brakes SUBARU LEGACY 2000 3.G Owners Manual

3-14NOTE
If the warning light behavior is as shown below, the ABS system may be considered normal.
The warning light comes on right after the engine is started but
goes out immediately, remaining off. The warning light remains on after the engine has been started,
but it goes out when the vehicle speed reaches about 8 mph (12km/h). The warning light comes on during driving, but it goes out
immediately and remains off.
When d riving with an insuffic ient b attery voltag e s uc h as when the en-
g ine is jump started , the ABS warning lig ht may c om e on. This is d ue to
the low b attery voltag e and d oes not ind ic ate a mal func tion. When the
b attery b ec omes fully c harg ed , the lig ht will g o ou t.
Brake system warning light
WARNING
Driving with the brake system warning light on is dangerous.
This indicates your brake system may not be working properly. If the light remains on, have the brakes inspected by a SUBARU
dealer immediately. If at all in doubt about whether the brakes are operating prop-
erly, do not drive the vehicle. Have your vehicle towed to the
nearest SUBARU dealer for repair.
This lig ht has the following two func tions: Parking brake warning
The lig ht c omes on with the p arking b rake ap p lied w hile the ig nition
switc h is in the “ON ” p osition. It g oes out when the p arking b rake is
fully released . Brake fluid level warning
This lig ht c omes on when the b rake fluid level has d rop p ed to near
the “MIN ” level of the b rake fluid reservoir with the ig niti on switc h in(U.S.)
(Canada)

7-12
Shifting speeds
n Recommended shifting speeds
The b est c omp romise b etween fuel ec onomy and vehic l e p erfor-
manc e d uring normal d riving is ensured b y shifting up at the sp eed s
listed in the following tab le.
Shift up
mp h (km/h)
1st to 2nd15 (24)
2nd to 3rd25 (40)
3rd to 4th40 (65)
4th to 5th45 (73)
nMaximum allowable speeds
WARNING
When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for thegear which is about to be selected. Failure to observe this pre-caution can lead to engine over-revving and this in turn canresult in engine damage.In addition, sudden application of engine brakes when the vehicleis travelling on a slippery surface can lead to wheel locking; as a
consequence, control of the vehicle may be lost and the risk ofan accident increased.
The following tab le shows the maximum sp eed s that a re p ossib le with
eac h d ifferent g ear.
Never exc eed the sp eed limit b elow for eac h g ear p o sition exc ep t for
b rief ac c eleration in an emerg enc y. The tac hometer ’s need le (if so
eq uip p ed ) will enter the red area if these sp eed s a re exc eed ed . Fail-
ure to ob seve this p rec aution c an lead to exc essive eng ine wear and
p oor fuel ec onomy.

7-18
Maximum speeds
WARNING
When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for thegear which is about to be selected. Failure to observe this pre-caution can lead to engine over-revving and this in turn canresult in engine damage.In addition, sudden application of engine brakes when the vehicleis travelling on a slippery surface can lead to wheel locking; as a
consequence, control of the vehicle may be lost and the risk ofan accident increased.
The following tab les show the maximum sp eed s that a re p ossib le with
eac h d ifferent g ear. The tac hometer ’s (if so eq uip p ed ) need le will
enter the red area if these sp eed s are exc eed ed .
When shifting d own a g ear, it is imp ortant to c onfi rm that the c urrent
vehic le sp eed is not in exc ess of the Maximum Allow ab le Sp eed of
the g ear whic h is ab out to b e selec ted .
Exc eed ing the Maximum Allowab le Sp eed s will result in over-revving
of the eng ine. In ad d ition a p owerful eng ine b rake will eng ag e and
c ontrol of the vehic le may b e lost.
mph (km/h)
Vehicle type
PositionBrighton, LGTOUTBACK
133 (53)27 (43)29 (47)
264 (103)57 (92)62 (100)
3102 (164)97 (156)104 (167)
NOTE In order to prevent over-revving during acceleration of the
vehicle, the transmission will automatically shift to the next high- est gear if the Maximum Allowable Speed for the current gear isexceeded.

Starting and operating7-21
–
CONTINUED –
Braking
Braking tips
WARNING
Never rest your foot on the brake pedal while driving. This can
cause dangerous overheating of the brakes and needless wearon the brake pads and linings.
When the brakes get wet
When d riving in rain or after washing the vehic le, the b rakes may g et
wet. As a result, b rake stop p ing d istanc e will b e l ong er. To d ry the
b rakes, d rive the vehic le at a safe sp eed while lig htly d ep ressing the
b rake p ed al to heat up the b rakes. Use of engine braking
Rememb er to make use of eng ine b raking in ad d ition to foot b raking .
When d esc end ing a g rad e, if only the foot b rake is used , the b rakes
may start working imp rop erly b ec ause of b rake fluid overheating ,
c aused b y overheated b rake p ad s. To help p revent th is, shift into a
lower g ear to g et strong er eng ine b raking . Braking when a tire is punctured
Do not d ep ress the b rake p ed al sud d enly when a tire is p unc tured .
This c ould c ause a loss of c ontrol of the vehic le. Keep d riving straig ht
ahead while g rad ually red uc ing sp eed . Then slowly p ull off the road
to a safe p lac e.
Brake system Two separate circuits
Your vehic le has two sep arate c irc uit b rake systems . Eac h c irc uit
works d iag onally ac ross the vehic le. If one c irc uit of the b rake system
should fail, the other half of the system still wor ks. If one c irc uit fails,
the b rake p ed al will g o d own muc h c loser to the flo or than usual and
you will need to p ress it d own muc h hard er. And a m uc h long er d is-
tanc e will b e need ed to stop the vehic le.

8-22Trailer hitch (if equipped)
WARNING
Never exceed the maximum weight specified for the trailer
hitch. Exceeding the maximum weight could cause an accident resulting in serious personal injuries. Permissible trailer weight
changes depending on the situation. Refer to the next section“ Trailer towing ” for possible recommendations and limitations.
Trailer brakes are required when the towing load exceeds
1,000 lbs. (453 kg). Be sure your trailer has safety chains and that
each chain will hold the trailer ’s maximum gross weight. Towing
trailers without safety chains could create a traffic safety hazardif the trailer separates from the hitch due to coupling damage orhitch ball damage. Be sure to check the hitch pin and safety pin for positive lock-
ing placement before towing a trailer. If the ball mount comes off
the hitch receiver, the trailer could get loose and create a trafficsafety hazard. Use only the ball mount supplied with this hitch. Use the hitch
only as a weight carrying hitch. Do not use with any type ofweight distributing hitch.
The trailer hitc h is d esig ned to tow a Class 1 rate d load . A maximum of
2,000 lbs. (906 kg) g ross trailer weig ht and a maximum of 200 lbs. (90
kg) g ross tong ue weig ht are p ermissib le for the traile r hitc h.
When you tow a trailer, follow the instruc tions in the next sec tion “Trailer
towing ”.

Driving tips8-27
–
CONTINUED –
CAUTION
Adequate size trailer brakes are required when the trailer and
its cargo exceed 1,000 lbs (453 kg) total weight. Before towing a trailer, check the trailer total weight, GVW,
GAWs and tongue load. Make sure the load and its distribution inyour vehicle and trailer are acceptable.
n Total trailer weight
The total trailer weig ht (trailer weig ht p lus its c arg o load ) must never
exc eed the maximum weig ht shown b elow.
Model
ConditionsMaximum totaltrailer weight
MT modelsWhen towing a trailer without brakes.1,000 lbs (453 kg)
When towing a trailer with brakes.2,000 lbs (906 kg)
AT modelsWhen towing a trailer without brakes.1,000 lbs (453 kg)
When towing a trailer with brakes.2,000 lbs (906 kg)
When towing a trailer on a long uphill grade continuously for over 5 miles (8 km) with an outside temperature of 104 F
(40 C) or above.1,000 lbs (453 kg)
OM-H2781
Total trailer weight

8-32
All vehicles except OUTBACK wagon
SUBARU d oes not offer ac c essory trailer hitc hes. Co nsult with a p ro-
fessional hitc h sup p lier to assist you in c hoosing an ap p rop riate hitc h
for your vehic le. Be sure to follow all of the hitc h manufac turer’s
instruc tions for installation and use.
Never use a hitc h that mounts only to the rear b ump er. The b ump er is
not d esig ned to hand le that typ e of load .
Reg ularly c hec k that the hitc h mounting b olts and n uts are tig ht.
Connecting a trailer
n Trailer brakes
WARNING
Adequate size trailer brakes are required when the trailer and
its cargo exceed 1,000 lbs (453 kg) total weight. Do not directly connect your trailer ’s hydraulic brake system
to the hydraulic brake system in your vehicle. Direct connectionwould cause the vehicle ’s brake performance to deteriorate and
could lead to an accident.
If your trailer ’s total weig ht (trailer weig ht p lus its c arg o weig h t)
exc eed s 1,000 lb s (453 kg ), the trailer is req uired to b e eq uip p ed with
its own b rake system. Elec tric b rakes or surg e b rak es are rec om-
mend ed , and must b e installed p rop erly. Chec k that your trailer’s
b rakes c onform with Fed eral, state/p rovinc e and /or other ap p lic ab le
reg ulations. Your SUBARU ’s b rake system is not d esig ned to b e
tap p ed into the trailer ’s hyd raulic b rake system. Please ask your
SUBARU d ealer and p rofessional trailer sup p lier for more information
ab out the trailer ’s b rake system.
n Trailer safety chains
WARNING
Always use safety chains between your vehicle and the trailer.
Towing trailer without safety chains could create a traffic safetyhazard if the trailer separates from the hitch due to coupling dam-age or hitch ball damage.

10-2Exterior care
Washing
CAUTION
When washing the vehicle, the brakes may get wet. As a result,
the brake stopping distance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brakepedal to heat up the brakes. Do not wash the engine compartment and areas adjacent to it.
If water enters the engine air intake, electrical parts or the power
steering fluid reservoir, it will cause engine trouble or faulty
power steering respectively.
The b est way to p reserve your vehic le ’s b eauty is freq uent washing .
Wash the vehic le at least onc e a month to avoid c on tamination b y road
g rime.
Wash d irt off with a wet sp ong e and p lenty of lukew arm or c old water. Do
not wash the vehic le with hot water and in d irec t s unlig ht.
Salt, c hemic als, insec ts, tar, soot and b ird d rop p i ng s should b e washed
off b y using a lig ht d eterg ent, as req uired . If you use a lig ht d eterg ent,
make c ertain that it is a neutral d eterg ent. Do not use strong soap or
c hemic al d eterg ents. All c leaning ag ents should b e p romp tly flushed
from the surfac e and not allowed to d ry there. Rins e the vehic le thor-
oug hly with p lenty of lukewarm water. Wip e the rema ining water off with a
c hamois or soft c loth. NOTE When having your vehicle washed in an automatic car wash, make
sure beforehand that the car wash is of suitable type. If the vehicle
is equipped with a rear/roof spoiler, it may be damaged by car washbrushes or other equipment.
