an 12V –27W 3156K
Station wag on 12V –27W 1156
Lug g ag e area lig ht 12V –13W —
Hig h mount stop lig ht Sed an 12V –18W 921
Station wag on 12V –13W 912
Rear turn sig nal lig ht Sed an 12V –21W —
Station wag on 12V –21W R2172 7440
Brake/tail lig ht
Sed an 12V –27/8W 3157K
Station wag on 12V –27/8W 1157
Lic enc e p late lig ht
Sed an 12V –5W 168
Station wag on 12V –3.8W or 5W 194 or 168
Trunk room lig ht 12V –5W W5W

Specifications12-11
–
CONTINUED –
Vehicle identification
HBD002BB
1 Emission c ontrol lab el
2 Vehic le id entific ation numb er
3 Rad io noise lab el (Canad a
mod el)
4 Vac uum hose c onnec tions
lab el 5
Tire inflation p ressure lab el
6 Certific ation and b ar c ord
lab el
7 Vehic le id entific ation numb er
p late
8 Mod el numb er p late

13
