steering wheel SUBARU OUTBACK 2000 3.G Owners Manual

v
± CONTINUED ±
deploys could suffer very serious injuries. Because the SRS air- bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat.


CHILD SAFETY
WARNING
Never hold a child on your lap or in your arms while the ve-
hicle is moving. The passenger cannot protect the child from in- jury in a collision, because the child will be caught between the
passenger and objects inside the vehicle. While riding in the vehicle, infants and small children should
always be placed in the REAR seat in an infant or child restraint
system which is appropriate for the child's age, height andweight. If a child is too big for a child restraint system, the childshould sit in the REAR seat and be restrained using the seatbelts.According to accident statistics, children are safer when properlyrestrained in the rear seating positions than in the front seatingpositions. Never allow a child to stand up or kneel on the seat. Put children aged 12 and under in the REAR seat properly re-
strained at all times in a child restraint device or in a seatbelt. TheSRS airbag deploys with considerable speed and force and caninjure or even kill children, especially if they are 12 years of ageand under and are not restrained or improperly restrained. Be-
cause children are lighter and weaker than adults, their risk being
injured from deployment is greater. NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE
FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE CHILD'S HEAD TOO CLOSE TO

14-8SRS frontal airb ag
1-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS sid e airb ag (if eq uip p ed ) 1-60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting a flood ed eng ine 7-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the eng ine 7-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the eng ine d uring c old weather b elow –4F ( –20 C) 7-10 . . . . . . . .
Starting the eng ine for a manual transmission vehic le 7-8. . . . . . . . . . . . . . . . .
Starting the eng ine for an automatic transmission v ehic le 7-9. . . . . . . . . . . .
State emission testing (U.S. only) 7-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stop p ing the eng ine 7-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storag e c omp artment 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storag e tray (if eq uip p ed ) 6-20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun visors 6-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T
Tac hometer (if eq uip p ed ) 3-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temp erature A, B, C 13-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temp erature g aug e 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temp orary sp are tire 9-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheel 3-33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilting /slid ing moonroof (Sed an) 2-27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire c hains 8-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire p ressure 11-36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 11-35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Top strap anc hors 1-35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 9-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trac tion AA, A, B, C 13-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer hitc h (if eq uip p ed ) 8-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer towing (for OUTBACK) 8-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tread wear 13-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid (Sed an) 2-24
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lig ht 11-58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn sig nal ind ic ator lig hts 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn sig nal lever 3-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typ e C117 aud io set (if eq uip p ed ) 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-2
Front seats
WARNING
Never adjust the seat while driving to avoid the possibility of
loss of vehicle control and of personal injury. Never drive the vehicle with the head restraints removed be-
cause they are designed to reduce the risk of serious neck injury
in the event that the vehicle is struck from the rear. Before adjusting the seat, make sure the hands and feet of rear
seat passengers are clear of the adjusting mechanism. Seatbelts provide maximum restraint when the occupant sits
well back and upright in the seat. To reduce the risk of sliding un-der the seatbelt in a collision, the front seatbacks should be al-ways used in the upright position while the vehicle is running. Ifthe front seatbacks are not used in the upright position in a colli-
sion, the risk of sliding under the lap belt and of the lap belt slid-ing up over the abdomen will increase, and both can result in se-rious internal injury or death. Do not put cushions or any other materials between occupants
and seatbacks or seat cushions. If you do so, the risk of sliding
under the lap belt and of the lap belt sliding up over the abdomen
will increase, and both can result in serious internal injury or death. The SRS airbags deploy with considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious injuries. Because the SRS air-bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat. Put children aged 12 and under in the rear seat properly re-
strained at all times. The SRS airbag deploys with considerable
speed and force and can injure or even kill children, especially if
they are 12 years of age and under and are not restrained or im-
properly restrained. Because children are lighter and weaker than

Seat, seatbelt and SRS airbags1-3
–
CONTINUED –
adults, their risk of being injured from deployment is greater. For
that reason, we strongly recommend that ALL children (including
those in child seats and those that have outgrown child restraint
devices) sit in the REAR seat properly restrained at all times in a
child restraint device or in a seatbelt, whichever is appropriate for
the child
’s age, height and weight.
Secure ALL types of child restraint devices (including forward fac-
ing child seat) in the REAR seats at all times.
NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE
FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE CHILD ’S HEAD TOO CLOSE TO THE
SRS AIRBAG.
According to accident statistics, children are safer when properly
restrained in the rear seating positions than in the front seating
positions. For instructions and precautions concerning child re-
straint systems, see the “Child restraint systems ” section in this
chapter.
HB0290
HS0233
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far from the steering wheel as practical. Adjust the seatback toupright position. Sit well back and upright.Move the seat as far back as possible.

Seat, seatbelt and SRS airbags1-19
–
CONTINUED –

Front and rear seatbelts (except rear center seatbelt on station wagon)
OM-H0044OM-H0043
1. Ad just the seat p osition:
Driver’ s seat: Ad just the seatb ac k to the up rig ht p osition. Move the
seatb ac k as far from the steering wheel as p rac tic a l while still main-
taining full vehic le c ontrol.Front passenger ’s seat: Ad just the seatb ac k to the up rig ht p osition.
Move the seat as far b ac k as p ossib le.
2. Sit well b ac k in the seat.
3. Pic k up the tong ue p late and p ull the b elt out sl owly. Do not let it
g et twisted . If the b elt stop s b efore reac hing the b uc kle, return the
b elt slig htly and p ull it out more slowly. If the b elt still c annot b e un-
loc ked , let the b elt retrac t slig htly after g iving a strong p ull on it, then
p ull it out slowly ag ain.
4. Insert the tong ue p late into the b uc kle until you hear a c lic k.
5. To make the lap p art tig ht, p ull up on the should er b elt. And p lac e
the lap b elt as low as p ossib le on your hip s, not o n your waist.
Rear center seatbelt on station wagon
WARNING
Fastening the seatbelt with the webbing twisted can increase
the risk or severity of injury in an accident. When fastening the
belt after it is out from the retractor, especially when inserting thesmaller tongue plate into the mating buckle (smaller one on right-

Seat, seatbelt and SRS airbags1-49
–
CONTINUED –
For instructions and precautions concerning the seatbelt system, see the
“Seatbelts” sections in this chapter.
Do not sit or lean unnecessarily close to the SRS airbag. Be-
cause the SRS airbag deploys with considerable speed – faster
than the blink of an eye – and force to protect in high speed colli-
sions, the force of an airbag can injure an occupant whose bodyis too close to SRS airbag. It is also important to wear your seatbelt to help avoid injuriesthat can result when the SRS airbag contacts an occupant not inproper position such as one thrown forward during pre-accidentbraking.Even when properly positioned, there remains a possibility thatan occupant may suffer minor injury such as abrasions andbruises to the face or arms because of the SRS airbag deploy-ment force. The SRS airbags deploy with considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious injuries. Because the SRS air-bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat. Do not place any objects over or near the SRS airbag cover or
between you and the SRS airbag. If the SRS airbag deploys,those objects could interfere with its proper operation and could
be propelled inside the car and cause injury. Put children aged 12 and under in the rear seat properly re-
strained at all times. The SRS airbag deploys with considerablespeed and force and can injure or even kill children, especially ifthey are 12 years of age and under and are not restrained or im-properly restrained. Because children are lighter and weaker than
adults, their risk of being injured from deployment is greater.
For that reason, we strongly recommend that ALL children (in-cluding those in child seats and those that have outgrown child
restraint devices) sit in the REAR seat properly restrained at all

Seat, seatbelt and SRS airbags1-53
–
CONTINUED –

SRS frontal airbag
WARNING
NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE
FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD ’S HEAD TOO CLOSE TO
THE SRS AIRBAG. Never allow a child to stand up, or to kneel on the front pas-
senger’ s seat, or never hold a child on your lap or in your arms.
The SRS airbag deploys with considerable force and can injure oreven kill the child. The SRS airbag deploys with considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious injuries. Because the SRS air-bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat. It is also important to wear your seatbelt to help avoid injuriesthat can result when the SRS airbag contacts an occupant not inproper position such as one thrown toward the front of the carduring pre-accident braking.
HB0306 HB0307
Never install rearward facing child seat in the front passenger
’s seat.
Never allow a child to stand up, or to kneel on the front passenger ’s
seat

1-54
HB0308
Never hold a child on your lap or in your arms.HS0233
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far from the steering wheel as practical.
HB0290
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far back as possible.
WARNING
Do not put any objects over the steering wheel pad and dash-
board. If the SRS frontal airbag deploys, those objects could in-
terfere with its proper operation and could be propelled inside the
vehicle and cause injury. Do not attach accessories to the windshield, or fit an extra-
wide mirror over the rear view mirror. If the SRS airbag deploys,those objects could become projectiles that could seriously in-jure vehicle occupants.

Seat, seatbelt and SRS airbags1-55
–
CONTINUED –
HB1047BB
The d river’s SRS frontal airb ag is stowed in the c enter p ortio n of the
steering wheel. The p asseng er ’s SRS frontal airb ag is stowed near the
top of the d ashb oard und er an “SRS AIRBAG ” mark.
In a mod erate to severe frontal c ollision, the d riv er’s and front p assen-
g er ’s SRS frontal airb ag s d ep loy and sup p lement the sea tb elts b y red uc -
ing the imp ac t on the d river ’s and front p asseng er ’s head and c hest.
Operation
CAUTION
Do not touch the SRS airbag system components around the steering wheel and dashboard with bare hands right after deploy-ment. Doing so can cause burns because the components can bevery hot as a result of deployment.

Seat, seatbelt and SRS airbags1-63
–
CONTINUED –
SRS side airbag deploys as soon as a collision occurs.
After deployment, SRS sideairbag starts to deflate immedi-
ately. HB0359
The SRS sid e airb ag c an func tion only when the ig nition switc h is in
the “ON ” p osition.
The d river ’s and front p asseng er ’s SRS sid e airb ag s d ep loy ind ep en-
d ently of eac h other sinc e eac h has its own imp ac t sensor. Also, the
SRS sid e airb ag d ep loys ind ep end ently of the fronta l airb ag s in the
steering wheel and instrument p anel.
An imp ac t sensor is inc orp orated into eac h of the v ehic le’s c enter p il-
lars. If either sensor d etec ts a c ertain p red etermi ned amount of forc e
d uring a sid e imp ac t c ollision, the c ontrol mod ule send s a sig nal to
the sid e airb ag mod ule on the imp ac ted sid e of the vehic le, instruc t-
ing it to inflate the SRS sid e airb ag . Then the sid e airb ag mod ule p ro-
d uc es g as, whic h instantly inflates the SRS sid e ai rb ag . After the d e-
p loyment, the SRS sid e airb ag immed iately starts to d eflate. The time
req uired from d etec ting imp ac t to d eflating of the SRS sid e airb ag af-
ter d ep loyment is shorter than the b link of eye.
The SRS sid e airb ag d ep loys even when no one oc c up i es the seat on
the sid e of whic h an imp ac t is ap p lied .
