SUBARU OUTBACK 2000 3.G Owners Manual

7-14Automatic transmission
WARNING
Do not shift from the “P” or “N” position into the “D”, “3”, “2”,
“1” or “R” position while depressing the accelerator pedal. This
may cause the vehicle to jump forward or backward.
CAUTION
Shift into the “P” or “R” position only after the vehicle is com-
pletely stopped. Shifting while the vehicle is moving may cause
damage to the transmission. Do not race the engine for more than five seconds in any posi-
tion except the “N” or “P” position when the brake is set or the
tires are on blocks. This may cause the automatic transmissionfluid to overheat. Avoid shifting from one of the forward driving positions into
the “R” position or vice versa until the vehicle has completely
stopped. Such shifting may cause damage to the transmission.
The automatic transmission is elec tronic ally c ontro lled with 4-forward
sp eed s and 1-reverse sp eed .
NOTE
Immediately after a disconnected battery is reconnected or ATF (au- tomatic transmission fluid) is replaced, you may feel that the auto-matic transmission operation is somewhat unusual.This results from erasure or invalidation of data the on-board com-puter has collected and stored in memory to allow the transmissionto shift at the most appropriate times for the current condition ofyour vehicle. Optimized shifting will be restored as the vehicle con-tinues to be driven for a while.

Starting and operating7-15
–
CONTINUED –

Selector lever for automatic transmission
HB7021BB
HB7010AA
The selec tor lever has seven p ositions.
P (Park)
This p osition is for p arking the vehic le and starti ng the eng ine.
In this p osition, the transmission is mec hanic ally loc ked to p revent the
vehic le from rolling freely.
When you p ark the vehic le, first set the p arking b r ake fully, then shift
into the “P ” p osition. Do not hold the vehic le with only the tr ansmis-
sion.
A shift interloc k func tion is emp loyed in the autom atic transmission
system to ensure safe starting of the vehic le.
To shift the selec tor lever from the “P ” to the any other p osition, you
have to d ep ress the b rake p ed al fully when the ig ni tion switc h is in the
“ ON ” p osition. This p revents the vehic le from lurc hing when it is
started .
If the shift lever d oes not move from the “P ” p osition with the b rake
p ed al d ep ressed , refer to the “Shift loc k release ” sec tion in this c hap -
ter. R (Reverse)
This p osition is for b ac king the vehic le.
To shift from the “N ” to “R ” p osition, first stop the vehic le c omp letely
then move the lever to the “R ” p osition.

7-16
N (Neutral)
WARNING
Do not drive the vehicle with the selector lever in the “N” (neutral)
position. Engine braking has no effect in this condition and the risk of an accident is consequently increased.
This p osition is for restarting a stalled eng ine.
In this p osition the wheels and transmission are no t loc ked . In this
p osition, the transmission is neutral; the vehic le will roll freely, even on
the slig htest inc line unless the p arking b rake or f oot b rake is on.
D (Drive)
This p osition is for normal d riving .
The transmission automatic ally shifts into a suitab le g ear from 1st to
4th ac c ord ing to the vehic le sp eed and the ac c elera tion you req uire.
When more ac c eleration is req uired in this p osition , p ress the ac c eler-
ator p ed al fully to the floor and hold that p ositio n. The transmission
will automatic ally d ownshift to 3rd , 2nd or 1st g ea r. When you release
the p ed al, the transmission will return to the orig inal g ear p osition.
n While climbing a grade
When d riving up a hill, und esired up shift to 4th g e ar is p revented from
taking p lac e when the ac c elerator is released . This minimizes the
c hanc e of sub seq uent d ownshifting to a lower g ear w hen ac c elerat-
ing ag ain. This p revents rep eated up shifting and d o wnshifting result-
ing in a smoother op eration of the vehic le. NOTE
The transmission may downshift to 2nd or 1st gear, depending on the way the accelerator pedal is pressed to accelerate the vehicleagain. n While going down a hill
When d esc end ing a steep hill, d ep ressing the b rake p ed al will c ause
the transmission to d ownshift to 3rd g ear, thus ap p lying eng ine b rak-
ing . Reac c eleration for a short time will c ause the transmission to up -

Starting and operating7-17
–
CONTINUED –
shift normally. NOTE In some cases, depressing the brake pedal on a downhill grade
does not result in an automatic downshift to 3rd gear. This canhappen when the automatic transmission fluid temperature is
very low, for example, during driving shortly after the vehicle has
been parked for an extended period of time. When the ATF tem-perature has risen to a certain level, automatic downshift normal-ly takes place. In the meantime, downshift manually for enginebraking as required.Also, downshifting when braking downhill will not occur at
speeds above approximately 50 mph (80 km/h).
3 (Third)
This p osition is for using eng ine b raking when g oin g d own a hill or for
c limb ing a g rad e.
The transmission automatic ally shifts into a suitab le g ear from 1st to
3rd ac c ord ing to the vehic le sp eed and the ac c elera tion you req uire.
When more ac c eleration is req uired in this p osition , p ress the ac c eler-
ator p ed al fully to the floor and hold that p ositio n. The transmission
will automatic ally d ownshift to 2nd or 1st g ear. Wh en you release the
p ed al, the transmission will return to the orig inal g ear p osition.
2 (Second)
This p osition is for using eng ine b raking when g oin g d own a hill or for
c limb ing a steep g rad e.
In this p osition, the transmission hold s in the 2nd g ear.
Use this p osition when starting off from a stand sti ll on slip p ery road
surfac es suc h as mud or snow. It will ensure g reate r trac tion.
1 (First)
This p osition is for d riving up or d own very steep g rad es, or d riving
throug h mud or sand , or on slip p ery surfac es. In th is p osition, the
transmission hold s in the 1st g ear.

7-18
Maximum speeds
WARNING
When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for thegear which is about to be selected. Failure to observe this pre-caution can lead to engine over-revving and this in turn canresult in engine damage.In addition, sudden application of engine brakes when the vehicleis travelling on a slippery surface can lead to wheel locking; as a
consequence, control of the vehicle may be lost and the risk ofan accident increased.
The following tab les show the maximum sp eed s that a re p ossib le with
eac h d ifferent g ear. The tac hometer ’s (if so eq uip p ed ) need le will
enter the red area if these sp eed s are exc eed ed .
When shifting d own a g ear, it is imp ortant to c onfi rm that the c urrent
vehic le sp eed is not in exc ess of the Maximum Allow ab le Sp eed of
the g ear whic h is ab out to b e selec ted .
Exc eed ing the Maximum Allowab le Sp eed s will result in over-revving
of the eng ine. In ad d ition a p owerful eng ine b rake will eng ag e and
c ontrol of the vehic le may b e lost.
mph (km/h)
Vehicle type
PositionBrighton, LGTOUTBACK
133 (53)27 (43)29 (47)
264 (103)57 (92)62 (100)
3102 (164)97 (156)104 (167)
NOTE In order to prevent over-revving during acceleration of the
vehicle, the transmission will automatically shift to the next high- est gear if the Maximum Allowable Speed for the current gear isexceeded.

Starting and operating7-19
–
CONTINUED –

Similarly, in order to prevent over-revving during deceleration
of the vehicle, the transmission will remain in the current gear if the speed of the vehicle is in excess of the Maximum AllowableSpeed for the gear to which the selector lever has been moved. Driving tips
Always ap p ly the foot or p arking b rake when the veh ic le is
stop p ed in the “D ”, “3 ”, “2 ”, “1 ” or “R ” p osition.
Always set the p arking b rake when p arking your vehi c le. Do not
hold the vehic le with only the transmission. Do not keep the vehic le in a stationary p osition on an up hill g rad e
b y using the “D ”, “3 ”, “2 ”, or “1 ” p osition. Use the b rake instead .
Shift lock release
If the selec tor lever d oes not move from the “P ” p osition with the b rake
p ed al d ep ressed and the ig nition switc h in the “ON ” p osition, p erform
the following step s:
To overrid e the shift loc k:
1. Set the p arking b rake and stop the eng ine.
2. Take out the sc rewd river from the tool b ag .
3. Remove the c over b y p rying on the ed g e with the r eg ular sc rewd river.
HB7020BA
HB7010CA
4. Insert the sc rewd river into the hole.
5. Push d own on the sc rewd river and move the selec to r lever from the
“ P ” to the “N ” p osition.
6. Remove the sc rewd river from the hole. Dep ress the b rake p ed al and

7-20start the eng ine.
Take your vehic le to the nearest SUBARU d ealer imme
d iately to have the
system rep aired . Rear viscous limited slip differential (LSD)
(GT, GT-LTD, OUTBACK-CW and OUTBACK-LTD)
CAUTION
Never start the engine while a tire on one side is jacked up, as
the vehicle may move. If one rear tire is spinning in mud, avoid continued spinning at
high speed as this could adversely affect the LSD. If a different size rear tire is temporarily used (as in an emer-
gency), it will adversely affect the LSD. Always replace it with aregular size tire as soon as possible.
The LSD p rovid es op timum d istrib ution of p ower ac c o rd ing to the d iffer-
enc e in revolutions b etween the rig ht and left rear wheels that may b e
c aused b y c ertain d riving c ond itions, thereb y imp ro ving d riving stab ility
on snow-c overed , mud d y or other slip p ery road s. Power steering
CAUTION
Do not hold the steering wheel at the fully locked position left or right for more than five seconds. This may damage the powersteering pump.
The p ower steering system op erates only when the en g ine is running .
If you lose p ower steering assist b ec ause the eng in e stop s or the system
fails to func tion, you c an steer b ut it will take m uc h more effort.

Starting and operating7-21
–
CONTINUED –
Braking
Braking tips
WARNING
Never rest your foot on the brake pedal while driving. This can
cause dangerous overheating of the brakes and needless wearon the brake pads and linings.
When the brakes get wet
When d riving in rain or after washing the vehic le, the b rakes may g et
wet. As a result, b rake stop p ing d istanc e will b e l ong er. To d ry the
b rakes, d rive the vehic le at a safe sp eed while lig htly d ep ressing the
b rake p ed al to heat up the b rakes. Use of engine braking
Rememb er to make use of eng ine b raking in ad d ition to foot b raking .
When d esc end ing a g rad e, if only the foot b rake is used , the b rakes
may start working imp rop erly b ec ause of b rake fluid overheating ,
c aused b y overheated b rake p ad s. To help p revent th is, shift into a
lower g ear to g et strong er eng ine b raking . Braking when a tire is punctured
Do not d ep ress the b rake p ed al sud d enly when a tire is p unc tured .
This c ould c ause a loss of c ontrol of the vehic le. Keep d riving straig ht
ahead while g rad ually red uc ing sp eed . Then slowly p ull off the road
to a safe p lac e.
Brake system Two separate circuits
Your vehic le has two sep arate c irc uit b rake systems . Eac h c irc uit
works d iag onally ac ross the vehic le. If one c irc uit of the b rake system
should fail, the other half of the system still wor ks. If one c irc uit fails,
the b rake p ed al will g o d own muc h c loser to the flo or than usual and
you will need to p ress it d own muc h hard er. And a m uc h long er d is-
tanc e will b e need ed to stop the vehic le.

7-22
Brake booster
The b rake b ooster uses eng ine manifold vac uum to as sist b raking
forc e. Do not turn off the eng ine while d riving b ec ause that will turn off
the b rake b ooster, resulting in p oor b raking p ower.
The b rakes will c ontinue to work even when the b rak e b ooster c om-
p letely stop s func tioning . If this hap p ens, however , you will have to
p ush the p ed al muc h hard er than normal and the b rak ing d istanc e
will inc rease.
Disc brake pad wear warning indicators
OM-H0163
The d isc b rake p ad wear warning ind ic ators on the d isc b rakes g ive a
warning noise when the b rake p ad s are worn.
If a sq ueaking or sc rap ing noise is heard from the d isc b rakes while
b raking , immed iately have your vehic le c hec ked b y y our SUBARU d eal-
er.

Starting and operating7-23
–
CONTINUED –
ABS (Anti-lock Brake System)
WARNING
Always use the utmost care in driving – overconfidence because
you are driving with an ABS equipped vehicle could easily lead to a serious accident.
CAUTION
The ABS system does not always decrease stopping distance.
You should always maintain a safe following distance from othervehicles. When driving on badly surfaced roads, gravel roads, icy road,
or over deep newly fallen snow, stopping distances may be long-er for a vehicle with the ABS system than one without. When driv-ing under these conditions, therefore, reduce your speed and
leave ample distance from other vehicles. When you feel the ABS system operating, you should maintain
constant brake pedal pressure. Do not pump the brake pedal
since doing so may defeat the operation of the ABS system.
The ABS system p revents the loc k-up of wheels whic h may oc c ur d uring
sud d en b raking or b raking on slip p ery road surfac es . This help s p revent
the loss of steering c ontrol and d irec tional stab il ity c aused b y wheel
loc k-up .
When the ABS system is op erating , you may hear a c h attering noise or
feel a slig ht vib ration in the b rake p ed al. This is normal when the ABS
op erates.
The ABS system will not op erate when the vehic le sp eed is b elow
ap p roximately 6 mp h (10 km/h).
ABS system self-check
You may feel a slig ht shoc k in the b rake p ed al and hear the op erating
sound of ABS from the eng ine c omp artment just after the vehic le is
