SUBARU OUTBACK 2006 Owners Manual

3-26 Instruments and controls
To adjust the time shown by the clock,
press the “+” button or the “–” button. The
indicated time will change in one-minute
increments. If you keep the button
pressed, the rate at which the indicated
time changes will speed up.
To reset the minutes to “00” with a radio
time signal, push the “SET” button. The clock will also show the time if you
press the “DISP” button while the ignition
switch is in the “LOCK” position. It is pos-
sible to adjust the time setting while the
time is being shown. If you do not press
the “+” button or “–” button for 10 seconds
while the time is being shown, the time in-
dication will go off.
Also, the time indication will go off if you
open and close the driver’s door while the
time is being shown. Information display (Vehicle
without Navigation System) NOTE If your vehicle is equipped with a navi-
gation system, refer to the separate
“Operating Instructions for Monitor
System”.
With the ignition switch in the “ON” posi-
tion, each successive push of the “DISP”
button toggles the display in the following
sequence:300599
To ensure safety, do not attempt to
set the time during driving, as an ac-
cident could result. 300600
300600

Instruments and controls
3-27
– CONTINUED –„ Outside temperature indica-
tor
U.S.-spec. vehicles Canada-spec. vehicles
The outside temperature indicator shows
the outside temperature in a range from –
22 to 122 ° F (–30 to 50 ° C).
The indicator can give a false reading un-
der any of the following conditions:
y When there is too much sun.
y During idling; while running at low
speeds in a traffic jam; when the engine is
restarted immediately following a shut-
down.
y When the actual outside temperature
falls outside the specified indicator range. T Road surface freeze warning indica-
tion
U.S.-spec. vehicles
Canada-spec. vehiclesOutside
tempera-
ture Current
fuel con-
sumption Average
fuel con-
sumption
Driving range
on remaining fuelJourney time
300594 300267
300595
300268

3-28 Instruments and controls
When the outside temperature drops to
37 ° F (3 ° C) or lower, the temperature indi-
cation flashes to show that the road sur-
face may be frozen.
If the outside temperature drops to 37 ° F
(3 ° C) or lower while the display is giving
an indication other than the outside tem-
perature, the display switches to the out-
side temperature indication and flashes
for five seconds before returning to its
original indication.
If the display is already indicating an out-
side temperature of 37 ° F (3 ° C) or lower
when the ignition switch is turned to the
“ON” position, the indication does not
flash.
NOTE The outside temperature indication
may differ from the actual outside tem-
perature. The road surface freeze warn-
ing indication should be treated only
as a guide. Be sure to check the condi-
tion of the road surface before driving. „ Current fuel consumption
U.S.-spec. vehicles
Canada-spec. vehicles
This indication shows the rate of fuel con- sumption at the present moment.
„ Average fuel consumption
U.S.-spec. vehicles 300270
300596 300272

Instruments and controls
3-29
– CONTINUED –Canada-spec. vehicles
This indication shows the average rate of
fuel consumption since the trip meter was
last reset.
Pressing the trip knob toggles the indica-
tion between the average fuel consump-
tion corresponding to the A trip meter indi-
cation and the average fuel consumption
corresponding to the B trip meter indica-
tion.
When either of the trip meter indications is
reset, the corresponding average fuel
consumption value is also reset.
NOTE y The indicated values vary in accor-
dance with changes in the vehicle’s
running conditions. Also, the indicated
values may differ slightly from the ac- tual values and should thus be treated
only as a guide.
y When either trip meter indication is
reset, the average fuel consumption
corresponding to that trip meter indica-
tion is not shown un til the vehicle has
subsequently covered a distance of 1
mile (or 1 km).
„ Driving range on remaining
fuel
U.S.-spec. vehicles Canada-spec. vehicles
The driving range indicates the distance
that can be driven taking into account the
amount of fuel remaining in the tank and
the average rate of fuel consumption.
When the low fuel warning light comes on,
the driving range indication flashes for five
seconds. (The display first switches to the
driving range indication if it was originally
giving some other indication.)300597
300274 300273

3-30 Instruments and controls
U.S.-spec. vehicles
Canada-spec. vehicles
If the driving range is shown as “ ”,
there is only a tiny amount of fuel left in the tank. You must refuel the vehicle immedi-
ately.
NOTE The driving range on remaining fuel is
only a guide. The indicated value may
differ from the actu al driving range on
remaining fuel, so you must immedi-
ately fill the tank when the low fuel
warning light comes on.
„ Journey time
The journey time shows the time that has
elapsed since the ignition switch was
turned to the “START” position. The journey time indication flashes each
time a complete hour has elapsed. If the
display is giving an indication other than
the journey time, the display switches to
the journey time, flashes for five seconds,
and returns to its original indication each
time a complete hour has elapsed.
NOTE The journey time is reset when the igni-
tion switch is turned to the “OFF” posi-
tion. It is also reset if the ignition
switch is turned to the “LOCK” or
“ACC” position prio r to restarting of
the engine.300275
400265 400266 400267

Instruments and controls
3-31
– CONTINUED –Light control switch
The light switch operates only when the
ignition switch is in the “ON” position. „ Headlights
To turn on the headlights, turn the knob on
the end of the turn signal lever.
first position
Parking lights, instrument panel illumina-
tion, tail lights and license plate light are
on.
second position
Headlights, parking li ghts, instrument pan-
el illumination, tail lights, and license plate
light are on. „ High/low beam change (dim-
mer)
To change from low beam to high beam,
push the turn signal lever forward. When
the headlights are on high beam, the high
beam indicator light “ ” on the instru-
ment panel is also on.
To switch back to low beam, pull the lever
back to the detent position.To prevent battery discharge result-
ing from accidentally leaving your
lights on when your vehicle is
parked, the light switch operates
only when the ignition switch is in
the “ON” position. In any other posi-
tion, the vehicle’s lights will be out.
If you park your vehicle on a road-
side at night, use the hazard warn-
ing flasher to alert the other drivers. 300506
300507

3-32 Instruments and controls
„ Headlight flasher
To flash the headlights, pull the lever to-
ward you and then release it. The high
beam will stay on for as long as you hold
the lever. The headlight flasher works
even though the lighting switch is in the
“OFF” position.
When the headlights are on high beam,
the high beam indicator light “ ” on
the instrument panel also comes on. „ Daytime running light system
The low beam headlights will automatical-
ly come on at reduced brightness when
the engine has started, under the follow-
ing conditions:
y The parking brake is fully released.
y The light switch is in the “OFF” or
“ ” position. Turn signal lever
To activate the right turn signal, push the
turn signal lever up. To activate the left
turn signal, push the turn signal lever
down. When the turn is finished, the lever
will return automatically. If the lever does
not return after corner ing, return the lever
to the neutral position by hand.
To signal a lane change, push the turn sig-
nal lever up or down slightly and hold it
during the lane change. The turn signal in-
dicator lights will flash in the direction of
the turn or lane change. The lever will re-
turn automatically to the neutral position
when you release it.Do not hold the le ver in the flashing
position for more than just a few
seconds. 300508
The tail lights, parking lights, and
side marker lights are not turned on
by the daytime running light system.
The light switch must always be
turned to the “ ” position when
it is dark outside. 300509

Instruments and controls
3-33
Illumination brightness con-
trol
The brightness of clock display, audio, air
conditioner, information display and in-
strument panel illumination dims when the
light switch is in the “ ” or “ ” po-
sitions. You can adjust brightness of the
instrument panel illumination for better
visibility.
In turbo models, you can also adjust the
brightness of the instrument panel illumi-
nation when the lighting switch is in the
OFF position.
To brighten, turn the control dial upward.
To darken, turn the control dial downward.
NOTE
When the control dial is turned fully up- ward, the illumination brightness be-
comes the maximum and the automatic
dimming function does not work at all.
Parking light switch
The parking light switch operates regard-
less of the ignition switch position.
By pushing the front end of this switch, fol-
lowing lights will come on.
– Parking lights
– Front and rear side marker lights
– Tail lights
– License plate lights
To turn off, push the rear end of the park-
ing light switch.
Avoid leaving these lights on for a long
time because that will run down the bat-
tery.300510 300178

3-34 Instruments and controls
Front fog light switch (if
equipped)
The front fog lights operate only when the
light switch is in the “ ” position.
However, the front fog lights turn off when
the headlights are switched to high beam.
To turn on the front fog lights, turn the front
fog light switch on the turn signal lever up-
ward to the “ ” position. To turn off the
front fog lights, turn the switch back down
to the “OFF” position. The indicator light located on the combi-
nation meter will illuminate when the front
fog lights are on. Wiper and washer300512 300282
In freezing weather, do not use the
windshield washer until the wind-
shield is sufficien tly warmed by the
defroster.
Otherwise the washer fluid can
freeze on the windshield, blocking
your view.
y Do not operate the washer contin-
uously for more than ten seconds,
or when the washer fluid tank is
empty. This may cause overheat-
ing of the washer motor. Check
the washer fluid level frequently,
such as at fuel stops.
y Do not operate the wipers when
the windshield or rear window is
dry. This may scratch the glass,
damage the wiper blades and
cause the wiper mo tor to burn out.
Before operating the wiper on a
dry windshield or rear window, al-
ways use the windshield washer.

Instruments and controls
3-35
– CONTINUED –NOTE y The front wiper mo tor is protected
against overloads by a circuit breaker.
If the motor operates continuously un-
der an unusually heavy load, the circuit
breaker may trip to stop the motor tem-
porarily. If this happens, park your ve-
hicle in a safe place, turn off the wiper
switch, and wait for approximately 10
minutes. The circuit breaker will reset
itself, and the wipers will again operate
normally.
y Clean your wiper blades and window
glass periodically with a washer solu-
tion to prevent streaking, and to re- move accumulations of road salt or
road film. Keep th e washer button de-
pressed at least for 1 second so that
washer solution will be sprinkled all
over the windshield or rear window.
y Grease, wax, insects or other materi-
al on the windshield or the wiper
blades results in jerky wiper operation
and streaking on the glass. If you can-
not remove those streaks after operat-
ing the washer or if the wiper operation
is jerky, clean the outer surface of the
windshield or rear window and the wip-
er blades using a sponge or soft cloth
with a neutral dete rgent or mild-abra-
sive cleaner. After cleaning, rinse the
window glass and wiper blades with
clean water. The glass is clean if no
beads form on the glass when you
rinse with water.
y If you cannot eliminate the streaking
even after following this procedure, re-
place the wiper blades with new ones.
Refer to the “Replacement of wiper
blades” section (chapter 11) for re-
placement instructions.
„ Windshield wiper and washer
switches The wiper operates only when the ignition
switch is in the “ON” or “ACC” position.y In freezing weather, be sure that
the wiper blades are not frozen to
the windshield or rear window be-
fore switching on the wipers. At-
tempting to oper ate the wiper with
the blades frozen to the window
glass could cause not only the
wiper blades to be damaged but
also the wiper moto r to burn out. If
the wiper blades ar e frozen to the
window glass, be sure to operate
the defroster, wip er deicer (if
equipped) or rear window defog-
ger before turning on the wiper.
y If the wipers stop during opera-
tion because of ice or some other
obstruction on the window, the
wiper motor could burn out even if
the wiper switch is turned off. If
this occurs, promptly stop the ve-
hicle in a safe place, turn the igni-
tion switch to the “LOCK” posi-
tion and clean the window glass
to allow proper wiper operation. y Use clean water if windshield
washer fluid is unavailable. In ar-
eas where water freezes in winter,
use SUBARU Windshield Washer
Fluid or the equivalent. (See
“Windshield washer fluid” section
in chapter 11.)
Also, when driving the vehicle
when there are freezing tempera-
tures, use non-freezing type wiper
blades.
y Do not clean the wiper blades with
gasoline or a solvent, such as
paint thinner or benzene. This will
cause deterioration of the wiper
blades.
